The Nervous System

1
The Nervous System
2
The Reflex Arc

• Reflexrapid, predictable, and involuntary
  response to a stimulus
• Occurs over pathways called reflex arcs
• Reflex arcdirect route from a sensory neuron, to
  an interneuron, to an effector

3
The Reflex Arc
4
The Reflex Arc
5
The Reflex Arc
6
The Reflex Arc
7
The Reflex Arc
Figure 7.11a, step 4
8
The Reflex Arc
9
Simple Reflex Arc
Sensory receptors(stretch receptorsin the
quadricepsmuscle)
Sensory receptors(pain receptors inthe skin)
Sensory (afferent)neuron
Spinal cord
Sensory (afferent)neuron
Synapse inventral horngray matter
Inter-neuron
Motor(efferent)neuron
Motor(efferent)neuron
Effector(quadricepsmuscle ofthigh)
Effector(bicepsbrachiimuscle)
(b)
(c)
10
Sensory receptors(stretch receptorsin the
quadricepsmuscle)
Spinal cord
(b)
11
Sensory receptors(stretch receptorsin the
quadricepsmuscle)
Sensory (afferent)neuron
Spinal cord
(b)
12
Sensory receptors(stretch receptorsin the
quadricepsmuscle)
Sensory (afferent)neuron
Spinal cord
Synapse inventral horngray matter
(b)
13
Sensory receptors(stretch receptorsin the
quadricepsmuscle)
Sensory (afferent)neuron
Spinal cord
Synapse inventral horngray matter
Motor(efferent)neuron
(b)
14
Sensory receptors(stretch receptorsin the
quadricepsmuscle)
Sensory (afferent)neuron
Spinal cord
Synapse inventral horngray matter
Motor(efferent)neuron
Effector(quadricepsmuscle ofthigh)
(b)
15
Sensory receptors(pain receptors inthe skin)
Spinal cord
(c)
16
Sensory receptors(pain receptors inthe skin)
Spinal cord
Sensory (afferent)neuron
(c)
17
Sensory receptors(pain receptors inthe skin)
Spinal cord
Sensory (afferent)neuron
Inter-neuron
(c)
18
Sensory receptors(pain receptors inthe skin)
Spinal cord
Sensory (afferent)neuron
Inter-neuron
Motor(efferent)neuron
(c)
19
Sensory receptors(pain receptors inthe skin)
Spinal cord
Sensory (afferent)neuron
Inter-neuron
Motor(efferent)neuron
Effector(bicepsbrachiimuscle)
(c)
20
Sensory receptors(stretch receptorsin the
quadricepsmuscle)
Sensory receptors(pain receptors inthe skin)
Sensory (afferent)neuron
Spinal cord
Sensory (afferent)neuron
Synapse inventral horngray matter
Inter-neuron
Motor(efferent)neuron
Motor(efferent)neuron
Effector(quadricepsmuscle ofthigh)
Effector(bicepsbrachiimuscle)
(b)
(c)
21
Types of Reflexes and Regulation

• Somatic reflexes
• Activation of skeletal muscles
• Example When you move your hand away from a hot
  stove

22
Types of Reflexes and Regulation

• Autonomic reflexes
• Smooth muscle regulation
• Heart and blood pressure regulation
• Regulation of glands
• Digestive system regulation

23
Types of Reflexes and Regulation

• Patellar, or knee-jerk, reflex is an example of a
  two-neuron reflex arc

24
Central Nervous System (CNS)

• Ventricles
• Four chambers within the brain
• Filled with cerebrospinal fluid

25
Regions of the Brain

• Cerebral hemispheres (cerebrum)
• Diencephalon
• Brain stem
• Cerebellum

26
Cerebrum
Figure 7.14
27
Regions of the Brain Cerebrum

• Cerebral areas involved in special senses
• Gustatory area (taste)
• Visual area
• Auditory area
• Olfactory area

28
Regions of the Brain Cerebrum
Figure 7.13c
29
Cerebrum

• Layers of the cerebrum
• Gray matterouter layer in the cerebral cortex
  composed mostly of neuron cell bodies
• White matterfiber tracts deep to the gray matter
• Corpus callosum connects hemispheres
• Basal nucleiislands of gray matter buried within
  the white matter

30
Cerebrum
31
Regions of the Brain Diencephalon
Figure 7.16
32
Diencephalon (Interbrain)

• On top of the brain stem
• Enclosed by the cerebral hemispheres
• Made of three parts
• Thalamus
• Hypothalamus
• Epithalamus

33
Diencephalon
Figure 7.12b
34
Diencephalon
Figure 7.16a
35
Diencephalon
36
Diencephalon

• Thalamus
• The relay station for sensory impulses
• Pleasant vs. unpleasant
• Transfers impulses to the sensory cortex

37
Diencephalon

• Hypothalamus
• Important autonomic nervous system center
• Regulate body temperature
• Controls water balance
• Regulates metabolism

38
Diencephalon

• Hypothalamus (continued)
• An important part of the limbic system (emotions)
• The pituitary gland is attached to the
  hypothalamus

39
Diencephalon

• Epithalamus
• Forms the roof of the third ventricle
• Houses the pineal body (an endocrine gland)
• Choroid plexusforms cerebrospinal fluid

40
Brain Stem

• Attaches to the spinal cord
• Parts of the brain stem
• Midbrain
• Pons
• Medulla oblongata

41
Brain Stem
Figure 7.16a
42
Brain Stem

• Midbrain
• Mostly composed of tracts of nerve fibers
• Has two bulging fiber tractscerebral peduncles
• Has four rounded protrusionscorpora
  quadrigemina
• Reflex centers for vision and hearing

43
Brain Stem

• Pons
• The bulging center part of the brain stem
• Mostly composed of fiber tracts
• Includes nuclei involved in the control of
  breathing

44
Brain Stem

• Medulla Oblongata
• The lowest part of the brain stem
• Merges into the spinal cord
• Includes important fiber tracts
• Contains important control centers
• Heart rate control
• Blood pressure regulation
• Breathing
• Swallowing
• Vomiting

45
Regions of the Brain Brain Stem

• Reticular Formation
• Diffuse mass of gray matter along the brain stem
• Involved in motor control of visceral organs
• Reticular activating system (RAS) plays a role in
  awake/sleep cycles and consciousness

46
RETICULAR FORMATION OF THE BRAIN STEM
Figure 7.16b
