Title: Connecting with Computer Science, 2e


1
Connecting with Computer Science, 2e
  • Chapter 15
  • Programming II

2
Objectives
  • In this chapter you will
  • Gain an understanding of the basics of high-level
    programming languages, using Java and C as
    examples
  • Learn about variable types in Java and C and
    how theyre used
  • Explore the different control structures in Java
    and C

3
Why You Need to Know About... Programming
Languages
  • Time, money, and effort go into learning computer
    programming languages
  • The only real way to learn is practice, practice,
    and more practice
  • After reading this chapter, you must sit down at
    the computer and practice the concepts frequently

4
Java and C Programming Languages
  • Criteria for choosing a programming language
  • Tasks to perform
  • Programmers skill level
  • Programs lifetime
  • Software complexity being designed
  • C and Java characteristics
  • Support an object-oriented environment
  • Usable on different operating systems
  • Provide strong foundation for learning how to
    program
  • Provide a springboard to other languages

5
Learning to Cook with Java and C
  • Four ingredients to write programs
  • Variables
  • Operators
  • Control structures
  • Objects
  • Java and C high-level programming languages
    provide computer interaction
  • Without speaking in binary 1s and 0s

6
Learning to Cook with Java and C (contd.)
  • Java history
  • Designed for Internet use
  • Introduced by Sun Microsystems in 1995
  • Intended for small tasks or small applications
    (i.e., applets)
  • No need to write entire programs
  • Developed into full-blown programming language
  • Language of choice to develop communication
    devices and media applications (e.g., PDAs, cell
    phones, Internet, and networks)

7
Learning to Cook with Java and C (contd.)
  • Javas advantages
  • Uses familiar syntax
  • Very portable
  • Powerful and popular
  • C history
  • Created by Bjarne Stroustrup at Bell Labs in 1983
  • Based on C with added features
  • Object-oriented programming language
  • Offers simplified memory management and access to
    low-level memory

8
Variables
  • Have specific effects on a programs outcome
  • Must have an identifier or name prior to use
  • Declaration statement associating an identifier
    with a variable, an action, or another
    programming element
  • When declared, you specify attributes
  • Identifier (name)
  • Type (character, numeric, Boolean, and so forth)
  • Content
  • Example int numTicketsBought

9
Variable Naming Conventions
  • Rules for declaring a variable in Java or C
  • Use only letters, underscores, numbers
  • Begin name with a letter
  • Avoid Java and C reserved words
  • Reserved word
  • Keyword with a specific instructional meaning
  • Name cannot be used for a variable
  • Programming language already using it as an
    instruction

10
Variable Types
  • Java and C are strongly typed
  • Must declare type of data a variable can hold
  • Major Java data types
  • Six number-related data types
  • One character related
  • One for true and false (Boolean)
  • Major C data types
  • Adds a type for signed or unsigned numbers
  • Syntax for declaring a variable
  • type variableName

11
Integer Data Types
  • Used for positive and negative whole numbers
  • Java example
  • int studentTickets
  • short studentFees
  • long studentTuition
  • byte studentGrade
  • C example
  • int studentTickets
  • short int studentFees
  • unsigned int totalPoints

12
Integer Data Types (contd.)
Table 15-1, Java integer data types
Table 15-2, C integer data types
13
Floating-Point Data Types
  • Used for positive and negative numbers containing
    decimals
  • Examples of declaring variables in both
    languages
  • float salary
  • double billGatesSalary

14
Floating-Point Data Types (contd.)
Table 15-3, Java floating-point data types
Table 15-4, C floating-point data types
15
Character Data Type
  • Used for variables holding only one character
  • Example char studentMiddleInit

Table 15-5, Java character data type
Table 15-6, C character data types
16
Boolean Data Type
  • Used for only one of two values true or false
  • Java and C
  • Cannot associate a number with a Boolean value
  • Rely on true or false
  • Java Boolean variable declaration
  • boolean deserveRaise
  • C Boolean variable declaration
  • bool deserveRaise

17
Boolean Data Type (contd.)
Table 15-8, C Boolean data type
Table 15-7, Java Boolean data type
18
String Data Type
  • Stores a piece of information
  • Not a number
  • Contains more than one character
  • Declared using double quotes
  • Uses the String or string keywords
  • Examples of an empty string
  • String sName //Java String
  • string sName //C string

19
String Data Type (contd.)
  • Examples of a string with contents assigned
  • String sName "Joe Blow" //Java
  • string sName "Joe Blow" //C
  • Concatenation operator
  • The () operator
  • Process of combining or joining strings into one
    value
  • See example code on pages 517518

20
Hungarian Notation
  • Variable-naming method
  • Adds a letter at the beginning of a variable name
  • Indicates data type

Table 15-9, Hungarian notation examples
21
Variable Content
  • When variable is declared
  • Use an equal sign () to assign a value
    immediately
  • Variable initialization supplying value when
    variable is first declared
  • Do not always have to initialize a variable
  • Programming language may assign a default value
  • Example
  • int iStudentCount
  • iStudentCount 456
  • Alternative
  • int iStudentCount 456

22
Variable Content (contd.)
  • Assigning a value to a character variable
  • Enclose in single quotes
  • Example
  • char cMiddleInit
  • cMiddleInit 'S'
  • Alternative
  • char cMiddleInit 'S'

23
Variable Content (contd.)
  • Assigning a value to a string variable
  • Enclose in double quotes
  • Example
  • String sMiddleName "S" //Java
  • string sMiddleName "S" //C

24
Java and C Control Structuresand Program Flow
  • Four types of control structures
  • Invocation
  • Top down
  • Selection
  • Repetition
  • Correct use allows for a(n)
  • Readable program
  • Easy to maintain program

25
Invocation
  • The main() function block of code
  • Tells operating system the starting point
  • Function block of code performing a task
  • Can return a value
  • Example Save_Ferris.java file

public class Save_Ferris public static void
main(String args) System.out.println("I could
have been the Walrus!")
26
Invocation (contd.)
  • Parameters received value assigned to a variable
  • Used by a block of source code
  • Passing parameters as values
  • Enter them on same line
  • After Java program name
  • Example C\gthello 10
  • C has a main() function in every program
  • Software engineers often include other files of
    source code to perform common task

27
Invocation (contd.)
  • C allows words inside parentheses
  • Indicates parameters receiving data when the
    program runs
  • Parameters allow users to pass data to main() and
    then use the data in the program
  • Examples
  • int argc, char argv
  • //C main receiving parameters
  • int main(int argc, char argv)

28
Top Down (or Sequence)
  • Used when program statements executed in
    sequential order
  • Starting at the top and working down to the
    bottom
  • See example code on pages 522 and 523

29
Blocks of Code
  • Sequence of several statements enclosed with
    opening and closing braces
  • Indicates a relation
  • Makes program more readable and accurate
  • Braces are used most often when working with
    invocation, selection, repetition control
    structures
  • Example

30
Java Output Data
  • Java System.out statement sends data to output
    device
  • Insertion point where the cursor is placed
  • Two methods to output data
  • System.out.print(expression)
  • System.out.println(expression)

31
Java Output Data (contd.)
Table 15-10 Java output statements
32
C Output Data
  • C cout statement
  • Sends data to output device
  • Uses redirection symbols (ltlt) to direct output
  • Example
  • cout ltlt "15 10 " ltlt iResult ltltendl
  • Instructs compiler to direct anything following
    the ltlt symbols to the defined output device

33
C Output Data (contd.)
Table 15-11, Sample C output statements
34
Input Data
  • Java System.in
  • Method to retrieve data from the input device
  • Must create a new variable from the Scanner class
  • Reads characters from input stream (keyboard)
  • Places them into another variable acting as a
    memory buffer for storing the entered string
  • Input assigned to a string variable declared by
    making a call to the next() method
  • C cin
  • Used to retrieve data from input device

35
Back to Control Structures
  • Java and C invocation
  • Implemented by calling functions and methods
  • Function performs a task, can return a value
  • Method function belonging to a class
  • Java equals() method
  • System passes control to code associated with
    equals()
  • Carries out the statements
  • Makes the comparison
  • Returns a Boolean value

36
Selection
  • First write algorithm with pseudocode
  • Ensures program meets language requirements
  • Guide or template for writing source code
  • Recall Chapter 14 algorithm converting Celsius to
    Fahrenheit temperatures and vice versa
  • See corresponding code on pages 531533

37
if and if-else Statements
  • Used to weigh results of decision making
  • Result exists for every choice
  • Syntax

if (condition) one or more statements
38
if and if-else Statements (contd.)
  • Condition
  • Expression returning true or false value
  • May add an else part to the control structure
  • Performs a function if the if control structure
    evaluates to a false value
  • Syntax

if (condition) one or more statements
else one or more statements
39
if-else-if Statement
  • Corrects problem in if-else statement
  • User enters incorrect input value
  • Allows certain blocks of code to execute
  • Depends on variables state in the program while
    it is running
  • Easy to use
  • Makes program more flexible

40
switch Statement
  • Nesting
  • Putting one control structure inside another
  • Decreases codes readability
  • switch statement
  • Allows testing of many options
  • Groups blocks of code to be executed depending on
    results
  • Test expressions value
  • Jump to some location in the switch statement
  • Expression must be a scalar data type

41
switch Statement (contd.)
Copy editor Syntax alignment OK as is?
(different in PDF)
  • break statement at end of each case
  • Informs system to quit processing case statements
  • Sends control to end of the switch statement
  • Syntax

switch (expression) case value_1
statement_1 break case value_2
statement_2 break case value_3
statement_3 break default statement_4 break

42
Repetition (Looping)
  • Allows repeating statements multiple times
  • No statement retyping
  • Three statements
  • for
  • while
  • do-while

43
for Statement
  • Used to repeat a group of statements a known
    number of times
  • Variable declaration
  • Declare and initialize a variable
  • Declare counter variable
  • Example int iCount
  • Syntax

for (variable declaration expression
increment/decrement) statement(s)
44
while Statement
  • Processes a group of statements a certain number
    of times
  • Like the for loop
  • Precondition loop
  • Loop checks the expression before any source code
    in the loop is executed
  • Might never be executed
  • Difference between for and while loops
  • while statement doesnt provide a specified area
    for updating the counter

45
while Statement (contd.)
  • Syntax

while (expression) statements
46
do-while Statement
  • Used when looping is based on an expression and
    statements are repeated before the expression is
    evaluated
  • Mainly when processing a table
  • Postcondition loop
  • Executes at least one time before the expression
    is evaluated
  • Syntax

do statement(s) while (expression)
47
One Last Thought
  • Most programming languages use the four major
    control structures discussed in this chapter
  • Organizations select a programming language based
    on applications needs
  • Programmers may need to update skills
  • C and Java is a good start
  • Must practice to become proficient
  • Software engineers responsibility write
    easy-to-read and easy-to-maintain structured
    programs

48
Summary
  • Java high-level programming language designed
    for the Internet
  • C high-level programming language based on the
    C language
  • Incorporates object-oriented principles
  • Variables
  • Integer (int), character (char), floating point,
    Boolean, and string
  • Initializing a variable assigning a value to a
    variable

49
Summary (contd.)
  • Four high-level programming language control
    structures
  • Invocation, top down, selection, repetition
  • Java uses methods for the invocation
  • C uses methods and functions
  • Output data
  • Java uses the System.out statement
  • C use the cout statement with the ltlt
    redirection symbols

50
Summary (contd.)
  • Input data
  • Java Scanner class gathers input
  • C uses the cin statement
  • Selection control structures
  • C and Java use if, if-else, if-else-if, switch
  • switch statement is used only with scalar
    variables
  • Repetition
  • C and Java use for, while, do-while loops
  • Practice, practice, and more practice
Write a Comment
User Comments (0)
About PowerShow.com
