Exact and Approximate Pattern in the Streaming Model

1
Exact and Approximate Pattern in the Streaming
Model
Benny Porat and Ely Porat 2009 FOCS

• Presented by - Tanushree Mitra

2
Problem Statement

• Find all instances of pattern P of length m, as a
  contiguous substring in a text string T, of
  length n, where m lt n.

3
Contributions

• Exact pattern matching - A fully online
  randomized algorithm for the classical pattern
  matching problem
• Time complexity - O(logm) per character that
  arrives
• Space complexity - O(logm), breaking the O(m)
  barrier that held for this problem for a long
  time.
• Approximate pattern matching An algorithm for
  pattern matching with k mismatches problem.
• Time complexity - O(k2poly(logm)) per
  character
• Space complexity - O(k3poly(logm))

4
Applications

• Monitoring Internet traffic
• Computational Biology
• Large Scale web searching
• Viruses and Malware detection
• Automatic Stock market analysis
• Robotics

5
Background

• Brute Force Algorithm
• Slide the pattern along the text and
• Compare it to the corresponding portion of the
  text
• Time Complexity O(mn)
• Speedup possible in these 2 steps.
• Sliding step speedup by pre-processing the
  pattern,
• Knuth-Morris-Pratt algorithm
• Boyer-Moore algorithm.
• Ukkonens algorithm to construct suffix trees
• Comparison step speedup
• Rabin-Karp algorithm.

6
Quick History
7
The Intuition

• When Rabin-Karps algorithm is done with the ith
  character, and advances to the next position in
  the text, it does not use any of the information
  gathered.
• The KMP algorithm, on the other hand, puts that
  information to good use.

The Idea

• Combine the key features of KMP and the
  Rabin-Karp algorithms to achieve an online
  algorithm that uses less space.

8
Definitions - Fingerprints
Fingerprint

• String S ?(S)

Sliding Fingerprint

• Polynomial Fingerprint
• q s1r s2r2 slrl mod p, where p??(N4),
  r?Fp
• False Positives
• If S1 ? S2, then probability of ?r,p(S1)
  ?r,p(S2) is lt 1/n3

9
Definitions - PeriodPl

• Period - A prefix Sp s1,s2,.,sl of a string S
  is defined to be a period of S, iff si sil,
  for 0 i n - l
• PeriodPl - For a pattern P p1,p2,.,pm, prefix
  is, Pl p1,p2,.,pl ,0 l m. The shortest
  period of Pl is periodPl

Put the information to good use

• If Pl matches the test at a given index i, then
  there cannot be a match between i to i
  periodPl

10
The Idea
False Positives?? Slide over periodPl position
that could be a match. Very LOW PROBABILITY of
false positives

• Match at ith index indicates that we know the
  last m characters, so no point saving them?
• Preprocessing phase Calculate Sliding
  fingerprint on the pattern ?p and on the shortest
  period ?period p
• Online phase Slide fingerprint ? over the
  entire text.
• While ? ?p, slide ? by PeriodPl characters
• If we do not reach end of text abort

Text and pattern should satisfy stringent
restrictions
11
Go for subpatterns

• Log m subpatterns

p1, p2, p3, pm-3, pm-2, pm-1, pm
P1
pm
pm-2 ,pm-1
pm-6,pm-5,pm-4,pm-3
P2
P4
p1, p2, p3, pm/2
Pm/2

• Starting point Find a position in which the
  smallest subpattern matches the text. Smallest
  subpattern is of length 1 this can be easily
  found.

12
Algorithm

• Guidelines
• Find a position where Pi is a match, try to
  match Pi 1 from the same starting point as Pi
• If Pi 1 does not match, use the information
  that Pi is a match.
• Check in jumps of periodPi until there is no
  overlap with the area where Pi matches.
• PROCESS
• Initialize an empty sliding fingerprint ?.
• For each character that arrive
• Extend ? to include the new character
• If ? 2i and ? ?i for some 0 i log m.
• If ? has at least periodPi-1 length overlaps
  with the last match, slide ? by periodPi-1
  characters.
• Else, abort.

What if there is a match that starts in substring
of 1st process and ends in substring of 2nd
process
13
Exact_PM final AlgorithmIntroduce Checkpoint

• Checkpoint - Start a new process in the
  last checkpoint of each process
• Algorithm
• Preprocessing -
• Initialize an empty sliding fingerprint ?.
• For each 0 i log m calculate the sliding
  fingerprint
• ?i of Pi and
• ?i,period of the period of Pi

14
Final Algorithm Online Phase

• Online Phase
• Start a new process
• For any character that arrive send it to all the
  processes
• If some process aborts start new prorcess
• If some process , A reaches to a checkpoint
• Stop the son process of A (if it has one)
• Start a new son process of A

15
Complexity

• Space
• All fingerprints from preprocessing use O(log m)
  space.
• Each process saves another fingerprint and there
  can be atmost log m processes in parallel
• OVERALL usage O(log m) space
• Time
• Each process spends O(1) time for each new
  character that arrives
• Each time there are at most 3 log m processes
  running (1. process A, 2. son-process of A,
  grandson-process of A. A has to die when
  great-granson of A is created)
• OVERALL running time O(log m) per character

16
Pattern Matching ( 1 Mistmatch)

• Partition the pattern and the text
• We need to align every partition of the pattern
  Pqi,j to qi text shifts

17
Intuition

• For each Pqi,j, run qi processes of Exact_PM.
• Processqi,j,s - sth process of the subpattern
  Pqi,j , for 0 s lt qi. This will try to match
  the Pqi,j to the text by considering the text as
  if it starts from the s character. (t mod qi j
  s)
• If for all qi,
• numOfNotMatchqi,s 0 match.
• numOfNotMatchqi,s 1, exactly
  1-mismatch
• Otherwise, more than 1-mismatch.

18
Complexity

• FACTS
• Run ?li1 qi2 processes of Exact_PM
• There exists a constant c such that for any x,
  there exist (x / logm) prime numbers, between x,
  and cx
• We have q1,q2, . . . ql groups of partitions.
  Each qi is a prime number
• Space - O(log4m / log log m)
• Time - O(log3m / log log m)

19
Pattern Matching ( k Errors)

• Preprocessing Phase Initialize a process
  Processqi,j,s of 1-mismatch, for each qi ?
  q1,q2, . . . ql, 0 i qi and 0 s lt qi
• Online Phase Send t character to each
  Processqi,j,s such that t mod qi j s
• d all mismatches from all processes that return
  exactly 1-mismatch
• d gt k more than k mismatches

20
Complexity

• Space
• Run ?i1klogm qi2 ? O(k3 log4m/ log log m)
  processes of 1-mismatch in parallel.
• Each process requires log4m space.
• OVERALL - O(k3poly(log m))
• Time
• Number of processes of 1-mismatch algorithm is
  bounded by ?i1klogm qi2 ? O(k3 log4m/ log log m)

• Running time of each character O(log3m)
• OVERALL - O(k2poly(log m))

21
Concluding Discussion

• The Two-Dimensional String-Matching Problem
• The String-Matching Problem with Wild Characters
  Example pattern P abcabc is found in
  texts T1 abcdcadbaccabc, T2 abcabc
• String matching with weighted mismatch
