Inheritance and Design

1
Inheritance and Design

• CSIS 3701 Advanced Object Oriented Programming

2
Key Questions

• Given list of required classes
• What classes should extend others?
• Are additional classes needed?
• What methods can be inherited/overridden?
• Do methods need to be designed for polymorphism?

3
Employees Example

• Goal Payroll system prints weekly paychecks
• Paycheck of form Pay for name amount
• Also tracks total pay for all employees
• Should store information in single data structure
• Problem Many types of workers paid in different
  ways

4
Employees Example

• Employee types
• Salaried Yearly salary / 52
• Manager Like salaried, with additional weekly
  bonus
• Intern Paid hourly rate for hours worked (may be
  different every week). Cannot work
  over 40 hours.
• Consultant Paid hourly rate for hours worked
  (may be different every
  week), with additional travel
  allowance

5
Polymorphism and Class Design

• Is polymorphism necessary?
• All objects in single container or manipulated by
  single method (add method in JPanel)
• What methods must be polymorphic?
• Will be iterated for all objects in container,
  etc.
• Must be defined in superclass
• Example
• All employees stored in single array
  (polymorphism needed)
• Will call getPay() and getCheck() for each

6
Hierarchy Design

• Inheritance hierarchy often tree structure
• Required classes often leafs
• Overall superclass at root
• Abilities inherited along branches

?????
Consultant
Intern
Salaried
Manager
7
Superclass Identification

• What abilities/information are common to all
  required classes?
• Defines overall superclass at root of hierarchy
• Example All employees have
• A name
• Ability to compute weekly pay
• Ability to print name/pay on paycheck

8
Superclass Identification

• Employee superclass

Employee String name double getPay() String
getCheck()
Consultant
Intern
Salaried
Manager
9
Abstract Classes

• Problem Users should not be able to create
  instances of Employee
• Only exists to define common features of actual
  required classes
• Will not actually have all required abilities for
  use
• Employee e new Employee()
• double p e.getPay()

This is not defined for generic employee
10
Abstract Classes

• Can define class as abstract
• Cannot be instantiated
• Very common in JavaExample abstract JComponent
  class
• Superclass of all visual swing components
• Defines common properties of x, y, width, height
• public abstract class Employee
• private String name
• public Employee(String n) name n

11
Abstract Methods

• Often need to declare a method in superclass
  without actually defining it
• Example getPay() method in Employee class
• No way to provide actual definition at this level
• Necessary if polymorphism required
• Employee e new Salaried(Fred, 26000)
• pay e.getPay()

Will not work unless getPay() in Employee class
12
Abstract Methods

• Can declare method abstract in superclass
• Must be overridden in subclasses
• Often used to enable polymorphism
• Form like C prototypes
• public abstract returntype methodname(params)

13
Final Employee Superclass

• public abstract class Employee
• private String name
• public Employee(String n)name n
• public abstract double getPay()
• public String getCheck()
• return "Pay for "name" \t" getPay()
• Can still define getCheck even if calls abstract
  method
• Will only be invoked on subclass objects
• Those will use their overridden version of
  getPay()

14
Hierarchical Decomposition

• What do some classes have in common?
• Salaried and Manager have salary
• Intern and Consultant have hours worked, rate of
  pay, and method to set hours
• What must those classes do differently?
• Manager also has bonus
• Consultant also has travel allowance
• Intern must validate that hours 40

Must look at data and methods
15
Hierarchical Decomposition

• Are the abilities of one class a subset of
  another?
• One class has all the same abilities as another,
  and some additional abilities
• If so, make C2 subclass of C1

additional
data method
data method

C2
C1
data methoddata method data method
16
Supervisor/Manager Example

• Salaried
• Stores name (inherited from Employee), salary
• Computes pay as salary/52
• Manager
• Stores name , salary, and bonus
• Computes pay as salary/52 bonus
• Manager should be subclass of Salaried

17
Hierarchical Decomposition

• Do abilities of different classes intersect
• Classes have shared abilities, but neither subset
  of other
• If so, create abstract class with shared abilites
• Both classes now extend it

data method shared data data method
shared method
data method
data method
C1
C2
New abstract C3
18
Hierarchical Decomposition

• Commonly done in Java
• Example JTextComponent class

JComponent int x, y, width, height
Common to all visual components
JTextComponent String text String getText() void
setText(String)
Common to visual components that accept text
JTextField
JTextArea
19
Consultant / Intern Example

• Consultant
• Stores name, hours, rate, travel
• Computes pay as hours rate travel
• Has method to set hours
• Intern
• Stores name, hours, rate
• Computes pay as hours rate
• Has method to set hours which must validate 40
• Create Hourly class with shared abilities

20
Consultant / Intern Example
Hourly int hours, double rate set by
constructor getPay() hours rate setHours(h)
hours h
Consultant double travel getPay() superclass
version travel
Intern setHours(h) check h lt 40
before calling superclass version
21
Final Hierarchy Design
Employee (abstract)
Hourly (abstract)
Salaried
Manager
Intern
Consultant
22
Method Design

• Design methodologies
• Subclass methods should only directly manipulate
  subclass variables
• Subclass methods should (if possible) call
  superclass version to manipulate inherited
  superclass variables

23
Supervisor/Manager Example
Salaried double salary getPay() salary/52
Manager double bonus getPay() salary/52 bonus
superclass version of getPay
24
Salaried Class

• public class Salaried extends Employee
• private double salary // Yearly salary
• public Salaried(String n, double s)
• super(n)
• salary s
• public double getPay()
• return salary/52

25
Manager Class

• public class Manager extends Salaried
• private double bonus
• public Manager(String n, double s, double b)

• super(n, s)
• bonus b
• public double getPay()
• return super.getPay() bonus

26
Hourly Class

• public abstract class Hourly extends Employee
• private double rate // Hourly pay rate
• private int hours // hours worked this
  week
• public Hourly(String n, double r)
• super(n)
• rate r
• hours 0
• public void setHours(int h)
• hours h
• public double getPay()
• return hours rate

27
Consultant Class

• public class Consultant extends Hourly
• private double travel // Travel allowance
• public Consultant(String n, double r, double t)

• super(n, r)
• travel t
• public double getPay()
• return super.getPay() travel

28
Intern Class

• public class Intern extends Hourly
• public Intern(String n, double r)
• super(n, r)
• public void setHours(int h)
• if (h gt 40)
• h 40
• super.setHours(h)

29
Encapsulation

• Access to superclass variables may not be
  possible with public methods
• superclass should provide protected methods to
  allow access to superclass variables
• Example
• Intern class must print message with employee
  name if error
• Employee must provide protected method to allow
  access to name

30
Encapsulation

• public abstract class Employee
• private String name
• protected String getName() return name
• public class Intern extends Hourly
• public void setHours(int h)
• if (h gt 40)
• System.out.println(getName()
  can only work 40 hours)
• else super.setHours(h)

31
Polymorphism

• Create objects in different classes
• public static void main(String args)
• Salaried wally new Salaried("Wally", 52000)
• Salaried alice new Salaried("Alice", 78000)
• Manager phb new Manager("Pointy Haired Boss",
  104000, 200)
• Intern asok new Intern("Asok", 20)
• asok.setHours(50)
• Consultant dogbert new Consultant("Dogbert",
  100, 500)
• dogbert.setHours(42)

32
Polymorphism

• Store in single data structure
• Employee workers new Employee5
• workers0 phb
• workers1 alice
• workers2 wally
• workers3 asok
• workers4 dogbert

33
Polymorphism

• Manipulate as though instances of superclass
• double total 0
• for (int i 0 i lt 5 i)
• System.out.println(workersi.getCheck())
• total workersi.getPay()
• System.out.println("Total pay \t" total)
