Volume Viz Problem

• Data points fill a 3D volume
• You can only display one 2D image at a time
• Naïve rendering of a volume will just let you see
  the surface
• How can you visualize the volume data in a way
  that lets you understand the internal structure
  of the data?

3
Structured vs. Scattered Data

• The best approach will depend on the
  characteristics of the data
• Data points arranged in rows, columns, and layers
  (3D image) can be referred to as voxels
  (volumetric-pixels)
• Data points that follow a non-gridded pattern are
  called scattered

Wikipedia image
4
Volume Viz Data Dimensionality

• Each data point has
• 3D coordinates (x,y,z), specifying a position in
  the volume
• and one of the following
• Scalar a single number, 0D data
• Vector a list of numbers, 1D data
• Tensor a matrix or ND array of numbers, for Ngt1

5
Data examples

• Scalar Data
• CT Scan ? x-ray opacity for each voxel
• PET Scan ? positron radiation for each voxel
• Atmospheric simulation (or measurement) ?
  pollutant concentration
• Ocean temperature distribution
• Vector Data
• Velocity vectors at each voxel
• Fluid flow (river water, arterial blood, etc.)
• Displacement vectors at each voxel
• Provides mapping between different deformed
  configurations of the same object
• Tensor data
• Higher dimensional data is more complicated
• Stress and strain matrices
• Gradients of 3D functions

6
Simplest Case

• Lets consider continuous, scalar, voxel data
• Geometrically regular arrangement (3D grid)
• Just 1 data value per voxel
• Think of CT data (3D x-ray)
• What would you be interested in seeing?
• How would you construct a visualization?

7

Scalar Voxel Viz.

• Simplest possible visualization is to just look
  at the slices
• Use color mapping (or grayscale mapping) to see
  slice values
• Slices can be useful
• We can do more interesting things

8
Scalar Voxel Viz.

• Bone voxels will be bright (have large values),
  other voxels will be dark
• How could you visualize the surface of the bones?
• Several alternatives exist, including
• 1. Render an isosurface Use Marching Cubes
  Algorithm
• 2. Ray Casting Integrate scalar variable along
  the view direction
• 3. Splatting

9
(No Transcript)
10
Isosurfaces from 3D

• How to construct a polygonal surface from a 3D
  dataset?
• Find points on the isosurface of a scalar
  variable
• 3D analog of 2D contour maps
• You pick a meaningful threshold value
• Voxels with data values below the threshold sit
  on one side of the isosurface, voxel with data
  values above the threshold sit on the other
• Simplifying assumption is that threshold value
  0
• To force this, just subtract the desired
  threshold value from all data points
• Tessellate points on the isosurface to create a
  polygonal representation of the surface
• The Marching Cubes algorithm does this
• This is one of the famous, older (gt20 yrs) viz.
  algorithms
• Render the tessellated isosurface using normal 3D
  graphics methods

11
(No Transcript)
12
(No Transcript)
13
(No Transcript)
14
Isosurfaces Opacity
15
The Visible Man Image Data
16
Visible Man Isosurfaces
17
(No Transcript)
18
Marching Cubes Considered

• How effective is the visualization perceptually?
• What can you see?
• What cant you see?
• How is this in terms of efficiency?
• Phase I
• Phase II
• Rendering
• Compare other approaches

19
Ray Casting Volume Data
20
Review Ordinary Ray Casting

• How does it work?

21
(No Transcript)
22
Ray Casting with a Voxel
23
(No Transcript)
24
Ray Casting for Approximation of Light Integral
25
(No Transcript)
26
Examples
27
Ray Casting Considered

• How effective?
• How are the images different from those produced
  by Marching Cubes?
• How efficient?
• Another alternative

28
Volume Splatting

• Ray casting is an image space method
• Ray are generated per pixel, and travel out into
  the volume
• Volume splatting is an object space method
• Data points in the volume are mapped (splatted)
  onto the image plane

29
Splatting A Feed Forward Process
Feed forward Splatting
Splat!
30
Splatting (feed-forward)
?
31
Fill the holes
We need to fill the pixel values between the
volume projection samples
?
32
3D Kernel for Splatting
Need to know the 3D extent of each voxel, and
Then project the extent to the image plane
This is called footprint
33
(No Transcript)
34
Visibility

• How does occlusion work?
• Splatting uses back to front compositing
• Samples in front are added on top of and
  partially obscure previously splatted (further
  back) samples

35
Gaussian kernel

• A popular kernel is the Gaussian function (think
  bell curve)
• Sigma controls the width
• Gaussians have circular splat footprints

36
Ray Casting vs. Splatting

• What are the differences in the images produced?
• Think about aliasing
• Efficiency considerations?
• In what order are the voxel data points accessed?
• For ray casting?
• For splatting?

37
Summary of Techniques

• Marching cubes
• Construct polygonal isosurfaces
• Render with regular graphics pipeline
• Ray casting
• Image space algorithm
• Shoot rays from image into volume, integrate
  color opacity along each ray
• Volume splatting
• Object space algorithm
• Project each voxel onto the image plane
• These are good ways of looking directly at the
  recorded data. What could you do to focus
  attention on significant features in the data?

38
Feature Extraction

• What is a significant feature?
• Answer is application dependent
• Often, regions with a high gradient are
  significant
• What is the gradient of a voxel volume?
• Look at the gradient of a 2D image

39
10 50 250 100 10
10 50 250 100 10
250 250 250 250 250
100 100 250 100 100
10 10 250 10 10
25 120 25 -120 -50
25 120 25 -120 -50
125 0 0 0 -125
50 75 0 -75 -50
5 120 0 -120 -5
-.5 0 .5
-.5 0 .5
-.5 0 .5
Derivative in X direction
40
10 50 250 100 10
10 50 250 100 10
250 250 250 250 250
100 100 250 100 100
10 10 250 10 10
-5 -25 -125 -50 -5
-120 -100 0 -75 -120
-45 -25 0 0 -45
120 120 0 120 120
50 50 125 50 50
.5 .5 .5
0 0 0
-.5 -.5 -.5
Derivative in Y direction
41
Gradient Direction Vectors
dI/dx
dI/dy
25 120 25 -120 -50
25 120 25 -120 -50
125 0 0 0 -125
50 75 0 -75 -50
5 120 0 -120 -5
-5 -25 -125 -50 -5
-120 -100 0 -75 -120
-45 -25 0 0 -45
120 120 0 120 120
50 50 125 50 50
42
Volume gradient

• Is a 3x1 vector
• dI/dx dI/dy dI/dz
• Vector points uphill in direction of increasing
  data value
• Vector length (magnitude) indicates how quickly
  data values in the neighborhood are changing

43
Gradient Magnitude

• Given scalar data, the gradient magnitude can be
  computed
• Result is another scalar data set
• Each voxel value gets the length of the gradient
  vector computed for the original data
• Large gradient magnitude values in a region
  indicate sharp changes in the original data

44
Gradient Magnitude Viz.

• Sharp changes are often significant
• May indicate an edge or surface
• Large gradient in CT data indicate a voxel is on
  bone surface
• May indicate where something important is
  happening
• Large temperature gradient in atmosphere can
  indicate a weather front
• Can apply the three visualization methods already
  discussed to the gradient magnitude data

45
Other feature extraction methods

• Can apply other types of pre-processing to the
  input data to find areas of interest
• Search for blobs of a certain size
• Search for areas with a certain texture or
  pattern
• Filter out high frequency noise from input data
• Create new data set by assigning voxel values
  based on how well original data matches the
  search criteria
• Have to know what youre looking for, what
  defines significant for a particular
  application

46
Still to come

• Consideration of volume viz. for higher
  dimensional data
• Vectors
• Tensors
• Time-varying sequences
• Data with probabilistic uncertainty

47
(No Transcript)
48
Streamlines
Follow the flow of a vector field, tracing the
path a particle would take
49
Tensor Glyphs

• Ellipsoids, Cuboids, Superquadratics (see
  right), other 3D polyhedra and implicit surface
  shapes
• For 3x3 matrices, illustrates 3 axes (or
  eigenvectors)
