STScI HST Servicing Mission 4 Delta Readiness Review

1
STScI HST Servicing Mission 4Delta Readiness
Review

• April 21, 2009
• Space Telescope Science Institute
• John N. Bahcall Auditorium

2
Agenda (1)

• Introduction and Summary Helmut Jenkner 30
• Agenda
• Purpose and Scope
• Proposal Processing
• Long Range Plan
• Data Management Systems
• Freeze Plan
• Data Release Policy
• NICMOS Readiness
• Operational Readiness
• SM4 Support
• SMOV Management and Reporting
• OPO Readiness

3
Agenda (2)

• SMOV Program Carl Biagetti 20
• Planning and Scheduling Merle Reinhart 15
• Commanding Alan Welty 10
• Calibration Pipeline Warren Hack 10
• WFC3 Readiness John MacKenty 20
• COS and STIS Readiness Alessandra Aloisi 25
• ACS Readiness Linda Smith 15
• FGS and OTA Readiness Ed Nelan / Matt Lallo 10
• ERO Readiness Keith Noll 10
• Infrastructure Doris McClure 10
• DRR Action Item Review Ken Sembach 10

4
Introduction and Summary

• Helmut Jenkner

5
Purpose and Scope

• Purpose Demonstrate STScI Readiness for SM4.
• Scope This is a Delta Readiness Review
• Builds on SM4 Readiness Review held on September
  9 and 10, 2008
• Presentations available at http//www.stsci.edu/in
  stitute/org/hstmo/sm4/readinessreview
• All action items from that review have been
  closed (see list in backup charts).
• Concentrates on updates, changes and new items,
  including new work done.
• Areas with only small changes are summarized in
  this initial presentation.

6
Proposal Processing

• Denise Taylor

7
SMOV Proposals

• 150 proposals (not including ERO and withdrawn
  props)
• 35 COS props (164 ext. orb., 111 int. orb.) - All
  ready.
• 31 ACS props (38 ext. orb., 493 int. orb.) All
  ready
• 42 WFC3 props (163 ext. orb., 370 int. orb.) -
  All ready
• 25 STIS props (21 ext. orb., 174 int. orb.) - All
  ready
• 12 NIC props (34 ext. orb., 136 int. orb.) - All
  ready
• 3 PCS props (41 ext. orb.) - All ready
• 2 FGS props (22 ext. orb.) - All ready

8
ERO Proposals

• 8 ERO proposals to be executed after SM4 for 89
  orbits (ERO proposal 11500 executed 3 orbits on
  Eta Carina in September 2008 with WFPC2.)
• All ERO proposals are ready for flight
• Three WFC3 ERO
• One STIS ERO
• One ACS ERO
• Three COS ERO

9
Cycle 17 Proposal Pool (1)

• 197 GO proposals including those from HST Cycle
  17 TAC, Chandra TAC, and previous HST TACs, for
  3627 orbits.
• 16 SNAP proposals, for 1417 orbits.
• 24 GTO/COS proposals for 291 orbits.
• 3 GTO/ACS proposals for 24 orbits.
• 2 ERS proposals for 214 orbits.
• 3 GO/PAR proposals for 410 orbits.
• 103 Calibration proposals for 1088 external
  orbits, 7069 internal orbits.

10
Cycle 17 Proposal Pool (2)

• Program Coordinators (PCs) are processing
  observations in the pool 7000 external and
  7000 internal orbits. Eight calibration
  proposals still to be submitted.
• Instrument teams have been reviewing these
  observations and will have most done before SM4.
  Remaining will be done according to Long Range
  Plan schedule.
• Final processing steps will wait until after SM4,
  when the ground system is reconfigured for 3 gyro
  mode.
• Time-critical Cycle 17 GO observations have been
  executing in 2-gyro mode since October 2008 (96
  orbits so far).
• After SM4, all remaining Cycle 15, 16 proposals
  will be re-worked for 3-gyro mode.
• Remaining NICMOS observations are being switched
  to another existing or future instrument, when
  possible to reach scientific goals without
  NICMOS.

11
Cycle 17 Long Range Plan

• David Adler

12
Cycle 17 Long Range Plan

• Cycle 17 Long Range Plan has been rebuilt.
• Distribution is mostly smooth, with some minor
  resource conflicts being worked

End of Cycle 17 Aug 31, 2010
End of SMOV Aug 17, 2009
SM4, SMOV (not in plan)
Cycle 17 tail
orbits/day
11 0
13
Cycle 17 Plan Numbers

• SMOV, EROs (not included in Cycle 17) 500
  orbits.
• Cycle 17 Statistics
• 380 days in length (8/17/09 - end of SMOV - to
  8/31/10).
• Cycle 17 GO, GTO, cals, etc 4550 orbits (100
  NIC).
• Cycle 15/16 carryover 600 orbits (500 NIC).
• Total C15/16/17 5150 orbits.
• Planned Cycle 17 tail 650 orbits.
• Expected subscription
• 4500 orbits/380 days 11.8 orb/day 82.6
  orbits/week.
• Slightly above the anticipated rate of 80
  orbits/week.
• Some science may come forward into SMOV if space
  allows.
• Some orbits may be dropped if NIC restart is
  unsuccessful.
• LRPG is ready for SMOV and Cycle 17.

14
Data Management Systems

• Al Holm, Lisa Gardner

15
SM4-Related Deliveries Since September 2008

• DMS 2008.4 was delivered on October 7, 2008
• 13 PRs for COS, 4 PRs for ACS, 1 PR for Fastrak
• DMS 2008.5 was delivered on November 13, 2008
• 2 PRs for COS and 1 PR for ACS
• DMS 2009.1 was delivered on March 9, 2009
• 18 PRs for COS, 3 PRs for ACS, and 1 PR for WFC3
• DMS 2009.2 was delivered on April 14, 2009
• 16 PRs for COS, 2 PRs for WFC3, 1 PR for both COS
  and WFC3, and 1 PR for STIS
• STSDAS deliveries were delivered with each of
  these builds and included a total of 55 PRs for
  COS, 25 PRs for WFC3, and 2 PRs for ACS

16
Outstanding SM4-Critical PRs

• The following Problem Reports are planned to be
  quick-fixed before SMOV
• OPUS 62322 "COS images with subarrays are not
  being populated correctly
• STSDAS 62336 "CALACS crashes with floating-point
  CCDGAIN in _raw files
• Both PRs have been tested and are ready to go

17
Freeze Plans

• HSTMO

18
SM4 Freeze Plans

• HSTP Level Freeze
• Started on April 13.
• Extends into SMOV (few weeks) at discretion of
  HST Operations Project Manager.
• Requires HSTP approval for installations while
  freeze is in effect.
• HSTMO Level Freeze
• Started on April 13.
• Extends into SMOV (few weeks) at discretion of
  HSTMO.
• Requires HSTMO approval for installations while
  freeze is in effect.
• Generally will be discussed and approved at SMOV
  meetings, or via email.
• Some systems will not be affected
• Must protect systems essential for SM4 and SMOV4
• But allow other work to proceed efficiently.

19
HSTP Level Freeze

• Software covered
• SPSS
• Commanding
• SRT
• GSSS, POPS, POMS, etc.
• PASS
• PRD
• Hardware covered
• PASS servers
• SPSS servers
• Network switches and routers

20
HSTMO Level Freeze

• Software covered
• APT and TRANS (HST operational versions)
• Assist
• SPIKE elements used in APT
• OPUS, including operational pipeline versions of
• CALxxx
• MultiDrizzle
• CDBS
• OMS
• DADS
• STSDAS
• Infrastructure and operating systems for above
  systems
• Hardware covered
• SOGS network
• DMS hardware (Sunfire 15K, EMC, safestore
  devices, etc.)

21
Other HST Systems

• Unaffected by freezes
• HLA
• GMS
• ETCs
• SPIKE
• PROMPT

22
Data Release Policy

• HSTMO, Science Policies Group

23
Data Release Policy Implementation (1)

• OPB has set initial proprietary period to one
  year for proposals using either new SIs or
  serviced modes.
• ERO and ERS data will remain proprietary until
  their press release.
• SMOV and calibration data for COS, WFC3, and the
  serviced modes will remain proprietary until ERO
  press release.

24
Data Release Policy Implementation (2)

• Manual process for shortening release dates will
  continue
• based on proposal ID, not visit or SI mode
• GO data taken with new SIs and with serviced
  modes will be embargoed
• authorization to access data from proposal will
  be withheld until the PI agrees not to discuss or
  present the data publicly until after ERO press
  releases

25
Embargo Agreement Text (as revised per STScI RR
AI04)
Because NASA has not yet made the first Early
Release Observations (EROs) public for the new
and serviced instruments, the STScI requires that
you agree to abide by the restrictions below
before we can make your data accessible to you
for retrieval. Once we receive an email reply
with your acceptance of these restrictions, we
will allow you access to your Cycle 17 data. All
Guest Observers requesting access to their Cycle
17 data from new and serviced instruments before
the NASA ERO press release date must agree to
refuse any public discussion or display of these
data and/or any scientific results derived from
them until after the official NASA ERO press
conference. Public discussions include seminars,
colloquia, press conferences, lectures,
conference posters, website postings, mass media
interviews, and journal publications. Do you
agree to these terms? Before you distribute
these data further to co-investigators or other
collaborators working with you on these data,
they must agree to these terms also.

Matt Mountain

Director, Space Telescope Science Institute
26
NICMOS Readiness

• Tommy Wiklind, Anton Koekemoer

27
NICMOS SMOV4 Readiness

• NCS re-start attempt during the first week of
  SMOV
• Detailed re-start procedure is being defined.
• Nominal cool-down time is estimated to be four
  weeks (previously two weeks).
• The NICMOS SMOV4 program remains the same as of
  September 2008.
• Coronagraphic programs placed at the end of the
  SMOV period.
• Photometric and grism calibrations will be done
  as part of a Special Cycle 17 Calibration
  program.
• If this NCS re-start attempt is unsuccessful,
  stand down from all NICMOS activities during SMOV.

28
NICMOS SMOV4 ProposalsTeam Assignments
29
NICMOS SMOV4 Calibration Timeline

• Week 1
• NCS re-start
• Week 1 - 4
• NCS cooling
• Week 5 (4 external orbits)
• NICMOS SAFE to OPER
• DC Transfer Test
• Filter Wheel Test
• Focus/Tilt I Check
• Week 6 (4 external orbits)
• Focus/Tilt II (FSW updates if necessary)
• FOM Functional (possibly FSW updates)
• Start of Darks/Read Noise
• Start of Thermal background characterization
• Week 8 (10 external orbits)
• Aperture Locations (for SIAF update)
• Optical Plate Scale (FSW update if necessary)
• NICMOS ERS enabled
• Week 12 - 14 (21 external orbits)

) Time critical activities
30
DMS Operational Readiness

• Al Holm

31
Successful Test Activity

• Processed science data received from PACOR via
  the backup CD-R method.
• Tested destination directories for all fast track
  data.
• Supported data processing and delivery for the
  ACS-R Optimization Campaign Dry Run.
• Supported data processing and delivery for the SI
  CDH SMGT.
• Supported data processing and delivery for
  SR4.2a.
• Conducted acceptance tests of DMS 2008.4, 2008.5,
  2009.1, and 2009.2, and supported their
  installation.

32
SM4 Support

• Chris Long et al.

33
Observatory Support Team
Project/JSC Project/GSFC STOCC STScI
Orbit Mountain Jenkner C. Long Blades
Planning Hauser Sembach Wheeler Biagetti
STScI GSFC JSC IDT
WFC3 WFC3 COS COS STIS STIS ACS ACS
GSFC STScI GSFC STScI GSFC STScI GSFC STScI
Orbit Hartig Petro Lennon Sahnow J. Green Penton McPhate Kaiser Oliveira Woodgate L. Smith Lucas Cox Platais Gonzaga
Analysis MacKenty Bushouse Baggett Hilbert Keyes Friedman Osterman Ake York Beland Froning Goudfrooij Proffitt Gull Linder Lennon Wolfe Golimowski Mutchler Lim Maybhate Chiaberge Desjardins
FGS NICMOS Commanding Lallo/ Nelan Koekemoer / Wiklind Welty / Dashevsky
34
SM4 Science Schedule
35
SMOV Management and Reporting

• Carl Biagetti, HSTMO

36
SMOV-Related Meetings

• SMOV Status and Planning Meeting (Morning
  Meeting)
• Daily (7 days/week) for first 4 weeks, 3
  days/week thereafter 830 a.m.
• STScI Board Room, audio (video?) tie-in with
  GSFC.
• Lead Biagetti backup Burley.
• SMOV Weekly Management Meeting
• Time/venue TBD.
• HSTP Management, HSTMO, Biagetti, Burley.
• HST Mission Status Reviews (MSRs)
• 3rd Tuesday of each month.
• Topics as required.
• SMOV Telescope Time Review Board (TTRB)
• Reviews changes to SMOV proposals and timeline.
• Biagetti, Burley, Niedner, Sembach, D. C. Taylor.
• SMOV Closure Review (November 2009)
• Formal team reports.
• Trace-back to SMOV requirements.

37
SMOV-Related Reporting

• Minutes from SMOV Status and Planning Meetings
  (Biagetti, Burley).
• HST Weekly Reports
• Highlights only links to Minutes.
• SMOV Closure Report
• Following SMOV Closure Review.

38
OPO Readiness

• Stratis Kakadelis, Mario Livio

39
OPO SM4 Readiness
All OPO SM4 products/services are ready for launch

• News newsroom support at KSC JSC daily video
  updates
• Education specialized content for students
  educators on Amazing Space special SM4-themed
  museum shows distributed through ViewSpace
  network
• Online partnership with NASA web portal for
  content videos complete SM4 portal page on
  HubbleSite
• Origins SM4 info feed to International Year of
  Astronomy websites and amateur groups

40
Backup Charts
41
Action Items from September Readiness Review -
Day 1 (1)

• A01 SMOV TTRB membership needs to be defined
  (Biagetti)
• A02 Provide recommendation for whether or not a
  SMOV replanning exercise is necessary (Biagetti,
  in consult with Burley and HSTMO)
• A03 Provide information about SNAP program to
  K. Kalinowski (Sembach)
• A04 Revise wording for Data Release Policy to
  include collaborators and Co-Is requesting access
  (Holm)
• A05 Provide recommendation for whether or not a
  Fastrack test using existing dataset (e.g.,
  NICMOS or ACS O-scope mode) is needed (Holm)
• A06 Secure shipping/receiving entrance so
  visitors must use front entrance) (Schnader /
  Directors Office)

42
Action Items from September Readiness Review -
Day 1 (2)

• A07 Assess options for identifying persons
  entering building with attention to what must be
  implemented both for permanent staff and for
  short/long-term visitors during SM4 and SMOV
  (Schnader / Directors Office)
• A08 Notify HSTMO when ACS Oscilloscope Mode data
  flow has been fully tested, including OPUS and
  Fastrack paths (Sirianni)
• A09 Provide HSTMO with WFC3 soft-safing
  description (MacKenty / Welty)
• A10 Provide Burley with summary chart of SM4
  readiness dates for instruments / data systems /
  commanding / PS / etc... (Sembach)
• A11 Provide Directorate with weekly
  description of SM4 preparedness and critical path
  items / dates (Doxsey)
• A12 Check with instrument and operations teams
  to make sure key personnel have GSFC badges in
  case long-term internet and/or power outage
  require relocation to GSFC (Sembach / Long /
  Workman)
• A13 Provide HSTMO with list/description of the
  12 CALCOS modules that have not been verified by
  the COS PVT (Aloisi)

43
Action Items from September Readiness Review -
Day 2

• B13 Provide HSTMO with hardcopy images of WFC3
  detector illumination for various CSM positions
  to use during SM4 FT assessment (MacKenty)
• B14 Identify key SMOV alignment/focus
  instrument activities and times for which George
  Hartig is needed (Biagetti)
• B15 Provide HSTMO with target completion dates
  for SMOV Analysis Plans (Team Leads)
• B16 Review ACS SMOV decision points and
  responsible parties with HSTMO and Biagetti
  (Smith)
• B17 Provide focus decision tree, in consult
  with HSTMO (Lallo)
• B18 Finalize analysis strategy/personnel for
  EROs in consultation with instrument teams.
  Provide final list to HSTMO. (Noll)
• B19 Finalize strategy for which ERO
  observations are executed if SMOV schedule slips
  or decision is made to show results from less
  than nominal 9 EROs at AAS (Noll)
• B20 Provide updated Fastrack and real-time
  contact request list to Burley for SMOV planning
  (Biagetti)

44
SMOV4 PLANNING READINESS

• STScI SM4 DELTA READINESS REVIEW
• 21 APR. 2009
• Carl Biagetti

45
SMOV4 PLANCHANGES TO DRIVERS

• ERO schedule is no longer driven by AAS schedule
• Therefore moved from weeks 7 8 to weeks 9 10
• All other drivers remain the same
• See 09Sep08 Readiness Review

46
SMOV4 PLANCHANGES TO CONSTRAINTS

• No changes to SMOV planning constraints
• See 09Sep08 Readiness Review

47
SMOV4 PLAN PRIORITIZATION OF ACTIVITIES

• SMOV4 Plan prioritizes SMOV activities to allow
  schedule flexibility and proper sequencing
• No changes in prioritizations
• See 09Sep08 Readiness Review

48
COS PLAN CHANGESSINCE SEP 2008

• Several recent Target Acq problems have surfaced
  and have been addressed
• Subarray specifications
• PSA/BOA reference points
• Corrections to target placements in detector
  frame
• Proposal impacts
• 20 proposals needed to be updated (complete)
• to address above problems
• for mid-2009 targets
• Timeline Impacts
• Additional uplink requirements
• In-line commanding (PMDB) updates identified
• Updates need to be submitted for upcoming SMSs
• Several changes in activity dependencies
• Several time-dependent targets (CVZ, etc.)

49
WFC3 PLAN CHANGESSINCE SEP 2008

• SMOV transition from PROTECT to Nominal state
• Dave Hickeys testing is complete
• resulted in some adjustments to r/t commanding
  for bench thermal management
• Otherwise transparent to SMOV timeline
• Proposal impacts
• None
• Timeline Impacts
• None

50

ACS PLAN CHANGESSINCE SEP 2008

• Optimization Campaign (OC) Dry Run encountered
  several problems
• ground and flight sw configurations
• being worked or already solved
• analysis time between iterations needs to
  increase
• Proposal impacts
• Additional CTE/Cross-Talk check during OC
• Timeline Impacts
• Sixteen additional days for OC (total 37 days)
• may be mitigated by potential for early
  completion of test
• Causes downstream delays to ACS CCD science/EROs

51
FGS PLAN CHANGESSINCE SEP 2008

• Mini-OFAD and FGS alignment (5 orbits ea.) moved
  to Cycle 17 Cal Plan
• FGS2 alignment wrt FGS 13 will be unstable in
  early SMOV
• New FGS will not be used as dominant guider in
  SMOV timeframe
• Therefore Proposals 11459 (Alignment) 11460
  (mini-OFAD) are deferred to Cycle 17
• Waiver of SMOV Requirements L.10.4.7.3.3
  L.10.4.7.3.
• Near Term Monitor of FGS2R2 Stability (4 orbits)
  moved to C17 Cal Plan
• Prop 11464 - relies on M35 which is not available
  in mid-2009
• Therefore deferred to Cycle 17 (Proposals 11874
  11875)
• Waiver of SMOV Requirement L.10.4.7.3.8
• FGS1R FGS3 Recommissioning (2 orbits) moved to
  C17 Cal Plan
• Prop 11463 - relies on M35 which is not available
  in mid-2009
• Therefore deferred to Cycle 17 (Proposal 11871)
• Waiver of SMOV Requirement L.10.4.7.3.7

52
FGS PLAN CHANGESSINCE SEP 2008 CONTD

• FGS2R2 AMA Adjustment Activity
• Proposal 11458 will be scheduled starting in SMOV
  Week 2 instead of Week 1
• Lessens the effect of outgassing on the
  measurement results
• Allows additional pre-look visits in Week 1 for
  target determination for Week 2 AMA adjustments
  and some scale and coarse alignment information
• Proposal impacts from FGS changes
• Nelan/Reinhart have updated SMOV proposals
• 11457, 11458, 11459, 11462
• Timeline Impacts from FGS changes
• Several SMOV days are gained by the deferrals to
  Cycle 17
• Gains are offset by decision to move AMA
  activities from Week 1 to Week 2
• FGS2R2 commissioning for guiding
• Remains at SMOV Day 42
• These timeline adjustments were worked out in the
  GSWG and SMOVWG

53
DMS PLAN CHANGESSINCE SEP 2008 CONTD

• Proposal for special BEA attitude to test Bay 10
  (SI CDH) thermal model
• Feasible in early BEA period
• gt New SMOV thermal requirement
• Proposal impacts
• None, only SMS-level changes
• Timeline Impacts
• None

54
NICMOS PLAN CHANGESSINCE SEP 2008 CONTD

• No recent changes
• Awaiting Project WG recommendation on NICMOS SMOV
  Plan
• Proposal impacts
• None
• Target updates for mid-2009 SMOV have been
  postponed
• Pending successful NCS reactivation and cooldown
• Timeline Impacts
• Current SMOV timeline includes nominal NICMOS
  plan on non-interference basis

55
SMOV4 MILESTONES VEHICLE
AS OF 21APR09
DELTA (DAYS)
AS OF 08DEC08
AS OF 08DEC08

• HST RELEASE SMOV START 20 MAY 20 MAY 0
• BEA PERIOD COMPLETES 10 JUNE 10 JUN 0
• FGS2R2 ENABLED FOR GUIDING 02 JUL 29 JUN -3

56
SMOV4 MILESTONES GO SCIENCE ENABLE POINTS
DELTA (DAYS)
AS OF 08DEC08
AS OF 21APR09

• FGS1R 22 JUN 10 JUN -12
• STIS CCD 09 JUN 10 JUN 1
• STIS NUV/FUV 12 JUN 17 JUN 5
• STIS SMOV COMPLETE 25 JUN 26 JUN 1
• ACS SBC 10 JUN 12 JUN 2
• ACS WFC 27 JUN 13 JUL 16
• ACS HRC 28 JUN 13 JUL 15
• ACS CORONAGRAPH 14 JUL 30 JUL 16
• ACS SMOV COMPLETE 14 JUL 31 JUL 17
• NICMOS IMAGING TBD 24 JUL TBD 05 AUG 12
• NICMOS CORONAGRAPHY TBD 30 AUG TBD 28 AUG -
  2
• NICMOS SMOV COMPLETE TBD 06 SEP TBD 04 SEP -
  2

57
SMOV4 MILESTONES GO SCIENCE ENABLE POINTS (2)
AS OF 21APR09
DELTA (DAYS)
AS OF 21APR09
AS OF 08DEC08
AS OF 08DEC08

• WFC3
• UVIS EASY 07 JUL 01 JUL - 6
• IR EASY 07 JUL 13 JUL 6
• UVIS HARD 11 AUG 12 AUG 1
• IR HARD 14 AUG 14 AUG 0
• SMOV COMPLETE 14 AUG 14 AUG 0
• COS
• FUV 18 JUL 27 JUL 9
• NUV IMAGING 11 AUG 08 AUG - 3
• NUV SPECTROSCOPY 31 JUL 13 AUG 13
• COS SMOV COMPLETE 11 AUG 30 AUG 19

58
SMOV4 MILESTONESERO ENABLE POINTS(Not
necessarily the execution dates)
AS OF 08DEC08
AS OF 21APR09
DELTA (DAYS)

• STIS
• CCD 09 JUN 10 JUN 1
• NUV/FUV (N/A) 22 JUN 17 JUN - 5
• ACS
• WFC 27 JUN 13 JUL 16
• HRC 28 JUN 13 JUL 15
• WFC3
• UVIS 04 JUL 06 JUL 2
• IR 06 JUL 12 JUL 6
• COS
• FUV 03 JUL 20 JUL 17
• NICMOS
• IMAGING TBD 08 JUL 27 JUL 19

59
WFC3 UVIS/IR HARD SCI ENABLE, COS NUV SCI ENABLE
FGS2R2 GUIDING
COS FUV SCI ENABLE, NIC SCIENCE ENABLE (TBD)
ACS SBC SCI ENABLE
ACS HRC SCI UVISEASY SCI
WFC3 IR EASY SCI ENABLE
STIS SCIENCE ENABLE
ACS WFC SCI ENABLE,
60
Critical Operations and Operational Challenges in
SMOV

• HV Ramp-ups for STIS and COS
• Unchanged since Sep 2008
• Focus Alignments for COS WFC3
• Iterative processes for each SI in the same weeks
• Unchanged since Sep 2008
• Realtime Commanding
• GENSLEWs (Use Offsets), Table uploads, Event flag
  mgmt, etc.
• Unchanged since Sep 2008
• Fast Data Turnaround (FASTRACK)
• Needed in several places for in-line analyses
• Command Instructions
• COS SMOV Plan has introduced in-line commanding
  (pmdb) updates
• ACS Optimization Campaign
• Intensive, in-line analyses, instruction changes,
  sms updates, r/t commanding

61
Critical Operations and Operational Challenges in
SMOV Weeks 1-7
Yellow indicate times of high activity FTn
Fastrack data delivery requested by n proposals
WEEK SYSTEM 1 20 MAY 2 01 JUNE 3 08 JUNE 4 15 JUNE 5 22 JUNE 6 29 JUNE 7 06 JULY
S/C FGS BEA, VDT, AMA ADJ, FT1 BEA AMA ADJ, FT2 BEA VDT
WFC3 OUTGAS OUTGAS, SDB CHK OUTGAS INIT UVIS ALIGN, INIT IR ALIGN, FT2 INIT UVIS ALIGN, INIT IR ALIGN, UVIS FINE ALIGN, FT3 UVIS/IR FINE ALIGN, FT2 IR FINE ALIGN, FT1
COS OUTGAS, SDB CHK OUTGAS FUV HV, COS/FGS ALIGN, NUV ALIGN, FT2 FUV HV, NUV ALIGN/FOCUS, FUV SENS, FT2 NUV ALIGN/FOCUS, EXT. SPECTRO. PERF., FT1 FUV SENSITIVITY, COS WL SCALES COS NUV SPECTRO SENSITIVITY FUV ALIGN /FOCUS,, FT2
ACS SDB CHK, TEMP SET PNT, WFC OC, FT1 WFC OC, FT1 WFC OC, FT4 WFC OC, CCD X-TALK, FT4 WFC OC WFC OC
STIS SDB CHK FT1 EROs
NICMOS COOLDOWN COOLDOWN COOLDOWN COOLDOWN FW TEST, FOCUS/PAM ADJ, FT2
62
SMOV PROPOSAL IMPLEMENTATION TEAM (PIT) EARNED
VALUE (EV) as of 17Apr09

• 10 EV points/proposal
• 3 pts for prop submit
• 2 pts for 1st PIT mtg
• 2 pts for 2nd PIT mtg
• 3 pts for prop complete

165 SMOV4 PROPOSALS 1650 total EV points - 165
PROPOSALS PIT-APPROVED PIT PROGRESS - 100
PLANNED EARNED VALUE for Apr 15 - 100 ACTUAL
EARNED VALUE as of Apr 17
63
SMOV4 READINESS

• SMOV PLAN
• COMPLETE
• SMOV PROPOSAL DATABASE
• COMPLETE
• SMOV TEAM
• READY

64
Planning and Scheduling

• Merle Reinhart

65
DatabaseNSSC-1 Flight Software

• NSSC-1 FSW updates are required to support SM4
• NSSC-1 8.6 supports full complement of SIs during
  SM4
• Installed Sep. 10 during SMS 252 (SMS 254 was
  first use)
• Avoids software changes during SM4
• NSSC-1 9.0 removes support for COSTAR and WFPCII
• This will be installed immediately after SM4
  during the HS SMS

66
DatabasePRD/SCIOPSDB

• OPSPRD 7.1 has been deployed to SMS 110
• Planned updates after SM4 rendezvous, prior to
  deploy
• PRD PRs
• 60663 PLCP PJSAFHLD for ACS safing recovery
  including TEC commanding
• 60739 AGCF and SCHF parameters for switch to
  3-gyro mode
• 60742 Table ODB for NSSC-1 9.0 FSW
• SCIOPSDB PRs
• 57951 Initial creation of T-Mode database
  records
• 59227 Update ACS Boot to Operate recon
  command_time
• 59975 Update ACS recons for SM4 - 10.2 rules
• 60611 Change to ACS SBC states to allow WFC/SBC
  for long durations during early SMOV4
• 60647 Update ACS recon timing for repair
• 60635 Remove WFPC2, COSTAR, add WFC3, COS RTCS'
  from DEFAULT.CSE for SM4
• 60726 Update DBDF - Mods SMS Syntax for
  Multi-Gyro Operation
• 60822 Add COS FUV and NUV for bright object
  checking
• 62426 Restrict sa_eps_parms maximum incidence
  for post-SM4 low-power time
• A Freeze Waiver will be requested for all of the
  above

67
DatabaseSMOV Preparation Environment

• SMOV4 development utilizes the same methodology
  that was successfully used for all previous
  Servicing Missions.
• Use a separate database and disk space from
  Operations, but the same machines/servers.
• spss_sm4 database for SMOV4 development
• spss database for current SPSS Operations
• Uses the operational software and tools, but
  utilizes different PRD/SCIOPSDB and SMS
  Instructions
• Allows simultaneous Flight Operations and SMOV
  development
• Two environments are isolated
• The spss_sm4 database is managed in the same way
  as the SPSS Operations database.
• This SMOV4 environment is used to
• Prepare the SMOV proposals for execution
• Create the SMGT products
• Create the SMOV4 representative products
• Post-SM4 DRM Planning and Scheduling exercise

68
DatabaseThe Merge

• SMOV environment, spss_sm4 database, gets merged
  into the Operations environment, spss database,
  after rendezvous and berthing occurs.
• PRD/SCIOPSDB group will audit the merged spss
  database for correctness
• OPS will audit the proposals for correctness
• End-to-end process generally takes about 2 days.
• This Merge process was successfully tested on
  September 15th.

69
DatabasePASS Configuration Files

• These are files used by the PASS software and
  configuration controlled by the PS Operations
  group.
• Mission Scheduler Basefile change to enable the
  solar array maximum incidence check
• Old USE_CALC_SA_ANGLE 'N
• New USE_CALC_SA_ANGLE Y'
• Command Loader Basefile changes to disable WFPC2
  and COSTAR and enable WFC3 and COS (or the
  appropriate combination).
• In the CLBASE Namelist
• Old NS_SINAME 'ACS ', 'NIC ', 'STIS', 'CSTR',
  'WFII
• New NS_SINAME 'ACS ', 'NIC ', 'STIS', 'COS ',
  'WFC3
• Old NSREDUNDV 'A', 'A', 'A', 'B', 'A', 'A
• New NSREDUNDV 'A', 'A', 'A', 'B', 'A', 'B
• Old NSSHPSI '_NSSHPS4
• New NSSHPSI '_NSSHPS5'

70
DatabasePASS Configuration Files (cont)

• MEGG initialization file changes to swap in the
  appropriate new instruments.
• Old
  New

WFPC standby COSTAR hold STIS operate NICMOS
saa_oper ACS hold NCS CPL_hold
WFC3 hold COS hold STIS operate NICMOS
saa_oper ACS hold NCS CPL_hold COS_NUV
hold COS_FUV hold
71
Planning and SchedulingProcedures

• The procedures are written, configured
  descriptions of a particular process workflow
  that describes the tools and actions that should
  be performed to accomplish that particular
  workflow.
• Procedures that need modification to support
  post-SM4
• None of these updated procedures will be put into
  place until after the database merge is complete.
• 3.2.01 - Scheduling Unit Selection
• Remove the WFPC2 decon references and add in the
  WFC3/ACS/STIS Anneal proposals
• 3.2.02 - Flight Calendar Preparation
• Add the STIS Low Voltage management (STISLs) back
  in
• 3.2.03 - Flight Calendar Building
• Remove the special checks for non-functional
  ACS/STIS detectors
• The following procedures were modified and
  installed
• 3.2.17 - Science Instrument Safe Mode Recovery
• Add WFC3/COS and post_SM4 ACS
• All Visits are ready for use

72
Planning and SchedulingTools

• The tools are configured programs or scripts that
  are used to perform certain actions called out in
  the Procedures used for building the weekly
  flight calendars.
• ccl_gsselect
• Selects the guidestars used in the SMS
• Dont allow FGS2R2 to be used as the dominant
  guider
• su_gaps.sqr
• Calendar Visit summary report
• Add COS/WFC3
• gimme_snaps.py
• Builds the lists of what to schedule on a
  particular week
• Change the default for SI/configs to exclude back
  to nothing
• Calendar/SMS checklists
• Checks correctness of flight calendars and SMSs
• Updates for the new Sis
• pass_prod_xfer.py
• Add Bay 10 incidence column to the pointing
  profile section of delivery letter
• All of these tools will be put into place
  operationally after the database merge is
  complete.

73
RendezvousTransitioning HST to Servicing Mission
4

• Objective prepare HST for rendezvous with the
  Space Shuttle while maximizing the science
  content of the launch week SMS
• Methodology utilize the nominal PS Intercept
  capability
• A primary science SMS with transition visits
• A pre-planned intercept SMS with Gyro-4 test and
  rendezvous attitude maintenance
• Post-launch switch from science to intercept
• TDRS Schedule rework
• Testing
• Previously used for SM3B
• Tested during the System Readiness 4.2 and 4.2a
  SMGTs
• Intercept loaded and executing but stopped prior
  to Gyro-4 test and rendezvous attitude
  maintenance to reduce test duration

74
Rendezvous
Science SMS
Rndz attitude
Rndz attitude
science
science
science
09.131
09.138
load breaks
Intercept SMS
Rndz attitude
science
G4 Tests
Rndz Att Maint
execution path if launch occurs
75
Deploy SMS ProcessFiring Up an Improved HST

• The deploy SMS is a Health Safety SMS generated
  using the nominal HS generation process
• 3-Gyro Onboard Attitude Determination (OBAD)
  Tmode
• Built using NSSC-1 FSW 9.0
• 36 hour duration
• BEA compliant initial attitude provided by PCS
• Contains no SI commanding
• Allows installation of NSSC-1 FSW 9.0 and COS FSW
• Removes support for COSTAR and WFPC2
• Fixes a COS Lamp startup failure issue
• Allows real-time commanding to configure HST for
  use
• Tested during the System Readiness 4.2 and 4.2a
  SMGTs
• First Science SMS
• NSSC-1 cold-start due to FSW install in previous
  SMS
• Begin SMOV activities
• Based upon preliminary SMOV template calendar

76
SMOV4 Calendar/SMS Builds

• Construct representative SMOV products assuming a
  nominal mission and a nominal SMOV
• Products will cover the first 4-6 weeks of SMOV
• Determines the scheduling feasibility of the SMOV
  Plan
• Finds any inconsistencies between the different
  SMOV Proposals
• These products will be widely distributed for
  review
• Ensures we havent missed or misinterpreted
  something
• Will be the starting point for building the
  templates the Flight Calendar Builders will use
  for flight.
• Templates will be started by T-14 days and
  handed to the Flight Calendar Builder by their
  nominal T-11d build start.
• Currently have the first 3 weeks built and
  delivered for review.
• Week 4 is nearly complete and expected to be
  delivered for review later this week.

77
PS Team SM4 ReadinessOperations Support

• PS staff will be on-site at STScI to cover
  critical activities as necessary
• Launch to update TDRS schedule
• Pre and Post reboost ephem processing
• Post-Deploy ephem
• HST Attitude from PCS and HS SMS creation
• Follow-on Science SMS creation
• Post-deploy scheduling
• Resume normal SMS build and delivery schedule for
  SMOV following post-deploy HS and first Science
  SMS
• PS Team ready for SM4, SMOV and Cycle 17
  operations

78
Items Still in Work

• Update Flight Rendezvous/Transition Visits
• Complete by April 30 after April 27 ephem
  received
• Rework SMOV Weeks as necessary based upon review
  feedback received.
• Complete by May 6
• Rework SMOV Weeks 2-4 as a result of ACS O-Mode
  changes
• Complete by May 6
• Finish building Representative SMOV Weeks out to
  at least 5
• Attempt to complete by May 6, no later than May 18

79
Commanding

• Alan Welty
• Commanding Branch - OED

80
Regression Testing1

• Bit Validation Status
• ACS
• Done
• NICMOS
• Done (revalidation not requested)
• STIS
• Done
• COS
• Done
• WFC3
• Done

81
Regression Testing2

• Certification Status
• ACS-R
• Last 27-Jan-09 Up to date
• NICMOS
• Last 09-Apr-09 Up to date
• STIS
• Last 05-Feb-09 Up to date
• COS
• Last 02-Apr-09 Up to date
• WFC3
• Last 27-Jan-09 Up to date
• FGS
• Last 23-Mar-09 Up to date

82
Commanding Changes1

• General
• Standardize TEXT blocks
• Facilitate more complete searches of Instructions
  PDB tables groups
• Standardize SI event flag management instructions
• ACS
• Address SBC turn-on timing problem
• 60 sec delay after WFC gain or readout mode
  change
• Eliminate possibility of commanding on side 2
• Include SCIHDR in ASIC diagnostics special
  commanding
• Update WFC Optimization special instruction
  EJCCDBIASR will require bench test freeze
  waiver
• NICMOS
• Special commanding to Enable FW motion

83
Commanding Changes2

• STIS
• Restore MAMA Recovery special commanding
• COS
• Updates to prevent associations from sharing
  auto-wavecals
• Update Target Acq subarrays FSW patchable
  constants
• Implement FUV Recovery special commanding
• WFC3
• Implement Safing Recovery instructions
• Update Operate to Boot regarding TEC event flags
• FGS
• Add support for Maintenance Slews
• Add support for specifying LOCOUNT on proposal

84
Other Work

• Instruction Audit
• SPSS_SM4/IMDB comparison completed 09-Apr-09
• COS WFC FSW Patchable Constants
• WFC3 verification nearing completion (target
  4/24/09)
• COS verification started (target launch on best
  effort basis)
• Target Acq constants done
• Documentation
• ACS DM-05 delivered Dec 2008
• COS WFC3 DM-05 minor updates will be made
  before SM4
• COS WFC3 OP-01 updates TBD
• SMS Review Tool
• Necessary code is complete some input data
  updates are TBD (related to tracking info, not
  SMS checking) will be done before launch
• To be installed during SM4 (some updates are not
  appropriate for pre-SM4 operation of ACS Freeze
  waiver needed)

85
Conclusion

• STScI Commanding software (IM, PDB tables
  groups, and the SRT) is ready for SMOV
• Bench test needed for EJCCDBIASR
• SRT not to be delivered until SM4
• DM-05 docs will be ready by SM4
• OP-01 docs will be updated as soon as we can, but
  likely not before SM4

86
Calibration Pipeline SSB Software for SMOV

• Warren Hack
• SSB/OED

87
Calibration Pipeline SSB

• STIS
• OPRs 60326 (zero-exposure time) and 60327
  (sc2dcorr fix) have been addressed.
• CALSTIS is ready to support SMOV activities when
  needed.
• NICMOS
• OPRs 61686 (pipeline update for BEPCORR and
  SAACORR) and 62269 (SAACLEAN) have been
  addressed.
• An update to CALNICB will be delivered as a
  quick-fix for 2009.2 to address OPR 61187
  (exposure-time related keywords).
• Otherwise, NICMOS pipeline calibration software
  is ready to fully support NICMOS SMOV activities
• ACS
• OPRs 62104 (time-dependent distortion keywords)
  addressed and installed in OPUS 2009.2.
• CALACS should be ready to support SMOV activities
  when OPR 62336 has been addressed with the
  quick-fix to OPUS 2009.2. This OPR corrects a
  problem with CALACS crashing with floating-point
  CCDGAIN values in the headers of RAW (_raw.fits)
  ACS files.
• MultiDrizzle
• Updates, primarily to support reprocessing,
  included recognizing WFPC2 DQ images in MEF and
  waiver-FITS format, getting full 64-bit support
  working under Solaris, processing data in native
  units or electrons, and fixing a bug processing
  ACS/WFC data in OTFR.
• MultiDrizzle remains ready to fully support all
  ACS data processing needs during SMOV and can be
  used to test WFC3 distortion calibrations in
  off-line processing as needed.

88
Calibration Pipeline WFC3

• 19 OPRs for CALWF3 itself were addressed since
  the last review.
• In addition, 7 additional algorithmic changes
  were also implemented that had no impact on
  pipeline calibration operations.
• Highlights of these fixes include
• NICMOS CR rejection algorithms now 'tuned' for
  WFC3 use
• UVIS calibrations now more robust for use with
  subarrays and L-FLATS
• Summary
• No issues remain for SMOV pipeline to fully
  support WFC3 SMOV activities

89
Calibration Pipeline COS

• 50 OPRs for CALCOS itself have been addressed
  since the last review.
• Highlights of these fixes include (but not
  limited to)
• Implementation of CSUM file generation by CALCOS
• Improvements to wavecal processing
• Proper handling of images with no data, including
  background regions of subarrays
• Support of imaging wavecals
• Improvements to finding a wavecal spectrum
• Summary
• A couple of modes remain unsupported in the
  pipeline ACQ image data will not be calibrated
  yet, wavelength calibration for NUV data needs
  improvement, and imaging wavecal for TIME-TAG
  TAGFLASH data in direct imaging mode can not be
  used to compensate for mirror/mechanism drift
  yet.
• A version of CALCOS will be available for
  off-line use by the COS team during SMOV that
  will support ACQ image calibration and include
  improved NUV wavelength calibration.
• All other modes required for SMOV support have
  been implemented, tested by the COS team and
  delivered for use in the pipeline.

90
Calibration Pipeline Software Versions

• Software versions installed in OPUS for use
  during SMOV

Instrument Version OPUS Build Notes
CALCOS 2.8a 2009.2 Installed
CALWF3 1.4 2009.2 Installed
CALACS 5.0.5 2009.2a Quick-fix
CALNICACALNICB 4.4.0 2.6.2 2009.2 2009.2a Installed Quick-fix
CALSTIS 2.27 2009.1 Installed
91
Calibration Pipeline COS OPRs

• 61075 - CALCOS should use different Doppler
  keywords.
• 61076 - CALCOS should not write MAXDQ or AVGDQ
  columns in x1d tables.
• 61077 - CALCOS should add comments to the jnk
  primary header.
• 61078 -CALCOS should align spectra by wavelength
  when averaging.
• 61093 - CALCOS should use separate keywords for
  slopes of spectra.
• 61162 -Modify calcos to write a calcos sum (csum)
  image.
• 61214 -CALCOS must update exptime local variable
• 61215 - CALCOS should use the product name in the
  jnk file.
• 61216 - Miscellaneous changes to CALCOS.
• 61218 - COS TDSCORR calibration step changes
• 61286 - Changes to CALCOS wavecal processing.
• 61293 - Change PSHIFT keywords to SHIFT1 in
  CALCOS.
• 61294 - CALCOS should shift ACCUM images by the
  wavecal offsets
• 61296 - CALCOS should set bad regions to zero in
  ACCUM images.
• 61297 - CALCOS should correct for bad data in
  background regions.
• 61299 - Remove dependence on keyword DOPPMAG in
  CALCOS.
• 61300 - CALCOS should apply TEMPCORR and GEOCORR
  to the DQ array.
• 61301 - CALCOS has the wrong sign for flat field
  Doppler shift for ACCUM.
• 61302 - CALCOS should use the TDSCORR keyword.

• 61511 - CALCOS should accept acq files as input.
• 61783 - CALCOS changes for version 2.7
• 61953 - CALCOS should check for no counts within
  active area.
• 61954 - Bug in CALCOS test for no data.
• 61955 - CALCOS should not increase image size for
  imaging data.
• 61957 - CALCOS should not test for missing column
  using try/except block.
• 62060 - CALCOS roundoff error when computing
  indices.
• 62061 - CALCOS error in computing count rate.
• 62062 - CALCOS should populate photometric
  keywords for imaging data.
• 62063 - CALCOS should not just copy an x1d file
  to x1dsum.
• 62064 - CALCOS should copy subarray keywords to
  the csum primary header.
• 62065 - CALCOS should print the numpy and pyfits
  version strings
• 62066 - CALCOS should exclude background regions
  outside subarrays.
• 62067 - Add the option to CALCOS to use two
  different background heights.
• 62068 - CALCOS should check for DQ_WGT being all
  zero.
• 62069 - CALCOS should check for exptime 0 when
  computing error array.
• 62070 - CALCOS should check whether xd_range is
  too large.
• 62080 - CALCOS uninitialized variable len_raw
• 62091 - CALCOS should process imaging wavecals.

92
Calibration Pipeline WFC3 OPRs

• 60727 - CALWF3 wf3rej not using correct UVIS
  readnoise values
• 60833 - Calwf3 UVIS blevcorr influenced by CR
  hits in parallel overscan
• 60930 - CALWF3 isn't completing EXPSCORR
  processing
• 60988 - calwf3 should convert IR image units to
  electrons
• 60990 - calwf3 UVIS flatcorr step could apply
  gain correction twice
• 60997 - calwf3 wf3rej skysubmode doesn't work
  well for flats
• 61138 - CALWF3 UVIS photcorr should compute
  PHOTFNU keyword value
• 61164 - CALWF3 throws an IRAF segv on missing
  input file
• 61347 - CALWF3 IR zsigcorr uses wrong sampzero
  time for subarrays
• 61425 - CALWF3 IR DQ flag for cosmic ray not
  propagated to all subsequent groups
• 61428 - CALWF3 IR flatcorr crashes when
  processing subarray images
• 61436 - CALWF3 IR dqicorr needs to allow for
  optional BPIXTAB columns
• 61497 - CALWF3 PHOTCORR needs to use different
  PHOTMODE construction
• 61608 - CALWF3 UVIS processing needs to verify
  matching reference file parameters
• 61698 - CALWF3 BLEVCORR crashing for some UVIS
  SMGT datasets
• 61741 - CALWF3 DQ flag assignments need to be
  updated
• 61785 - CALWF3 UVIS FLATCORR crashes applying
  L-FLAT
• 61819 - CALWF3 wf3rej is propagating CR flags for
  one input image to all following images
• 62005 - CALWF3 wf3rej routine not flagging all
  rejected input image pixels

93
Wide Field Camera 3 Readiness

• John MacKenty

94
WFC3 Highlights

• Development of Cycle 17 Calibration Proposals
• Extensive testing of CALWF3 pipeline
• Both of these activities were optimized to
  provide training and integration into the WFC3
  team of new staff
• Published WFC3 Data Handbook
• Second delivery of pre-launch CDBS Reference
  Files
• Ongoing TV3 analysis
• 16 Instrument Science Reports since Sept 2008
  SMOV review
• Support for DCL activities on Bowtie and IR
  Linearity issues
• Studies and simulations of astrometry and
  Multi-drizzle
• Review of remaining NICMOS proposals to support
  transfer to WFC3 where appropriate

95
WFC3 Team Role

• WFC3 team at STScI has responsibility for all
  aspects of instrument commissioning (no separate
  IDT)
• Engineering support from STScI and WFC3 Project
  at GSFC
• Randy Kimble will provide part time Science IPT
  support in SMOV
• GSFC/DCL retains some detector experiment and
  analysis resources
• ERO team responsible for conduct of ERO program
• WFC3 SOC responsible for Early Release Science
  (feedback on calibrations)
• ESA/ECF responsible via MOU for GRISM support and
  calibration
• WFC3 team is organized into tasks with
  individual task leads and matrixed team members
  supporting each task.
• Most team members have extensive experience with
  WFC3 ground testing
• Resources planned to accommodate work peaks
• Evolving model to incorporate 3-4 FTE growth in
  Sept/Oct timeframe

96
Team Organization, Leads, Members

• Group Tasks
• SM4 Support Larry Petro
• SMOV Susana Deustua (Andre Martel ? JWST/CSA)
• TV3 Analysis Howard Bushouse
• Cycle 17 Calibration Susana Deustua
• Process Tasks
• Calibration Products Sylvia Baggett
• Software and Data Processing Howard Bushouse
• User Support Cheryl Pavlovsky
• Documentation (Jessica Kim Quijano)
• Operations Support Larry Petro
• Analysis Tasks
• Imaging Linda Dressel
• Photometry Jason Klirai and Elena Sabbi (Tom
  Brown ? JWST)
• Detectors Peter McCullough
• Grisms ECF with Howard Bushouse as interface
• Other team members
• Tiffany Borders, Michael Dulude, George Hartig,
  Bryan Hilbert, Brian McLean, Vera Platias,
  Abhijith Rajan, Adam Riess, Michael Wong

97
Team Member Changes

• New team members (since TV3)
• Tiffany Borders, Michael Dulude, Abhi Rajan RIA
  new hires
• Jason Kalirai AURA astronomer
• Brian McLean loan from OED, astrometric support
• Adam Riess shared with JHU (works WFC3 2nd half
  of year)
• Elena Sabbi ESA astronomer
• Michael Wong visiting Scientist from UC
  Berkeley
• Departing team members
• Tom Brown (JWST MO, will analyze LOS SMOV
  proposal)
• Andre Martel (JWST/CSA, will analyze SMOV data)
• Jessica Kim Quijano

98
SM4 Support from STScI/WFC3

• UNCHANGED since Sept 2008
• Larry Petro (STScI WFC3 group) is responsible for
  organization of Sci IPT support and training, FT
  science contents, software tool development for
  FT analysis, and science performance assessment
• Orbit Shift _at_ GSFC
• Larry Petro on SI Console monitoring AT
• George Hartig in Science room
• Planning Shift _at_ GSFC
• Howard Bushouse on SI Console monitoring FT
• Conducts FT analysis in Science room
• John MacKenty in Science room to assess Science
  Pass/Fail
• Planning Shift _at_ STScI
• Sylvia Baggett and Bryan Hilbert in STRESS to
  provide independent analysis of FT data

99
SMOV Development Status

• Susana Deustua is responsible for WFC3 SMOV
  coordination
• Replaced Andre Martel who moved to JWST/CSA
• Proposal PIs mostly based on Thermal Vac
  activity leads
• Observing strategy combination of TV and
  ACS/NICMOS
• Analysis strategy follows TV (quicklook, ISR,
  products)
• Considerable synergy achieved between TV3
  analysis, SMOV, Cycle 17 calibration proposal
  planning, and CDBS produce generation well
  defined individuals or teams identified for each
  activity.
• Launch delay resulted in three target changes
• 11450 UVIS Photometric Zero Points and 11451 IR
  Photometric Zero points change to photometric
  standard star GD153
• 11426 UVIS SMOV Contamination Monitor uses star
  GRW70D5824
• 11441 IR Pointing Stability uses MESSIER-75
• We have also transitioned reponsibility for 11450
  and 11451 from Tom Brown to Jason Kalirai
• Current plan remains at 160 external orbits

100
WFC3 SMOV Strategy

• WFC3 schedule paced by 21 day detector venting
  and Bright Earth avoidance periods prior to
  cooling detectors.
• SMOV4 designed to avoid linkage between UVIS and
  IR channels
• Commissioning Sequence
• Provide operational integrity of instrument
  (mechs, memory, etc).
• Establish operating conditions (e.g. thermal
  setpoints for detectors)
• Optical Alignment
• ERO Science
• Initial SMOV calibrations
• Easy Science enabled
• Science Oversight Committee Early Release Science
  starts
• Remainder of SMOV calibrations
• Hard Science enabled

101
WFC3 SMOV Timeline (1)
Weeks Activities Milestones Comments
1-3 1,2,3 FT re-run, Memory and Databuffer Checks During 21 day BEA and Detector outgas periods
4 4,5,6,7 UVIS and IR Detector cooldown and functional tests PI approval
4 8,9,10 CSM, SOFA, FSM, W Cal lamp
45 16,17 UVIS and IR TEC performance Assess thermal state
5 14,15 UVIS Shutter, D2 lamp PI approval
56 11,12 UVIS and IR initial alignment Multiple uplinks
78 21,22 UVIS and IR fine alignment
5 13,44 UV contam and bowtie monitors
6 18 CCD Hot Pixel Anneal Start monthly cadence
7 29,30 UVIS and IR to FGS alignment Enables ERO EASY
10 29,30 SIAF update
12-13 SMOV complete Enables HARD
102
WFC3 SMOV Timeline (2)
Weeks Activities Milestones Comments
11,12 23,24 UVIS and IR Image Quality
11 43 UVIS PSF Core Modulation Shutter jitter test
12,13 25,26 UVIS and IR PSF Wings tests saturation residuals
5-11 19,33,35 UVIS Int Flats, Dark/RN/CTE, SAA
5-12 20,34,36 IR Int Flats, Dark/RN/Bckgnd, SAA
7 37,39,31 UVIS Photometry Zero Points, Flat Uniformity, Plate Scale EASY GO Science start
8-9 38,40,32 IR Photometry Zero Points, Flat Uniformity, Plate Scale EASY GO Science start
9 42 IR Grism Test
10 27,28 UVIS and IR Pointing Stability
103
CALWF3 Testing and Updates

• CALWF3 pipeline improved and received additional
  testing
• CALWF3 v1.0 delivered Sept 2008 (DMS/OPUS 2008.3)
• CALWF3 v1.1 delivered Dec 2008 (DMS/OPUS 2008.4)
• Stacking code (UVIS image combination) for
  reference file generation
• CALWF3 v1.2 delivered Feb 2009 (DMS/OPUS 2009.1)
• Bug fixed from testing campaign in Dec 2008
• CALWF3 v1.3 delivered Mar 2009 (DMS/OPUS 2009.2)
• IR up the ramp fitting improvements
• UVIS subarray bias subtraction bug fix
• Keyword modif
