EEG / MEG: Experimental Design

1
EEG / MEG Experimental Design Preprocessing

• Alexandra Hopkins
• Jennifer Jung

2
Outline

• Experimental Design
• fMRI M/EEG
• Analysis
• Oscillatory activity
• EP
• Design
• Inferences
• Limitations
• Combined Measures

• Preprocessing in SPM12
• Data Conversion
• Montage Mapping
• Epoching
• Downsampling
• Filtering
• Artefact Removal
• Referencing

3
MEG vs. EEG

• Both EEG and MEG signals arise from direct
  neuronal activity
• -gt postsynaptic dendritic potentials
• Electric field is distorted by changes in
  conductivity across different layers unlike
  magnetic field
• High temporal resolution ms.

4
Sources of M/EEG signals

• MEG sensors only detect tangential components of
  fields from cortical pyramidal neurons
• Less sensitive to deeper regions
• EEG signal consists of both tangential and radial
  components of fields

gyrus
sulcus
5
(No Transcript)
6
Two types of MEG/EEG analysis
Event related changes (EP / ERP ERF)
Oscillatory activity cortical rhythms
(Time-frequency analysis)
Time locked to stimulus
Otten, L. (2012, November 21). EEG/MEG
Acquisition, Analysis and Interpretation, MSc
Cognitive Neuroscience, UCL
7
Event Related Changes
pre-stim
post-stim
Repeats at same time
Averaging
evoked response
When response is time locked - signal averages
in!
8
Evoked vs. Induced
Average trial by trial
With jitter effect - signal averages out!
(Hermann et al. 2004)
9
Oscillatory activity
active awake state
resting state
falling asleep
sleep
deep sleep
coma
50 uV
1 sec
ongoing rhythms
10
Oscillations

• Non-averaged data collected during continuous
  stimulation or task performance (or during rest)
  lends itself to analysis of spectral power.
• Signals can be decomposed into a sum of pure
  frequency components which gives information on
  the signal power at each frequency.
• i.e. We can do Fourier analysis and look at
  spectra (not-event related break data in
  arbitrary segments and do some averaging

11
(8 12or 13 Hz)

• Cortical and behavioral deactivation or
  inhibition
• Closed eyes

(12 30 Hz)
Alert, REM sleep Attention, and higher cognitive
function

• (30 80 Hz)

Visual awareness Binding of information Encoding,
retention and
(0 4 Hz)
Attentional and syntactic language processes Deep
sleep
(4 8 Hz)
Codes locations in space, navigation Declarative/e
pisodic memory processes Successful memory
encoding
12
EP vs. ERP / ERF

• Evoked potential (EP)
• sensory processes
• short latencies (lt 100ms)
• small amplitudes (lt 1µV)
• Event related potential (EEG) / event related
  field (ERF)
• higher cognitive processes
• longer latencies (100 600ms),
• higher amplitudes (10 100µV)

used interchangeably in general
13
ERP/ ERF
Averaging

• Non-time locked activity(noise) lost via
  averaging over trials

14
Experimental design

• Number of trials
• EP 120 trials, 15-20 will be excluded
• Oscillatory activity 40-50 trials
• Duration of stimuli / task
• Short Averaged EP is fine
• (Very) long spectrotemporal analysis on averaged
  EP or non-averaged data
• Collecting Behavioral Responses

15
Inferences Not Based On Prior Knowledge
Observation
Inference

• Same ERP pattern
• Timing signals
• Distribution across scalp
• Differences in ERP across conditions and time

• Invariant patterns of neural activity from
  specific cognitive processes
• Timing of cognitive processes
• Degree of engagement
• Functional equivalence of underlying cognitive
  process

16
Observed vs Latent Components
Latent components
Observed waveform
OR
17
Design Strategies

• Focus on specific, large and easily isolated
  component
• E.g., P3, N400, LRP, N2pc
• Use well-studied experimental manipulations
• Similar conditions
• Component-independent experimental designs
• Very hard to study anything interesting

Luck, Ten Simple Rules for Designing and
Interpreting ERP Experiments
18
How quickly can the visual system differentiate
between different classes of object?
Component-independent experimental designs
Thorpe et al (1996)
19
Design Strategies

• Avoid confounds and misinterpretations
• Physical stimulus confounds
• Side effect
• What you manipulated indirectly influences other
  things
• Vary conditions within rather than between blocks
• Fatigue effect
• Be cautious of behavioural confounds
• Motor evoked potentials (MEPs)

20
Sources of Noise in M/EEG

• M/EEG activity not elicited by stimuli
• e.g. alpha waves ? relaxed but alert
• Trial-to-trial variability in the ERP components
• variations in neural and cognitive activity ?
  trial by trial consistency
• Artefactual bioelectric activity
• eye blinks, eye movement, cardiac and muscular
  activity, skin potentials ? keep electrode
  impedances low
• Environmental electrical activity
• power lines, SQUID jumps, noisy, broken or
  saturated sensors ? shielding

21
Signal-to-Noise Ratio

• Size of the noise in average (1/vN) R
• Number of trials
• Large component 30 60 per condition
• Medium component 150 200 per condition
• Small component 400 800 per condition
• Double with children or psychiatric patients

22
Limitations

• Ambiguous relation between observed ERP and
  latent components
• Signal distorted en route to scalp
• arguably worse in EEG than MEG (head as
  spherical conductor)
• MEG restrictions with magnetic implants
• Poor localization (cf. inverse problem)

23
Combining Techniques

• Why? How?
• Converging evidence, generative models
• fMRI EEG, fMRI MEG
• Drawbacks
• Signal interference
• Complex experimental design

24
Outline

• Experimental Design
• fMRI M/EEG
• Analysis
• Oscillatory activity
• EP
• Design
• Inferences
• Limitations
• Combined Measures

• Preprocessing in SPM12
• Data Conversion
• Montage Mapping
• Epoching
• Downsampling
• Filtering
• Artefact Removal
• Referencing

25
PREPROCESSING IN SPM12

• Goal get from raw data to averaged ERP (EEG) or
  ERF (MEG) using SPM12

26
Conversion of data

• Convert data from its native machine-dependent
  format to MATLAB based SPM format

27
Data Conversion

• Define settings
• Read data as continuous or as trials (is raw data
  already divided into trials?)
• Select channels
• Define file name
• just read option is a convenient way to look at
  all the data quickly

28
Data Conversion - Example

• 128 channels selected
• Unusually flat because data contain very low
  frequencies and baseline shifts
• Viewing all channels only with a low gain

29
Downsampling

• Sampling frequency is very high at acquisition
  (e.g. 2048 Hz)
• Downsampling is required for efficient data
  storage
• Sampling rate gt 2 x highest frequency in the
  signal of interest The Nyquist frequency

30
Downsampling
31
Aliasing
Sampling below Nyquist frequency will introduce
artefacts known as aliases.
32
Downsampling SPM 12 Interface

• Downsampling reduces the file size and speeds up
  the subsequent processing steps
• At least 2x low pass filter
• e.g. 1000 to 200 Hz.

33
Montaging Referencing

• Montage - representation of EEG channels
• Referential montage - have a reference electrode
  for each channel
• Identify vEOG and hEOG channels, remove several
  channels that dont carry EEG data.
• Specify reference for remaining channels
• Single electrode reference free from neural
  activity of interest e.g. Cz
• Average reference Output of all amplifiers are
  summed and averaged and the averaged signal is
  used as a common reference for each channel, like
  a virtual electrode and less biased

34
RE-referencing
35
Montage Referencing SPM 12 Interface
36
Montage Referencing SPM 12 Interface
Review channel mapping
37
Epoching
Cut out chunks of continuous data ( single
trials, referenced to stim onset)
EEG1
EEG2
EEG3
Event 1
Event 2
38
Epoching

• Specify time
• e.g. 100 ms prestimulus - 600 ms poststimulus
  single epoch/trial
• Baseline-correction automatic mean of the
  pre-stimulus time is subtracted from the whole
  trial
• Padding adds time points before and after each
• trial to avoid edge effects when
  filtering

39
Epoching SPM 12 Interface
40
Filtering

• M/EEG data consist of signal and noise
• Noise of different frequency filter it out
• Any filter distorts at least some part of the
  signal but reduces file size
• Focus on signal of interest - boost signal to
  noise ratio
• SPM12 Butterworth filter
• High-, low-, band-pass or bandstop filter

41
Types of Filters

• High-pass filters out low-frequency noise,
  removes the DC offset and slow drifts in the
  data e.g. sweat and non-neural physiological
  activity
• Low-pass remove high-frequency noise. Similar
  to smoothing e.g. muscle activity, neck
• Notch (band-stop) remove artefacts limited in
  frequency, most commonly electrical line noise
  and its harmonics. Usually around 50/60Hz.
• Band-pass focus on the frequency of interest
  and remove the rest. More suitable for relatively
  narrow frequency ranges.

42
Examples of Filters
43
Bandpass Filter
44
Filtering SPM 12 Interface
45
Artefacts
46
Removing Artefacts
EASY

• Removal
• Visual inspection - reject trials
• Automatic SPM functions
• Thresholding (e.g. 200 µV)
• 1st bad channels, 2nd bad trials
• No change to data, just tagged
• Robust averaging estimates weights (0-1)
  indicating how artefactual a trial is

47
Robust Averaging
48
Removing Artefacts
HARDER

• Use your EoG!
• Regress out of your signal
• Use Independent Component Analysis (ICA)
• Eyeblinks are very stereotyped and large
• Usually 1st component

49
(No Transcript)
50
Special thanks to our expertsBernadette and
Vladimir Litvak
51
References

• Ashburner, J. et al. (2010). SPM8 Manual.
  http//www.fil.ion.ucl.ac.uk/spm/
• Hansen, C.P., Kringelbach M.L., Salmelin, R.
  (2010) MEG An Introduction to Methods. Oxford
  University Press,
• Hermann, C. et al. (2004). Cognitive functions of
  gammaband activity memory match and utilization.
  Trends in Cognitive Science, 8(8), 347-355.
• Herrmann, C. S., Grigutsch, M., Busch, N.
  A. (2005). EEG oscillations and wavelet analysis.
  In T. C. Handy (Ed.), Event-related potentials A
  methods handbook (pp. 229-259). Cambridge, MA
  MIT Press.
• Luck, S. J. (2005). Ten simple rules for
  designing ERP experiments. In T. C. Handy (Ed.),
  Event-related potentials a methods handbook.
  Cambridge, MA MIT Press.
• Luck, S. J. (2010). Powerpoint Slides from ERP
  Boot Camp Lectures. http//erpinfo.org/Members/ldt
  ien/bootcamp-lecture-pptx
• Otten, L. (2012, November 21). EEG/MEG
  Acquisition, Analysis and Interpretation, MSc
  Cognitive Neuroscience, UCL
• Otten, L. J. Rugg, M. D. (2005). Interpreting
  event-related brain potentials. In T. C. Handy
  (Ed.), Event-related potentials a methods
  handbook. Cambridge, MA MIT Press..
• Sauseng, P., Klimesch, W. (2008). What does
  phase information of oscillatory brain activity
  tell us about cognitive processes? Review.
  Neuroscience and Biobehavioral Reviews, 32(5),
  1001-1013. doi 10.1016/j.neubiorev.2008.03.014
• http//sccn.ucsd.edu/jung/artifact.html
• MfD slides from previous years
