Energy, Enzymes, and Metabolism

1
Energy, Enzymes, and Metabolism
2
Energy, Enzymes, and Metabolism

• Energy and Energy Conversions
• ATP Transferring Energy in Cells
• Enzymes Biological Catalysts
• Molecular Structure Determines Enzyme Function
• Metabolism and the Regulation of Enzymes

3
Energy and Energy Conversions

• To physicists, energy represents the capacity to
  do work.
• To biochemists, energy represents the capacity
  for change.
• Cells must acquire energy from their environment.
• Cells cannot make energy energy is neither
  created nor destroyed, but energy can be
  transformed.
• In life, energy transformations consist primarily
  of movement of molecules and changes in chemical
  bonds.

4
Energy and Energy Conversions

• There are two main types of energy
• Potential energy is energy of state or
  positionit is stored energy.
• Kinetic energy is the energy of movement. Kinetic
  energy does work that alters the state or motion
  of matter.

5
Figure 6.1 Energy Conversions and Work
6
Energy and Energy Conversions

• Metabolism can be divided into two types of
  activities
• Anabolic reactions link simple molecules together
  to make complex ones. These are energy-storing
  reactions.
• Catabolic reactions break down complex molecules
  into simpler ones. Some of these reactions
  provide the energy for anabolic reactions.

7
Energy and Energy Conversions

• The first law of thermodynamics states that
  During any conversion of forms of energy, the
  total initial energy will equal the total final
  energy. Energy is neither created nor destroyed.
• Although living cells are open systems (they
  exchange matter and energy with their
  surroundings), they still obey these laws.

8
Figure 6.2 (a) The Laws of Thermodynamics
9
Energy and Energy Conversions

• Second law of thermodynamics When energy is
  transformed, some becomes unavailable to do work.

• No physical process or chemical reaction is 100
  per cent efficient, that is, not all the energy
  released can be used to do work.

10
Figure 6.2 (b) The Laws of Thermodynamics
11
Energy and Energy Conversions

• In any system
• total energy usable energy unusable energy
• Or
• enthalpy (H) free energy (G) entropy (S)
• H G TS (T absolute temperature)
• Entropy is a measure of the disorder of a system.
• Usable energy
• G H TS

12
Energy and Energy Conversions

• G, H, and S cannot be measured precisely.
• Change in each at a constant temperature can be
  measured precisely in calories or joules.
• DG DH TDS
• If DG is positive (), free energy is required.
  This is the case for anabolic reactions.
• If DG is negative (), free energy is released.
  This is the case for catabolic reactions.

13
Energy and Energy Conversions

• If a chemical reaction increases entropy, its
  products are more disordered or random than its
  reactants are.
• An example is the hydrolysis of a protein to its
  amino acids. Free energy is released, DG is
  negative, and DS is positive (entropy increases).
• When proteins are made from amino acids, free
  energy is required, there are fewer products, and
  DS is negative.

14
Energy and Energy Conversions

• The second law of thermodynamics also predicts
  that, as a result of energy conversions, disorder
  tends to increase.
• This tendency for disorder to increase gives a
  directionality to physical and chemical
  processes, explaining why some reactions proceed
  in one direction rather than another.

15
Energy and Energy Conversions

• It may seem that highly complex organisms, such
  as the human body, are in apparent disagreement
  with the second law, but this is not the case.
• The metabolic processes that take place in living
  tissues produce far more disorder than the order
  present within the tissues.
• To maintain order, life requires a constant input
  of energy.

16
Energy and Energy Conversions

• Anabolic reactions may make single products from
  many smaller units such reactions consume
  energy.
• Catabolic reactions may reduce an organized
  substance (glucose) into smaller, more randomly
  distributed substances (CO2 and H2O). Such
  reactions release energy.
• There is a direct relationship between the amount
  of energy released by a reaction (DG), or the
  amount taken up (DG), and the tendency of a
  reaction to run to completion without an input of
  energy.

17
Energy and Energy Conversions

• A spontaneous reaction goes more than halfway to
  completion without input of energy, whereas a
  nonspontaneous reaction proceeds that far only
  with an input of energy.
• Spontaneous reactions are called exergonic and
  have negative DG values (they release energy).
• Nonspontaneous reactions are called endergonic
  and have positive DG values (they consume
  energy).
• If under certain conditions A B is spontaneous
  (exergonic), then B A must be nonspontaneous
  (endergonic).

18
Figure 6.3 Exergonic and Endergonic Reactions
19
Energy and Energy Conversions

• In principle, all reactions are reversible (A
  B).
• Adding more A speeds up the forward reaction, A
  B adding more B speeds up the reverse
  reaction, B A.
• At the point of chemical equilibrium, the
  relative concentrations of A and B are such that
  forward and reverse reactions take place at the
  same rate.
• Although no further net change occurs at this
  point, reactions of individual molecules continue.

20
Energy and Energy Conversions

• An example of equilibrium can be seen in the
  cellular conversion of glucose 1-phosphate to
  glucose 6-phosphate.
• At pH 7 and 25C, the concentration of the
  product rises while the concentration of the
  reactant falls.
• Equilibrium is reached when the
  product-to-reactant ratio is 191.
• At this point the forward reaction has gone 95
  percent to completion.
• The further a reaction goes toward completion in
  order to reach equilibrium, the greater the
  amount of free energy released.

21
Figure 6.4 Concentration at Equilibrium
22
ATP Transferring Energy in Cells

• All living cells use adenosine triphosphate (ATP)
  for capture, transfer, and storage of energy.
• Some of the free energy released by certain
  exergonic reactions is captured in ATP, which
  then can release free energy to drive endergonic
  reactions.
• ATP is not an unusual molecule and it has other
  uses as well for example, it can be converted
  into a building block for DNA and RNA.

23
Figure 6.5 ATP (Part 1)
24
Figure 6.5 ATP (Part 2)
25
ATP Transferring Energy in Cells

• ATP can hydrolyze to yield ADP and an inorganic
  phosphate ion (Pi).
• ATP H2O ADP Pi free energy
• The reaction is exergonic (DG 12 kcal/mol).
• Free energy of the PO bond is much higher than
  the HO bond that forms after hydrolysis.
• Phosphates are negatively charged, so energy is
  required to get them near each other to bond (to
  add a phosphate to ADP).

26
ATP Transferring Energy in Cells

• The formation of ATP from ADP and Pi, is
  endergonic and consumes as much free energy as is
  released by the breakdown of ATP
• ADP Pi free energy ATP H2O
• ATP shuttles energy from exergonic reactions to
  endergonic reactions.
• Each cell requires millions of molecules of ATP
  per second to drive its biochemical machinery.
• Each ATP molecule undergoes about 10,000 cycles
  of synthesis and hydrolysis every day.

27
Figure 6.6 The Energy-Coupling Cycle of ATP
28
Figure 6.7 Coupling ATP Hydrolysis to an
Endergonic Reaction
29
Enzymes Biological Catalysts

• A catalyst is any substance that speeds up a
  chemical reaction without itself being used up.
• Living cells use biological catalysts to increase
  rates of chemical reactions.
• Most biological catalysts are proteins called
  enzymes. Certain RNA molecules called ribozymes
  are also catalysts.

30
Enzymes Biological Catalysts

• The direction of a reaction can be predicted if
  DG is known, but not the rate of the reaction.
• Some reactions are slow because there is an
  energy barrier between reactants and products.
• Exergonic reactions proceed only after the
  addition of a small amount of added energy,
  called the activation energy (Ea).
• In a chemical reaction, activation energy is the
  energy needed to put molecules into a transition
  state.
• Transition-state species have higher free energy
  than either reactants or products.

31
Figure 6.8 Activation Energy Initiates Reactions
32
Enzymes Biological Catalysts

• Exergonic reactions often are initiated by the
  addition of heat, which increases the average
  kinetic energy of the molecules.
• However, adding heat is not an appropriate way
  for biological systems to drive reactions.
• Enzymes solve this problem by lowering the
  energy barrier.

33
Figure 6.9 Over the Energy Barrier
34
Enzymes Biological Catalysts

• Enzymes bind specific reactant molecules called
  substrates.
• Substrates bind to a particular site on the
  enzyme surface called the active site, where
  catalysis takes place.
• Enzymes are highly specific They bind specific
  substrates and catalyze particular reactions
  under certain conditions.
• The specificity of an enzyme results from the
  exact three-dimensional shape and structure of
  the active site.

35
Figure 6.10 Enzyme and Substrate
36
Enzymes Biological Catalysts

• The names of enzymes reflect their function
• RNA polymerase catalyzes formation of RNA but not
  DNA.
• RNA nuclease hydrolyzes RNA polymers.
• Hexokinase accelerates phosphorylation of hexose.

• All kinases add phosphates. All phosphatases
  remove phosphates.

37
Enzymes Biological Catalysts

• Binding a substrate to the active site produces
  an enzymesubstrate complex (ES).
• Hydrogen bonding, ionic attraction, or covalent
  bonding acting individually or together hold
  these complexes together.
• The enzymesubstrate complex (ES) generates the
  product (P) and free enzyme (E)
• E S ES E P

38
Enzymes Biological Catalysts

• Enzymes lower activation energy requirements and
  thus speed up the overall reaction, but they do
  not change the difference in free energy (DG)
  between the reactants and the products.
• Thus they do not affect the final equilibrium.
• Enzymes can have a profound effect on reaction
  rates. Reactions that might take years to happen
  can occur in a fraction of a second.

39
Figure 6.11 Enzymes Lower the Energy Barrier
40
Enzymes Biological Catalysts

• At the active sites, enzymes and substrates
  interact by breaking old bonds and forming new
  ones.
• Enzymes catalyze reactions using one or more of
  the following mechanisms
• Orienting substrates
• Adding charges to substrates
• Inducing strain in the substrates

41
Figure 6.12 Life at the Active Site
42
Enzymes Biological Catalysts

• Enzymes orient substrates.
• While free in solution, substrates tumble and
  collide.
• The probability of collision at the angle
  necessary to change chemical interactions is low.
• When bound to enzymes, two substrates can be
  oriented such that a reaction is more likely to
  occur.

43
Enzymes Biological Catalysts

• The R groups of an enzymes amino acids can make
  substrates more chemically reactive.
• In acid-base catalysis, acidic or basic R groups
  form the active site and transfer H to or from
  the substrate, destabilizing a covalent bond in a
  substrate.
• In covalent catalysis, a functional group side
  chain forms a temporary covalent bond with the
  substrate.
• In metal ion catalysis, metal ions gain or lose
  electrons without detaching from the protein,
  making them important participants in redox
  reactions.

44
Enzymes Biological Catalysts

• Some enzymes induce strain in the substrate.
• For example, the carbohydrate substrate for the
  enzyme lysozyme enters the active site in a
  flat-ringed chair shape.
• The active site causes it to flatten out into a
  sofa shape.
• The stretching of the bonds decreases their
  stability, making them more reactive to water.

45
Figure 6.13 Tertiary Structure of Lysozyme
46
Molecular Structure Determines Enzyme Function

• Most enzymes are much larger than their
  substrate.
• The active site of most enzymes is only a small
  region of the whole protein.
• The specificity of an enzyme for a particular
  substrate depends on a precise interlock.
• In 1894, Emil Fischer compared the fit to that of
  a lock and key.
• In 1965, using X-ray crystallography, David
  Phillips observed a pocket in the enzyme lysozyme
  that neatly fit its substrate.

47
Molecular Structure Determines Enzyme Function

• The change in enzyme shape caused by substrate
  binding is called induced fit.
• Induced fit at least partly explains why enzymes
  are so large.
• The rest of the macromolecule may have two
  functions
• To provide a framework so that the amino acids of
  the active site are properly positioned
• To participate in the small changes in protein
  shape that allow induced fit

48
Figure 6.14 Some Enzymes Change Shape When
Substrate Binds to Them
49
Molecular Structure Determines Enzyme Function

• Some enzymes require other molecules in order to
  function
• Cofactors are metal ions (e.g., copper, zinc,
  iron) that bind temporarily to certain enzymes
  and are essential to their function.
• Coenzymes are small molecules that act like
  substrates. They bind to the active site and
  change chemically during the reaction, then
  separate to participate in other reactions.
• Prosthetic groups are permanently bound to
  enzymes. They include the heme groups that are
  attached to hemoglobin.

50
Figure 6.15 An Enzyme with a Coenzyme
51
Molecular Structure Determines Enzyme Function

• The rate of an uncatalyzed reaction is directly
  proportional to the concentration of reactants.
• This is true up to a point with catalyzed
  reactions, but then the rate levels off.
• This is due to saturation of the enzyme, when all
  the enzyme molecules are bound to substrate.
• Turnover number is the number of substrate
  molecules converted to product per unit time.
• The turnover number ranges from 1 molecule every
  2 seconds for lysozyme, to 40 million per second
  for the liver enzyme catalase.

52
Figure 6.16 Catalyzed Reactions Reach a Maximum
Rate
53
Metabolism and the Regulation of Enzymes

• A major characteristic of life is homeostasis,
  the maintenance of stable internal conditions.
• Regulation of enzyme activity contributes to
  metabolic homeostasis.

54
Metabolism and the Regulation of Enzymes

• An organisms metabolism is the total of all
  biochemical reactions taking place within it.
• Metabolism is organized into sequences of
  enzyme-catalyzed chemical reactions called
  pathways.
• In these sequences, the product of one reaction
  is the substrate for the next.
• A B C
  D

55
Metabolism and the Regulation of Enzymes

• Some metabolic pathways are anabolic and
  synthesize the building blocks of macromolecules.
• Some are catabolic and break down macro-molecules
  and fuel molecules.
• The balance among these pathways can change
  depending on the cells needs, so a cell must
  regulate its metabolic pathways constantly.

56
Metabolism and the Regulation of Enzymes

• Enzyme activity can be inhibited by natural and
  artificial binders.
• Naturally occurring inhibitors regulate
  metabolism.
• Irreversible inhibition occurs when the inhibitor
  destroys the enzymes ability to interact with
  its normal substrate(s).
• DIPF, a nerve gas, irreversibly inhibits
  acetylcholinesterase, an enzyme necessary for
  propagation of nerve impulses.

57
Figure 6.17 Irreversible Inhibition
58
Metabolism and the Regulation of Enzymes

• Not all inhibition is irreversible.
• When an inhibitor binds reversibly to an enzymes
  active site, it competes with the substrate for
  the binding site and is called a competitive
  inhibitor.
• When the concentration of the competitive
  inhibitor is reduced, it no longer binds to the
  active site, and the enzyme can function again.

59
Figure 6.18 (a) Reversible Inhibition (Part 1)
60
Figure 6.18 (a) Reversible Inhibition (Part 2)
61
Metabolism and the Regulation of Enzymes

• When an inhibitor binds reversibly to a site
  distinct from the active site, it is called a
  noncompetitive inhibitor.
• Noncompetitive inhibitors act by changing the
  shape of the enzyme in such a way that the active
  site no longer binds the substrate.
• Noncompetitive inhibitors can unbind from the
  enzyme, making the effects reversible.

62
Figure 6.18 (b) Reversible Inhibition (Part 1)
63
Figure 6.18 (b) Reversible Inhibition (Part 2)
64
Metabolism and the Regulation of Enzymes

• The change in enzyme shape due to noncompetitive
  inhibitor binding is an example of allostery.
• Allosteric enzymes are controlled by allosteric
  regulators.
• Allosteric regulators bind to an allosteric site,
  which is separate from the active site, and this
  changes the structure and function of the enzyme.
• Allosteric regulators work in two ways
• Positive regulators stabilize the active form.
• Negative regulators stabilize the inactive form.

65
Figure 6.19 Allosteric Regulation of Enzymes
66
Metabolism and the Regulation of Enzymes

• Allosteric enzymes usually have more than one
  type of subunit (quaternary structure).
• A catalytic subunit has an active site that binds
  the enzymes substrate.
• A regulatory subunit has one or more allosteric
  sites that bind specific regulators.
• In the active state, the active sites on the
  catalytic subunits can bind substrate.
• In the inactive state, the allosteric sites on
  the regulatory subunits can bind inhibitor.

67
Metabolism and the Regulation of Enzymes

• Some allosteric enzymes have multiple active
  sites.
• When one binding site is occupied, it changes the
  other(s) so that they bind additional substrate
  molecules more readily.
• How the rate of a reaction changes with
  increasing substrate concentration depends on
  whether the enzyme is allosterically regulated.
• The enzymes catalytic rate becomes
  concentration-sensitive and concentration-responsi
  ve.

68
Figure 6.20 Allostery and Reaction Rate
69
Metabolism and the Regulation of Enzymes

• Metabolic pathways typically involve a starting
  material, intermediates, and an end product.
• The first step in the pathway is called the start
  up or commitment step.
• Once this step occurs, other enzyme-catalyzed
  reactions follow until the product of the series
  builds up.
• One way to control the whole pathway is to have
  the end product inhibit the first step in the
  pathway.
• This is called end-product inhibition or feedback
  inhibition.

70
Figure 6.21 Inhibition of Metabolic Pathways
71
Metabolism and the Regulation of Enzymes

• Rates of most enzyme-catalyzed reaction depend on
  the pH of the medium.
• Each enzyme is most active at a particular pH.
• pH can change the charges of the carboxyl and
  amino groups of amino acids. This affects the
  interactions of the amino acids and can change
  the structure of the protein.

72
Figure 6.22 pH Affects Enzyme Activity
73
Metabolism and the Regulation of Enzymes

• Temperature also affects enzyme activity.
• High temperature can inactivate enzymes by
  breaking non-covalent bonds.
• If the tertiary structure is disrupted the enzyme
  is called denatured.
• Some organisms that can live at different
  temperatures generate different forms of an
  enzyme, called isozymes.
• Enzymes adapted to warm temperatures usually have
  a tertiary structure of covalent bonds, such as
  disulfide bridges.

74
Figure 6.23 Temperature Affects Enzyme Activity
