Preserving Scientific Data

1
Preserving Scientific Data

• Jamie Shiers, Information Technology Department,
  CERN, Geneva, Switzerland

2
Agenda

• Motivation for preserving scientific data
  examples from a range of sciences
• Volume of data involved and related issues
• Some concrete archiving examples from Particle
  Physics
• Remaining challenges
• Conclusions

3
Motivation

• Climate data in an era when climate change is
  hotly debated, the motivations appear clear
• Medical data important for understanding issues
  such as historical pandemics, cross-species
  diseases etc. Avian flu, HIV,
• Cosmological data plays a vital role in our
  evolving understanding of the Universe
  astrophysics community has an explicit policy
  (data is made public after 1 year data volume
  doubles each year)
• Particle Physics data Similar arguments will
  we ever be able to build similar accelerators to
  those of today? If we lose this data, what of
  our scientific heritage? Need to look at old data
  for a signal that should have been seen (has
  happened several times)

4
Standard Cosmology Good model from 0.01
sec after Big Bang Supported by considerable
observational evidence
Elementary Particle Physics From the Standard
Model into the unknown towards energies of 1 TeV
and beyond the Terascale
Towards Quantum Gravity From the unknown into
the unknown...
http//www.damtp.cam.ac.uk/user/gr/public/bb_histo
ry.html
5
Issues

• How much data is involved?
• Preserving the bits
• Understanding the bits

6
How much data is involved?

• In 1998, the following estimates were made
  regarding the data from LEP (1989 2000) that
  should be kept

Experiment Analysis dataset Reconstructable dataset
ALEPH 250GB 1-2TB
DELPHI 2-6TB
L3 500GB 5TB
OPAL 300GB 1-2TB

• By todays standards, these data volumes are
  trivial
• Even though the total volume of data at the LHC
  is much much higher, the data that must be kept
  beyond the life of the machine (2007 to 2020)
  will be easily handled by then
• The LHC will generate some 15PB of data per year!

7
The LHC machine - Overview
Introduction Status of LHCb ATLAS
ALICE CMS Conclusions
8
The size of HEP detectors
Introduction Status of LHCb ATLAS
ALICE CMS Conclusions
ATLAS
Bld. 40
CMS
9
Understanding the bits

• In the mid-1990s, a successful re-analysis of
  10-year old data from the JADE collaboration at
  the PETRA accelerator at DESY was made
• A sub-set of the data was found abandoned in an
  office corner. The programs to read the data were
  in an obsolete language and were unusable. The
  data format was proprietary (but de-codable).
• This provided valuable input into the LEP data
  archive
• Data format will this be readable in 5 / 10 /
  100 years? 1000?
• Programs languages / operating systems /
  hardware platforms have very short life-spans wrt
  an archive
• Metadata essential to understand what the data
  means
• The best solution to date is a so-called Museum
  system, but this is still a very short term
  solution wrt even Einstein, let alone Tyco Brahe,
  Kepler and Newton

10
Preserving the bits

• Lifetimes of Particle Physics experiments are
  extremely long! Currently measured in decades
• Ironically, one of the solutions proposed for the
  LEP data archive (the then-current proposal for
  the LHC) was later abandoned (technical /
  commercial reasons)
• This necessitated a triple migration
• Of 300TB of data between storage media
• Of the same data from one data format to another
• Of the accompanying processing codes.
• In the end, the exercise took around 2 months per
  100TB of data migrated, as well as a significant
  amount of effort (1 FTE / 100TB) and hardware
  resources

11
Outstanding Issues

• There are no data formats, programming languages,
  computing hardware or operating systems with
  lifetimes that can be guaranteed beyond the short
  term
• Virtual machine technology may extend an
  environments (see above) natural life perhaps
  doubling it
• Reducing the data into a much simplified and
  widely-used format can have significant
  advantages, but only allows restricted analyses
  to be performed
• Preserving the detailed knowledge of the
  experimental apparatus is beyond current
  technology it would require extreme discipline
  on behalf of the researchers as well as major
  advances in the understanding and description of
  metadata

12
Conclusions

• As long as advances in storage capacity continue,
  there are no significant issues related to the
  volume of scientific data that must be kept
• Periodic migration between different types of
  storage media must be foreseen
• Specific storage formats must also be catered for
  this can require much more significant (time
  consuming and expensive) migrations
• By far the biggest problem concerns understanding
  the data there is currently no clear solution
  in this domain

13
References

• LEP Data archive
• 1997 http//s.web.cern.ch/s/sticklan/www/archive/

• 2002 http//mgt-focus.web.cern.ch/mgt-focus/Focus
  25/maggim.pdf
• 2003 http//cern.ch/pfeiffer/LEP-Data-Archive/pro
  posal/ProposalForTheLEPDataArchive.html
• http//tenchini.home.cern.ch/tenchini/Status_Archi
  ving_6_Mar_2003.pdf
• Lisbon workshop
• http//cern.ch/knobloch/talks/CernCodataLisbon.ppt

• http//www.erpanet.org/events/2003/lisbon/LisbonRe
  portFinal.pdf
• COMPASS / HARP data migrations
• http//storageconference.org/2003/papers/06-Lubeck
  -Overview.pdf
• http//www.slac.stanford.edu/econf/C0303241/proc/p
  apers/THKT001.PDF
• http//indico.cern.ch/getFile.py/access?contribId
  448sessionId24resId1materialIdpaperconfId0


14
Acknowledgements

• The following people provided material and / or
  pointers for this talk (knowingly or otherwise)
• LEP Data Archive coordinators
• David Stickland, David.Stickland_at_cern.ch (L3)
• Andreas Pfeiffer, Andreas.Pfeiffer_at_cern.ch
• Marcello Maggi, Marcello.Maggi_at_ba.infn.it (ALEPH)
• COMPASS / HARP migrations
• Andrea Valassi, Andrea.Valassi_at_cern.ch
• ERPANET/CODATA Workshop
• Jürgen Knobloch, Juergen.Knobloch_at_cern.ch

15
The End
