Title: The Heart


1
The Heart
  • From physiology to ECG measurement and beyond

2
Lesson overview
  • Introduction to the physiology of the heart
  • Activation potential
  • Basic anatomy
  • ECG
  • Devices for ECG measurement

3
Electrophysiology of the cardiac muscle cell
4
(No Transcript)
5
The anatomy of the heart and associated vessels
6
The conduction system of the heart
7
Propagation of activation front between a pair
of extracellular electrodes
8
Electrophysiology of the heart.The different
waveforms for each of the specialized cells found
in the heart are shown. The latency shown
approximates that normally found in the healthy
heart.
9
The generation of the ECG signal in the
Einthoven limb leads
10
The generation of the ECG signal in the
Einthoven limb leads
11
(No Transcript)
12
(No Transcript)
13
Einthoven, Wilson and Goldbergs precordial leads
14
(No Transcript)
15
(No Transcript)
16
Holter
  • Dlouhé záznamy, 24-hodinové, zjednodušený svodový
    systém
  • Rozdíly proti standardnímu 12-ti svodovému EKG
  • Nevýhody
  • Méne kanálu
  • Více šumu
  • Obtížná detekce P-vlny
  • Pohybové artefakty
  • Velká dynamika RR-intervalu
  • Výhody
  • Vetší casový záber
  • Lepší detekce arytmií
  • Pokrytí bežných lidských cinností

17
Holter
  • Demonstrace variability signálu pri holterovském
    merení
  • Je treba velké robustnosti jak u analýzy signálu
    tak pri diagnostice

18
Holter príklad
  • Roztrídení (clustering) beatu z holterovského EKG
    záznamu
  • Na základe zmerených parametru vypocítán medián
  • Cíl Koherentní skupina pro další diagnostiku

19
Mapy - príklady usporádání elektrod
20
Mapy usporádání elektrod
  • 80 elektrod rovnomerne rozložených
  • na hrudníku a zádech pacienta (systém
    Cardiag)
  • pro predzpracování signálu bylo využito
    nekolikero metod,
  • vcetne metody vlnkové transformace
  • Na generovaných mapách se dají, stejne jako na
    signálu,
  • hledat príznaky

21
Okamžikové potenciálové mapy
  • základní typ map definovaný
  • príklad potenciálové mapy z oblasti QRS komplexu

22
Integrálové mapy
  • typ map vytvárený podle vztahu
  • príklad integrálové mapy z oblasti QRS komplexu

23
Isochronní mapy
  • typ map vytvárený podle vztahu
  • príklad isochronní mapy casu trvání intervalu QT

24
Rozdílové mapy
  • typ map vytvárený podle vztahu
  • príklad rozdílové integrální mapy z oblasti QRS
    komplexu

25
Mapování 3D inverzní úloha
  • Vyhledávání a zobrazení potenciálu srdce na
    samotném epikardu
  • Merení provádeno bud prímo v srdci
  • Nebo hledání rozložení potenciálu na srdci z
    povrchového rozložení
  • Vede na rešení inverzní úlohy
  • Hledání ložisek v objemu srdce

26
Nové trendy v elektrokardiografii
  • Vetší duraz na prevenci
  • Vetší možnosti pacienta podílet se na kontrole
    svého zdravotního stavu
  • Nové zpusoby merení EKG senzory prímo v
    oblecení
  • Nové zpracování na mobilních telefonech
  • Telemedicínské aplikace

27
Nové trendy v elektrokardiografii
? Sensorické tílko
? Základna
GPRS
Bluetooth
? Mobilní telefon
? PBM
28
(No Transcript)
29
(No Transcript)
30
(No Transcript)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
  • An average heart pumps 2.4 ounces (70
    milliliters) per heartbeat. An average heartbeat
    is 72 beats per minute. Therefore an average
    heart pumps 1.3 gallons (5 Liters) per minute. In
    other words it pumps 1,900 gallons (7,200 Liters)
    per day, almost 700,000 gallons (2,628,000
    Liters) per year, or 48 million gallons
    (184,086,000 liters) by the time someone is 70
    years old. That's not bad for a 10 ounce pump!
  • For more information on the human heart and
    related topics, check out the links on the next
    page.
  • What causes the sound your heart makes?
  • When someone listens to your heart with a
    stethoscope the sound is often described as -
    lub-dub lub-dub. The 1st heart sound (lub) is
    caused by the acceleration and deceleration of
    blood and vibration of the heart at the time of
    the closure of the Tricuspid and Mitral Valves.
    The 2nd heart sound (dub) is caused by the same
    acceleration and deceleration of blood and
    vibrations at the time of closure of the Pulmonic
    and Aortic Valves.
  • How many times does you heart beat?
  • The average heartbeat is 72 times per minute. In
    the course of one day it beats over 100,000
    times. In one year the heart beats almost 38
    million times, and by the time you are 70 years
    old, on average, it beats 2.5 billion times!
  • Does your heart rate change as we age?
  • Everyone's pulse (average heart rate per minute)
    changes as we age. Here is a chart of average
    pulse at different ages
  • Age Pulse
  • Newborn 130
  • 3 months 140
  • 6 months 130
  • 1 year 120
  • 2 years 115
  • 3 years 100

35
  • The AbioCor, developed by Abiomed, is a very
    sophisticated medical device, but the core
    mechanism of the device is the hydraulic pump
    that shuttles hydraulic fluid from side to side.
    To understand how it works, let's look at the
    various components of the system
  • Hydraulic pump - The basic idea with this device
    is similar to the hydraulic pumps used in heavy
    equipment. Force that is applied at one point is
    transmitted to another point using an
    incompressible fluid. A gear inside the pump
    spins at 10,000 revolutions per minute (rpm) to
    create pressure.
  • Porting valve - This valve opens and closes to
    let the hydraulic fluid flow from one side of the
    artificial heart to the other. When the fluid
    moves to the right, blood gets pumped to the
    lungs through an artificial ventricle. When the
    fluid moves to the left, blood gets pumped to the
    rest of the body.
  • Wireless energy-transfer system - Also called the
    Transcutaneous Energy Transfer (TET), this system
    consists of two coils, one internal and one
    external, that transmit power via magnetic force
    from an external battery across the skin without
    piercing the surface. The internal coil receives
    the power and sends it to the internal battery
    and controller device.
  • Internal battery - A rechargeable battery is
    implanted inside the patient's abdomen. This
    gives a patient 30 to 40 minutes to perform
    certain activities, such as showering, while
    disconnected from the main battery pack.
  • External battery - This battery is worn on a
    Velcro-belt pack around the patient's waist. Each
    rechargeable battery offers about four to five
    hours of power.
  • Controller - This small electronic device is
    implanted in the patient's abdominal wall. It
    monitors and controls the pumping speed of the
    heart.
  • The AbioCor heart, which is composed of titanium
    and plastic, connects to four locations
  • Right atrium
  • Left atrium
  • Aorta
  • Pulmonary artery
  • The entire system weighs about 2 pounds (0.9 kg).
    In the next section, you will learn how surgeons
    implanted the AbioCor heart during a seven-hour
    operation.

36
  • Until recently, the only option for many severe
    heart failure patients has been heart
    transplants. However, there are only slightly
    more than 2,000 heart transplants performed in
    the United States annually, meaning that tens of
    thousands of people die waiting for a donor
    heart. On July 2, 2001, heart failure patients
    were given new hope as surgeons at Jewish
    Hospital in Louisville, Kentucky, performed the
    first artificial heart transplant in nearly two
    decades. The AbioCor Implantable Replacement
    Heart is the first completely self-contained
    artificial heart and is expected to at least
    double the life expectancy of heart patients.
  • In this article, you will get an in-depth look at
    how this new artificial heart works, how it's
    implanted into a patient's chest and who might be
    a candidate for receiving one of these mechanical
    hearts. We will also compare the AbioCor heart to
    the artificial hearts that have failed in the
    past.

37
  • Heartbeat
  • Smaller animals have faster heartbeats. This is
    evident within a species as well, as the young
    beat their hearts faster than the adults. See
    "Early development" above for information about
    the early human heart rates. The Gray Whale's
    heart beats 9 times per minute, Harbour Seal 10
    when diving, 140 when on land, elephant 25, human
    70, sparrow 500, shrew 600, and hummingbird 1,200
    when hovering. An ectothermic animal will usually
    have a slower, and more variable heartbeat than
    an endothermic animal of similar size.

38
  • he study of diseases of the heart is known as
    cardiology. Important diseases of the heart
    include
  • Coronary heart disease is the lack of oxygen
    supply to the heart muscle it can cause severe
    pain and discomfort known as Angina.
  • A heart attack occurs when heart muscle cells die
    because blood circulation to a part of the heart
    is interrupted.
  • Congestive heart failure is the gradual loss of
    pumping power of the heart.
  • Endocarditis and myocarditis are inflammations of
    the heart.
  • Cardiac arrhythmia is an irregularity in the
    heartbeat. It is sometimes treated by implanting
    an artificial pacemaker
  • Congenital heart defects.
  • If a coronary artery is blocked or narrowed, the
    problem spot can be bypassed with coronary artery
    bypass surgery or it can be widened with
    angioplasty.
  • Beta blockers are drugs that lower the heart rate
    and blood pressure and reduce the heart's oxygen
    requirements. Nitroglycerin and other compounds
    that give off nitric oxide are used to treat
    heart disease as they cause the dilation of
    coronary vessels.
  • At Groote Schuur Hospital in Cape Town, South
    Africa, 53-year-old Louis Washkansky on December
    3, 1967 became the first human to receive a heart
    transplant (however he died 18 days later from
    double pneumonia). The transplant team was headed
    by Christiaan Barnard.

39
  • The heart (Latin cor) is a hollow, muscular organ
    in vertebrates that pumps blood through the blood
    vessels by repeated, rhythmic contractions, or a
    similar structure in annelids, mollusks, and
    arthropods. The term cardiac means "related to
    the heart", from the Greek kardia (?a?d?a) for
    "heart". The human heart is the most studied
    organ in biology.

40
  • So the heart is the beginning of life, the Sun of
    the Microcosm, even as the Sun deserves to be
    call'd the heart of the world for it is the
    heart by whose virtue and pulsation the blood is
    moved, perfected, made apt to nourish, and is
    preserved from corruption and coagulation it is
    the household divinity which, discharging its
    function, nourishes, cherishes, quickens the
    whole body, and is indeed the foundation of life,
    the source of all action."

41
  • http//www.invisionguide.com/heart/flash/index_pro
    .php

42
Prehled prezentace
  • OBECNÁ CÁST
  • Úvod do Biomedicínských signálu
  • Vzorkování
  • Vzorkování Shanon.
  • casová a frekvencní reprezentace signálu
  • Filtrace
  • Princip
  • Príklady
  • Analýza EKG
  • Rozmerování signálu
  • Výber príznaku
  • Diagnostika
  • Co umožnuje automatická diagnostika
  • Príklady
  • PRAKTICKÁ CÁST
  • 12-ti svodové EKG
  • Holter
Write a Comment
User Comments (0)
About PowerShow.com
