Intro to Stata

1
SIAP-SRTC Training Course on Sampling Acceed
Center, AIM, Makati Philippines 4 April 2002
2
OUTLINE

• Statistical Computing Resources
• Data Management with Stata
• Table Generation
• Tab and Table Commands
• Survey Commands

3
(No Transcript)
4
Computing Resources

• The Age of ICT has brought about a synergy of
  computing and communications
• Implications
• More DATA collected
• More DATA stored
• More DATA accessible and distributed

5
Computing Resources

• There are a host of statistical software that
  provide pre-programmed analytical and data
  management capabilities. These software may be
  classified according to use and cost.

6
Computing Resources

• Types of Stat Software by usage
• General Purpose -- SAS, SPSS, R, Splus,
  Statistica, Stata
• Special Purposes -- econometric modeling
  (Eviews), seasonal adjustment (X12), Bayesian
  modeling (WINBUGS), survey data tabulation
  variance estimation (IMPS, CENVAR)

7
Computing Resources

• Types of Stat Software by cost
• Commercial Software - SAS, SPSS, Stata, S-plus
• Freeware - R, IMPS, X12

8
Computing Resources

• FOR SURVEY DATA
• Bascula from Statistics Netherlands.
• CENVAR ( IMPS)from U.S. Bureau of the Census.
• CLUSTERS from University of Essex.
• Epi Info from Centers for Disease Control.
• Generalized Estimation System (GES) from
  Statistics Canada.
• IVEWare (beta version) from University of
  Michigan.

9
Computing Resources

• FOR SURVEY DATA
• PCCARP from Iowa State University.
• SAS/STAT from SAS Institute.
• Stata from Stata Corporation.
• SUDAAN from Research Triangle Institute.
• VPLX from U.S. Bureau of the Census.
• WesVar from Westat, Inc.

10
Computing Resources

• Lists of Statistical Software
• http//members.aol.com/johnp71/javasta2.html
• http//www.stir.ac.uk/Departments/HumanSciences/S
  ocInfo/Statistical.htm
• http//www.fas.harvard.edu/stats/survey-soft/
• http//www.feweb.vu.nl/econometriclinks/software.
  html

11
Computing Resources

• This afternoon, we will provide a demonstration
  on how to use STATA for accomplishing some of the
  most common tasks of data management, statistical
  computing and analysis of survey data.

12
Computing Resources

• Stata
• Estimation of means, totals, ratios, and
  proportions
• linear regression, logistic regression, and
  probit.
• Point estimates, associated standard errors,
  confidence intervals, and design effects for the
  full population or subpopulations are displayed.

13
Computing Resources

• Stata
• Auxiliary commands display various information
  for linear combinations (e.g., differences) of
  estimators, and conduct hypothesis tests.
• New in Stata contingency tables with Rao-Scott
  corrections of chi-squared tests new
  survey-corrected regression commands including
  tobit, interval, censored, instrumental
  variables, multinomial logit, ordered logit and
  probit, and Poisson

14
Computing Resources

• Stata
• stratified designs
• cluster sampling
• FPCs can be calculated for simple random sampling
  w/o replacement of sampling units within strata
• variance estimation for multistage sample data
  carried out through the customary
  between-PSU-squared-differences calculation.

15
Computing Resources

• Stata
• Variance estimation is done thru Taylor-series
  linearization in the survey analysis commands.
  There are also commands for jackknife and
  bootstrap variance estimation, but these are not
  specifically oriented toward survey data.

16
Computing Resources

• Note
• We will demonstrate the use of STATA version 6.
  Current version is version 7 even a Special
  Edition (SE) which can handle up to 32,766
  variables w/ strings up to 244 chars, and up to
  11,000 x 11,000 matrices.

17
(No Transcript)
18
Data Management

• STARTING UP
• Go to Start, Programs, Stata, Intercooled Stata
• Alternatively, from Windows Explorer, go to
  folder
• c\stata
• Double click
• wstata.exe

19
Data Management
20
Data Management

• CREATING A NEW DATASET
• Open the STATA spreadsheet editor

21
Data Management

• CREATING A NEW DATASET
• Enter data into the editor, when done close the
  editor.

22
Data Management

• CREATING A NEW DATASET
• In the STATA COMMAND window enter the command
• save newfile

23
Data Management

• NOTE
• A STATA dataset will have extension name dta.
  That is, newfile is actually newfile.dta
• Public use files of some surveys, e.g. VLSS
  (Vietnam Living Standards Survey), are in Stata
  format.

24
Data Management

• INSPECTING DATA BASE
• In the STATA COMMAND window enter the following
  commands
• describe
• list
• summarize

25
Data Management

• NOTE
• Stata is case sensitive.
• Stata commands may be abbreviated, e.g. D for
  DESCRIBE, SUM for SUMMARIZE, etc.
• We may use Page Up/Down keys or mouse for
  re-selecting commands in the Review window.

26
Data Management

• NOTE
• Commands and output are shown in Results window.
  Windows may be re-sized.
• Commands and output may be logged into a log
  file by pressing Open Log button.

27
Data Management

• RENAMING VARIABLES
• ONE WAY (From Data Editor) Double click
  anywhere in the variables column resulting in a
  dialogue box

28
Data Management

• RENAMING VARIABLES
• SECOND WAY (In the STATA COMMAND window) enter
• rename var1 domain
• rename var2 hcn
• rename var3 age
• label variable age HH head age
• d

29
Data Management

• SAVING EDITED DATABASE
• In the STATA COMMAND window enter the following
  commands
• save newfile, replace
• Note typing only
• save newfile
• will result in an error message

30
Data Management

• READING PRE-EXISTING
• STATA DATASET
• If dataset is in folder c\fies2000 and filename
  is fies00small.dta, enter
• clear
• set mem 64m
• cd c\fies2000
• use fies00small

NOTE Impt for MEMORY MANAGEMENT
31
Data Management

• IMPORTING DATA
• Suppose we have a dataset try.txt in c\fies2000
  folder

NOTE Missing Data coded as .
32
Data Management

• IMPORTING DATA
• Suppose we have a dataset try.txt in c\fies2000
  folder
• Use the infile command with syntax
• infile variable-list using filename.raw
• In particular, enter
• cd c\fies2000
• infile domain hcn age using try.txt,
• automatic

33
Data Management

• TRIVIA ON STRING VARIABLES
• When using the infile command for character
  (string) variables, we need to identify these
  variables. For instance
• infile domain hcn str30 prov using tr.txt
• For more details regarding infile, enter
• help infile1

34
Data Management

• IMPORTING DATA
• Suppose we have a dataset try2.txt in c\fies2000
  folder with the data in specific fields

Assumes last line is blank line
35
Data Management

• IMPORTING DATA
• Suppose we have a dataset try2.txt in c\fies2000
  folder with the data in specific fields
• Use the infix command
• infix domain 1 hcn 2 age 3-4 using try2.txt,
  clear

36
Data Management

• Thus, Stata can read text files with
• Infile (if the data in text is separated by
  spaces and does not have strings, or if strings
  are just one word, or if all strings are enclosed
  in quotes)
• Infix (fixed format text)
• Insheet (if text file was created by a
  spreadsheet or db program)

37
Data Management

• NOTE
• The commands infile, infix, insheet read data
  from ASCII files. Outfile is a way to save the
  data in ASCII.
• There are third party programs, esp.
  Stat/Transfer and DBMS/COPY, that perform
  translations from one data format (e.g., dBASE,
  Excel, SAS, SPSS, Stata) to another.

38
Data Management
39
Data Management

• OTHER USEFUL COMMANDS
• To sort the dataset by age
• sort age
• To get a listing of the dataset
• list
• To get a listing of the 2nd-4th data
• list in 2/4

40
Data Management

• OTHER USEFUL COMMANDS
• To summarize the restricted dataset of HHs whose
  heads age is less than/equal to 50
• summarize if age lt50
• HH head age between 35 and 50
• summarize if age lt50 age gt35

41
Data Management

• Comparison operators
• gt gt
• lt lt !
• Logical operators
• (and) ! (not)
• (or) (not)

42
Data Management

• OTHER USEFUL COMMANDS
• To tabulate domain
• tab domain
• To generate contingency tables
• tab domain hcn if agegt35
• To get the correlation matrix
• correlate x y z

43
Data Management

• GENERATING REPLACING VARIABLES
• Suppose we want to obtain per capita income (pci)
  of FIES 2000 households
• clear
• cd d\fies00
• use fies00small
• gen pcitoinc/hsize

44
Data Management

• GENERATING REPLACING VARIABLES
• Now tag the household as poor (1) if pci lt some
  threshold, say 13823, determine percent of HHs
  that are poor.
• gen poor1 if pci lt 13823
• replace poor0 if poor.
• sum poor awrfact
• save fies00small, replace

45
Data Management

• NOTE
• Small portion of data set of FIES 2000 was used.
  The Family Income and Expenditure Survey (FIES)
  is conducted by the National Statistics Office
  (NSO)every 3 years. Data may be purchased
  through the NSO website
• www.census.gov.ph

46
SIAP-SRTC Training Course on Sampling Acceed
Center, AIM, Makati Philippines 5 April 2002
47
Data Management

• RECALL
• That if we use our fies2000 data set
• set mem 64m
• cd c\fies2000
• use fies00small
• sum poor awrfact
• Note poverty line we provided is a weighted
  average of the variable poverty lines in the
  Philippines (for urban-rural areas across the
  different regions)

48
(No Transcript)
49
Estimating Food Poverty Line

• Food poverty line estimated from low cost one day
  menus (breakfast, lunch, supper snack)
  constructed for each urban-rural area of a region
  by Food and Nutrient Research Institute (FNRI)
  which meet 100 sufficiency in energy and protein
  requirements and 80 sufficiency of other
  nutrients and vitamins.
• RDAs for energy 2000 Kcal per person
• RDAs for protein 50 grams per person
• 29 such menus constructed on the basis of the
  1988 Food Consumption Survey

50
Annual Per Capita Food Line Urban, by Region
51
Annual Per Capita Food Line Rural, by Region
52
Estimating Poverty Line

• Poverty Line Food Threshold/ Engels Coefficient

• Engels coefficient estimated by analyzing the
  consumption pattern of families having incomes
  within plus or minus 10 percentage points from
  food threshold.
• Engels coeff Food Exp/ Total Basic Exp

53
Annual Per Capita Poverty Line Urban, by Region
54
Annual Per Capita Poverty Line Rural, by Region
55
Poverty Statistics (Family)
Measures 2000 1997

Poverty Incidence 33.60.3 31.8
Poverty Gap 10.7 0.1 10.0
Severity Index 4.6 0.1 4.3
Standard Error
56
Poverty Incidence All Areas, by Region
57
Small Area Poverty Stats?

• Stata has some add ons for generating SEs for
  poverty stats
• If we wish to generate provincial poverty
  statistics, we will find out that SEs are too
  high, i.e. figures are unreliable

58
(No Transcript)
59
Data Management

• RECALL
• That if we use our fies2000 data set
• set mem 64m
• cd c\fies2000
• use fies00small
• sum poor awrfact
• Note poverty line we provided is a weighted
  average of the variable poverty lines in the
  Philippines (for urban-rural areas across the
  different regions)

60
Data Management

• NOTE
• STATA uses several types of weights
• fw frequency weights
• aw analytic weights
• iw importance weights
• pw probability weights

61
Data Management

• NOTE
• Within the command generate or replace, we may
  transform or create variables by using functions,
  e.g.,
• generate logincln(toinc)
• generate ycos(x_pi/180)
• replace newvarnormd(z)
• generate rvaruniform()

62
Data Management

• DELETING VARIABLES/DATA
• To drop a variable, say age
• drop age
• To drop some observations
• drop in 2/3
• Try also the command keep.
• To drop all data in memory
• clear

63
Data Management

• NOTE
• So far we have used STATA interactively. We can
  also do batch processing through the DO FILE
  editor.

64
Data Management

• NOTE
• The STATA toolbar has 13 buttons.
• The first three are to OPEN a Stata dataset
• SAVE to the disk the resident dataset
• PRINT a graph or log

65
Data Management

• The next five are for Starting/stopping/suspendin
  g a LOG
• Bringing the Log to the Front
• Bringing the Dialog to Front
• Bringing the Results to Front
• Bringing the Graph to Front

66
Data Management

• The last five are for
• Opening the DO FILE editor
• Opening the DATA editor
• Opening the DATA Browser
• Telling Stat to continue when it has paused
  in mid of long output
• Stopping the current task

67
Exercise

• What is the average income of families that are
  below or above the mean family expenditure?

68
Exercise

• Compare correlation of food expenditures (fexp)
  and nonfood expenditures for families in rural
  urban areas.

69
Extra

• Enter
• graph food nfood

70
Extra

• Now try
• sort urb
• graph food nfood, by (urb)
• graph food nfood, by (urb) total

71
Extra

• Matrix plots
• graph toinc food nfood, matrix

72
(No Transcript)
73
Table Generation w/ tab

• Earlier, we showed the use of the tab(ulate)
  command. Try
• tab urb
• tab urb awrfact
• tab urb iwrfact
• tab urb regn

74
Tab

• The tab command has options for generating 1-way
  tables of freqs
• tab urb, summ(toinc)
• and two way tables
• tab urb sex
• tab urb sex, row
• tab urb sex, row col chi2
• tab urb sex, all exact

75
Table Generation w/ table

• Aside from the tab command, we can generate
  tables of statistics with the table command.
  Compare
• tab urb
• with
• table urb

76
Table

• To generate the average (family) income and
  average (family) expenditure across urban and
  rural areas, enter
• table urb, c(mean toinc mean toexp)
• Using weights
• table urb awrfact, c(mean toinc mean toexp)

77
Table

• The contents option may specify at most five of
  the ff statistics
• freq (for frequency)
• mean varname (for mean of varname)
• sd varname (for standard deviation)
• sum varname (for sum)
• rawsum varname (for sums ignoring optionally
  specified weight)
• count varname (for count of nonmissing data)

78
Table

• The contents option may specify at most five of
  the ff statistics
• n varname (same as count)
• max varname (for maximum)
• min varname (for minimum)
• median varname (for median)
• p1 varname (for 1st percentile)
• p2 varname (for 2nd percentile)
• ...
• iqr varname (for interquartile range)

79
Exercise Using Table

• Obtain the average and median per capita income
  of households by sex of household head
• table sex, c(mean pci median pci)
• Obtain the weighted frequency of poor and
  nonpoor households across regions
• table poor regn iwrfact

80
Using Survey Commands

• STATA has designed a family of commands
  especially for sample surveys. These commands
  all begin with svy
• svyset setting variables
• svydes describe strata and PSUs
• svymean estimate popn subpop means
• svytotals estimate popn subpop totals

81
Using Survey Commands

• Svy commands
• svyprop estimate popn subpop props
• svyratio estimate popn subpop ratios
• svytab for two way tables
• svyreg for regression
• svyivreg for instrumental variables reg
• svylogit for logit reg
• svyprobit for probit reg

82
Using Survey Commands

• Svy commands
• svytest for hypothesis testing
• svylc for estimating linear combs
• svymlog for multinomial logistic reg
• svyolog for ordered logistic reg
• svyoprob for ordered probit reg
• svypois for poisson reg
• svyintrg for censored interval reg

83
Using Survey Commands

• Before issuing any svy estimation command, we
  identify the weight, strata and PSU identifier
  variables
• svyset pweight rfact
• svyset strata domain
• svyset psu hcn

84
Using Survey Commands

• To obtain the average family income average
  family expenditure
• svymean toinc toexp
• To obtain the total family income, total family
  expenditure by province
• svytotal toinc toexp, by(regn)

85
Using Survey Commands

• To obtain the per capita income per capita
  expenditure
• svyratio toinc/fsize toexp/fsize
• pci pce by urban/rural
• svyratio toinc/fsize toexp/fsize, by(urb)

86
Using Survey Commands

• Linear regression of ln(pci)
• gen logincln(pci)
• svyreg loginc age fsize sex prov urb
• Compare the results with the regular regression
  command
• reg loginc age fsize sex prov urb

87
Using Survey Commands

• Two way tables
• svytab urb poor, row se
• compared with
• tab urb poor awrfact, no freq row

88
Alternatives to STATA
89
Learning More about Stata

• Online tutorial, type
• tutorial intro
• List of Tutorials
• Tutorial Description
• --------------------------------------------------
  ---
• intro An introduction to Stata
• graphics How to make graphs
• tables How to make tables
• regress Estimating regression models, inc
  2SLS
• anova Estimating one-, two- and N-way
  ANOVA and ANCOVA models

90
Learning More about Stata

• Tutorial Description
• --------------------------------------------------
  ---
• logit Estimating maximum-likelihood logit
  and probit models
• survival Estimating ML survival models
• factor Estimating factor and principal
  component models
• ourdata Description of the data we provide
• yourdata How to input your own data into Stata

91
Learning More about Stata

• Email distribution list. Send email to
• Majordomo_at_hsphsun2.harvard.edu
• In the body of your email message type the
  message   subscribe statalist email_at_addressor
  for a daily summary
• subscribe statalist-digest email_at_address

92

• Maraming Salamat sa inyong pakikinig.
• (Thank you for your attention)
