Chapter 1 Crystal Structures

1
Chapter 1Crystal Structures
2
Two Categories of Solid State Materials
Crystalline quartz, diamond.. Amorphous
glass, polymer..
3
Ice crystals
4
crylstals
5
(No Transcript)
6
(No Transcript)
7
Lattice Points, Lattice and Unit Cell

• How to define lattice points, lattice and unit
  cell?

8
LATTICE

• LATTICE An infinite array of points in space,
  in which each point has identical surroundings to
  all others.
• CRYSTAL STRUCTURE The periodic arrangement of
  atoms in the crystal.
• It can be described by associating with each
  lattice point a group of atoms called the MOTIF
  (BASIS)

9

10
Notes for lattice points

• Don't mix up atoms with lattice points
• Lattice points are infinitesimal points in space
• Atoms are physical objects
• Lattice Points do not necessarily lie at the
  centre of atoms

11
An example of 2D lattice
12
An example of 3D lattice
13
Unit cell A
repeat unit (or motif) of the regular
arrangements of a crystal is defined
as the smallest repeating unit which
shows the full symmetry of the crystal structure
14
More than one ways
15
How to assign a unit cell
16
A cubic unit cell
17
3 cubic unit cells
18
Crystal system

• is governed by unit cell shape and symmetry

19
The Interconversion of Trigonal Lattices
????????
20
The seven crystal systems
21
Symmetry
Space group point group translation
22
Definition of symmetry elements

• --------------------------------------------------
  -----------
• Elements of symmetry
• ------------------------------------------------
• Symbol Description
  Symmetry operations
• --------------------------------------------------
  -------------------
• E Identity
  No change
• s Plane of symmetry
  Reflection through the plane
• i Center of symmetry
  Inversion through the center
• Cn Axis of symmetry
  Rotation about the axis by (360/n)o
• Sn Rotation-reflection
  Rotation about the axis by (360/n)o
• axis of symmetry
  followed by reflection through the

•
  plane perpendicular to the
  axis
• --------------------------------------------------
  -------------------

23
Center of symmetry, i
24
Rotation operation, Cn
25
Plane reflection , ?
26
Matrix representation of symmetry operators
27
Symmetry operation
28
Symmetry elements
C3
29
space group point group translation
Symmetry elements
Screw axes 21(//a), 21(//b), 41(//c) 42(//c), 31(//c) etc
Glide planes c-glide (- b), n-glide, d-glide etc
30
21 screw axis // b-axis
31
Glide plane
32
Where are glide planes?
33
Examples for 2D symmetry
http//www.clarku.edu/djoyce/wallpaper/seventeen.
html
34
Examples of 2D symmetry
35
General positions of Group 14 (P 21/c) unique
axis b
1 x,y,z identity
2 -x,y1/2,-z1/2 Screw axis
3 -x,-y,-z i
4 x,-y1/2,z1/2 Glide plane
36
Multiplicity, Wyckoff Letter, Site Symmetry
4e 1 (x,y,z) (-x, ½ y,½ -z) (-x,-y,-z) (x,½ -y, ½ z)
2d i (½, 0, ½) (½, ½, 0)
2c i (0, 0, ½) (0, ½, 0)
2b i (½, 0, 0) (½, ½, ½)
2a i (0, 0, 0) (0, ½, ½)
37
General positions of Group 15 (C 2/c) unique
axis b
1 x,y,z identity
2 -x,y,-z1/2 2-fold rotation
3 -x,-y,-z inversion
4 x,-y,z1/2 c-glide
5 x1/2,y1/2,z identity c-center
6 -x1/2,y1/2,-z1/2 2 c-center
7 -x1/2,-y1/2,-z i c-center
8 x1/2,-y1/2,z1/2 c-glide c-center
38
P21/c in international table A
39
P21/c in international table B
40
Cn and ?
41
Relation between cubic and tetragonal unit cell
42
Lattice the manner of repetition of atoms, ions
or molecules in a crystal by an array of points
43
Types of lattice

• Primitive lattice (P)
• - the lattice point only at corner
• Face centred lattice (F)
• - contains additional lattice points in the
  center of each face
• Side centred lattice (C)
• - contains extra lattice points on only one
  pair of opposite faces
• Body centred lattice (I)
• - contains lattice points at the corner of a
  cubic unit cell and body center

44
Examples of F, C, and I lattices
45
14 Possible Bravais lattices combination of
four types of lattice and seven crystal systems
46
How to index crystal planes?
47
Lattice planes and Miller indices
48
Lattice planes
49
Miller indices
50
Assignment of Miller indices to a set of
planes1. Identify that plane which is adjacent
to the one that passes through the origin.2.
Find the intersection of this plane on the three
axes of the cell and write these intersections as
fractions of the cell edges. 3. Take
reciprocals of these fractions.Example fig.
10 (b) of previous page cut the
x axis at a/2, the y axis at band the z axis at
c/3 the reciprocals are
therefore, 1/2, 1, 1/3 Miller
index is ( 2 1 3 )
51
Examples of Miller indices
52
Miller Index and other indices

• (1 1 1), (2 1 0)
• 1 0 0 (1 0 0), (0 1 0), (0 0 1) .
• 2 1 0, -3 2 3
• lt1 0 0gt 1 0 0, 0 1 0, 0 0 1

53
???
Assign the Miller indices for the crystal faces
54
Descriptions of crystal structures

• The close packing approach
• The space-filling polyhedron approach

55
Materials can be described as close packed

• Metal- ccp, hcp and bcc
• Alloy- CuAu (ccp), Cu(ccp), Au(ccp)
• Ionic structures - NaCl
• Covalent network structures (diamond)
• Molecular structures

56
Close packed layer
57
A NON-CLOSE-PACKED structure
58
Close packed
59
Two cp layers
60
P sphere, O octahedral hole, T / T-
tetrahedral holes
61
Three close packed layers in ccp sequence
62
(No Transcript)
63
ccp
64
ABCABC.... repeat gives Cubic Close-Packing (CCP)

• Unit cell showing the full symmetry of the
  arrangement is Face-Centered Cubic
• Cubic a b c, a b g 90
• 4 atoms in the unit cell (0, 0, 0) (0, 1/2, 1/2)
  (1/2, 0, 1/2) (1/2, 1/2, 0)

65
(No Transcript)
66
hcp
67
ABABAB.... repeat gives Hexagonal Close-Packing
(HCP)

• Unit cell showing the full symmetry of the
  arrangement is Hexagonal
• Hexagonal a b, c 1.63a, a b 90, g
  120
• 2 atoms in the unit cell (0, 0, 0) (2/3, 1/3,
  1/2)

68
(No Transcript)
69
Coordination number in hcp and ccp structures
70
hcp
71
Face centred cubic unit cell of a ccp arrangement
of spheres
72
Hexagonal unit cell of a hcp arrangement of
spheres
73
Unit cell dimensions for a face centred unit cell
74
(No Transcript)
75
Density of metal
76
Tetrahedral sites
77
Covalent network structures of silicates
78
C60 and Al2Br6
79
(No Transcript)
80
The space-filling approachCorners and edges
sharing
81
Example of edge-sharing
82
Example of edge-sharing
83
Example of corner-sharing
84
Corner-sharing of silicates
