Mathematical Modeling and Optimization: Summary of

1
Mathematical Modeling and OptimizationSummary
of Big Ideas
2
A schematic view of modeling/optimization process
assumptions, abstraction,data,simplifications
Real-world problem
Mathematical model
makes sense? change the model, assumptions?
optimization algorithm
Solution to real-world problem
Solution to model
interpretation
3
Mathematical models in Optimization

• The general form of an optimization model
• min or max f(x1,,xn) (objective function)
• subject to gi(x1,,xn) 0 (functional
  constraints)
• x1,,xn ? S (set constraints)
• x1,,xn are called decision variables
• In words,
• the goal is to find x1,,xn that
• satisfy the constraints
• achieve min (max) objective function value.

4
Types of Optimization Models
Stochastic (probabilistic information on data)
Deterministic (data are certain)
Discrete, Integer (S Zn)
Continuous (S Rn)
Linear (f and g are linear)
Nonlinear (f and g are nonlinear)
5
What is Discrete Optimization?

• Discrete Optimization
• is a field of applied mathematics,
• combining techniques from
• combinatorics and graph theory,
• linear programming,
• theory of algorithms,
• to solve optimization problems
• over discrete structures.

6
Solution Methods for Discrete Optimization
Problems

• Integer Programming
• Network Algorithms
• Dynamic Programming
• Approximation Algorithms

7
Integer Programming

• Programming Planning in this context
• In a survey of Fortune 500 firms, 85 of those
  responding said that they had used linear or
  integer programming.
• Why is it so popular?
• Many different real-life situations can be
  modeled as IPs.
• There are efficient algorithms to solve IPs.

8
Topics in this class about Integer Programming

• Modeling real-life situations as integer programs
• Applications of integer programming
• Solution methods (algorithms) for integer
  programs
• (maybe) Using software (called AMPL) to solve
  integer programs

9
IP modeling techniques

• Using binary variables
• Restrictions on number of options
• Contingent decisions
• Variables (functions) with k possible values
• Either-Or Constraints
• Big M method
• Balance constraints
• Fixed Charges
• Making choices with non-binary variables
• Piecewise linear functions

10
IP applications

• Facility Location Problem
• Knapsack Problem
• Multi-period production planning
• Inventory management
• Fair representation in electoral systems
• Consultant hiring
• Bin Packing Problem
• Pairing Problem
• Traveling Salesman Problem

11
Difficulties of real-life modeling

• The problems that you will encounter in the real
  world are always a lot messier than the clean''
  problems we looked at in this class there are
  always side constraints that complicate getting
  even a feasible solution.
• Most real world problems have multiple
  objectives, and it is hard to choose from among
  them.
• In the real world you must gain experience with
  how to adapt the idealized models of academia to
  each new problem you are asked to solve.

12
Utilizing the relationship between problems

• Important modeling skill
• Suppose you know
• how to model Problems A1,,Ap
• You need to solve Problem B
• Notice the similarities between Problems Ai and
  B
• Build a model for Problem B, using the model for
  Problem Ai as a prototype.
• Example
• The version of the facility location problem as a
  special case of the knapsack problem
• Solving the committee assignment problem by graph
  coloring

13
Complexity of Solving Discrete Optimization
Problems

• Two classes
• Class 1 problems have polynomial-time algorithms
  for solving the problems optimally.
• Examples Min. Spanning Tree Problem,
• Assignement Problem
• For Class 2 problems (NP-hard problems)
• No polynomial-time algorithm is known
• And more likely there is no one.
• Examples Traveling Salesman Problem
• Coloring Problem
• Most discrete optimization problems are in the
  second class.

14

• Three main directions to solve
• NP-hard discrete optimization problems
• Integer programming techniques
• Approximation algorithms
• Heuristics
• Important Observation Any solution method
  suggests a tradeoff between time and
  accuracy.
• On time-accuracy tradeoff schedule

Integer programming
Approximation algorithms
Heuristics
Brute force
Least accuracy
Most accuracy
Worst time
Best time
15
Solving Integer Programs (IP) vs solving Linear
Programs (LP)

• LP algorithms
• Simplex Method
• Interior-point methods
• IP algorithms use the above-mentioned LP
  algorithms as subroutines.
• The algorithms for solving LPs are much more
  time-efficient than the algorithms for IPs.
• Important modeling consideration Whenever
  possible avoid integer variables in your model.

16
LP-relaxation-based solution methods for Integer
Programs

• Branch-and-Bound Technique
• Cutting Plane Algorithms

17
Basic Concepts of Branch-and-Bound

• The basic concept underlying the branch-and-bound
  technique
• is to divide and conquer.
• Since the original large problem is hard to
  solve directly,
• it is divided into smaller and smaller
  subproblems
• until these subproblems can be conquered.
• The dividing (branching) is done by partitioning
• the entire set of feasible solutions into
  smaller and smaller subsets.
• The conquering (fathoming) is done partially by
• (i) giving a bound for the best solution in the
  subset
• (ii) discarding the subset if the bound
  indicates that
• it cant contain an optimal solution.

18
Summary of branch-and-bound

• Steps for each iteration
• Branching Among the unfathomed subproblems,
  select the one that was created most recently.
  (Break ties according to which has larger LP
  value.)
• Choose a variable xi which has a noninteger
  value xi in the LP solution of the subproblem.
  Create two new subproblems by adding the
  respective constraints xi ? ? xi? and xi ?
  xi? .
• Bounding Solve the new subproblems, record their
  LP solutions. Based on the LP values, update the
  incumbent, and the lower and upper bounds for
  OPT(IP) if necessary.
• Fathoming For each new subproblem, apply the
  three fathoming tests. Discard the subproblems
  that are fathomed.
• Optimality test If there are no unfathomed
  subproblems left then return the current
  incumbent as optimal solution
• (if there is no incumbent then IP is
  infeasible.)
• Otherwise, perform another iteration.

19
Importance of tight lower and upper bounds in
branch-and-bound

• Having tight lower and upper bounds on the IP
  optimal value might significantly reduce the
  number of branch-and-bound iterations.
• For maximization problem,
• A lower bound can be found
• by applying a fast heuristic algorithm to the
  problem.
• An upper bound can be found by solving a
  relaxation of the problem (e.g., LP-relaxation).
• If the current lower and upper bounds are close
  enough, we can stop the branch-and-bound
  algorithm and return the current incumbent
  solution
• (it cant be too far from the optimum).

20
General Idea of Cutting Plane Technique

• Add new constraints (cutting planes) to the
  problem such that
• (i) the set of feasible integer solutions
  remains the same, i.e., we still have the same
  integer program.
• (ii) the new constraints cut off some of the
  fractional solutions making the feasible region
  of the LP-relaxation smaller.
• Smaller feasible region might result in a better
  LP value (i.e., closer to the IP value), thus
  making the search for the optimal IP solution
  more efficient.
• Each integer program might have many different
  formulations.
• Important modeling skill
• Give as tight formulation as possible.
• How? Find cutting planes that make the
  formulation of the original IP tighter.

21
Methods of getting Cutting Planes

• Exploit the special structure of the problem
• to get cutting planes
• (e.g., bin packing problem, pairing problem)
• Often can be hard to get
• Topic of intensive research
• More general methods are also available
• Can be used automatically for many problems
• (e.g., knapsack-type constraints)

22
Branch-and-cut algorithms

• Integer programs are rarely solved based solely
  on cutting plane method.
• More often cutting planes and branch-and-bound
  are combined to provide a powerful algorithmic
  approach for solving integer programs.
• Cutting planes are added to
• the subproblems created in branch-and-bound
• to achieve tighter bounds
• and thus to accelerate the solution process.
• This kind of methods are known as
• branch-and-cut algorithms.

23
Network Models

• Minimum Spanning Tree Problem
• Assignment Problem
• Traveling Salesman Problem
• Coloring Problem
• Min. Spanning Tree and Assignment Problem are in
  Class 1 (has polynomial-time algorithms for
  solving the problem optimally).
• Traveling Salesman Problem and Graph Coloring are
  in Class 2 (NP-hard problem).

24
Methods for solving NP-hard problems

• Three main directions to solve
• NP-hard discrete optimization problems
• Integer programming techniques
• Heuristics
• Approximation algorithms
• We gave examples of all three methods for TSP.
• 2-approximation algorithm for TSP was given and
  analyzed in details.

25
Some Characteristics of Approximation Algorithms

• Time-efficient (sometimes not as efficient as
  heuristics)
• Dont guarantee optimal solution
• Guarantee good solution within some factor of the
  optimum
• Rigorous mathematical analysis to prove the
  approximation guarantee
• Often use algorithms for related problems as
  subroutines
• The 2-approximation algorithm for TSP used the
  algorithm of finding a minimum spanning tree as
  subroutine.

26
Performance of TSP algorithms in practice

• A more sophisticated algorithm (which again uses
  the MST algorithm as a subroutine) guarantees a
  solution within factor of 1.5 of the optimum
  (Christofides).
• For many discrete optimization problems, there
  are benchmarks of instances on which algorithms
  are tested.
• For TSP, such a benchmark is TSPLIB.
• On TSPLIB instances, the Christofides algorithm
  outputs solutions which are on average 1.09 times
  the optimum.
• For comparison, the nearest neighbor algorithm
  outputs solutions which are on average 1.26 times
  the optimum.
• A good approximation factor often leads to good
  performance in practice.

27
Dynamic Programming

• Dynamic programming is a widely-used mathematical
  technique for solving problems that can be
  divided into stages and where decisions are
  required in each stage.
• The goal of dynamic programming is to find a
  combination of decisions that optimizes a certain
  amount associated with a system.

28
General characteristics of Dynamic Programming

• The problem structure is divided into stages
• Each stage has a number of states associated with
  it
• Making decisions at one stage transforms one
  state of the current stage into a state in the
  next stage.
• Given the current state, the optimal decision for
  each of the remaining states does not depend on
  the previous states or decisions. This is known
  as the principle of optimality for dynamic
  programming.
• The principle of optimality allows to solve the
  problem stage by stage recursively.

29
Problems that can be solved by Dynamic Programming

• Shortest path problems
• Multi-period production planning
• Resource allocation problems

30
Advantages of Dynamic Programming

• More time-efficient compared to integer
  programming (but large-scale real-life problems
  might require lots of states)
• Can solve a variety of problems (however integer
  programming is a more universal technique)
• Can handle stochastic data (for example,
  stochastic demand in multi-period production
  planning)
