PROTEINS

1
Proteins
2
Objectives

• Write the general formula for an amino acid.
• Define a peptide bond and write a formula that
  shows what this bond looks like.
• Define and show the relationship between a
  protein and polypeptide.
• Define essential amino acids and complete
  proteins.

3
Objectives

• Write formulas and/or structures that will
  illustrate what is meant by primary, secondary
  and tertiary structure of a protein.
• Explain what denaturation is and how it can be
  produced.
• Describe at least two human diseases that result
  from improper protein nutritional practices.

4
Protein Prime importance
Found in Cells (2/3 of dry cell weight )
Tissues All body fluids
except urine and bile Not
stored for future use (like
carbohydrates and lipids)
5

• Proteins ?
• Major components of

Skin, nails, claws, hair, wool, feathers, hooves,
muscles, tendons and cartilage.
6

• Proteins ?
• Essential Functions

? Support (keratin/collagen) ? Enzymes
(specific catalysts) ? Transport
(channel proteins/hemoglobin) ?
Defense (antibodies) ?
Hormones (regulatory - insulin)
? Motion (actin/myosin)
7
Protein Composition
Polymers Amino Acid Monomers 20 amino acids in
proteins
8
Amino Acids
acid group
amino group
9
Amino Acids
Some are chemically neutral.
Glycine has 1 carboxyl group and 1 basic group.
10
Amino Acids
Some are chemically acidic.
Glutamic acid has two carboxyl groups only 1
amino acid.
11
Amino Acids
Some are chemically basic.
Lysine has two amino groups and 1 carboxyl.
12
Amino Acids
Differ in nature of R group.
13
Amino Acids
Some are hydrophobic.
14
Amino Acids
Some are hydrophilic.
15
Peptide
Two or more amino acids bonded together.
16
Peptide Bond

• Covalent bond between amino acids.
• Electrons shared unevenly (O2 is more
  electro-negative than N2).
• Polarity permits hydrogen bonding between parts
  of a polypeptide.

17
Polypeptides

• Chains of many amino acids joined by peptide
  bonds.
• Proteins may contain more than one polypeptide
  chain.
• Can have large numbers of amino acids.
• Since amino acids differ by R group proteins
  differ by a particular sequence of the R groups.

18
Protein Functions

• Enzymatic
• Structural
• Storage
• Transport
• Hormonal
• Receptor
• Contractile
• Defensive
• Regulatory
• Sensory

19
Enzymatic Action
20
Protein Structure

• Shape determines function.

Animation Protein Structure Introduction
21
Interactions and Protein Shape

• Hydrogen bonds
• Disulfide bridges
• Ionic bonds
• Van der Waals attractions
• Hydrophilic/hydrophobic reactions

22
Interactions and Protein Shape
23
Interactions and Protein Shape

• R group of cysteine ends with a sulfhydryl group
• (-SH)
• Enables one chain of amino acids to connect to
  another by a disulfide bond (-S-S-).

24
Interactions and Protein Shape
25
Interactions and Protein Shape
26
Interactions and Protein Shape
27
Levels of Protein StructurePrimary
The specific sequence of amino acids joined by
peptide bonds.
Animation Primary Protein Structure
28
Primary StructureHistorical Perspective
- Fredrick Sanger determined first protein
sequence (insulin). - Broke into fragments and
determined AA sequence of fragments. - Then
determined sequence of fragments. - Required ten
years research modern automated sequencers
analyze sequences in hours.
29
Levels of Protein StructureSecondary

• The specific geometric shape caused by
  intramolecular and intermolecular hydrogen
  bonding.

Animation Secondary Protein Structure
30
Levels of Protein StructureSecondary

• ? Helix
• Discovered by Linus Pauling and
• Robert Corey.
• Oxygen partially -, hydrogen partially .
• Hydrogen bonding between the CO
• of one AA and the N-H of another.
• Hydrogen bonding between every fourth
• AA acid holds spiral shape of an alpha
• helix.
• In keratin ? helices covalently bonded by
• disulfide (-S-S-) linkages between two
• cysteine amino acids.

31
Levels of Protein StructureSecondary

• ? Pleated Sheet
• Polypeptides turn back upon themselves
• Hydrogen bonding between extended lengths.
• keratin includes feathers, hooves, claws, beaks,
  scales and horns silk

32
Levels of Protein StructureMotifs

• Folds or creases
• Beta ribbon
• Greek Key
• Omega loop
• Helix-loop-helix
• Zinc finger
• Helix-turn-helix
• Beta hairpin

33
Greek Key
4 beta strands folded over into a sandwich shape.
It is named for its resemblance to the Greek key
meander pattern in art.
34
Omega Loop
W

• Named after its shape, the Greek capital letter
  Omega
• Consists of a loop of any length and any amino
  acid sequence.

35
Helix-Loop-Helix
Two a helices connected by a loop. Some of these
facilitate DNA binding.
36
Zinc Finger
Protein (blue) containing three zinc fingers in
complex with DNA (orange). The Zinc ions are
green. (Transcription Factors)
37
Helix-Turn-Helix

• Binds to major groove of DNA through hydrogen
  bonds and various Van der Waals interactions with
  exposed bases.
• Two a helices joined by a short strand of amino
  acids
• Found in many proteins that regulate gene
  expression.

38
Beta Hairpin

• Two beta strands that look like a hairpin.
• Beta strands are adjacent in primary sequence and
  oriented in an antiparallel arrangement in the
  hairpin

39
Levels of Protein StructureTertiary

• Result when proteins of secondary structure are
  folded, due to various interactions Between R
  groups of their constituent amino acids.

Animation Tertiary Protein Structure
40
Levels of Protein StructureQuarternary

• Results when two or more polypeptides combine.
• - Hemoglobin is globular protein with a
  quaternary structure of four polypeptides.
• - Collagen is a fibrous protein consisting
  of three polypeptides coiled like a rope
• - Most enzymes have a quaternary structure.

Animation Quaternary Protein Structure
41
(No Transcript)
42
Sickle-Cell Disease

• Slight change in primary structure can affect a
  proteins structure and ability to function
• Sickle-cell disease, an inherited blood disorder,
  results from a single amino acid substitution in
  the protein hemoglobin.

43
Chaperone Proteins

• Special proteins which help new proteins fold
  correctly.
• Chaperone deficiencies may play a role in
  facilitating certain diseases.

44
Denaturation Of Proteins
Loss of normal configuration a physical
change. Once a protein loses it normal shape, it
cannot perform its usual function. Sometimes will
renature.
45
How Proteins Can Be Denatured

• Temperature
• Cooking an egg
• Albumin congeals
• Addition of hydrogen or hydroxide ions (large pH
  changes)
• Adding acid to milk
• Causes curdling
• Vigorous Shaking
• Organic Solvents
• Salts of heavy metals (mercury, silver lead)
• Detergents
• Ultraviolet Radiation

46
Essential Amino Acids
Dietary requirements Not synthesized
47
Essential Amino Acids
methionine or cysteine leucine isoleucine
lysine phenylalanine (or tyrosine)
threonine, typtophan valine
48
Complete Proteins
Proteins that contain all essential amino acids.
They are usually derived from animal sources.
49
Protein Deficiency Diseases

• Marasmus Kwashiokor
• Two of the most common childrens diseases
  worldwide.
• Weaned diet deficient in protein.

50
Kwashiokor

• Sufficient calories, insufficient protein.
• Symptoms
• Loss of appetite
• Diarrhea
• Enlarged liver
• Pigmented skin
• Apathy
• Irritability
• Bloated belly

51
Marasmus

• Inadequate calories and protein
• Symptoms similar to Kwashikor
• Swollen belly
• Loss of muscular tone
• Rough, leathery skin
• Generally retarded physical and mental
  development
