Study of the Immune System

1
Study of the Immune System
2
Now that we know all about microbes..

• What provokes us to fight against microbes?
• How do we know that they are foreign?
• What initiates the response?

3
Introduction to Antigens

• Antigen (Ag)
• Any substance that stimulates an immune response
• Requirements for antigenicity
• foreignness (recognition of nonself)
• large size
• complexity

most antigenic
4
Characteristics of Antigens

• Epitope
• antigenic determinant
• small molecular group that is recognized by
• Antibodies
• B cells
• T cells

5
Defense Mechanisms of the Host

• Immune system
• relies on a multilevel network of physical
  barriers, immunologically active cells, and
  a variety of chemicals
• 3 main lines of defense
• first line of defense
• any barrier that blocks invasion at the portal of
  entry
• nonspecific
• second line of defense
• protective cells and fluids
• inflammation and phagocytosis
• nonspecific
• third line of defense
• acquired with exposure to foreign substance
• Stronger immune response
• produces protective antibodies and creates memory
  cells
• specific

6
(No Transcript)
7
Physical or Anatomical Barriers First Line of
Defense

• Skin and mucous membranes
• outermost layer of skin
• few pathogens can penetrate if intact
• flushing effect of sweat glands
• mucous coat impedes attachment and entry of
  bacteria
• blinking and tear production
• stomach acid
• nasal hair traps larger particles
• Vaginal secretions

8
Structure and Function of the Organs of Defense
and Immunity

• Immunology
• study of the bodys second and third lines of
  defense
• Functions of a healthy functioning immune system
• Constant surveillance of the body
• Recognition of foreign material
• Destruction of entities deemed to be foreign

9
Blood

• Plasma
• Serum - fluid portion
• complement proteins and antibodies
• Three types of formed elements
• Erythrocytes
• Platelets
• Leukocytes
• Divided into granulocytes and agranulocytes

10
White Blood Cells

• Leukocytes
• Housekeeping and defense
• Scavenge dead or worn-out cells
• Disease organisms
• Squeeze out of blood vessels and enter tissues
• Develop from stem cells in bone marrow
• Granulocytes
• Neutrophils
• Eosinophils
• Basophils
• Agranulocytes
• Monocytes
• Macrophages
• Lymphocytes
• B-cells
• T-cells

11
White Blood Cells

• Neutrophils
• 55-90
• lobed nuclei with lavender granules
• phagocytes
• Eosinophils
• 1-3
• orange granules and bilobed nucleus
• destroy eukaryotic pathogens
• Basophils, mast cells
• 0.5
• constricted nuclei, dark blue granules
• release potent chemical mediators
• Lymphocytes
• 20-35
• large nucleus
• involved in specific immune responses
• B (humoral immunity)
• T cells (cell-mediated immunity)
• Monocytes, macrophages

12
(No Transcript)
13
Innate Immunity

• Second line of defense

14
Second Line of Defense

• cells and mechanisms that defend the host from
  infection by other organisms
• genetically-encoded to recognize
• common pathogenic features
• foreign substances
• does not confer long-lasting or protective
  immunity to the host
• provide immediate defense against infection

15
Actions of the Second Line of Defense

• Recognition
• Inflammation
• Phagocytosis
• Interferon
• Complement

16
1. Recognition

• Toll-like receptors (TLRs)
• protein receptors within cell membrane of
  macrophages
• recognize structurally conserved molecules
  derived from microbes
• Detect foreign molecules and signal the
  macrophage to produce chemicals
• cytokines
• stimulate an inflammatory response (nonspecific)
• promote the activity of B and T cells (specific)

17
2. Functions of inflammation

• Mobilize and attract immune cells to site
• Set mechanisms to repair tissue damage
• Destroy microbes and block further invasion

18
2. Inflammatory Response

• Classic signs and symptoms characterized by
• Redness
• increased circulation and vasodilation in injured
  tissue
• Warmth
• heat given off by the increased blood flow
• Swelling
• increased fluid escaping into the tissue as blood
  vessels dilate
• edema
• WBCs, microbes, debris and fluid collect to form
  pus
• helps prevent spread of infection
• Pain
• stimulation of nerve endings
• Possible loss of function

19
Fever

• Initiated by circulating pyrogens
• cytokines produced by some leukocytes
• reset the hypothalamus to increase body
  temperature
• signals muscles to increase heat production and
  vasoconstrict
• Benefits of fever
• inhibits multiplication of temperature-sensitive
  microorganisms
• impedes nutrition of bacteria
• increases metabolism and stimulates immune
  reactions

20
3. Phagocytosis

• nonspecific defense mechanism
• clear microbes from infected tissues
• capture and digestion of foreign particles

21
Phagocytes

• 3 main types of phagocytes
• Neutrophils
• general-purpose
• react early to bacteria and other foreign
  materials, and to damaged tissue
• Eosinophils
• attracted to sites of parasitic infections and
  antigen-antibody reactions
• Macrophages
• derived from monocytes
• scavenge and process foreign substances to
  prepare them for reactions with B and T
  lymphocytes

22
4. Interferon

• Type of cytokine
• Produced in response to viruses, RNA, immune
  products, and various antigens
• Bind to cell surfaces and induce expression of
  antiviral proteins
• Inhibit expression of cancer genes

23
5. Complement (C)

• Consists of 26 blood proteins
• proteins are activated
• work in concert to destroy bacteria and viruses

24
Adaptive Immunity

• Third line of defense

25
Adaptive Line of Defense

• acquired immunity
• stronger immune response as well as immunological
  memory
• Production of specific antibodies
• dual system of B and T lymphocytes
• in response to an encounter with a foreign
  molecule
• allows for the generation of responses that are
  tailored to specific pathogens or
  pathogen-infected cells

26
Specific Immunity Adaptive Line of Defense

• Two features that characterize specific immunity
• specificity
• antibodies produced
• function only against the antigen that they were
  produced in response to
• memory
• lymphocytes are programmed to recall their
  first encounter with an antigen
• respond rapidly to subsequent encounters

27
Classifying Immunities

• Active immunity
• person is challenged with antigen that stimulates
  production of antibodies
• creates memory, takes time and is lasting
• Passive immunity
• preformed antibodies are donated to an individual
• does not create memory, acts immediately, and is
  short term
• Natural immunity
• acquired as part of normal life experiences
• Artificial immunity
• acquired through a medical procedure such as a
  vaccine

28
Combinations of acquired immunity

• Natural active immunity
• acquired upon infection and recovery
• Natural passive immunity
• acquired by a child through placenta and breast
  milk
• Artificial active immunity
• acquired through inoculation with a selected Ag
• Artificial passive immunity
• administration of immune serum or globulin

29
Development of the Immune Response System

• Cell receptors or markers confer specificity and
  identity of a cell
• Major functions of receptors are
• perceive and attach to nonself or foreign
  molecules
• promote the recognition of self molecules
• receive and transmit chemical messages among
  other cells of the system
• aid in cellular development

30
Acquired Immunity Generates Two Responses to Most
Pathogens

• B lymphocytes
• (B cells)
• involved in producing antibodies against epitopes
• Humoral immune response
• T lymphocytes
• (T cells)
• provide resistance through lysis of infected or
  abnormal cells
• Cell-mediated immune response

31
Lymphocyte Receptors

• Lymphocytes role in surveillance and recognition
  is a function of their receptors
• B-cell receptors
• bind free antigens
• T-cell receptors
• bind processed antigens

32
Antibody Structure and Functions

• Immunoglobulins
• Large Y-shaped protein
• Contains 2 identical fragments (Fab) with ends
  that bind to specific antigen
• Fc binds to various cells and molecules of the
  immune system

33
Classes of Antibodies

• IgD
• important in B cell activation
• IgM
• released by plasma cells during the primary
  immune response
• IgG
• crosses the placenta and confers passive immunity
• IgA
• helps prevent attachment of pathogens to
  epithelial cell surfaces
• IgE
• causing histamine release when activated

34
B-cell Activation and Antibody Production

• Antibodies in Serum (Antiserum)
• The 1st introduction of an Ag to the immune
  system
• produces a primary response
• gradual increase in Ab titer
• The 2nd contact with the same Ag
• produces a secondary, or anamnestic, response
• due to memory cells produced during the initial
  response

35
T Cells Cell Mediated Immunity

• Cell mediated immunity requires the direct
  involvement of T lymphocytes
• T cells act directly against Ag and foreign cells
  when presented in association with an MHC carrier
• T cells secrete cytokines that act on other cells
• Sensitized T cells proliferate into long-lasting
  memory T cells

36
Antibody-Antigen Interactions

• Opsonization
• process of coating microorganisms or other
  particles with specific antibodies
• more readily recognized by phagocytes
• Agglutination
• Ab aggregation
• cross-linking cells or particles into large
  clumps
• Neutralization
• Abs fill the surface receptors on a virus or the
  active site on a microbial enzyme
• prevent it from attaching
• Antitoxins
• special type of Ab that neutralize a bacterial
  exotoxin

37
Immunization

• Passive immunization
• patient is given preformed antibodies
• form of immunotherapy
• Active immunization
• patient is vaccinated with a microbe or its
  antigens
• providing a form of advance protection

38
Vaccines

• Type of active immunity
• Provide an antigenic stimulus that does not cause
  disease
• Most vaccine preparations are based on one of the
  following antigen preparations
• Killed whole cells or inactivated viruses
• Live, attenuated cells or viruses
• Antigenic molecules derived from bacterial cells
  or viruses
• Genetically engineered microbes or microbial
  antigens

39
Disorders in Immunity
40
Immunopathology

• Allergy, hypersensitivity
• misdirected expression of immune responses to an
  allergen (antigen)
• Autoimmunity
• abnormal responses to self Ag
• Immunodeficiency
• deficiency or loss of immunity
• Four types..

41
Type Systems involved Examples
I Immediate Hypersensitivity IgE Mast cells Hay fever Asthma
II Antibody Mediated IgG Ab IgM Ab Blood group incompatability
III Immune Complex Mediated IgG Ab-mediated inflammation Arthritis Serum sickness
IV T-cell Mediated Delayed hypersensitivity Cytotoxic rxns Injection rxns Contact dermatitis Graft rxns
42
1. Type I Hypersensitivity

• Two levels of severity
• Atopy
• any chronic local allergy
• Ex hay fever or asthma
• Anaphylaxis
• a systemic, often explosive reaction that
  involves airway obstruction and circulatory
  collapse

43
Contact With Allergens

• Generalized predisposition to allergies is
  familial
• not to a specific allergy
• Allergy can be affected by age, infection, and
  geographic area
• Atopic allergies may be lifelong or may be
  outgrown
• may also develop later in life

44
Mechanism of Type I Allergy

• Develop in stages
• Sensitizing dose
• on first contact with allergen
• specific B cells form IgE which attach to mast
  cells and basophils
• generally no signs or symptoms
• Provocative dose
• subsequent exposure with the same allergen
• binds to the IgE-mast cell complex

45
Chemical Mediators and Allergic Symptoms

• General targets include
• skin, upper respiratory tract, GI tract, and
  conjunctiva
• Responses
• rashes, itching, redness, rhinitis, sneezing,
  diarrhea, shedding tears
• Systemic targets
• smooth muscles, mucous glands, and nervous tissue
• Responses
• vascular dilation and constriction resulting in
  change in blood pressure and respiration

46
Specific Diseases

• Atopic disease
• hay fever, rhinitis seasonal, inhaled plant
  pollen or mold
• asthma
• Food allergy
• intestinal portal can affect skin and respiratory
  tract
• vomiting, diarrhea, abdominal pain
• possibly severe
• eczema, hives, rhinitis, asthma, occasionally
  anaphylaxis
• Drug allergy
• common side effect of treatment
• reaction from mild atopy to fatal anaphylaxis
• Sudden respiratory and circulatory disruption
  that can be fatal in a few minutes
• Bee stings, antibiotics or serum injection

47
Treatment and Prevention

• General methods include
• Avoiding allergen
• Use drugs
• block the action of the lymphocytes, mast cells
• antihistamines
• Desensitization therapy
• injected allergens

48
2. Type II Hypersensitivity

• Involve antibodies and complement
• leading to lysis of foreign cells
• Transfusion reactions
• ABO blood groups
• Rh factor
• hemolytic disease of the newborn

49
Human ABO Antigens and Blood Types

• Genetically determined RBC glycoproteins
• inherited as 2 alleles of A, B, or O
• 4 blood types A, B, AB, or O
• type O persons lack both A and B antigens
• Tissues other than RBCs also carry A and B
  antigens

50
Antibodies Against A and B Antigens

• Serum contains pre-formed antibodies that react
  with blood of another antigenic
  type-agglutination
• Type A
• contains Abs that react against B antigens
• Type B
• contains Abs that react against A antigens
• Type O
• contains Abs that react against A and B antigens
• Type AB
• contains no Abs that react against A or B
  antigens

51
Rh Factor

• Rhesus factor
• RBC antigen
• type results from combination of 2 alleles
• Either there or not
• Rh-
• Rh
• Inheriting one dominant gene results in the
  production of the Rh antigen

52
Rh Factor and Hemolytic Disease of the Newborn

• Hemolytic Disease of the Newborn (HDN)
• Rh- mother forms antibodies to her Rh fetus
• requires subsequent exposure to the antigen to be
  hemolytic
• Prevention
• use of passive immunization with antibodies
  against the Rh antigen
• prevents sensitization of mother

53
3. Type III Hypersensitivity

• Large quantity of foreign Ag stimulates Ab
• produce small, soluble Ag-Ab complexes
• Immune complexes become trapped in tissues and
  incite a damaging inflammatory response
• arthus reaction
• local reaction to series of injected Ag to same
  body site
• serum sickness
• systemic disease resulting from repeated
  injections of foreign proteins

54
4. Type IV Hypersensitivity

• T cell-mediated
• Delayed response to Ag involving activation of
  and damage by T cells
• Delayed allergic response
• skin response to allergens
• tuberculin skin test, contact dermititis from
  plants, metals, cosmetics
• Graft rejection
• reaction of cytotoxic T cells directed against
  foreign cells of a grafted tissue
• MHC markers of donor tissue (graft) are different
• host may reject graft graft may reject host

55
Immunodeficiency Diseases

• Components of the immune response system are
  absent
• B and T cells, phagocytes, and complement
• 2 general categories
• primary immunodeficiency
• Congenital
• usually genetic errors
• T-cell or B-cell defect
• severe combined immunodeficiency (SCID)
• secondary diseases
• acquired after birth
• caused by natural or artificial agents
• Chemotherapy
• AIDS

56
Evasion of the Immune System by Pathogenic
Microorganisms
57
Why develop a strategy for evasion?

• Pathogen evolution
• Microorganism capable of causing disease
• Must subvert host immune system
• Successful pathogens effective evasion

58
Defenses against human host responses

• Antiphagocytic factors
• Glycocalyx / Capsules (Encapsulation)
• Host cell invasion
• Grow intracellularly
• Neighbor cell transfer
• Syncytium
• Latency
• Genetic changes
• Antigenic shift
• Antigenic drift

59
Antiphagocytic Factors
60
The Bacterial Surface Coating? Glycocalyx

• Coating of molecules external to the cell wall
• Functions
• attachment
• inhibits killing by WBCs

Talaro, 2008
61
Capsules

• Formation correlates with pathogenicity
• Encapsulated cells protect against WBCs
• Chemicals similar to those in human body
• Negative charges on capsule and phagocyte surface
• Slippery
• Pseudopodia cannot grip them

Bauman, 2011
Some Killers Have Pretty Nice Capsules S.
pneumoniae K. pneumoniae H. influenzae P.
aeruginosa N. meningitidis C. neoformans
http//medicineworld.org/stories/lead/2-2009/how-a
-deadly-fungus-evades-the-human-immune-system.html
62
Streptococcus pyogenes

• GAS
• Most serious streptococcal pathogen
• Many surface antigens that enable virulence and
  evasion

Talaro, 2008
63
S. pyogenes. Theres an app for
that
Capsule made of hyaluronic acid (HA) Chemically masked from HA in human tissues
M-protein Makes surface projections that resist phagocytosis
C-carbohydrates Protect bacterium from being dissolved by lysozyme
C5a protease Catalyzes cleavage of C5a protein (hinders C-associated aspects neutrophil response)
64
Host Cell Invasion
65
Survive inside phagocytes after ingestion

• Ingested by alveolar phagocytes
• Prevent fusion with lysosomes
• Multiply intracellularly
• After cell death, attract more phagocytes and
  continue cycle
• Mycobacterium

Bauman, 2011
66
Neighboring cell transfer

• Can escape out of phagosomes
• Transfer to neighbor cells w/o leaving host cell
• Not exposed to Ab
• Listeria monocytogenes

Pommerville, 2007
67
Syncytium

• Induces cells to fuse
• Multinucleate giant cell
• Allows pathogen to move from cell to cell
• HIV
• RSV
• Paramyxoviruses

Talaro, 2008
68
Latency

• Pathogen remains inactive for period of time
• Reactivate at later date
• Herpes

Bauman, 2011
69
Genetic Changes
70
Viruses

• Glycoprotein spikes
• Adherence
• Recognized by host immune system
• Influenza A B
• Contains two types of spikes
• Hemagglutin (HA)
• Neuraminidase (NA)

Pommerville, 2007
71
Genetic changes of viruses

• Antigenic drift
• Mutation in spikes
• Change their aa composition
• Small changes
• Single strain
• Antigenic shift
• Shift of gene strand with one from another host
• Human, pig, birds, etc.
• Abrupt, major change
• Reorganization of strains
• H1N1

Bauman, 2011
