Operant Conditioning

1
Operant Conditioning

• Chapter 13, Unit 4 Psychology

2
Introduction

• While CC is useful for explaining learned
  behaviour, there are many other learned
  behaviours that CC cannot explain, such as
  behaviours that are voluntary.
• Much of our learning occurs by trial and error.
• We all make adjustments to our behaviour
  according to the outcomes or consequences it
  produces.
• Operant conditioning is the learning that take
  places as a result of these consequences.

3
Trial and error learning

• Describes an organisms attempts to learn, or to
  solve a problem, by trying alternative
  possibilities until a correct solution or desired
  outcome is achieved.
• Involves a number of attempts (trials) and a
  number of incorrect choices (errors) before the
  correct behaviour is learned.

• Also referred to as instrumental learning, as
  the individual is instrumental in learning the
  correct response.
• More recently however, this learning has been
  referred to as operant conditioning, because the
  individual operates on the environment to solve
  a problem.

4
Trial and error learning cont

• It involves
• Motivation
• Exploration
• Incorrect and correct responses
• Reward
• Receiving a reward of some kind leads to the
  repeated performance of the correct response,
  strengthening the association between the
  behaviour and its outcome.

5
Thorndikes experiments with cats

• American psychologist Edward Lee Thorndike
  (1874-1949) undertook the first studies of trial
  and error learning.
• He put a hungry cat in a puzzle box and placed
  a piece of fish outside the box where it could be
  seen (and smelt) but was just outside of the
  cats reach.

• The cat had to learn to escape from the box by
  operating a latch to escape from the box by
  operating a latch to release a door on the side
  of the box.
• Learning was measured by the time it took the
  cat, on consecutive trials to escape.

6
The law of effect

• The results of Thorndikes experiments left
  Thorndike to develop the law of effect.
• It states that a behaviour that is followed by
  satisfying consequences is strengthened and a
  behaviour that is followed by annoying
  consequences is weakened.

• In the puzzle-box experiments, behaviour that
  enabled the cat to escape and get to the food
  (satisfying) was more likely to occur and
  behaviour that kept the cat in the box (annoying)
  was less likely to occur.
• The cat became instrumental in obtaining its
  release to get the food.

7
Operant conditioning

• Term operant conditioning (OC) was not introduced
  until some years after Thorndikes experiments
  with cats escaping from puzzle boxes.
• OC was coined by American psychologist Burrhus
  Skinner.
• He referred to the responses observed in a trial
  and error learning as operants.

• An operant is a response that occurs and acts on
  the environment to produce some kind of effect.
• OC is based on the principle that an organism
  will tend to repeat behaviours that have
  desirable consequences, or that will enable it to
  avoid undesirable consequences.
• Organisms will tend not to repeat behaviours that
  have undesirable consequences.

8
Burrhus Skinner (1904-1990)

• Began his own experiments in the 1930s, but used
  to term operant conditioning to emphasise that
  animals and people learn to operate on the
  environment to produce desired consequences.
• He also contrasted operants with respondents in
  CC.
• Respondents are behaviours elicited by known or
  recognised stimuli (e.g. the meat powder making
  the dog salivate in Pavlovs experiment).

• He believed that all behaviour can be explained
  by the relationships between the behaviour, its
  antecedents (the events that precede or come
  before it), and its consequences.
• He argued that any behaviour that is followed by
  a consequence will change in strength and
  frequency depending on the nature if that
  consequence.

9
The Skinner box

• He created an apparatus called a Skinner box,
  which is a small chamber in which an experimental
  animal learns to make a particular response for
  which the consequences can be controlled by the
  researcher.
• It is attached to a cumulative recorder which
  indicates how often each response is made
  (frequency) and the rate of response (speed).

10
Skinners experiments with rats

• 1938 Skinner uses the box to demonstrate OC.
• 1. a hungry rat is placed in the box.
• 2. it scurries around and randomly touches parts
  of the floor and walls.
• 3. rat accidentally presses the lever and rat
  food is released into the box.

• After additional repetitions, the rats random
  acts subsided and were replaced with more
  consistent lever pressing.
• Eventually, the rat was pressing the lever as
  fast as it could eat each pellet.
• Pellet is reward for the correct response.
• Skinner referred to different types of rewards as
  a reinforcer.

11
Skinners experiment cont

• The hunger of the rats was their motivation for
  frantic activity.
• Skinner believed that there was no need to search
  for internal agents to explain changes in
  behaviour.
• This view was based on the notion that behaviour
  can be understood in terms of environmental or
  external influences.

12
Elements of operant conditioning

• Reinforcement Punishment

13
Elements of operant conditioning

• Central to OC is reinforcement (reward).
• A response that is rewarded is strengthened,
  whereas one that is punished is weakened.

14
Reinforcement

• Reinforcement may involve receiving a pleasant
  stimulus or escaping an unpleasant stimulus.
• Reinforcement is applying a positive stimulus or
  removing a negative stimulus to subsequently
  strengthen or increase the likelihood of a
  particular response that it follows.
• A reinforcer is any object or event that changes
  the probability that an operant behaviour will
  occur again.

• The term reinforcer is often used interchangeably
  with the term reward although they are not
  technically the same.
• 1 difference is that a reward suggests an outcome
  that is positive a stimulus is a reinforcer if
  it strengthens the preceding behaviour.
• Also a stimulus can be rewarding because it is
  pleasurable, but it cannot be said to reinforce
  unless it increases the likelihood of a response
  occurring.

A person might enjoy eating chocolate find it
pleasurable, but chocolate cannot be considered
to be a reinforcer unless it promotes or
strengthens a particular response.
15
Schedules of reinforcement

• The schedule of reinforcement is the way in which
  the reinforcement is delivered in experimental
  settings.
• It influences the speed of learning and the
  strength of the learned response.
• Reinforcement may be provided on a continuous or
  partial reinforcement schedule.

• Continuous reinforcement is when every correct
  response in the early stages of learning is
  reinforced (the reinforcer is typically provided
  immediately after every correct response).
• Partial reinforcement is the process of
  reinforcing some correct responses but not all of
  them. It may be delivered in number of ways or by
  different schedules.

16
Schedules of reinforcement Cont

• The term schedule of reinforcement refers to the
  frequency and manner in which a desired response
  is reinforced.
• For instance, reinforcement can be given after a
  certain number of correct response have been made
  (i.e. after an interval).
• Furthermore, reinforcement may be given on a
  regular basis, such as after every 6th correct
  response, or every 30 seconds following a correct
  response (that is, fixed) or it may be
  unpredictable (that is, variable)

17
Positive reinforcement

• The food pellet in the Skinner box is a positive
  reinforcer for the hungry rat pressing the lever.
• A positive reinforcer is a stimulus that
  strengthens or increases the likelihood of a
  desired response by providing a satisfying
  consequence (reward).
• Positive reinforcement occurs from giving or
  applying a positive reinforcer after the desired
  response has been made.

18
Negative reinforcement

• A negative reinforcer is any unpleasant or
  aversive stimulus that, when removed or avoided,
  strengthens or increases the likelihood of a
  desired response.
• Negative reinforcement is the removal or
  avoidance of an unpleasant stimulus. It has the
  effect of increasing the likelihood of a response
  being repeated.

• E.g. a Skinner box has a grid on the floor
  through which a mild electrical current can be
  passed continuously. The rat can feel the
  unpleasant foot shock (stimulus). When the rat
  presses the lever, the electric current is
  switched off and the mild shock is taken away.
• The removal of the shock (negative reinforcer) is
  referred to as negative reinforcement.

19
Distinction between - reinforcers

• Positive reinforcers are given and negative
  reinforcers are removed or avoided.
• Yet because both procedures lead to desirable
  consequences, each procedure strengthens
  (reinforces) the behaviour that produced the
  consequence.

• Examples of negative reinforcement in everyday
  life
• Turning off a scary video
• Taking an aspirin to remove a headache
• Not drink-driving for fear of losing your license
• In these examples, the removal of the negative
  reinforcer is providing a satisfying or desirable
  consequence.

20
A quick calculation

• Positive reinforcer () adding something
  pleasant
• Negative reinforcer (-) subtracting something
  unpleasant

21
punishment

• Punishment is the delivery of an unpleasant
  stimulus following a response, or the removal of
  a pleasant stimulus following a response.
• It has the same unpleasant quality as a negative
  reinforcer, the punishment is given or applied,
  whereas the negative reinforcer is prevented or
  avoided.

• When closely associated with a response,
  punishment weakens the response, or decreases the
  probability of that response occurring again over
  time.

22
Factors that influence the effectiveness of
reinforcement and punishment

• Reinforcement is intended to increase the
  likelihood of a behaviour being repeated and
  punishment is intended to decrease the likelihood
  of behaviour being repeated.

• In OC, what happens after the desired response is
  performed is very important in determining the
  strength of learning and the rate at which is
  occurs.
• E.g. when in the process of OC the consequence is
  presented, the time lapse between the response
  and consequence, and the appropriateness of the
  consequence used are all important in determining
  the effectiveness of reinforcement or punishment
  and therefore learning.

23
Order of presentation

• For reinforcement and punishment to be used
  effectively, it must be presented after a desired
  response, never before.
• This ensures that an organism learns the
  consequences of a particular response.

• E.g., presenting a child with a lolly after every
  time they use the toilet instead of their nappy
  when they are in the process of being toilet
  trained.

24
timing

• Reinforcement and punishment are most effective
  when given immediately after the response has
  occurred.
• This allows for association between the response
  and the reinforcer or punisher.
• It also influences the strength of the response,
  e.g., if there is a delay, the learning will
  generally be very slow to progress and in some
  cases may not occur at all.

• This is easily controlled in a lab, but not as
  easy in everyday life.
• E.g. a delay between studying hard in Year 12 and
  receiving your desired ENTER.
• Or receiving a detention for misbehaviour can
  occur more than one day after the misdemeanour.

25
appropriateness

• For any stimulus to be a reinforcer, it must
  provide a pleasing or satisfying consequence
  (reward) its recipient.
• Technically, it will not be known if something
  will act as reinforcer until after it has been
  used.
• Also it cannot be assumed that a reinforcer that
  works in one situation will work in another.

• Similarly, for any stimulus to be an appropriate
  punisher, it must provide a consequence that is
  unpleasant and therefore likely to decrease the
  likelihood of the undesirable behaviour.
• An inappropriate punisher can have the opposite
  effect and produce the same consequence as a
  reinforcer.

26
Key processes in operant conditioning

• Acquisition, Extinction, Spontaneous Recovery,
  Stimulus Generalisation, Stimulus Discrimination
  involved in both CC and OC, however, the way in
  which these processes occur is slightly different
  in operant conditioning.

27
acquisition

• Refers to the overall learning process during
  which a specific response is established.
• Differs from acquisition in CC as the means by
  which the behaviour is acquired is different
  the types of behaviours acquired through OC are
  usually more complex than the reflexive,
  involuntary responses that became learned
  responses in CC.

• In OC, acquisition is the establishment of a
  response through reinforcement.
• The speed that the response is established
  depends on whether continuous or partial
  reinforcement is used.
• Also, a gradual progression towards a more
  complex target behaviour can be achieved, by
  reinforcing successive approximations. This is
  known as shaping.

28
Acquisition cont

• Shaping is a procedure in which reinforcement is
  given for any response that successively
  approximates and ultimately leads to the final
  desired response, or target behaviour.
• Consequently, shaping is also known as the method
  of successive approximations.
• Skinner used shaping in 1 experiment where he set
  a target behaviour for a pigeon to turn a
  complete circle in an anticlockwise direction.

• He initially continually reinforced the pigeon
  with a food pellet that was delivered through a
  mechanically operated door every time it turned
  slightly to the left.
• He then waited until the pigeon turned left
  further before reinforcing it.
• By limiting the reinforcement only to those
  responses that gradually edged towards the target
  behaviour, Skinner was able to condition the
  pigeon to turn complete circles regularly.

29
Extinction

• In OC, extinction is the gradual decrease in the
  strength or rate of a conditioned (learned)
  response following consistent non-reinforcement
  of the response.
• It is said to occur when a conditioned response
  is no longer present.
• With OC, extinction occurs over time, but after
  reinforcement is no longer given.

• E.g., when Skinner sopped reinforcing his rats or
  pigeons with food pellets, their conditioned
  response (e.g. of lever pressing or turning
  circles) was eventually extinguished.
• Extinction is less likely to occur when partial
  reinforcement is used i.e. when reinforcement
  does not regularly follow every correct response,
  as the uncertainty of the reinforcement leads to
  a greater tendency for the response to continue.

30
Spontaneous recovery

• Same as in CC, extinction is often not permanent
  in OC.
• After the apparent extinction of the CR,
  spontaneous recovery can occur and the organism
  will once again show the response in the absence
  of any reinforcement.

31
Stimulus generalisation

• This occurs when the correct response is made to
  another stimulus that is similar (but not
  necessarily identical) to the stimulus that was
  present when the CR was reinforced (usually at a
  reduced level).
• E.g. the sound of a car back firing as it goes
  past an athletics carnival may cause the athletes
  to generalise this sound to that of the starters
  pistol.

32
Stimulus discrimination

• In OC, stimulus discrimination occurs when an
  organism makes the correct response to a stimulus
  and is reinforced, but does not respond to any
  other stimulus, even when stimuli are similar
  (but not identical).
• Skinner taught lab animals to discriminate
  between similar stimuli by reinforcing some
  responses but not others.

• E.g. a pigeon in a Skinner box could be taught to
  discriminate between a red and a green light, by
  reinforcing the pigeon when it pecked a target
  when the green light was illuminated, but not
  when the red one was.
• Also, sniffer dogs are used in airports
  throughout the world to detect the smuggling on
  contraband items (e.g. drugs).
• They have been taught this by OC.

33
Comparison of cC and oc

• The role of the learning, timing of the stimulus
  and response, the nature of the response

34
Similarities of CC and Oc

• Acquisition
• Extinction
• Spontaneous recovery
• Stimulus generalisation and discrimination
• Both types of conditioning are achieved as a
  result of the repeated association of 2 events
  that follow each other closely in time.

• These similarities have led some psychologists to
  believe that both OC CC are variants of a
  single learning process.
• E.g. when Little Albert learned to fear the rat,
  his response (trembling) was CC. But when he
  learned to avoid the rat by crawling away (a
  response that had the effect of reducing his
  fear), that was an example of OC

35
Differences of CC OC

• OC
• Emphasis on the consequences of a response.
• Involves voluntary responses

• CC
• The behaviour of the learner does not have any
  environmental consequences.
• Response is involuntary.

36
The role of the learner

• In CC the learner is relatively passive when
  either the CS of the UCS is presented.
• In OC the learner must actively operate on the
  environment so as to obtain the reinforcement or
  the punishment.

37
Timing of the stimulus and response

• In CC the response depends on the presentation of
  the UCS occurring first.
• In OC the presentation of the reinforcer depends
  on the response occurring first.
• In CC, the timing of the 2 stimuli (CS, then
  UCS), produces an association between them that
  conditions the learner to anticipate the UCS and
  respond to it even if is not presented.

• In OC, the association that is conditioned is
  between the stimulus and the response.
• In CC the timing of the 2 stimuli needs to be
  very close and the sequencing is vital the CS
  must come before the UCS.
• In OC, while learning generally occurs faster
  when the reinforcement or punishment occurs soon
  after the response, there can be a considerable
  time difference between them.

38
The nature of the response

• In CC, the response by the learner is usually a
  reflexive, involuntary one.
• In OC, the response by the learner is usually a
  voluntary one.
• In CC, the response is often one involving the
  action of the autonomic nervous system, and the
  association of the 2 stimuli is often not a
  conscious or deliberate one.

• In OC, the response is more likely to involve the
  central nervous system and to be conscious,
  intentional and often goal-directed.
