GELLO Update

1
(No Transcript)
2
GELLO Update

• HL7 Working Group Meeting _at_ Baltimore
• 2nd October 2002
• Aziz Boxwala and Robert Greenes
• Brigham and Womens Hospital
• Harvard Medical School

3
What is GELLO?

• Expression language
• Query language
• maps variables in expressions to data in external
  systems
• Embedded language
• Can be used as part of other specs
• MLM, guidelines, RIM, template constraints, etc.
• Goal is to facilitate sharing of knowledge

4
Model
5
Status report

• As of May 2002 meeting, we had agreed to bring
  this to TC ballot
• But decided to defer because of desire to
• Reduce complexity of syntax
• Make more compatible with generic language
  specification efforts
• Eliminate side effects in expressions
• Facilitate use as embedded language distinct from
  other elements of an application, e.g., those
  that do assignment or flow control
• Revised language specification developed
• To be presented here

6
Requirements - 1

• Work with an object-oriented data structure
  compatible with the RIM
• Should support different data models (such as
  VMR)
• Be platform independent
• Be easy to write and read for defined class of
  users
• Be usable in different applications (Arden
  MLMs, guidelines, templates, )
• Leverage existing standard frameworks/languages
  where possible

7
Requirements - 2

• Be side-effects free
• Built-in data types (if any) should be compatible
  with those defined in the RIM
• Be extensible
• classes must be compatible with the RIM and
  language framework
• Be free of ambiguities

8
Using OCL grammar

• Object Constraint Language
• Part of UML spec
• Object Management Group standard
• Language for specifying invariants on classes and
  its member attributes and functions
• Not a complete programming language
• Side-effects free
• Maps to our needs and requirements

9
An example with an MLM
maintenance title Screening for elevated
calcium-phosphate product library purpose
provide an alert if the product of the blood
calcium and phosphorus exceeds a certain
threshold in the setting of renal failure
explanation An elevated Ca-PO4 product suggests
a tendency toward renal osteodystrophy and
predisposes to soft-tissue calcification
10
MLM
knowledge data / trigger on Ca, PO4 or Cr
/ creatinine read last
'dam'"PDQRES2",'constraints'"C"
'32752' calcium read last
'dam'"PDQRES2",'constraints'"C"
'32109' phosphate read last
'dam'"PDQRES2",'constraints'"C"
'33824' creatinine_threshold 2
product_threshold 70
11
MLM
logic if (creatinine is not number) or
(calcium is not number) or (phosphate is
not number) then conclude false
endif product calcium phosphate if
(creatinine gt creatinine_threshold) and
(product gt product_threshold) then
conclude true else conclude false
endif
12
MLM in GELLO (data slot)
data creatinine Observation.allInstances-gt
select(coded_concept "C0428279") .sort(critical_
time.high).last() calcium
Observation.allInstances -gtselect(coded_concept
"C0428302") .sort(critical_time.high). last()
phosphate Observation.allInstances
-gtselect(coded_concept "C0428304") .sort(critic
al_time.high).last()
ListltObservationgt last(select obs from
Observation as obs where obs.service_cd.equals
(new Concept(MTH, C042879)) sort
descending obs.critical_time.high)
creatinine read last 'dam'"PDQRES2",'co
nstraints'"C" '32752'
There are ways to make the GELLO query syntax
easier for example by defining class/static
functions in VMR classes to retrieve
instances Observation.select(coded_concept
"C0428279").last()
13
MLM in GELLO (data slot)
renal_failure_threshold PhysicalQuantity.new(2.
0, "mg/dl") renal_failure if
creatinine-gtnotEmpty and creatine.observed_quan
tity gt renal_failure_threshold then
true else false endif threshold_for_osteodystroph
y 70 calcium_phosphate_product if
calcium-gtnotEmpty and phosphate-gtnotEmpty
then calcium.observed_quantity.value
phospate.observed_quantity.value else -1 endif
14
MLM in GELLO
logic renal_failure and calcium_phosphate_product
gt threshold_for_osteodystrophy
if (creatinine is not number) or (calcium is not
number) or (phosphate is not number) then
conclude false endif product
calcium phosphate if (creatinine gt
creatinine_threshold) and (product gt
product_threshold) then conclude true
else conclude false endif
15
Implementation model
Application (e.g., Arden alert engine)
GELLO Interpreter
evaluate(ab)
result 7
Variable evaluator
valueOf(a)
5
Observation.allInstances-gtselect()
Data retrieval
resultCollection/tuple
16
Issues

• Side-effect free language
• Constructors
• Restructuring of MLM Let expressions
• Built-in datatypes
• Same specification or different?
• Reconciling OCL standard lib with HL7 datatypes
• Writing back data
• Observation.write()
• Exception management
