Plant Structure and Growth

1
Plant Structure and Growth

• Chapter 35

2
Monocots vs. dicots
3
Monocot or Dicot?
4
Monocot or Dicot?
5
Monocot or Dicot?
6
Monocot or Dicot?
7
Roots

• Fibrous Root systems
• Monocots
• Anchor plants tenaciously
• Prevent erosion
• Increases surface area for absorption of water
  and nutrients

8
Taproot Systems

• Dicots
• Anchor plants firmly
• Stores food
• Carrots, turnips, sugar beets
• Can go far below ground
• Desert plants

9
(No Transcript)
10
(No Transcript)
11
Root Hairs

• Epidermal extensions
• Increase surface area

12
(No Transcript)
13
Symbiosis with fungi

• Most plants have mutualistic partnership with
  fungi forming a root/fungus structure called
  mycorrhizae
• Fungi absorb water and select minerals for host
  plant (HUGE surface area)
• Host plant nourishes fungus

14
(No Transcript)
15
Stems

• Axillary Bud usually dormant bud, can form
  branch
• Terminal bud bud at shoot tip that has
  developmental leaves

16
(No Transcript)
17
(No Transcript)
18
What is apical domiance?

• Concentration of growth at the tip of a plant
  shoot, where a terminal bud inhibits axillary bud
  growth
• Hormonally regulated (auxin produced from
  terminal bud)
• Adaptation allows for plant to get taller in
  shaded woods

19
Why do owners of houseplants pinch them back?

• To remove the terminal bud, thereby removing
  inhibition of the axillary buds, causing branching

20
Modified stems

• Stolons

21
Modified Stems

• Rhizomes

22
Modified Stems

• Bulbs

23
Leaves

• Flattened blades
• Petioles join leaf to the stem node
• Not present in many monocots
• Monocots have parallel leaf veins
• Dicots have net-like leaf veins

24
(No Transcript)
25
Cell Types

• Parenchyma
• Most abundant type
• typical plant cell
• Relatively unspecialized
• Thin primary cell walls
• Most ground tissue, sieve tube members, fruit
  tissue

26
Cell types

• Collenchyma
• Thick primary cell walls
• Lack secondary walls
• Provides support for young shoot, petioloes
• Living, flexible, capable of elongating

27
Cell types

• Sclerenchyma
• Supports
• Thick secondary cell walls
• Not capable of elongating (cant grow)
• May be dead at maturity (tracheids of xylem)
• Hemp, flax

28
(No Transcript)
29
Tissue Systems

• Dermal tissue
• Protects
• Secretes waxy cuticle
• Root hairs
• Guard Cells, stomata

30

• Vascular Tissue

31
Xylem

• Transports water and nutrients up from the roots
• Tracheids and vessel elements (functional cells)
• All vascular have tracheids
• Angiosperms and few others have vessel elements
• Dead at maturity
• Pits connect tracheids
• Has thick secondary walls (often hardened with
  lignin), supports the plant

32
(No Transcript)
33
Phloem

• Transports food from leaves to other parts of the
  plant
• Sieve tube members and companion cells
  (functional cells)
• Sieve tube members lack nuclei, ribosomes
• Alive at maturity
• Sieve plates connect sieve tube members

34
(No Transcript)
35
Ground Tissue

• Photosynthetic
• Storage

36
Vascular tissue organization

• Dicot root xylem forms a cross in the center

37
(No Transcript)
38
(No Transcript)
39
Vascular tissue organization

• Monocot Root xylem and phloem alternate in a
  ring

40
(No Transcript)
41
(No Transcript)
42
Vascular tissue organization

• Monocot Stem vascular bundles (combo of xylem
  and phloem) scattered
• Dicot stem vascular bundles arranged in a ring
  around the periphery

43
(No Transcript)
44
Plant Growth

• Meristems
• def perpetually embryonic tissues
• Indeterminate growth
• Primary growth lengthens roots and shoots
• Secondary growth thickens roots and shoots

45
(No Transcript)
46
Primary Growth

• Tip covered by root cap
• Protection
• Polysaccharide slime secretion
• Zone of cell division
• Zone of cell elongation
• Zone of cell maturation
• Quiescent center

47
(No Transcript)
48
(No Transcript)
49
Secondary Growth

• Growth in girth
• Two lateral meristems (dicots)
• Vascular cambium
• Forms secondary xylem and phloem
• Secondary xylem accumulates (wood) while
  secondary phloem is sloughed off
• Cork cambium
• Forms cork
• Barkcork, cork cambium, and secondary phloem

50
(No Transcript)
51
(No Transcript)
52
Leaves

• What is the ground tissue of the leaf?
• Mesophyll
• How is the mesophyll arranged?
• Spongy and palisade regions
• Spongy region has spaces for gas circulation

53
(No Transcript)
54
(No Transcript)
