Parallel

1
High-Performance Grid Computing and Research
Networking
Concurrent Computers
Instructor S. Masoud Sadjadi http//www.cs.fiu.ed
u/sadjadi/Teaching/ sadjadi At cs Dot fiu Dot
edu
2
Acknowledgements

• The content of many of the slides in this lecture
  notes have been adopted from the online resources
  prepared previously by the people listed below.
  Many thanks!
• Henri Casanova
• Principles of High Performance Computing
• http//navet.ics.hawaii.edu/casanova
• henric_at_hawaii.edu
• Kai Wang
• Department of Computer Science
• University of South Dakota
• http//www.usd.edu/Kai.Wang
• Andrew Tanenbaum

3
Concurrency and Computers

• We will see computer systems designed to allow
  concurrency (for performance benefits)
• Concurrency occurs at many levels in computer
  systems
• Within a CPU
• For example, On-Chip Parallelism
• Within a Box
• For example, Coprocessor and Multiprocessor
• Across Boxes
• For example, Multicomputers, Clusters, and Grids

4
Parallel Computer Architectures

• (a) On-chip parallelism. (b) A coprocessor. (c) A
  multiprocessor.
• (d) A multicomputer. (e) A grid.

5
Concurrency and Computers

• We will see computer systems designed to allow
  concurrency (for performance benefits)
• Concurrency occurs at many levels in computer
  systems
• Within a CPU
• Within a Box
• Across Boxes

6
Concurrency within a CPU
Registers ALUs Hardware to
decode instructions and do all types of useful
things
CPU
Caches
Busses
RAM
adapters
Controllers
Controllers
I/O devices Displays Keyboards
Networks
7
Concurrency within a CPU

• Several techniques to allow concurrency within a
  single CPU
• Pipelining
• RISC architectures
• Pipelined functional units
• ILP
• Vector units
• On-Chip Multithreading
• Lets look at them briefly

8
Concurrency within a CPU

• Several techniques to allow concurrency within a
  single CPU
• Pipelining
• RISC architectures
• Pipelined functional units
• ILP
• Vector units
• On-Chip Multithreading
• Lets look at them briefly

9
Pipelining

• If one has a sequence of tasks to do
• If each task consists of the same n steps or
  stages
• If different steps can be done simultaneously
• Then one can have a pipelined execution of the
  tasks
• e.g., for assembly line
• Goal higher throughput (i.e., number of tasks
  per time unit)

Time to do 1 task 9 Time to do 2 tasks
13 Time to do 3 tasks 17 Time to do 4 tasks
21 Time to do 10 tasks 45 Time to do 100
tasks 409 Pays off if many tasks
10
Pipelining

• Each step goes as fast as the slowest stage
• Therefore, the asymptotic throughput (i.e., the
  throughput when the number of tasks tends to
  infinity) is equal to
• 1 / (duration of the slowest stage)
• Therefore, in an ideal pipeline, all stages would
  be identical (balanced pipeline)
• Question Can we make computer instructions all
  consist of the same number of stage, where all
  stages take the same number of clock cycles?

duration of the slowest stage
11
RISC

• Having all instructions doable in the same number
  of stages of the same durations is the RISC idea
• Example
• MIPS architecture (See THE architecture book by
  Patterson and Hennessy)
• 5 stages
• Instruction Fetch (IF)
• Instruction Decode (ID)
• Instruction Execute (EX)
• Memory accesses (MEM)
• Register Write Back (WB)
• Each stage takes one clock cycle

12
Pipelined Functional Units

• Although the RISC idea is attractive, some
  operations are just too expensive to be done in
  one clock cycle (during the EX stage)
• Common example floating point operations
• Solution implement them as a sequence of stages,
  so that they can be pipelined

EX Integer unit
FP/integer multiply
IF
ID
MEM
WB
M1
M2
M3
M4
M5
M6
M7
FP/integer add
A1
A2
A3
A4
13
Pipelining Today

• Pipelined functional units are common
• Fallacy All computers today are RISC
• RISC was of course one of the most fundamental
  new ideas in computer architectures
• x86 Most commonly used Instruction Set
  Architecture today
• Kept around for backwards compatibility reasons,
  because its easy to implement (not to program
  for)
• BUT modern x86 processors decode instructions
  into micro-ops, which are then executed in a
  RISC manner
• Bottom line pipelining is a pervasive (and
  conveniently hidden) form of concurrency in
  computers today
• Take a computer architecture course to know all
  about it

14
Concurrency within a CPU

• Several techniques to allow concurrency within a
  single CPU
• Pipelining
• ILP
• Vector units
• On-Chip Multithreading

15
Instruction Level Parallelism

• Instruction Level Parallelism is the set of
  techniques by which performance of a pipelined
  processor can be pushed even further
• ILP can be done by the hardware
• Dynamic instruction scheduling
• Dynamic branch predictions
• Multi-issue superscalar processors
• ILP can be done by the compiler
• Static instruction scheduling
• Multi-issue VLIW (Very Long Instruction Word)
  processors
• with multiple functional units
• Broad concept More than one instruction is
  issued per clock cycle
• e.g., 8-way multi-issue processor

16
Concurrency within a CPU

• Several techniques to allow concurrency within a
  single CPU
• Pipelining
• ILP
• Vector units
• On-Chip Multithreading

17
Vector Units

• A functional unit that can do elt-wise operations
  on entire vectors with a single instruction,
  called a vector instruction
• These are specified as operations on vector
  registers
• A vector processor comes with some number of
  such registers
• MMX extension on x86 architectures

elts
elts

elts adds in parallel
elts
18
Vector Units

• Typically, a vector register holds 32-64
  elements
• But the number of elements is always larger than
  the amount of parallel hardware, called vector
  pipes or lanes, say 2-4

elts
elts
elts / pipes adds in parallel
elts
19
MMX Extension

• Many techniques that are initially implemented in
  the supercomputer market, find their way to the
  mainstream
• Vector units were pioneered in supercomputers
• Supercomputers are mostly used for scientific
  computing
• Scientific computing uses tons of arrays (to
  represent mathematical vectors and often does
  regular computation with these arrays
• Therefore, scientific code is easy to
  vectorize, i.e., to generate assembly that uses
  the vector registers and the vector instructions
• Intels MMX or PowerPCs AltiVec
• MMX vector registers
• eight 8-bit elements
• four 16-bit elements
• two 32-bit elements
• AltiVec twice the lengths
• Used for multi-media applications
• image processing
• rendering
• ...

20
Vectorization Example

• Conversion from RGB to YUV
• Y (9798R 19235G 3736B) / 32768
• U (-4784R - 9437G 4221B) / 32768 128
• V (20218R - 16941G - 3277B) / 32768 128
• This kind of code is perfectly parallel as all
  pixels can be computed independently
• Can be done easily with MMX vector capabilities
• Load 8 R values into an MMX vector register
• Load 8 G values into an MMX vector register
• Load 8 B values into an MMX vector register
• Do the , , and / in parallel
• Repeat

21
Concurrency within a CPU

• Several techniques to allow concurrency within a
  single CPU
• Pipelining
• ILP
• Vector units
• On-Chip Multithreading

22
Multi-threaded Architectures

• Computer architecture is a difficult field to
  make innovations in
• Whos going to spend money to manufacture your
  new idea?
• Whos going to be convinced that a new compiler
  can/should be written
• Whos going to be convinced of a new approach to
  computing?
• One of the cool innovations in the last decade
  has been the concept of a Multi-threaded
  Architecture

23
On-Chip Multithreading

• Multithreading has been arounds for years, so
  whats new about this???
• Here were talking about Hardware Support for
  threads
• Simultaneous Multi Threading (SMT)
• SuperThreading
• HyperThreading
• Lets try to understand what all of these mean
  before looking at multi-threaded Supercomputers

24
Single-treaded Processor

• The processor provides the illusion of concurrent
  execution
• Front-end fetching/decoding/reordering
• Execution core
• actual execution
• Multiple programs in memory
• Only one executes at a time
• 4-issue CPU with bubbles
• 7-unit CPU with pipeline bubbles
• Time-slicing via context switching

25
Single-threaded SMP?

• Two threads execute at once, so threads spend
  less time waiting
• The number of bubbles is also doubled
• Twice as much speed and twice as much waste

26
Super-threading

• Principle the processor can execute more than
  one thread at a time
• Also called time-slice multithreading
• The processor is then called a multithreaded
  processor
• Requires more hardware cleverness
• logic switches at each cycle
• Leads to less Waste
• A thread can run during a cycle while another
  thread is waiting for the memory
• Just a finer grain of interleaving
• But there is a restriction
• Each stage of the front end or the execution core
  only runs instructions from ONE thread!
• Does not help with poor instruction parallelism
  within one thread
• Does not reduce bubbles within a row

27
Hyper-threading

• Principle the processor can execute more than
  one thread at a time, even within a single clock
  cycle!!
• Requires even more hardware cleverness
• logic switches within each cycle
• On the diagram Only two threads execute
  simultaneously.
• Intels hyper-threading only adds 5 to the die
  area
• Some people argue that two is not hyper ?
• Finest level of interleaving
• From the OS perspective, there are two logical
  processors

28
Concurrency and Computers

• We will see computer systems designed to allow
  concurrency (for performance benefits)
• Concurrency occurs at many levels in computer
  systems
• Within a CPU
• Within a Box
• Across Boxes

29
Concurrency within a Box

• Two main techniques
• SMP
• Multi-core
• Lets look at both of them

30
SMPs

• Symmetric Multi-Processors
• often mislabeled as Shared-Memory Processors,
  which has now become tolerated
• Processors are all connected to a single memory
• Symmetric each memory cell is equally close to
  all processors
• Many dual-proc and quad-proc systems
• e.g., for servers

31
Distributed caches

• The problem with distributed caches is that of
  memory consistency
• Intuitive memory model
• Reading an address should return the last value
  written to that address
• Easy to do in uniprocessors
• although there may be some I/O issues
• But difficult in multi-processor / multi-core
• Memory consistency A multiprocessor is
  sequentially consistent if the result of any
  execution is the same as if the operations of all
  the processors were executed in some sequential
  order, and the operations of each individual
  processor appear in this sequence in the order
  specified by its program. Lamport, 1979

32
Cache Coherency

• Memory consistency is jeopardized by having
  multiple caches
• P1 and P2 both have a cached copy of a data item
• P1 write to it, possibly write-through to memory
• At this point P2 owns a stale copy
• When designing a multi-processor system, one must
  ensure that this cannot happen
• By defining protocols for cache coherence

33
Snoopy Cache-Coherence
Pn
P0
bus snoop


memory bus
memory op from Pn
Mem
Mem

• Memory bus is a broadcast medium
• Caches contain information on which addresses
  they store
• Cache Controller snoops all transactions on the
  bus
• A transaction is a relevant transaction if it
  involves a cache block currently contained in
  this cache
• Take action to ensure coherence
• invalidate, update, or supply value

34
Limits of Snoopy Coherence

• Assume
• 4 GHz processor
• gt 16 GB/s inst BW per processor (32-bit)
• gt 9.6 GB/s data BW at 30 load-store of 8-byte
  elements
• Suppose 98 inst hit rate and 90 data hit rate
• gt 320 MB/s inst BW per processor
• gt 960 MB/s data BW per processor
• gt 1.28 GB/s combined BW
• Assuming 10 GB/s bus bandwidth
• 8 processors will saturate the bus

MEM
MEM

1.28 GB/s

cache
cache
25.6 GB/s
PROC
PROC
35
Sample Machines

• Intel Pentium Pro Quad
• Coherent
• 4 processors
• Sun Enterprise server
• Coherent
• Up to 16 processor and/or memory-I/O cards

36
Directory-based Coherence

• Idea Implement a directory that keeps track of
  where each copy of a data item is stored
• The directory acts as a filter
• processors must ask permission for loading data
  from memory to cache
• when an entry is changed the directory either
  update or invalidate cached copies
• Eliminate the overhead of broadcasting/snooping,
  a thus bandwidth consumption
• But is slower in terms of latency
• Used to scale up to numbers of processors that
  would saturate the memory bus

37
Example machine

• SGI Altix 3000
• A node contains up to 4 Itanium 2 processors and
  32GB of memory
• Uses a mixture of snoopy and directory-based
  coherence
• Up to 512 processors that are cache coherent
  (global address space is possible for larger
  machines)

38
Sequential Consistency?

• A lot of hardware and technology to ensure cache
  coherence
• But the sequential consistency model may be
  broken anyway
• The compiler reorders/removes code
• Prefetch instructions cause reordering
• The network may reorder two write messages
• Basically, a bunch of things can happen
• Virtually all commercial systems give up on the
  idea of maintaining strong sequential consistency
• The programmer must program with weaker memory
  models than Sequential Consistency
• Done with some rules
• Avoid race conditions
• Use system-provided synchronization primitives

39
Weaker models

• The programmer must program with weaker memory
  models than Sequential Consistency
• Done with some rules
• Avoid race conditions
• Use system-provided synchronization primitives
• We will see how to program shared-memory machines

40
Concurrency within a Box

• Two main techniques
• SMP
• Multi-core

41
Moores Law!

• Many people interpret Moores law as computer
  gets twice as fast every 18 months
• which is not technically true
• its all about microprocessor density
• But this is no longer true
• We should have 10GHz processors right now
• And we dont!

42
No more Moore?

• We are used to getting faster CPUs all the time
• We are used for them to keep up with more
  demanding software
• Known as Andy giveth, and Bill taketh away
• Andy Grove
• Bill Gates
• Its a nice way to force people to buy computers
  often
• But basically, our computers get better, do more
  things, and it just happens automatically
• Some people call this the performance free
  lunch
• Conventional wisdom Not to worry, tomorrows
  processors will have even more throughput, and
  anyway todays applications are increasingly
  throttled by factors other than CPU throughput
  and memory speed (e.g., theyre often I/O-bound,
  network-bound, database-bound).

43
Commodity improvements

• There are three main ways in which commodity
  processors keep improving
• Higher clock rate
• More aggressive instruction reordering and
  concurrent units
• Bigger/faster caches
• All applications can easily benefit from these
  improvements
• at the cost of perhaps a recompilation
• Unfortunately, the first two are hitting their
  limit
• Higher clock rate lead to high heat, power
  consumption
• No more instruction reordering without
  compromising correctness

44
Is Moores laws not true?

• Ironically, Moores law is still true
• The density indeed still doubles
• But its wrong interpretation is not
• Clock rates do not doubled any more
• But we cant let this happen computers have to
  get more powerful
• Therefore, the industry has thought of new ways
  to improve them multi-core
• Multiple CPUs on a single chip
• Multi-core adds another level of concurrency
• But unlike, say multiple functional units, hard
  to compile for them
• Therefore, applications must be rewritten to
  benefit from the (nowadays expected) performance
  increase
• Concurrency is the next major revolution in how
  we write software (Dr. Dobbs Journal, 30(3),
  March 2005)

45
Multi-core processors

• In addition to putting concurrency in the
  publics eye, multi-core architectures will have
  deep impact
• Languages will be forced to deal well with
  concurrency
• New language designs?
• New language extensions?
• New compilers?
• Efficiency and Performance optimization will
  become more important write code that is fast on
  one core with limited clock rate
• The CPU may very well become a bottleneck (again)
  for single-core programs
• Other factors will improve, but not the clock
  rate
• Prediction many companies will be hiring people
  to (re)write concurrent applications

46
Multi-Core

• Quote from PC World Magazine Summer 2005
• Don't expect dual-core to be the top performer
  today for games and other demanding
  single-threaded applications. But that will
  change as applications are rewritten. For
  example, by year's end, Unreal Tournament should
  have released a new game engine that takes
  advantage of dual-core processing.

47
Concurrency and Computers

• We will see computer systems designed to allow
  concurrency (for performance benefits)
• Concurrency occurs at many levels in computer
  systems
• Within a CPU
• Within a Box
• Across Boxes

48
Multiple boxes together

• Example
• Take four boxes
• e.g., four Intel Itaniums bought at Dell
• Hook them up to a network
• e.g., a switch bought at CISCO, Myricom, etc.
• Install software that allows you to write/run
  applications that can utilize these four boxes
  concurrently
• This is a simple way to achieve concurrency
  across computer systems
• Everybody has heard of clusters by now
• They are basically like the above example and can
  be purchased already built from vendors
• We will talk about this kind of concurrent
  platform at length during this class

49
Multiple Boxes Together

• Why do we use multiple boxes?
• Every programmer would rather have an
  SMP/multi-core architecture that provides all the
  power/memory she/he needs
• The problem is that single boxes do not scale to
  meet the needs of many scientific applications
• Cant have enough processors or powerful enough
  cores
• Cant have enough memory
• But if you can live with a single box, do it!
• We will see that single-box programming is much
  easier than multi-box programming

50
Where does this leave us?

• So far we have seen many ways in which
  concurrency can be achieved/implemented in
  computer systems
• Within a box
• Across boxes
• So we could look at a system and just list all
  the ways in which it does concurrency
• It would be nice to have a great taxonomy of
  parallel platforms in which we can pigeon-hole
  all (past and present) systems
• Provides simple names that everybody can use and
  understand quickly

51
Taxonomy of parallel machines?

• Its not going to happen
• Up until last year Gordon Bell and Jim Gray
  published an article in Comm. of the ACM,
  discussing what the taxonomy should be
• Dongarra, Sterling, etc. answered telling them
  they were wrong and saying what the taxonomy
  should be, and proposing a new multi-dimensional
  scheme!
• Both papers agree that most terms are conflated,
  misused, etc. (MPP)
• Complicated by the fact that concurrency appears
  at so many levels
• Example A 16-node cluster, where each node is a
  4-way multi-processor, where each processor is
  hyperthreaded, has vector units, and is fully
  pipelined with multiple, pipelined functional
  units

52
Taxonomy of platforms?

• Well look at one traditional taxonomy
• Well look at current categorizations from Top500
• Well look at examples of platforms
• Well look at interesting/noteworthy
  architectural features that one should know as
  part of ones parallel computing culture

53
The Flynn taxonomy

• Proposed in 1966!!!
• Functional taxonomy based on the notion of
  streams of information data and instructions
• Platforms are classified according to whether
  they have a single (S) or multiple (M) stream of
  each of the above
• Four possibilities
• SISD (sequential machine)
• SIMD
• MIMD
• MISD (rare, no commercial system... systolic
  arrays)

54
Taxonomy of Parallel Computers

• Flynns taxonomy of parallel computers.

55
SIMD

• PEs can be deactivated and activated on-the-fly
• Vector processing (e.g., vector add) is easy to
  implement on SIMD
• Debate is a vector processor an SIMD machine?
• often confused
• strictly not true according to the taxonomy (its
  really SISD with pipelined operations)
• but its convenient to think of the two as
  equivalent

56
MIMD

• Most general category
• Pretty much every supercomputer in existence
  today is a MIMD machine at some level
• This limits the usefulness of the taxonomy
• But you had to have heard of it at least once
  because people keep referring to it, somehow...
• Other taxonomies have been proposed, none very
  satisfying
• Shared- vs. Distributed- memory is a common
  distinction among machines, but these days many
  are hybrid anyway

57
Taxonomy of Parallel Computers

• A taxonomy of parallel computers.

58
A host of parallel machines

• There are (have been) many kinds of parallel
  machines
• For the last 12 years their performance has been
  measured and recorded with the LINPACK benchmark,
  as part of Top500
• It is a good source of information about what
  machines are (were) and
  how they have evolved
• Note that its really about supercomputers
• http//www.top500.org

59
LINPACK Benchmark?

• LINPACK LINear algebra PACKage
• A FORTRAN
• Matrix multiply, LU/QR/Choleski factorizations,
  eigensolvers, SVD, etc.
• LINPACK Benchmark
• Dense linear system solve with LU factorization
• 2/3 n3 O(n2)
• Measure MFlops
• The problem size can be chosen
• You have to report the best performance for the
  best n, and the n that achieves half of the best
  performance.

60
What can we find on the Top500?
61
Pies
62
Top Ten Computers (http//www.top500.org)
63
Top 500 Computers--Countries (http//www.top500.or
g)
64
Top 500 Computers--Manufacturers
(http//www.top500.org)
65
Top 500 ComputersManufacturers Trend
(http//www.top500.org)
66
Top 500 Computers--Operating Systems
(http//www.top500.org)
67
Top 500 ComputersOperating Systems Trend
(http//www.top500.org)
68
Top 500 Computers--Processors (http//www.top500.o
rg)
69
Top 500 ComputersProcessors Trend
(http//www.top500.org)
70
Top 500 Computers--Customers (http//www.top500.or
g)
71
Top 500 ComputersCustomers Trend
(http//www.top500.org)
72
Top 500 Computers--Applications
(http//www.top500.org)
73
Top 500 Computers--Applications Trend
(http//www.top500.org)
74
Top 500 ComputersArchitecture (http//www.top500.
org)
75
Top 500 ComputersArchitecture Trend
(http//www.top500.org)
76
SIMD

• ILLIAC-IV, TMC CM-1, MasPar MP-1
• Expensive logic for CU, but there is only one
• Cheap logic for PEs and there can be a lot of
  them
• 32 procs on 1 chip of the MasPar, 1024-proc
  system with 32 chips that fit on a single board!
• 65,536 processors for the CM-1
• Thinking Machines gimmick was
• that the human brain consists of
  many simple neurons that are
  turned
• on and off, and so was their machine
• CM-5
• hybrid SIMD and MIMD
• Death
• Machines not popular, but the programming
  model is.
• Vector processors often labeled SIMD
  because thats in effect what they do,
  but they are not SIMD machines
• Led to the MPP terminology (Massively Parallel
  Processor)
• Ironic because none of todays MPPs are SIMD

77
SMPs

• Symmetric MultiProcessors (often mislabeled as
  Shared-Memory Processors, which has now become
  tolerated)
• Processors all connected to a (large) memory
• UMA Uniform Memory Access, makes is easy to
  program
• Symmetric all memory is equally close to all
  processors
• Difficult to scale to many processors (lt32
  typically)
• Cache Coherence via snoopy caches or
  directories

78
Distributed Shared Memory

• Memory is logically shared, but physically
  distributed in banks
• Any processor can access any address in memory
• Cache lines (or pages) are passed around the
  machine
• Cache coherence Distributed Directories
• NUMA Non-Uniform Memory Access (some processors
  may be closer to some banks)
• SGI Origin2000 is a canonical example
• Scales to 100s of processors
• Hypercube topology for the memory (later)

P1
P2
Pn



memory
memory
network
memory
memory
79
Clusters, Constellations, MPPs

• These are the only 3 categories today in the
  Top500
• They all belong to the Distributed Memory model
  (MIMD) (with many twists)
• Each processor/node has its own memory and cache
  but cannot directly access another processors
  memory.
• nodes may be SMPs
• Each node has a network interface (NI) for all
  communication and synchronization.
• So what are these 3 categories?

80
Clusters

• 58.2 of the Top500 machines are labeled as
  clusters
• Definition Parallel computer system comprising
  an integrated collection of independent nodes,
  each of which is a system in its own right
  capable on independent operation and derived from
  products developed and marketed for other
  standalone purposes
• A commodity cluster is one in which both the
  network and the compute nodes are available in
  the market
• In the Top500, cluster means commodity
  cluster
• A well-known type of commodity clusters are
  Beowulf-class PC clusters, or Beowulfs

81
What is Beowulf?

• An experiment in parallel computing systems
• Established vision of low cost, high end
  computing, with public domain software (and led
  to software development)
• Tutorials and book for best practice on how to
  build such platforms
• Today by Beowulf cluster one means a
  commodity cluster that runs Linux and
  GNU-type software
• Project initiated by T. Sterling and D.
  Becker at NASA in 1994

82
Constellations???

• Commodity clusters that differ from the previous
  ones by the dominant level of parallelism
• Clusters consist of nodes, and nodes are
  typically SMPs
• If there are more procs in a node than nodes in
  the cluster, then we have a constellation
• Typically, constellations are space-shared among
  users, with each user running openMP on a node,
  although an app could run on the whole machine
  using MPI/openMP
• To be honest, this term is not very useful and
  not very used.

83
MPP????????

• Probably the most imprecise term for describing a
  machine (isnt a 256-node cluster of 4-way SMPs
  massively parallel?)
• May use proprietary networks, vector processors,
  as opposed to commodity component
• Cray T3E, Cray X1, and Earth Simulator are
  distributed memory machines, but the nodes are
  SMPs.
• Basicallly, everything thats fast and not
  commodity is an MPP, in terms of todays Top500.
• Lets look at these non-commodity things
• Peoples definition of commodity varies

84
Vector Processors

• Vector architectures were based on a single
  processor
• Multiple functional units
• All performing the same operation
• Instructions may specify large amounts of
  parallelism (e.g., 64-way) but hardware executes
  only a subset in parallel
• Historically important
• Overtaken by MPPs in the 90s as seen in Top500
• Re-emerging in recent years
• At a large scale in the Earth Simulator (NEC SX6)
  and Cray X1
• At a small scale in SIMD media extensions to
  microprocessors
• SSE, SSE2 (Intel Pentium/IA64)
• Altivec (IBM/Motorola/Apple PowerPC)
• VIS (Sun Sparc)
• Key idea Compiler does some of the difficult
  work of finding parallelism, so the hardware
  doesnt have to

85
Vector Processors

• Advantages
• quick fetch and decode of a single instruction
  for multiple operations
• the instruction provides the processor with a
  regular source of data, which can arrive at each
  cycle, and processed in a pipelined fashion
• The compiler does the work for you of course
• Memory-to-memory
• no registers
• can process very long vectors, but startup time
  is large
• appeared in the 70s and died in the 80s
• Cray, Fujitsu, Hitachi, NEC

86
Global Address Space

• Cray T3D, T3E, X1, and HP Alphaserver cluster
• Network interface supports Remote Direct Memory
  Access
• NI can directly access memory without
  interrupting the CPU
• One processor can read/write memory with
  one-sided operations (put/get)
• Not just a load/store as on a shared memory
  machine
• Remote data is typically not cached locally

87
Cray X1 Parallel Vector Architecture

• Cray combines several technologies in the X1
• 12.8 Gflop/s Vector processors (MSP)
• Shared caches (unusual on earlier vector
  machines)
• 4 processor nodes sharing up to 64 GB of memory
• Single System Image to 4096 Processors
• Remote put/get between nodes (faster than
  explicit messaging)

88
Cray X1 the MSP

• Cray X1 building block is the MSP
• Multi-Streaming vector Processor
• 4 SSPs (each a 2-pipe vector processor)
• Compiler will (try to) vectorize/parallelize
  across the MSP, achieving streaming

custom blocks
12.8 Gflops (64 bit)
S
S
S
S
25.6 Gflops (32 bit)
V
V
V
V
V
V
V
V
25-41 GB/s
0.5 MB
0.5 MB
0.5 MB
0.5 MB
shared caches
2 MB Ecache
At frequency of 400/800 MHz
To local memory and network
25.6 GB/s
12.8 - 20.5 GB/s
Figure source J. Levesque, Cray
89
Cray X1 A node

• Shared memory
• 32 network links and four I/O links per node

90
Cray X1 32 nodes
Fast Switch
91
Cray X1 128 nodes
92
Cray X1 Parallelism

• Many levels of parallelism
• Within a processor vectorization
• Within an MSP streaming
• Within a node shared memory
• Across nodes message passing
• Some are automated by the compiler, some require
  work by the programmer
• This is a common theme
• The more complex the architecture, the more
  difficult it is for the programmer to exploit it
• Hard to fit this machine into a simple taxonomy
• Similar story for the Earth Simulator

93
The Earth Simulator (NEC)

• Each node
• Shared memory (16GB)
• 8 vector processors I/O processor
• 640 nodes fully-connected by a 640x640 crossbar
  switch
• Total 5120 8GFlop processors -gt 40GFlop peak

94
Blue Gene/L

• 65,536 processors
• Relatively modest clock rates, so that power
  consumption is low, cooling is easy, and space is
  small (1024 nodes in the same rack)
• Besides, processor speed is on par with the
  memory speed so faster clock rate does not help
• 2-way SMP nodes (really different from the X1)
• several networks
• 64x32x32 3-D torus for point-to-point
• tree for collective operations and for I/O
• plus other Ethernet, etc.

95
BlueGene

• The BlueGene/L custom processor chip.

96
BlueGene

• The BlueGene/L. (a) Chip. (b) Card. (c) Board.
• (d) Cabinet. (e) System.

97
Red Storm

• Packaging of the Red Storm components.

98
Red Storm

• The Red Storm system as viewed from above.

99
If you like dead Supercomputers

• Lots of old supercomputers w/ pictures
• http//www.geocities.com/Athens/6270/superp.html
• Dead Supercomputers
• http//www.paralogos.com/DeadSuper/Projects.html
• e-Bay
• Cray Y-MP/C90, 1993
• 45,100.70
• From the Pittsburgh Supercomputer Center who
  wanted to get rid of it to make space in their
  machine room
• Original cost 35,000,000
• Weight 30 tons
• Cost 400,000 to make it work at the buyers
  ranch in Northern California

100
Network Topologies

• People have experimented with different
  topologies for distributed memory machines, or to
  arrange memory banks in NUMA shared-memory
  machines
• Examples include
• Ring KSR (1991)
• 2-D grid Intel Paragon (1992)
• Torus
• Hypercube nCube, Intel iPSC/860, used in the
  SGI Origin 2000 for memory
• Fat-tree IBM Colony and Federation Interconnects
  (SP-x)
• Arrangement of switches
• pioneered with Butterfly networks like in the
  BBN TC2000 in the early 1990
• 200 MHz processors in a multi-stage network of
  switches
• Virtually Shared Distributed memory (NUMA)
• I actually worked with that one!

101
Hypercube

• Defined by its dimension, d

1D
2D
3D
4D
102
Hypercube

• Properties
• Has 2d nodes
• The number of hops between two nodes is at most d
• The diameter of the network grows logarithmically
  with the number of nodes, which was the key for
  interest in hypercubes
• But each node needs d neighbors, which is a
  problem
• Routing and Addressing

1111
1110
0110
0111

• d-bit address
• routing from xxxx to yyyy just keep going to a
  neighbor that has a smaller Hamming distance
• reminiscent of some p2p things
• TONS of Hypercube research (even today!!)

1010
0011
0010
1011
1101
0101
1100
0100
1001
1000
0001
0000
103
Conclusion

• Concurrency appears at all levels
• Both in commodity systems and in
  supercomputers
• The distinction is rather annoying
• When needing performance, one has to exploit
  concurrency to the best of its capabilities
• e.g., as a developer of a geophysics application
  to run on a 10,000 heavy-iron supercomputers at
  the SANDIA national lab
• e.g., as a game developer on a 8-way multi-core
  hyper-threaded desktop system sold by Dell
• In this course well gain hands-on understanding
  of how to write concurrent/parallel software
• Using GCB cluster
