Title: 10.5 Hyperbolas


1
10.5 Hyperbolas
  • L. Kealii Alicea

2
Hyperbolas
  • Like an ellipse but instead of the sum of
    distances it is the difference
  • A hyperbola is the set of all points P such that
    the differences from P to two fixed points,
    called foci, is constant
  • The line thru the foci intersects the hyperbola _at_
    two points (the vertices)
  • The line segment joining the vertices is the
    transverse axis, and its midpoint is the center
    of the hyperbola.
  • Has 2 branches and 2 asymptotes
  • The asymptotes contain the diagonals of a
    rectangle centered at the hyperbolas center

3
Asymptotes
(0,b)
Vertex (a,0)
Vertex (-a,0)
Focus
Focus
(0,-b)
This is an example of a horizontal transverse
axis (a, the biggest number, is under the x2
term with the minus before the y)
4
Vertical transverse axis
5
Standard Form of Hyperbola w/ center _at_ origin
Equation Transverse Axis Asymptotes Vertices
Horizontal y/- (b/a)x (/-a,o)
Vertical y/- (a/b)x (0,/-a)
Foci lie on transverse axis, c units from the
center c2 a2b2
6
Graph 4x2 9y2 36
  • Write in standard form (divide through by 36)
  • a3 b2 because x2 term is transverse axis
    is horizontal vertices are (-3,0) (3,0)
  • Draw a rectangle centered at the origin.
  • Draw asymptotes.
  • Draw hyperbola.

7
(No Transcript)
8
Write the equation of a hyperbole with foci
(0,-3) (0,3) and vertices (0,-2) (0,2).
  • Vertical because foci vertices lie on the
    y-axis
  • Center _at_ origin because f v are equidistant
    from the origin
  • Since c3 a2, c2 b2 a2
  • 9 b2 4
  • 5 b2
  • /-v5 b

9
Assignment10.5A (all)10.5B(odd)
