Functional Verification IV: Revisiting Loop Invariants

1
Functional Verification IV Revisiting Loop
Invariants
Software Testing and Verification Lecture Notes
24

• Prepared by
• Stephen M. Thebaut, Ph.D.
• University of Florida

2
Last Time

• Iteration Recursion Lemma (IRL)
• Termination predicate term(f,P)
• Correctness conditions for while_do statement
• Sufficient correctness conditions
• Correctness conditions for repeat_until statement
• Subgoal Induction

3
Todays Topics

• Thinking about invariants again
• Invariant Status Theorem (IST)
• While Loop Initialization
• Utility of IST

4
Todays Topics

• Thinking about invariants again
• Invariant Status Theorem (IST)
• While Loop Initialization
• Utility of IST

5
Thinking about invariants again

• In Lecture Notes 18 we considered heuristics for
  synthesizing Q-adequate loop invariants.
• In Lecture Notes 23, it was observed that a loop
  computing a function maintains an important
  property of state across iterations the function
  value of the current state, X, is the same as the
  function value of the initial state, X0. That is
  f(X)f(X0).
• We now expand on this observation and show that
  this property represents the weakest f-adequate
  loop invariant over D(f)!
• To be defined shortly...

6
Hypothesize I
Flashback to LN 18...
true
Finalization ?
false
true
Initialization ?
strengthen
false
true
Preservation ?
weaken
false
finish
false
refine
Initialization ?
true
false
Preservation ?
true
7
Thinking about invariants again

• In Lecture Notes 18 we considered heuristics for
  synthesizing Q-adequate loop invariants.
• In Lecture Notes 23, it was observed that a loop
  computing a function maintains an important
  property of state across iterations the function
  value of the current state, X, is the same as the
  function value of the initial state, X0. That is
  f(X)f(X0).
• We now expand on this observation and show that
  this property represents the weakest f-adequate
  loop invariant over D(f)!
• To be defined shortly...

8
Thinking about invariants again

• In Lecture Notes 18 we considered heuristics for
  synthesizing Q-adequate loop invariants.
• In Lecture Notes 23, it was observed that a loop
  computing a function maintains an important
  property of state across iterations the function
  value of the current state, X, is the same as the
  function value of the initial state, X0. That is
  f(X)f(X0).
• We now expand on this observation and show that
  this property represents the weakest f-adequate
  loop invariant over D(f)!
• To be defined shortly...

9
Flashback to LN 23...

• As f while p do g if p then gf end_if,
  it follows that
• f(X0) f(X1) ... f(Xn) Xn
• More generally, after each iteration of the loop,
  the function value of the current state, X, must
  be the same as the function value of the initial
  state, X0. That is
• f(X) f(X0)
• We will revisit this observation in connection
  with Mills Invariant Status Theorem shortly.

10
Thinking about invariants again

• In Lecture Notes 18 we considered heuristics for
  synthesizing Q-adequate loop invariants.
• In Lecture Notes 23, it was observed that a loop
  computing a function maintains an important
  property of state across iterations the function
  value of the current state, X, is the same as the
  function value of the initial state, X0. That is
  f(X)f(X0).
• We now expand on this observation and show that
  this property represents the weakest f-adequate
  loop invariant over D(f)!
• To be defined shortly...

11
Thinking about invariants again

• In Lecture Notes 18 we considered heuristics for
  synthesizing Q-adequate loop invariants.
• In Lecture Notes 23, it was observed that a loop
  computing a function maintains an important
  property of state across iterations the function
  value of the current state, X, is the same as the
  function value of the initial state, X0. That is
  f(X)f(X0).
• We now expand on this observation and show that
  this property represents the weakest f-adequate
  loop invariant over D(f)!
• To be defined shortly...

12
Thinking about invariants again

• Consider the following assertion, where z0 and y0
  represent the initial values of z and y,
  respectively
• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0

13
Thinking about invariants again

• Consider the following assertion, where z0 and y0
  represent the initial values of z and y,
  respectively
• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Can you identify a Q-adequate invariant, I, that
  could be used to prove this...?

14
Thinking about invariants again

• Consider the following assertion, where z0 and y0
  represent the initial values of z and y,
  respectively
• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Can you identify a Q-adequate invariant, I, that
  could be used to prove this...?

Consider I y y0(z0-z) This can be rewritten
as
15
Thinking about invariants again

• Consider the following assertion, where z0 and y0
  represent the initial values of z and y,
  respectively
• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Can you identify a Q-adequate invariant, I, that
  could be used to prove this...?

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
16
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Now, independent of the given pre- and
  post-conditions, what function, f, is computed by
  the loop?

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
17
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Now, independent of the given pre- and
  post-conditions, what function, f, is computed by
  the loop?
• (z0 ? y,z ?,?)

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
18
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Now, independent of the given pre- and
  post-conditions, what function, f, is computed by
  the loop?
• (z0 ? y,z yz,0)

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
19
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• So, for f (z0 ? y,z yz,0), what is the
  relationship between f and the specified
  post-condition?

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
20
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• So, for f (z0 ? y,z yz,0), what is the
  relationship between f and the specified
  post-condition? zfz(X0)0 ? yfy(X0)y0z0.
• (This can be written more simply as just
  Xf(X0), where X is shorthand for y,z.)

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
21
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• So, for f (z0 ? y,z yz,0), what is the
  relationship between f and the specified
  post-condition? zfz(X0)0 ? yfy(X0)y0z0.
• (This can be written more simply as just
  Xf(X0), where X is shorthand for y,z.)

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
22
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• But note that a specified post-condition is not
  an innate property of a program as is the
  programs actual function! It just so happens
  that where f is defined, Q Xf(X0) in this
  particular case...

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
23
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Getting back now to our Q-adequate invariant, I,
  where f (z0 ? y,z yz,0)...
• Recall that the IRL implies that after each
  iteration of the loop, the function value of the
  current state, X, must be the same as the
  function value of the initial state, X0. That is,
  f(X)f(X0).

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
24
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Getting back now to our Q-adequate invariant, I,
  where f (z0 ? y,z yz,0)...
• Recall that the IRL implies that after each
  iteration of the loop, the function value of the
  current state, X, must be the same as the
  function value of the initial state, X0. That is,
  f(X)f(X0).

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
25
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Thus, f(X)f(X0) captures a constant
  relationship between the values of variables on
  entry to a loop (denoted by X0), and their values
  after every iteration of a loop (denoted by X)
  computing f.
• What, then, is this relationship for the
  function (z0 ? y,z yz,0)?

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
26
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Thus, f(X)f(X0) captures a constant
  relationship between the values of variables on
  entry to a loop (denoted by X0), and their values
  after every iteration of a loop (denoted by X)
  computing f.
• What, then, is this relationship for the
  function (z0 ? y,z yz,0)?

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
27
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Where f is defined, fy(X)yz and fy(X0)y0z0.
• Similarly, fz(X)0 and fz(X0)0.
• Setting f(X) equal to f(X0) for each variable
  gives
• 00 ? yzy0x0
• That is, for z0.

Consider I y y0(z0-z) This can be rewritten
as yz y0z0

28
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Where f is defined, fy(X)yz and fy(X0)y0z0.
• Similarly, fz(X)0 and fz(X0)0.
• Setting f(X) equal to f(X0) for each variable
  gives
• 00 ? yzy0x0
• That is, for z0.

Consider I y y0(z0-z) This can be rewritten
as yz y0z0

29
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Where f is defined, fy(X)yz and fy(X0)y0z0.
• Similarly, fz(X)0 and fz(X0)0.
• Setting f(X) equal to f(X0) for each variable
  gives
• 00 ? yzy0z0
• That is, for z0.

Consider I y y0(z0-z) This can be rewritten
as yz y0z0

30
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Where f is defined, fy(X)yz and fy(X0)y0z0.
• Similarly, fz(X)0 and fz(X0)0.
• Setting f(X) equal to f(X0) for each variable
  gives
• 00 ? yzy0z0 I
• That is, for z0.

Consider I y y0(z0-z) This can be rewritten
as yz y0z0

31
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Thus, setting f(X) equal to f(X0) results in a
  Q-adequate loop invariant that could (by
  definition) be used with the while loop ROI to
  prove the given assertion!

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
32
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Thus, setting f(X) equal to f(X0) results in a
  Q-adequate loop invariant that could (by
  definition) be used with the while loop ROI to
  prove the given assertion!
• Are you not awestruck?

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
33
Thinking about invariants again

• true
• while zltgt0 do
• y y1
• z z-1
• end_while
• z0 ? yy0z0
• Thus, setting f(X) equal to f(X0) results in a
  Q-adequate loop invariant that could (by
  definition) be used with the while loop ROI to
  prove the given assertion!
• Are you not awestruck?
• But remember the specified post-condition
  conveniently corresponds to the programs actual
  function in this case.

Consider I y y0(z0-z) This can be rewritten
as yz y0z0
34
Todays Topics

• Thinking about invariants again
• Invariant Status Theorem (IST)
• While Loop Initialization
• Utility of IST

35
Invariant Status Theorem (IST)

• Theorem.
• Let f while p do g. If X0?D(f), X?D(f), and
  q(X)( f(X)f(X0) ), then q is an invariant of
  while p do g i.e., it has the following
  properties

36
Invariant Status Theorem (IST)

• Theorem.
• Let f while p do g. If X0?D(f), X?D(f), and
  q(X)( f(X)f(X0) ), then q is an invariant of
  while p do g i.e., it has the following
  properties
• q(X0) is true, and

37
Invariant Status Theorem (IST)

• Theorem.
• Let f while p do g. If X0?D(f), X?D(f), and
  q(X)( f(X)f(X0) ), then q is an invariant of
  while p do g i.e., it has the following
  properties
• q(X0) is true, and
• ( q(X) ? p(X) ) ? qog(X).

38
Invariant Status Theorem (IST)

• Theorem.
• Let f while p do g. If X0?D(f), X?D(f), and
  q(X)( f(X)f(X0) ), then q is an invariant of
  while p do g i.e., it has the following
  properties
• q(X0) is true, and
• ( q(X) ? p(X) ) ? qog(X).
• In addition, q(X) is an f-adequate invariant
  i.e.,

39
Invariant Status Theorem (IST)

• Theorem.
• Let f while p do g. If X0?D(f), X?D(f), and
  q(X)( f(X)f(X0) ), then q is an invariant of
  while p do g i.e., it has the following
  properties
• q(X0) is true, and
• ( q(X) ? p(X) ) ? qog(X).
• In addition, q(X) is an f-adequate invariant
  i.e.,
• ( q(X) ? p(X) ) ? ( Xf(X0) )

40
Invariant Status Theorem (IST)

• Theorem.
• Let f while p do g. If X0?D(f), X?D(f), and
  q(X)( f(X)f(X0) ), then q is an invariant of
  while p do g i.e., it has the following
  properties
• q(X0) is true, and
• ( q(X) ? p(X) ) ? qog(X).
• In addition, q(X) is an f-adequate invariant
  i.e.,
• ( q(X) ? p(X) ) ? ( Xf(X0) )

This represents the final state values as a
function, f, of the initial state values.
41
Invariant Status Theorem (contd)

• Proof.
• q(X0) is true

42
Invariant Status Theorem (contd)

• Proof.
• q(X0) is true
• q(X) ( f(X)f(X0) ), so
• q(X0)( f(X0)f(X0) )

43
Invariant Status Theorem (contd)

• Proof.
• q(X0) is true
• q(X) ( f(X)f(X0) ), so
• q(X0)( f(X0)f(X0) )
• true
• as desired.

44
Invariant Status Theorem (contd)

• Proof.
• q(X0) is true
• q(X) ( f(X)f(X0) ), so
• q(X0)( f(X0)f(X0) )
• true
• as desired.
• (Note that based on the definition of q(X), this
  property is a tautology.)

45
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? qog(X)

46
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? qog(X)
• For X?D(f) we know
• p(X) ? ( f(X)fog(X) )
• by the Iteration Recursion Lemma.

47
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? qog(X)
• For X?D(f) we know
• p(X) ? ( f(X)fog(X) )
• by the Iteration Recursion Lemma. Since
• q(X)( f(X)f(X0) )
• by definition, it follows that

48
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? qog(X)
• For X?D(f) we know
• p(X) ? ( f(X)fog(X) )
• by the Iteration Recursion Lemma. Since
• q(X)( f(X)f(X0) )
• by definition, it follows that
• ( q(X) ? p(X) ) ? ( fog(X)f(X0) ).

49
Invariant Status Theorem (contd)

• Proof. (contd)
• But the right-hand side of
• ( q(X) ? p(X) ) ? ( fog(X)f(X0) )
• is just
• ( f(g(X))f(X0) ) q(g(X))
• qog(X)
• Therefore,
• ( q(X) ? p(X) ) ? qog(X)
• as desired.

50
Invariant Status Theorem (contd)

• Proof. (contd)
• But the right-hand side of
• ( q(X) ? p(X) ) ? ( fog(X)f(X0) )
• is just
• ( f(g(X))f(X0) ) q(g(X))
• qog(X)
• Therefore,
• ( q(X) ? p(X) ) ? qog(X)
• as desired.

51
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? ( Xf(X0) )

52
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? ( Xf(X0) )
• If p(X), then f(X) I by definition of the
  while construct. This can be rewritten as f(X)
  X.

53
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? ( Xf(X0) )
• If p(X), then f(X) I by definition of the
  while construct. This can be rewritten as f(X)
  X.
• And since q(X) ( f(X)f(X0) ), it follows
• that

54
Invariant Status Theorem (contd)

• Proof. (contd)
• ( q(X) ? p(X) ) ? ( Xf(X0) )
• If p(X), then f(X) I by definition of the
  while construct. This can be rewritten as f(X)
  X.
• And since q(X) ( f(X)f(X0) ), it follows
• that
• ( p(X) ? q(X) ) ? ( Xf(X0) )
• as desired.

55
An important corollary...

• IST Corollary.
• Let f while p do g. If X0?D(f), X?D(f), and
  q(X)
• ( f(X)f(X0) ), then q is an f-adequate
  invariant of ANY program of the form while p do g
  for which properties (2) and (3) of the IST hold
• ( q(X) ? p(X) ) ? qog(X)
• ( q(X) ? p(X) ) ? ( Xf(X0) )
• Thus, verifying these properties for a given
  while_do statement, K, and intended function, f,
  for which term(f,K) has already been shown,
  constitutes a proof that f K.

56
Example 1

• Consider the following assertion, where a0 and b0
  represent the initial values of a and b,
  respectively
• true
• while altgt0 do
• b ba
• a a-1
• end_while
• a0 ? bb0a0!

What function, f, is computed by the while loop?
57
Example 1

• Consider the following assertion, where a0 and b0
  represent the initial values of a and b,
  respectively
• true
• while altgt0 do
• b ba
• a a-1
• end_while
• a0 ? bb0a0!

What function, f, is computed by the while loop?
58
Example 1

• Consider the following assertion, where a0 and b0
  represent the initial values of a and b,
  respectively
• true
• while altgt0 do
• b ba
• a a-1
• end_while
• a0 ? bb0a0!

What function, f, is computed by the while loop?
(a0 ? a,b 0,ba!)
59
Example 1 (contd)

• For f (a0 ? a,b 0,ba!), an invariant q(X)(
  f(X)f(X0) ) can be derived by tabu-lating f(X)
  and f(X0) for each member of the data space, X
• X f(X) f(X0)
• a
• b
• and equating components of f(X) and f(X0)

60
Example 1 (contd)

• For f (a0 ? a,b 0,ba!), an invariant q(X)(
  f(X)f(X0) ) can be derived by tabu-lating f(X)
  and f(X0) for each member of the data space, X
• X f(X) f(X0)
• a 0
• b
• and equating components of f(X) and f(X0)

61
Example 1 (contd)

• For f (a0 ? a,b 0,ba!), an invariant q(X)(
  f(X)f(X0) ) can be derived by tabu-lating f(X)
  and f(X0) for each member of the data space, X
• X f(X) f(X0)
• a 0 0
• b
• and equating components of f(X) and f(X0)

62
Example 1 (contd)

• For f (a0 ? a,b 0,ba!), an invariant q(X)(
  f(X)f(X0) ) can be derived by tabu-lating f(X)
  and f(X0) for each member of the data space, X
• X f(X) f(X0)
• a 0 0
• b ba! b0a0!
• and equating components of f(X) and f(X0)

63
Example 1 (contd)

• For f (a0 ? a,b 0,ba!), an invariant q(X)(
  f(X)f(X0) ) can be derived by tabu-lating f(X)
  and f(X0) for each member of the data space, X
• X f(X) f(X0)
• a 0 0
• b ba! b0a0!
• and equating components of f(X) and f(X0)
• 0 0
• ba! b0a0!

64
Example 1 (contd)

• We can rewrite the second equation as
• b b0(a0!/a!)
• and use it as an invariant to prove the given
  assertion using the while loop Rule of
  Infer-ence.
• When combined with a0 (specifying the domain of
  f) we get
• q ( b b0(a0!/a!) ? a0 )

65
Example 1 (contd)

• We can rewrite the second equation as
• b b0(a0!/a!)
• and use it as an invariant to prove the given
  assertion using the while loop Rule of
  Infer-ence.
• When combined with a0 (specifying the domain of
  f) we get
• q ( b b0(a0!/a!) ? a0 )

66
Another interesting property of q(X)

• In the context of functional verification, loop
  invariants are generally a function of the
  current values of program variables (denoted by
  X), AND their values on entry to the loop
  (denoted by X0).
• Many f-adequate invariants may exist for a given
  loop, so what criteria might be used to determine
  which is the best to use?
• In general, we want f-adequate invariants to be
  as weak as possible. The weaker an invariant is
  (while still being f-adequate), the easier it
  will be to use.

67
Another interesting property of q(X)

• In the context of functional verification, loop
  invariants are generally a function of the
  current values of program variables (denoted by
  X), AND their values on entry to the loop
  (denoted by X0).
• Many f-adequate invariants may exist for a given
  loop, so what criteria might be used to determine
  which is the best to use?
• In general, we want f-adequate invariants to be
  as weak as possible. The weaker an invariant is
  (while still being f-adequate), the easier it
  will be to use.

68
Another interesting property of q(X)

• In the context of functional verification, loop
  invariants are generally a function of the
  current values of program variables (denoted by
  X), AND their values on entry to the loop
  (denoted by X0).
• Many f-adequate invariants may exist for a given
  loop, so what criteria might be used to determine
  which is the best to use?
• In general, we want f-adequate invariants to be
  as weak as possible. The weaker an invariant is
  (while still being f-adequate), the easier it
  will be to use.

69
Another interesting property of q(X) (contd)

• Claim q(X)( f(X)f(X0) ) is the weakest
  f-adequate loop invariant over D(f) in the sense
  that it is implied by all others.
• Proof Let I(X) be any f-adequate loop invariant
  for (while p do g) over D(f), and let
  X0,X1,...,Xn be the states associated with the
  loop in D(f). Since Xnf(X), we know I(f(X)) and
  p(f(X)). And since I(X) is f-adequate ( I(X) ?
  p(X) ? Xf(X0) ), it follows that ( I(f(X)) ?
  p(f(X)) ? f(X)f(X0) ). Therefore, for all X in
  D(f), I(X) ? q(X) as claimed.
• (See Part 3, The Loop Invariant f(X0)f(X),
• of the Dunlop/Basili paper.)

70
Another interesting property of q(X) (contd)

• Claim q(X)( f(X)f(X0) ) is the weakest
  f-adequate loop invariant over D(f) in the sense
  that it is implied by all others.
• Proof Let I(X) be any f-adequate loop invariant
  for (while p do g) over D(f), and let
  X0,X1,...,Xn be the states associated with the
  loop in D(f). Since Xnf(X), we know I(f(X)) and
  p(f(X)). And since I(X) is f-adequate ( I(X) ?
  p(X) ? Xf(X0) ), it follows that ( I(f(X)) ?
  p(f(X)) ? f(X)f(X0) ). Therefore, for all X in
  D(f), I(X) ? q(X) as claimed.
• (See Part 3, The Loop Invariant f(X0)f(X),
• of the Dunlop/Basili paper.)

71
Another interesting property of q(X) (contd)

• Claim q(X)( f(X)f(X0) ) is the weakest
  f-adequate loop invariant over D(f) in the sense
  that it is implied by all others.
• Proof Let I(X) be any f-adequate loop invariant
  for (while p do g) over D(f), and let
  X0,X1,...,Xn be the states associated with the
  loop in D(f). Since Xnf(X), we know I(f(X)) and
  p(f(X)). And since I(X) is f-adequate ( I(X) ?
  p(X) ? Xf(X0) ), it follows that ( I(f(X)) ?
  p(f(X)) ? f(X)f(X0) ). Therefore, for all X in
  D(f), I(X) ? q(X) as claimed.
• (See Part 3, The Loop Invariant f(X0)f(X),
• of the Dunlop/Basili paper.)

72
Another interesting property of q(X) (contd)

• To expand on the unique nature of q(X), note that
  the set of states satisfying f(X)f(X0) includes
  ALL intermediate states that could possibly be
  generated by ANY while loop that computes f!
• Thus, q(X) is strong (i.e., specific) enough to
  describe the net effect of the loop on the input
  set D(f), but sufficiently weak (i.e., general)
  that it may offer no hint about the method used
  to achieve the effect.

73
Another interesting property of q(X) (contd)

• To expand on the unique nature of q(X), note that
  the set of states satisfying f(X)f(X0) includes
  ALL intermediate states that could possibly be
  generated by ANY while loop that computes f!
• Thus, q(X) is strong (i.e., specific) enough to
  describe the net effect of the loop on the input
  set D(f), but sufficiently weak (i.e., general)
  that it may offer no hint about the method used
  to achieve the effect.

74
Another interesting property of q(X) (contd)

• Recall the program
• while zltgt0 do
• y y1
• z z-1
• end_while

75
Another interesting property of q(X) (contd)

• Recall the program
• while zltgt0 do
• y y1
• z z-1
• end_while

The function computed is f (z0 ? y,z
yz,0) and from the IST, the weakest f-adequate
invariant over D(f) is q(X) ? ( yz y0z0 ?
z0 )
Consider the sample y0,z0 input 2,4. The
loop then pro-duces the series of states 2,4,
3,3, 4,2, 5,1, 6,0. q(X), of course,
agrees with these states, but it also agrees with
-3,9! This implies that some loop that
computes f could produce the intermediate state
-3,9 while mapping 2,4 to 6,0. We further
conclude that no loop that computes f could
pro-duce 4,4 as an intermediate state from the
input 2,4.
76
Another interesting property of q(X) (contd)

• Recall the program
• while zltgt0 do
• y y1
• z z-1
• end_while

The function computed is f (z0 ? y,z
yz,0) and from the IST, the weakest f-adequate
invariant over D(f) is q(X) ? ( yz y0z0 ?
z0 )
Consider the sample y0,z0 input 2,4. The
loop then pro-duces the series of states 2,4,
3,3, 4,2, 5,1, 6,0. q(X), of course,
agrees with these states, but it also agrees with
-3,9! This implies that some loop that
computes f could produce the intermediate state
-3,9 while mapping 2,4 to 6,0. We further
conclude that no loop that computes f could
pro-duce 4,4 as an intermediate state from the
input 2,4.
77
Another interesting property of q(X) (contd)

• Recall the program
• while zltgt0 do
• y y1
• z z-1
• end_while

The function computed is f (z0 ? y,z
yz,0) and from the IST, the weakest f-adequate
invariant over D(f) is q(X) ? ( yz y0z0 ?
z0 )
Consider the sample y0,z0 input 2,4. The
loop then pro-duces the series of states 2,4,
3,3, 4,2, 5,1, 6,0. q(X), of course,
agrees with these states, but it also agrees with
-3,9! This implies that some loop that
computes f could produce the intermediate state
-3,9 while mapping 2,4 to 6,0. We further
conclude that no loop that computes f could
pro-duce 4,4 as an intermediate state from the
input 2,4.
78
Another interesting property of q(X) (contd)

• Recall the program
• while zltgt0 do
• y y1
• z z-1
• end_while

The function computed is f (z0 ? y,z
yz,0) and from the IST, the weakest f-adequate
invariant over D(f) is q(X) ? ( yz y0z0 ?
z0 )
Consider the sample y0,z0 input 2,4. The
loop then pro-duces the series of states 2,4,
3,3, 4,2, 5,1, 6,0. q(X), of course,
agrees with these states, but it also agrees with
-3,9! This implies that some loop that
computes f could produce the intermediate state
-3,9 while mapping 2,4 to 6,0. We further
conclude that no loop that computes f could
pro-duce 4,4 as an intermediate state from the
input 2,4.
79
Another interesting property of q(X) (contd)

• Recall the program
• while zltgt0 do
• y y1
• z z-1
• end_while

The function computed is f (z0 ? y,z
yz,0) and from the IST, the weakest f-adequate
invariant over D(f) is q(X) ? ( yz y0z0 ?
z0 )
Consider the sample y0,z0 input 2,4. The
loop then pro-duces the series of states 2,4,
3,3, 4,2, 5,1, 6,0. q(X), of course,
agrees with these states, but it also agrees with
-3,9! This implies that some loop that
computes f could produce the intermediate state
-3,9 while mapping 2,4 to 6,0. We further
conclude that no loop that computes f could
pro-duce 4,4 as an intermediate state from the
input 2,4.
80
Another interesting property of q(X) (contd)

• Consider a more concrete (wood, aluminum, etc.)
  illustration of qs properties...
• Let f represent a general mapping from an initial
  building construction state (e.g., a vacant lot)
  to a final construction state (a finished
  building).
• Let P be a specific, step-by-step, iterative
  construction process that produces a finished
  building in accordance with f.

81
Another interesting property of q(X) (contd)

• Consider a more concrete (wood, aluminum, etc.)
  illustration of qs properties...
• Let f represent a general mapping from an initial
  building construction state (e.g., a vacant lot)
  to a final construction state (a finished
  building).
• Let P be a specific, step-by-step, iterative
  construction process that produces a finished
  building in accordance with f.

82
Another interesting property of q(X) (contd)

• Consider a more concrete (wood, aluminum, etc.)
  illustration of qs properties...
• Let f represent a general mapping from an initial
  building construction state (e.g., a vacant lot)
  to a final construction state (a finished
  building).
• Let P be a specific, step-by-step, iterative
  construction process that produces a finished
  building in accordance with f.

83
Another interesting property of q(X) (contd)

• In particular, suppose that from an initial
  building state, Svac
• P produces the series of (successor) states
• where Sfin represents a finished building.

vac
84
Another interesting property of q(X) (contd)

• In particular, suppose that from an initial
  building state, Svac
• P produces the series of (successor) states
• where Sfin represents a finished building.

vac
?
?
?
?
fin
X
K
T
Y
85
Another interesting property of q(X) (contd)

• Now, let q(S)( f(S)f(S0) ) where S0 is the
  initial building state, S is the current building
  state, and S, S0 are in D(f).
• It follows, then, that q agrees with the series
  of states produced by P. That is
• q(Svac), q(SX), q(SK), q(ST), q(SY), q(Sfin)
• But suppose q also holds for another state in
  D(f)

86
Another interesting property of q(X) (contd)

• Now, let q(S)( f(S)f(S0) ) where S0 is the
  initial building state, S is the current building
  state, and S, S0 are in D(f).
• It follows, then, that q agrees with the series
  of states produced by P. That is
• q(Svac), q(SX), q(SK), q(ST), q(SY), q(Sfin)
• But suppose q also holds for another state in
  D(f)

87
Another interesting property of q(X) (contd)

• Now, let q(S)( f(S)f(S0) ) where S0 is the
  initial building state, S is the current building
  state, and S, S0 are in D(f).
• It follows, then, that q agrees with the series
  of states produced by P. That is
• q(Svac), q(SX), q(SK), q(ST), q(SY), q(Sfin)
• But suppose q also holds for another state in
  D(f)

Z
88
Another interesting property of q(X) (contd)

• This would imply that some other iterative
  construction process, P, that also results in a
  finished building in accordance with f, could
  produce SZ in the process of producing Sfin
  starting from Svac!
• Finally, suppose that q does NOT hold for SE

89
Another interesting property of q(X) (contd)

• This would imply that some other iterative
  construction process, P, that also results in a
  finished building in accordance with f, could
  produce SZ in the process of producing Sfin
  starting from Svac!
• Finally, suppose that q does NOT hold for SE

E
90
Another interesting property of q(X) (contd)

• This would imply that no iterative construction
  process that results in a finished building in
  accordance with f could produce SE from the
  initial state Svac!

91
Todays Topics

• Thinking about invariants again
• Invariant Status Theorem (IST)
• While Loop Initialization
• Utility of IST

92
While Loop Initialization

• In many situations, a loop invariant may hold by
  virtue of its initialization. In particular,
  given
• f while p do g, X0 ? D(f)
• a limited f-adequate invariant of the
  initialized while loop
• h while p do g
• is
• qh(X) ( f(X)foh(X0) )

93
While Loop Initialization (contd)

• Such an invariant has the following properties
• qhoh(X0) is true, and
• (qh(X) ? p(X) ) ? qhog(X), and
• (qh(X) ? p(X) ) ? ( Xfoh(X0) )

94
Example 2

• Consider the assertion
• n0
• p 1
• k 0
• while kltgtn do
• p p2
• k k1
• end_while
• p2n

What function, h, is computed by the loop
initialization?
95
Example 2

• Consider the assertion
• n0
• p 1
• k 0
• while kltgtn do
• p p2
• k k1
• end_while
• p2n

What function, h, is computed by the loop
initialization?
96
Example 2

• Consider the assertion
• n0
• p 1
• k 0
• while kltgtn do
• p p2
• k k1
• end_while
• p2n

What function, h, is computed by the loop
initialization?
(p,k 1,0)
97
Example 2

• Consider the assertion
• n0
• p 1
• k 0
• while kltgtn do
• p p2
• k k1
• end_while
• p2n

What function, f, is computed by the while loop?
98
Example 2

• Consider the assertion
• n0
• p 1
• k 0
• while kltgtn do
• p p2
• k k1
• end_while
• p2n

What function, f, is computed by the while loop?
(kn ? p,k ?,?)
99
Example 2

• Consider the assertion
• n0
• p 1
• k 0
• while kltgtn do
• p p2
• k k1
• end_while
• p2n

What function, f, is computed by the while loop?
(kn ? p,k ?,n)
100
Example 2

• Consider the assertion
• n0
• p 1
• k 0
• while kltgtn do
• p p2
• k k1
• end_while
• p2n

What function, f, is computed by the while loop?
(kn ? p,k p2n-k,n)
101
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p k
102
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p ? k
103
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k k
104
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k ? k
105
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k (1)2n0-0 k

106
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k (1)2n0-0 k
?

107
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k (1)2n0-0 k
n

108
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k (1)2n0-0 k
n ?

109
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k (1)2n0-0 k
n n0

110
Example 2 (contd)

• For f (kn ? p,k p2n-k,n), and h (p,k
  1,0), an invariant qh(X)( ( f(X)foh(X0) ) can
  be derived by tabulating f(X) and foh(X0) for
  each member of the data space
• and equating components of f(X) and foh(X0)

X f(X) foh(X0) p p2n-k (1)2n0-0 k
n n0
p2n-k (1)2n0-0 n n0
111
Example 2 (contd)

• When combined, these equations yield the
  invariant
• p2k
• which can be used with the while loop Rule of
  Inference to prove the given assertion.
• When the condition kn (specifying the domain of
  f) is included, we get
• q ( p2k ? kn )

112
Exercise

• Recall that in Example 3 of Lecture Notes 18, we
  proved the assertion below using the invariant I
  ZXJ.

true Z X J 1 while
JltgtY do Z ZX J J1
end_while ZXY
113
Exercise (contd)

• Derive a limited invariant for the initialized
  while loop using the Invariant Status Theorem.

114
Todays Topics

• Thinking about invariants again
• Invariant Status Theorem (IST)
• While Loop Initialization
• Utility of IST

115
Utility of Invariant Status Theorem

• Does the IST eliminate the need for heuristics to
  synthesize Q-adequate loop invariants?

116
Utility of Invariant Status Theorem

• Does the IST eliminate the need for heuristics to
  synthesize Q-adequate loop invariants?
• Unfortunately, no. The derivation of q(X)
  requires knowledge of the program function, f.
  Further-more, if the specified post-condition, Q,
  is not of the form Xf(X0), the translation
  between Q and f may not be obvious. Finally, if Q
  is weaker than f, then q(X) will be stronger than
  needed and may, therefore, be more cumbersome to
  use than some weaker Q-adequate invariant.

117
Utility of Invariant Status Theorem (contd)

• None of the functions considered so far has used
  conditional rules. How does one deter-mine q(X)
  for intended functions of the form
• f (p1 ? r1 p2 ? r2 pk ? rk) ?

Other than simple functions of the form (p ?
r).
118
Utility of Invariant Status Theorem (contd)

• None of the functions considered so far has used
  conditional rules. How does one deter-mine q(X)
  for intended functions of the form
• f (p1 ? r1 p2 ? r2 pk ? rk) ?
• This can be tedious since the rule employed to
  deter-mine f(X0) for every initial state X0 plus
  those rules employed to determine f(X) for each
  of X0s successor states must be considered. The
  problem is analogous to that encountered in
  showing p(X) ? ( f(X)fog(X) ) when the rule for
  f on the left-hand side of the equality may be
  different than that on the right-hand side of the
  equality (i.e., after applying g).

Other than simple functions of the form (p ?
r).
119
Utility of Invariant Status Theorem (contd)

• Would verifying the properties of q(X) for a
  given while_do statement, K, and hypothesized
  function, f, for which term(f,K) has been shown,
  constitute a proof that f K?

120
Utility of Invariant Status Theorem (contd)

• Would verifying the properties of q(X) for a
  given while_do statement, K, and hypothesized
  function, f, for which term(f,K) has been shown,
  constitute a proof that f K?
• Yes, properties (2) and (3) of the IST are
  equivalent to the 2nd and 3rd while_do
  correctness conditions when using q(X) as the
  predicate. This is because ( q(X) ? p(X) ) ?
  qog(X) follows from p(X) ? ( f(X)fog(X) ), and (
  q(X) ? p(X) ) ? ( Xf(X0) ) follows from p(X) ?
  ( f(X) I ).
• Also, since q(X) is the weakest f-adequate loop
  invariant for K, it is generally the easiest
  invariant over D(f) that can be used to verify
  that the loop computes f.

121
Utility of Invariant Status Theorem (contd)

• For some additional important and interesting
  insights into the nature of q(X), functions, and
  both iterative and non-iterative program
  con-structs, be sure to see problems 8 and 9 in
  Problem Set 7!

122
Summary

• Thinking about invariants again
• Invariant Status Theorem (IST)
• While Loop Initialization
• Utility of IST

123
Functional Verification IV Revisiting Loop
Invariants
Software Testing and Verification Lecture Notes
24

• Prepared by
• Stephen M. Thebaut, Ph.D.
• University of Florida
