How Does GPS work?

1
How Does GPS work?
Justin Chi Martin Chi Elizabeth Tom
2
What is GPS?
GPS Global Positioning System Satellite
Navigation System 27 Satellites (24 in use, 3 for
emergency)
3
Applications

• Military
• Navigation
• Surveying
• Visually Impaired
• Geocaching
• Airplanes
• Time

4
Types

• Differential GPS (DGPS)
• Wide Area Augmentation System (WAAS)
• Local Area Augmentation System (LAAS)
• Exploitation of DGPS for Guidance Enhancement
  (EDGE)
• Carrier Phase Enhancement (CPGPS)
• Wide Area GPS Enhancement (WAGE)
• Relative Kinematic Position (RKP)

5
Geometry
6
Simplified GPS

• Using 4 satellites
• (actual GPS uses 4 satellites and least
  squares method)

• xyz-coordinate system
• Earth is the origin
• A position can be expressed as (x, y, z) ? can
  be translated into longitude and latitude
• In this system, a point at sea level is x2
  y2 z2 1
• Speed of light is about .047 (units of earth
  radii per millisecond)

7
Ship Example
Satellite Position Time
1 (1,2,0) 19.9
2 (2,0,2) 2.4
3 (1,1,1) 32.6
4 (2,1,0) 19.9
Let (x, y, z) ships position t time when
signals arrive
8
Calculating distance for Satellite 1
Satellite Position Time
1 (1,2,0) 19.9
d .047(t 19.9)
AND
d
(x 1)2 (y 2)2 z2 .0472(t 19.9)2
9
(x 1)2 (y 2)2 z2 .0472(t 19.9)2
2x 4y 2(.0472)(19.9)t 12 22 -
.0472(19.9)2 x2 y2 z2 - .0472t2
We can do this for the rest of the satellites
2x 4y 0z 2(.0472)(19.9)t 12 22 02 -
.0472(19.9)2 x2 y2 z2 - .0472t2
4x 0y 4z 2(.0472)(2.4)t 22 02 22 -
.0472(2.4)2 x2 y2 z2 - .0472t2
2x 2y 2z 2(.0472)(32.6)t 12 12 12 -
.0472(32.6)2 x2 y2 z2 - .0472t2
4x 2y 0z 2(.0472)(19.9)t 22 12 02 -
.0472(19.9)2 x2 y2 z2 - .0472t2
10
2x 4y 4z 2(.0472)(17.5)t 8 5
.0472(19.92 - 2.42) 0x 2y 2z -
2(.0472)(12.7)t 3 5 .0472(19.92 - 2.42) 2x
2y 0z 2(.0472)(0)t 5 5 .0472(19.92
19.92)
11
(No Transcript)
12
x 5.41 - .095t, y 5.41 - .095t, z 3.67 -
.067t t is free
(5.41 - .095t 1)2 (5.41 - .095t 2)2 (3.67
- .067t)2 .0472(t 19.9)2 .02t2 - 1.88t
43.56 0
2 answers t 43.1 t 50.0
13
t 43.1
(x, y, z) (1.317, 1.317, .790) d is about
2 Since the units are Earth radii this means that
the point is about 4000 miles above the surface
of the Earth
14
t 50.0
(x, y, z) (.667, .667, .332) d is about
.9997 Since the units are Earth radii this means
the point is on the surface of the Earth. We
can convert this into longitude and latitude
15
Wide Area Augmentation System

• Improves upon GPS
• Uses a combination of satellites and ground
  based stations to send correction signals to the
  receiver
• Can improve accuracy up to 5 times
