Actuators for Robots
Actuators are used in order to produce mechanical
movement in robots.

• In this lecture we will present
• Actuators types
• Control method for
• DC motor
• AC motor
• Stepper motor
• Servos motor

3
Actuator Types
4
Electrical Actuator
5
DC Motor
6
AC Motor
7
AC Motor
8
Stepper Motor
9
Stepper Motor
10
Servos Motor
11
Hydraulic Actuators
12
Hydraulic Actuators
13
Pneumatic Actuators
14
Pneumatic Actuators
15
Other Actuators
16
DC motor control

• Controller H-bridge
• PWM control

17
DC motor control
18
H-Bridge

• DC motors only have two leads. The direction it
  spins is determined by which terminal has power
  applied and which is connected to ground.
• An H-bridge consists of four switches (in our
  case BJTs) and depending on which two are closed,
  allow the motor to operate in either direction
• We chose to use an L298 chip from
  STMicroelectronics because it has two H-bridges
  in one package.

19
DC motor control PWM control

• A pulse-width modulated signal is a rectangular
  waveform with a varying duty cycle.
• A longer duty cycle means the voltage is on for
  longer and the average voltage applied to the
  motor is higher and vice versa.
• Will be implemented using the PWM generator on
  our microcontroller.

20
Pulse-Width Modulation
21
Stepper Motor (uni-polar)
22
Stepper Motor
0001
0010
0100
1000
Stepping Sequences for Single Coil Excitation
Only one coil is active at a given instant of time
23
Stepper Motor
Single Coil Excitation
24
Stepper Motor (Single Coil Excitation)
25
Stepper Motor (Double Coil Excitation)
1001
0011
0110
1100
Stepping Sequences for Double Coil Excitation
Two coils active at any given instant of time
26
Stepper Motor (Double Coil Excitation)
27
Stepper Motor (Driver circuit)
28
Stepper Motor (Driver circuit)
29
Stepper Motor (sequence)
30
Stepper Motor (sequence)
31
Servos motor
32
Servos motor

• Do not confuse servos with servo motors

33
Servos Motor
34
Motors and Encoders
35
Feedback measurement optical encoder
- direction
- resolution

• Relative position

light sensor
decode circuitry
light emitter
grating
36
Optical Encoders
mask/diffuser
light sensor
decode circuitry
light emitter
grating
A diffuser tends to smooth these signals
Ideal
Real
37
Optical Encoders

• Relative position

- direction
light sensor
- resolution
decode circuitry
light emitter
grating
38
Optical Encoders

• Relative position

- direction
light sensor
- resolution
decode circuitry
light emitter
grating
A
A
A lags B
B
B
39
Optical Encoders

• Relative position

- direction
light sensor
- resolution
decode circuitry
light emitter
grating
Phase lag between A and B is 90 degree
A
B
A leads B
40
Design problems
Design 1 ( Stepper motor)

• Design controller for stepper motor
• Switch for on/off
• Switch for right/left rotation with single coil
  excitation method.
• Switch for right/left rotation with double coil
  excitation method.
• Switch for speed (1,2) selection.
