Iteration Structures

1
Lesson 7

• Iteration Structures

2
Iteration Structures

• Iteration is the third control structure we will
  explore.
• Iteration simply means to do something
  repeatedly.
• All iteration control structures test a condition
  each time before the loop is executed.

3
Types of Loops

• There are three types of loops that Java employs.
• Pretest Loop- test a condition each time before
  the loop is executed.
• Posttest Loop - test a condition after each loop
  execution.
• Fixed repetition - cause a loop to be executed a
  predetermined number of times.

4
Three Iteration Control Structures

• The three iteration control structures are the
  while, do/while, and for.
• The difference between them is the means by which
  they control the exiting of the loop.
• The while is a pretest loop.
• The do/while is a posttest loop.
• The for is a fixed repetition loop.

5
The WHILE loop

• If the test expression is true the loop
  statements are executed.
• If the test expression is false the loop
  statements are bypassed.
• To get out of the loop something must change the
  expression to false, otherwise the the result
  will be an infinite loop.

6
Syntax for the While Loop
while (test expression) statement1 statement2
statementn
7
While Loop Example (counter)

• //Compute 1 2 . . . 100
• class counter
• public static void main (String Args)
• int sum 0, cntr 1
• while (cntr lt100)
• sum cntr
• cntr
• System.out.println (sum)

8
While Loop Example (Square Roots)

• //Display the square roots of 25, 20, 15, and 10
• class SquareRoots
• public static void main (String args)
• int number 25
• while (number gt10)
• System.out.println ("The square root of "
  number " is Math.sqrt(number))
• number -5

9
The DO/WHILE loop

• The do/while loop is tested at the end of the
  loop compared to the while which is tested at the
  beginning.
• The loop statements will always be executed once.
• To break the loop the test expression must become
  false.

10
Syntax for DO/WHILE
do statement1 statement2 statementn whil
e (test expression)
11

• class dowhile
• public static void main(String args)
• int myNum
• //generate random numbers until we get 5
• do
• myNum (int)(Math.random() 10)
• System.out.print(myNum)
• while (myNum !5)

12
Using Counters and Accumulators

• Numeric variables used within a repetition
  structure to calculate subtotals, totals, and
  averages
• Counter
• Used for counting something
• Accumulator
• Used for accumulating (adding together) something

13
Sentinel Values

• Values used to end loops
• Should be easily distinguishable from the valid
  data used by the program
• Also called trip values or trailer values

14
Sentinel values

• Our program can read numbers repeatedly until it
  encounters a special value called a sentinel that
  marks the end of the list.
• For example, if all the numbers in the list are
  positive, then the sentinel could be -1.

15

• import TerminalIO.KeyboardReader
• class sentinel
• public static void main(String args)
• KeyboardReader reader new KeyboardReader()
• double number, sum 0
• int count 0
• while (true)
• number reader.readDouble("Enter a positive
  number or -1 to quit ")
• if (number -1)
• break
• sum number
• count
• System.out.println("The average is "
  sum/count)

16
The FOR loop

• The for loop runs a fixed number of times
• The first thing that is done is the
  initialization of the counter.
• If the results of the test expression is true,
  then the statements are executed.
• Each time the loop is executed, the loop counter
  must be incremented or decremented.

17
Syntax for FOR loop
for (initialize counter test counter update
counter) statement1 statement2 statementn

18

• class Racer
• public static void main (String args)
• System.out.println("GO!")
• for (int lap1 lap lt10 lap)
• System.out.println("Completed " lap "
  laps.")
• System.out.println("Finish!")

19
Nested Loops

• Many times it is desirable to have looping
  operations within loops.
• This is called nested looping.
• Each inner loop will as many times as desired X
  the number of times the outer loop runs.

20
Each iteration of the outer loop causes multiple
iterations of the inner loop.

• class NestedForLoop
• public static void main (String args)
• for (int i 0 i lt3 i)
• for (int j 0 j lt 3 j)
• System.out.println("i " i ", j "
  j)

21
Break and Continue Option

• If you want a loop to terminate if some desired
  value is found, it is possible to use the break
  statement to force the loop to quit.
• If you want one iteration of the loop to be
  terminated, it is possible to use a continue
  statement to force the loop to quit one iteration
  and continue on with another.

22
Syntax for BREAK
while (test expression) statement1 statement2
if (test expression) break statementn
23
The loop will iterate once because the condition
is true, but the break statement takes the
program right out of the loop.

• class breakExample
• public static void main (String args)
• while (true)
• System.out.print ("true")
• break
• System.out.println(" out of loop")

24
Syntax for CONTINUE
for (initialize counter test counter update
counter) statement1 statement2 if (test
expression) continue statementn
25
The continue statement causes the loop to stop
where it is and loop again from the beginning,
causing an infinite loop.

• class ContinueExample
• public static void main (String args)
• boolean b true
• while (b)
• if (b) continue
• System.out.println("never gets here")
• b false

26
Bottoms Up On The

• Fifth Cup
