Treatment Learning: Implementation and Application

1
Treatment LearningImplementation and Application

• Ying Hu
• Electrical Computer Engineering
• University of British Columbia

2
Outline

• An example
• Background Review
• TAR2 Treatment Learner
• TARZAN Tim Menzies
• TAR2 Ying Hu Tim Menzies
• TAR3 improved tar2
• TAR3 Ying Hu
• Evaluation of treatment learning
• Application of Treatment Learning
• Conclusion

3
First Impression

• Boston Housing Dataset
• (506 examples, 4 classes)

4
Review Background

• What is KDD ?
• KDD Knowledge Discovery in Database fayyad96
• Data mining one step in KDD process
• Machine learning learning algorithms
• Common data mining tasks
• Classification
• Decision tree induction (C4.5) quinlan86
• Nearest neighbors cover67
• Neural networks rosenblatt62
• Naive Bayes classifier duda73
• Association rule mining
• APRIORI algorithm agrawal93
• Variants of APRIORI

5
Treatment Learning Definition

• Input classified dataset
• Assume classes are ordered
• Output Rxconjunction of attribute-value pairs
• Size of Rx of pairs in the Rx
• confidence(Rx w.r.t Class) P(ClassRx)
• Goal to find Rx that have different level of
  confidence across classes
• Evaluate Rx lift
• Visualization form of output

6
Motivation Narrow Funnel Effect

• When is enough learning enough?
• Attributes lt 50, accuracy decrease 3-5
  shavlik91
• 1-level decision tree is comparable to C4
  Holte93
• Data engineering ignoring 81 features result in
  2 increase of accuracy kohavi97
• Scheduling random sampling outperforms complete
  search (depth-first) crawford94
• Narrow funnel effect
• Control variables vs. derived variables
• Treatment learning finding funnel variables

7
TAR2 The Algorithm

• Search attribute utility estimation
• Estimation heuristic Confidence1
• Search depth-first search
• Search space confidence1 gt threshold
• Discretization equal width interval binning
• Reporting Rx
• Lift(Rx) gt threshold
• Software package and online distribution

8
The Pilot Case Study

• Requirement optimization
• Goal optimal set of mitigations in a cost
  effective manner

Risks
Cost
relates
Requirements
incur
reduce
achieve
Mitigations
Benefit

• Iterative learning cycle

9
The Pilot Study (continue)

• Cost-benefit distribution (30/99 mitigations)

10
Problem of TAR2

• Runtime vs. Rx size

• To generate Rx of size r
• To generate Rx from size 1..N

11
TAR3 the improvement

• Random sampling
• Key idea
• Confidence1 distribution probability
  distribution
• sample Rx from confidence1 distribution
• Steps
• Place item (ai) in increasing order according to
  confidence1 value
• Compute CDF of each ai
• Sample a uniform value u in 0..1
• The sample is the least ai whose CDFgtu
• Repeat till we get a Rx of given size

12
Comparison of Efficiency
13
Comparison of Results

• 10 UCI domains, identical best Rx

• Final Rx TAR219, TAR320

14
External Evaluation
C4.5 Naive Bayes

• FSS framework

All attributes (10 UCI datasets)
Feature subset selector TAR2less
15
The Results

• Number of attributes

• Accuracy using C4.5
• (avg decrease 0.9)

• Accuracy using Naïve Bayes

(Avg increase 0.8 )
16
Compare to other FSS methods

• of attribute selected (C4.5 )

• of attribute selected (Naive Bayes)

• 17/20, fewest attributes selected
• Another evidence for funnels

17
Applications of Treatment Learning

• Downloading site http//www.ece.ubc.ca/yingh/
• Collaborators JPL, WV, Portland, Miami
• Application examples
• pair programming vs. conventional programming
• identify software matrix that are superior error
  indicators
• identify attributes that make FSMs easy to test
• find the best software inspection policy for a
  particular software development organization
• Other applications
• 1 journal, 4 conference, 6 workshop papers

18
Main Contributions

• New learning approach
• A novel mining algorithm
• Algorithm optimization
• Complete package and online distribution
• Narrow funnel effect
• Treatment learner as FSS
• Application on various research domains

19

• Some notes follow

20
Rx Definition example

• Input example
• classified dataset
• Output example
• Rxconjunction of attribute-value pairs
  confidence(Rx w.r.t C) P(CRx)

21
TAR2 in practice

• Domains containing narrow funnels
• A tail in the confidence1 distribution
• A small number of variables that have
  disproportionally large confidence1 value
• Satisfactory Rx of small size (lt6)

22
Background Classification

• 2-step procedure
• The learning phase
• The testing phase
• Strategies employed
• Eager learning
• Decision tree induction (e.g. C4.5)
• Neural Networks (e.g. Backpropagation)
• Lazy learning
• Nearest neighbor classifiers (e.g. K-nearest
  neighbor classifier)

23
Background Association Rule
ID Transactions
1 A, B, C,E,F
2 B,C,E
3 B,C,D,E
4

• Representative algorithms
• APRIORI
• Apriori property of large itemset
• Max-Miner
• More concise representation of the discovered
  rules
• Different prune strategies.

• Possible Rule
• B gt C,E
• support2, confidence 80
• Where
• support(X-gtY) P(X)
• confidence(X-gtY) P(YX)

24
Background Extension

• CBA classifier
• CBA Classification Based on Association
• XgtY, Y class label
• More accurate than C4.5 (16/26)
• JEP classifier
• JEP Jumping Emerging Patterns
• Support(X w.r.t D1) 0, Support(X w.r.t D2) gt 0
• Model collection of JEPs
• Classify maximum collective impact
• More accurate than both C4.5 CBA (15/25)

25
Background Standard FSS Method

• Information Gain attribute ranking
• Relief
• Principle Component Analysis (PCA)
• Correlation based feature selection
• Consistency based subset evaluation
• Wrapper subset evaluation

26
Comparison

• Relation to classification
• Class boundary / class density
• Class weighting
• Relation to association rule mining
• Multiple classes / no class
• Confidence-based pruning
• Relation to change detecting algorithm
• support P(Xyc1)-P(Xyc2)
• confidence P(yc1X)-P(yc2X)
• Bayes rule

27
Confidence Property

• Universal-extential upward closure
• R1 Age.young -gt Salary.low
• R2 Age.young, Gender.m -gt Salary.low
• R2 Age.young, Gender.f -gt Salary.low
• Long rule tend to have high confidence
• Large Rx tend to have high lift value

28
TAR3 Usability

• Usability more user-friendly
• Intuitive, default setting
