Title: Rolling, Torque, and Angular Momentum


1
Rolling, Torque, and Angular Momentum
  • AP Physics C
  • Montwood High School
  • R. Casao

2
Rolling
  • When a wheel moves along a straight track, the
    center of the wheel moves forward in pure
    translation.
  • A point on the rim of the wheel traces out a
    complex path called a cycloid.

3
  • For a wheel passing at constant speed while
    rolling smoothly (no sliding)
  • the center of mass O of the wheel moves forward
    at constant speed vcom.
  • the point P where the wheel makes contact with
    the surface also moves forward at speed vcom so
    that it remains directly below the center of mass
    O.
  • During time interval t, both
  • O and P move forward by
  • a distance s. Observers
  • see the wheel rotate thru an
  • angle q about the center of
  • the wheel.

4
  • The point on the wheel P that was touching the
    surface at t 0 s moves through an arc length s.
  • Equations s R? vcom ds/dt ? d?/dt
  • Differentiating the arc length equation wrt time
    ds/dt Rd?/dt to give us vcom R?.

5
  • The rolling motion of a wheel is a combination of
    purely translational and purely rotational
    motions.
  • Every point on the wheel rotates about the center
    with angular speed ?.
  • Every point on the outside edge of the wheel has
    linear speed vcom.
  • Purely translational motion every point on the
    wheel moves forward with speed vcom.
  • Combination of rotational motion and
    translational motion produces the rolling motion
    of the wheel.

6
(No Transcript)
7
  • The portion of the wheel at the bottom (point P)
    is stationary and the top of the wheel is moving
    at speed 2vcom. The wheel is moving fastest
    near the top than near the bottom because the
    spokes are more blurred at the top than at the
    bottom.

8
Kinetic Energy of Rolling
  • Consider the rolling motion about an axis thru
    point P K 0.5Ip?²
  • Ip is the rotational inertia of wheel about axis
    thru point P and ? is the angular speed of the
    wheel.
  • Apply the parallel-axis theorem to determine Ip
  • Ip Icom Mh² for the wheel, h R
  • Substituting
  • K 0.5Icom?² 0.5MR²?²
  • Because vcom R?,
  • K 0.5Icom?² 0.5Mvcom²

9
  • A rolling object has two types of kinetic energy
    a rotational kinetic energy (0.5Icom?²) due to
    its rotation about its center of mass and a
    translational kinetic energy (0.5Mvcom²) due to
    translation of its center of mass.
  • Forces of Rolling
  • If a wheel rolls at constant speed it has no
    tendency to slide at the point of contact P and
    no frictional force acts there acom 0 at point
    P.
  • If a net force acts on the rolling wheel to speed
    it up or slow it down, the net force causes an
    acceleration of the center of mass along the
    direction of travel.

10
  • The wheel also rotates faster or slower, so an
    angular acceleration ? occurs about the center of
    mass.
  • These accelerations tend to make the wheel slide
    at point P and a frictional force must act on the
    wheel at P to oppose the tendency to slide.
  • If the wheel does NOT slide, the force is a
    static frictional force fs and the motion is
    smooth rolling motion.
  • Smooth rolling motion acom R?
  • If the wheel does slide when the net force acts
    on it, the frictional force that acts at P is a
    kinetic frictional force and the motion is not
  • smooth rolling motion.

11
Rolling Down a Ramp
  • For a uniform body of mass M and radius R rolling
    smoothly down a ramp at angle ? along an x axis.
  • The normal force N acts at
  • point P but has been shifted
  • up to the center of mass.
  • Static frictional force fs acts
  • at point P and is directed
  • up the incline. If the body
  • were to slide down the
  • incline, the frictional force
  • would oppose that motion.

12
  • Motion along the x-axis (up as positive)
  • fs Mgsin ? Macom
  • Angular motion Torque I?
  • N and Fgsin ? pass thru the pivot at the center
    of mass and do not produce a torque.
  • fs applied perpendicularly a distance R at point
    P and produces a torque.
  • Torque F?r? fsR fsR Icom?
  • -acom R? acom is negative because it is
    directed in the negative direction on the x-axis.
    Unlike the linear motion problems we have done
    in the past where we took the direction of motion
    as positive, with the rotation involved, we take
    the positive direction as the positive direction
    of the rotation (ccw positive cw negative).

13
  • Solve for ? and substitute ? -acom/R
  • fsR Icom -acom/R

14
Yo-Yo
  • As yo-yo rolls down its string from height h,
    potential energy mgh is converted to both
    rotational (0.5Icom?²) and translational
    kinetic energy (0.5Mvcom²). As it climbs back
    up, kinetic energy is converted to potential
    energy.
  • The string is looped around the axle and when the
    yo-yo hits the bottom of the string, an upward
    force on the axle from the string stops the
    descent.
  • The yo-yo spins with the axle inside the loop
    with only rotational kinetic energy.

15
  • The yo-yo spins until you jerk on the string to
    cause the string to catch on the axle and allow
    the yo-yo to climb back up.
  • The rotational kinetic energy of the yo-yo at the
    bottom of the string can be increased by throwing
    the yo-yo downward so that it starts down the
    string with initial speeds vcom and ? instead of
    rolling down from rest.
  • The yo-yo rolls on the axle of radius Ro.
  • The yo-yo is slowed by the tension force T from
    the string on the axle.

16
  • Acceleration equation
  • the yo-yo has the same downward acceleration
    when it is climbing back up the string because
    the forces acting on it are still those shown in
    the figure.
  • Torque Revisited
  • We previously defined torque for a rigid body
    that rotated about a fixed axis in a circle.
  • To define the torque for an individual particle
    that moves along any path relative to a fixed
    point (rather than a fixed axis), the path
    doesnt have to be a circle and the torque has to
    be written as a vector.

17
  • The figure shows a particle at point A in the xy
    plane with a single force F acting on the
    particle.
  • The particles position relative to the origin O
    is given by the position vector r.
  • Torque equation

18
  • To find the direction of the torque, slide the
    force vector without changing its direction until
    its tail is at the origin O so that it is tail to
    tail with the position vector.
  • Use the right hand rule to rotate the position
    vector r into the force vector F. The thumb
    points in the direction of the torque.

19
  • The magnitude of the torque is given by
  • ? is the angle between the position vector r and
    the force vector F.
  • Angular Momentum
  • The figure shows a particle of mass
  • m with linear momentum p mv
  • as it passes thru point a in the xy
  • plane. The angular momentum l of
  • the particle with respect to the
  • origin O is

20
  • r is the position vector of the particle wrt O.
  • As the particle moves wrt O in the direction of
    its momentum p, the position vector r rotates
    around O.
  • To have angular momentum, the
  • particle itself does not have to
  • rotate around O.
  • Unit for angular momentum
  • kgm²/s Js
  • The direction of the angular
  • momentum vector is found by
  • sliding the vector p until its tail
  • is at the origin O.

21
  • Use the right-hand rule, rotating the vector r
    into vector p. The thumb points in the direction
    of the angular momentum vector.
  • The magnitude of the angular momentum vector is
    l rmvsin ?, where ? is the angle between r
    and p when the two vectors are tail to tail.
  • Angular momentum only has meaning wrt a specific
    origin.
  • The direction of the angular momentum vector is
    always perpendicular to the plane formed by the
    position vector and the linear momentum vector.

22
Newtons Second Law in Angular Form
  • Fnet dp/dt expresses the close relation between
    force and linear momentum for a single particle.
  • There is also a close relationship between torque
    and angular momentum Tnet dl/dt
  • The vector sums of all the torques acting on a
    particle is equal to the time rate of change in
    the angular momentum of that particle.
  • The torques and angular momentum are both defined
    wrt the same origin.

23
Angular Momentum of a System of Particles
  • For a system of particles with respect to an
    origin, the total angular momentum L of the
    system is the vector sum of the angular momenta l
    of the individual particles
  • Over time, the angular momenta of individual
    particles may change due to interactions within
    the system between individual particles or
    because of outside influences on the system.

24
  • Since Tnet dl/dt, then
  • The rate of change of the systems angular
    momentum L is equal to the vector sum of the
    torques on the individual particles.
  • These torques include internal torques due to
    forces between particles and external torques due
    to forces on the particles from bodies outside of
    the system.
  • The forces between particles always occur in 3rd
    law pairs so their torques cancel each other, so
    the only torques that can change the total
    angular momentum L of a system are external
  • torques.

25
  • 2nd law for rotation of a system of particles
    the net external torque Tnet acting on a system
    of particles is equal to the time rate of change
    of the systems total angular momentum L.
  • The torque and the systems angular momentum must
    be measured from the same origin.
  • Angular Momentum of a Rigid Body Rotating About a
    Fixed Axis
  • For a system of particles that form a rigid body
    that rotates about a fixed axis rotating with
    constant angular speed ? L I?

26
Conservation of Angular Momentum
  • If the net external torque acting on a system is
    zero, the angular momentum L of the system
    remains constant, no matter what changes take
    place within the system Li Lf Iiwi Ifwf
  • Because momentum is a vector quantity , the
    conservation of momentum has to be considered in
    all three dimensions (x, y, z). Depending on the
    torques acting on a system, the angular momentum
    of the system might be conserved in only 1 or 2
    directions but not in all directions.

27
(11-16)
28
(No Transcript)
29
(No Transcript)
