Distributed Parallel Computing Cluster

• Patrick McGuigan
• mcguigan_at_cse.uta.edu

2
DPCC Background

• NSF funded Major Research Instrumentation (MRI)
  grant
• Goals
• Personnel
• PI
• Co-PIs
• Senior Personnel
• Systems Administrator

3
DPCC Goals

• Establish a regional Distributed and Parallel
  Computing Cluster at UTA (DPCC_at_UTA)
• An inter-departmental and inter-institutional
  facility
• Facilitate collaborative research that requires
  large scale storage (tera to peta bytes), high
  speed access (gigabit or more) and mega
  processing (100s of processors)

4
DPCC Research Areas

• Data mining / KDD
• Association rules, graph-mining, Stream
  processing etc.
• High Energy Physics
• Simulation, moving towards a regional Dø Center
• Dermatology/skin cancer
• Image database, lesion detection and monitoring
• Distributed computing
• Grid computing, PICO
• Networking
• Non-intrusive network performance evaluation
• Software Engineering
• Formal specification and verification
• Multimedia
• Video streaming, scene analysis
• Facilitate collaborative efforts that need
  high-performance computing

5
DPCC Personnel

• PI Dr. Chakravarthy
• CO-PIs
• Drs. Aslandogan, Das, Holder, Yu
• Senior Personnel
• Paul Bergstresser, Kaushik De, Farhad Kamangar,
  David Kung, Mohan Kumar, David Levine, Jung-Hwan
  Oh, Gregely Zaruba
• Systems Administrator
• Patrick McGuigan

6
DPCC Components

• Establish a distributed memory cluster (150
  processors)
• Establish a Symmetric or shared multiprocessor
  system
• Establish a large shareable high speed storage
  (100s of Terabytes)

7
DPCC Cluster as of 2/1/2004

• Located in 101 GACB
• Inauguration 2/23 as part of E-Week
• 5 racks of equipment UPS

8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11

• Photos (scaled for presentation)

12
DPCC Resources

• 97 machines
• 81 worker nodes
• 2 interactive nodes
• 10 IDE based RAID servers
• 4 nodes support Fibre Channel SAN
• 50 TB storage
• 4.5 TB in each IDE RAID
• 5.2 TB in FC SAN

13
DPCC Resources (continued)

• 1 Gb/s network interconnections
• core switch
• satellite switches
• 1 Gb/s SAN network
• UPS

14
DPCC Layout
15
DPCC Resource Details

• Worker nodes
• Dual Xeon processors
• 32 machines _at_ 2.4GHz
• 49 machines _at_ 2.6GHz
• 2 GB RAM
• IDE Storage
• 32 machines _at_ 60 GB
• 49 machines _at_ 80 GB
• Redhat 7.3 Linux (2.4.20 kernel)

16
DPCC Resource Details (cont.)

• Raid Server
• Dual Xeon processors (2.4 GHz)
• 2 GB RAM
• 4 Raid Controllers
• 2 port controller (qty 1) Mirrored OS disks
• 8 port controller (qty 3) RAID5 with hot spare
• 24 250GB disks
• 2 40GB disk
• NFS used to support worker nodes

17
DPCC Resource Details (cont.)

• FC SAN
• RAID5 Array
• 42 142GB FC disks
• FC Switch
• 3 GFS nodes
• Dual Xeon (2.4 Ghz)
• 2 GB RAM
• Global File System (GFS)
• Serve to cluster via NFS
• 1 GFS Lockserver

18
Using DPCC

• Two nodes available for interactive use
• master.dpcc.uta.edu
• grid.dpcc.uta.edu
• More nodes are likely to support other services
  (Web, DB access)
• Access through SSH (version 2 client)
• Freeware Windows clients are available (ssh.com)
• File transfers through SCP/SFTP

19
Using DPCC (continued)

• User quotas not implemented on home directory
  yet. Be sensible in your usage.
• Large data sets will be stored on RAIDs
  (requires coordination with sys admin)
• All storage visible to all nodes.

20
Getting Accounts

• Have your supervisor request account
• Account will be created
• Bring ID to 101 GACB to receive password
• Keep password safe
• Login to any interactive machine
• master.dpcc.uta.edu
• grid.dpcc.uta.edu
• USE yppasswd command to change password
• If you forget your password
• See me in my office, I will reset your password
  (with ID)
• Call or e-mail me, I will reset your password to
  the original password

21
User environment

• Default shell is bash
• Change with ypchsh
• Customize user environment using startup files
• .bash_profile (login session)
• .bashrc (non-login)
• Customize with statements like
• export ltvariablegtltvaluegt
• source ltshell filegt
• Much more information in man page

22
Program development tools

• GCC 2.96
• C
• C
• Java (gcj)
• Objective C
• Chill
• Java
• JDK Sun J2SDK 1.4.2

23
Development tools (cont.)

• Python
• python version 1.5.2
• python2 version 2.2.2
• Perl
• Version 5.6.1
• Flex, Bison, gdb
• If your favorite tool is not available, well
  consider adding it!

24
Batch Queue System

• OpenPBS
• Server runs on master
• pbs_mom runs on worker nodes
• Scheduler runs on master
• Jobs can be submitted from any interactive node
• User commands
• qsub submit a job for execution
• qstat determine status of job, queue, server
• qdel delete a job from the queue
• qalter modify attributes of a job
• Single queue (workq)

25
PBS qsub

• qsub used to submit jobs to PBS
• A job is represented by a shell script
• Shell script can alter environment and proceed
  with execution
• Script may contain embedded PBS directives
• Script is responsible for starting parallel jobs
  (not PBS)

26
Hello World

• mcguigan_at_master pbs_examples cat helloworld
• echo Hello World from HOSTNAME
• mcguigan_at_master pbs_examples qsub helloworld
• 15795.master.cluster
• mcguigan_at_master pbs_examples ls
• helloworld helloworld.e15795 helloworld.o15795
• mcguigan_at_master pbs_examples more
  helloworld.o15795
• Hello World from node1.cluster

27
Hello World (continued)

• Job ID is returned from qsub
• Default attributes allow job to run
• 1 Node
• 1 CPU
• 360000 CPU time
• standard out and standard error streams are
  returned

28
Hello World (continued)

• Environment of job
• Defaults to login shell (overide with !) or S
  switch
• Login environment variable list with PBS
  additions
• PBS_O_HOST
• PBS_O_QUEUE
• PBS_O_WORKDIR
• PBS_ENVIRONMENT
• PBS_JOBID
• PBS_JOBNAME
• PBS_NODEFILE
• PBS_QUEUE
• Additional environment variables may be
  transferred using -v switch

29
PBS Environment Variables

• PBS_ENVIRONMENT
• PBS_JOBCOOKIE
• PBS_JOBID
• PBS_JOBNAME
• PBS_MOMPORT
• PBS_NODENUM
• PBS_O_HOME
• PBS_O_HOST
• PBS_O_LANG
• PBS_O_LOGNAME
• PBS_O_MAIL
• PBS_O_PATH
• PBS_O_QUEUE
• PBS_O_SHELL
• PBS_O_WORKDIR
• PBS_QUEUEworkq
• PBS_TASKNUM1

30
qsub options

• Output streams
• -e (error output path)
• -o (standard output path)
• -j (join error output as either output or
  error)
• Mail options
• -m aben when to mail (abort, begin, end, none)
• -M who to mail
• Name of job
• -N (15 printable characters MAX first is
  alphabetical)
• Which queue to submit job to
• -q name Unimportant for now
• Environment variables
• -v pass specific variables
• -V pass all environment variables of qsub to job
• Additional attributes
• -w specify dependencies

31
Qsub options (continued)

• -l switch used to specify needed resources
• Number of nodes
• nodes x
• Number of processors
• ncpus x
• CPU time
• cputhhmmss
• Walltime
• walltimehhmmss
• See man page for pbs_resources

32
Hello World

• qsub l nodes1 l ncpus1 l cput360000 N
  helloworld m a q workq helloworld
• Options can be included in script
• PBS -l nodes1
• PBS -l ncpus1
• PBS -m a
• PBS -N helloworld2
• PBS -l cput360000
• echo Hello World from HOSTNAME

33
qstat

• Used to determine status of jobs, queues, server
• qstat
• qstat ltjob idgt
• Switches
• -u ltusergt list jobs of user
• -f provides extra output
• -n provides nodes given to job
• -q status of the queue
• -i show idle jobs

34
qdel qalter

• qdel used to remove a job from a queue
• qdel ltjob IDgt
• qalter used to alter attributes of currently
  queued job
• qalter ltjob idgt attributes (similar to qsub)

35
Processing on a worker node

• All RAID storage visible to all nodes
• /dataxy where x is raid ID, y is Volume (1-3)
• /gfsx where x is gfs volume (1-3)
• Local storage on each worker node
• /scratch
• Data intensive applications should copy input
  data (when possible) to /scratch for manipulation
  and copy results back to raid storage

36
Parallel Processing

• MPI installed on interactive worker nodes
• MPICH 1.2.5
• Path /usr/local/mpich-1.2.5
• Asking for multiple processors
• -l nodesx
• -l ncpus2x

37
Parallel Processing (continued)

• PBS node file created when job executes
• Available to job via PBS_NODEFILE
• Used to start processes on remote nodes
• mpirun
• rsh

38
Using node file (example job)

• !/bin/sh
• PBS -m n
• PBS -l nodes3ppn2
• PBS -l walltime003000
• PBS -j oe
• PBS -o helloworld.out
• PBS -N helloword_mpi
• NNcat PBS_NODEFILE wc -l
• echo "Processors received "NN
• echo "script running on host hostname"
• cd PBS_O_WORKDIR
• echo
• echo "PBS NODE FILE"
• cat PBS_NODEFILE
• echo
• /usr/local/mpich-1.2.5/bin/mpirun -machinefile
  PBS_NODEFILE -np NN /mpi-example/helloworld

39
MPI

• Shared Memory vs. Message Passing
• MPI
• C based library to allow programs to communicate
• Each cooperating execution is running the same
  program image
• Different images can do different computations
  based on notion of rank
• MPI primitives allow for construction of more
  sophisticated synchronization mechanisms
  (barrier, mutex)

40
helloworld.c

• include ltstdio.hgt
• include ltunistd.hgt
• include ltstring.hgt
• include "mpi.h"
• int main( argc, argv )
• int argc
• char argv
• int rank, size
• char host256
• int val
• val gethostname(host,255)
• if ( val ! 0 )
• strcpy(host,"UNKNOWN")
• MPI_Init( argc, argv )

41
Using MPI programs

• Compiling
• /usr/local/mpich-1.2.5/bin/mpicc helloworld.c
• Executing
• /usr/local/mpich-1.2.5/bin/mpirun ltoptionsgt \
  helloworld
• Common options
• -np number of processes to create
• -machinefile list of nodes to run on

42
Resources for MPI

• http//www-hep.uta.edu/mcguigan/dpcc/mpi
• MPI documentation
• http//www-unix.mcs.anl.gov/mpi/indexold.html
• Links to various tutorials
• Parallel programming course
