BRX210

1
BRX210 Mechanical Blueprint Reading

• Unit 13
• Print Reading Review

2
When completing these quizzes, use the following
procedure

• 1. Begin by studying the drawing. Imagine that
  you are making the part that is shown in the
  print. Try to visualize the piece by asking
  yourself these questions
• What type of material is used? What color will
  the finished product be? Will the edges be
  smooth or rough?
• How large is the piece? Could you easily hold it
  in your hand, or would several people be needed
  to lift it?

3

• Which machining processes are used to create the
  piece? Do holes require reaming or tapping?
  Which surfaces need to be machined?
• For whom is the piece being manufactured? Why do
  they need this piece?
• Are there any unusual notes or tolerances that
  will require additional work or time?
• 2. Once you have visualized the piece, answer the
  quiz questions
• 3. After completing the questions, recheck your
  answers. Use common sense to make sure that your
  answers are reasonable
