Title: Servo Motor Control


1
Servo Motor Control
2
Design Problem
  • You are to design an automated goalie for an air
    hockey table. The goalie can be 1 inch wide.
  • Tasks
  • determine puck location
  • position blocker

3
Concepts
  • You are to design an automated goalie for an air
    hockey table. The goalie can be 1 inch wide.
  • Tasks
  • determine puck location
  • camera placed abovetable
  • position blocker

4
Concepts
  • You are to design an automated goalie for an air
    hockey table. The goalie can be 1 inch wide.
  • Tasks
  • determine puck location
  • camera placed abovetable
  • position blocker
  • linear motion of blockerpiece using belt
    andpulleys
  • linear motion of blockerusing screw
  • linear motion of blockerusing slider crank
    mechanism
  • rotational motion of blocker piece

5
Concepts
  • You are to design an automated goalie for an air
    hockey table. The goalie can be 1 inch wide.
  • Tasks
  • determine puck location
  • camera placed abovetable
  • position blocker
  • linear motion of blockerpiece using belt
    andpulleys
  • linear motion of blockerusing screw
  • linear motion of blockerusing slider crank
    mechanism
  • rotational motion of blocker piece

6
Concepts
  • You are to design an automated goalie for an air
    hockey table. The goalie can be 1 inch wide.
  • Tasks
  • determine puck location
  • camera placed abovetable
  • position blocker
  • linear motion of blockerpiece using belt
    andpulleys
  • linear motion of blockerusing screw
  • linear motion of blockerusing slider crank
    mechanism
  • rotational motion of blocker piece

7
Concepts
  • You are to design an automated goalie for an air
    hockey table. The goalie can be 1 inch wide.
  • Tasks
  • determine puck location
  • camera placed abovetable
  • position blocker
  • linear motion of blockerpiece using belt
    andpulleys
  • linear motion of blockerusing screw
  • linear motion of blockerusing slider crank
    mechanism
  • rotational motion of blocker piece

8
Concept Selection
  • list the pros and cons of each design
  • formulate concept evaluation table

9
Other Design Choices
  • power
  • electric servo motor
  • electric stepper motor
  • hydraulic actuator
  • pneumatics
  • open or closed loop control
  • open loop
  • closed loop
  • closed loop control requires a feedback sensor to
    measure the motors rotation

10
Another Example
  • Control the steering angle of an autonomous
    ground vehicle.
  • Must be able to control the rotation angle.

11
How to pick a motor?
  • How much power isneeded?
  • Is a speed reducer needed?

12
Design Choices
  • How much power is needed?
  • determine the maximum product of motor torque
    times angular velocity

13
Design Choices
  • Is a speed reducer needed?
  • a typical DC motor can rotate at a top speed of
    2600 rpm (43? rev/sec)
  • gear box
  • epicyclic gear train
  • ball screw drive

14
gear box
worm gear drive
15
epicyclic gear train
ball screw drive
16
Design Choices
  • Open-loop or closed-loop control?
  • open-loop
  • well suited for remote control using a joystick
  • computer control can be implemented using a
    stepper motor
  • closed-loop
  • requires a sensor to measure the motors rotation
    angle

17
Design Choices
  • What power source will be used?
  • electric servo motor
  • How much power is needed?
  • experiment or perform analysis(very little
    torque will be needed to move the goalie further
    the rotational speed will be very low)
  • Is a speed reducer needed?
  • yes
  • Open-loop or closed-loop control?
  • closed-loop

18
How does this work?
motor
gear reducer
desired steering angle
how is the motor connected to the steering shaft?
how does the computer cause the motor to turn?
how does the computer know the current steering
angle?
19
Motor and Gear Box
how is the motor connected to the steering shaft?
20
Motor and Gear Box
21
motor with gear reducer
flex coupling
22
Servo Motor Control
  • select means of angle measurement
  • optical encoder
  • incremental
  • absolute
  • potentiometer
  • resolver

how does the computer know the current steering
angle?
23
Incremental Optical Encoder
  • this disk has 12 slots (30º resolution)
  • typical incremental encoders have up to 2540
    counts per revolution (0.142º resolution) (488.
    41 each at McMaster-Carr)

24
Incremental Optical Encoder
25
Incremental Optical Encoder
you can count pulses, but which way is it
rotating?
26
Incremental Optical Encoder
an encoder will typically also have anindex that
will blink once each revolution
27
Incremental Optical Encoder
quadrature - there are 4n events per one
revolution of the disk - the resolution can in
effect be four times the number of slots
28
Incremental Optical Encoder
note many encoders will have an index that will
pulse once per revolution
29
Honeywell / Clarostat 600128CN1 Allied
Electronics part 753-0059
cost 41.67
30
Incremental Optical Encoder
problem - you start up the device - where are
you when you start?
31
Absolute Optical Encoder
BEI brand encoder 455
32
Homing and Limit Protection
  • for an incremental optical encoder, we need to
    add a switch to set the homing position
  • we also need to have limit switches

33
motor with gear reducer
flex coupling
optical encoder
34
How does this work?
motor
gear reducer
desired steering angle
how is the motor connected to the steering shaft?
how does the computer cause the motor to turn?
gear reducer and flex couplings (if needed)
how does the computer know the current steering
angle?
computer controls the current going to the motor
incremental optical encoder with homing switch to
initialize position
35
How does the computer control the motor?
control the current (via the voltage)
36
(No Transcript)
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Summary of Closed-Loop Control
computer controls the current going to the motor
motor
gear reducer
desired steering angle compared to current
steering angle
gear reducer and flex couplings (if needed)
connect motor to steering shaft
incremental optical encoder (with homing switch
to initialize position) feeds back current motor
position
