Evaluation of Relational Operations: Other Operations

1
Evaluation of Relational Operations Other
Operations

• Chapter 14 Ramakrishnan Gehrke
• (Sections 14.1-14.3 14.5-14.7)

2
What you will learn from this lecture

• General selections.
• Union/intersection.
• Group-by.

3
Simple Selections
SELECT FROM Songs S WHERE S.sname C

• Of the form
• Size of result approximated as size of R
  reduction factor
• reduction factor typically estimated with the
  uniformity assumption
• or estimated with the help of a histogram will
  discuss soon.
• With no index, unsorted (worst case) ? table
  scan only option cost M (pages of R).
• With an index on selection attribute Use index
  to find qualifying data entries, then retrieve
  corresponding data records. (Hash index useful
  only for equality selections.)
• What about a sorted indexless relation? Is binary
  search always superior to table scan?

4
Using an Index for Selections

• Cost depends on qualifying tuples, and
  clustering.
• Cost of finding qualifying data entries
  (typically small) plus cost of retrieving records
  (could be large w/o clustering).
• For example, assuming uniform distribution of
  snames(!), about 1/26 of tuples qualify (20
  pages, 1600 tuples). With a clustered index,
  cost is about 20 I/Os if unclustered, upto 1600
  I/Os! assumes S has 500 pages.
• Important refinement for unclustered indexes
• 1. Find qualifying data entries.
• 2. Sort the rids of the data records to be
  retrieved (or, if the records are not stored in
  rid-order, sort the page addresses).
• 3. Fetch rids in order. This ensures that each
  data page is looked at just once (though of
  such pages likely to be higher than with
  clustering).

5
General Selection Conditions

• (timelt8/9/04 AND uid123) OR rating5 OR sid3

• Such selection conditions are first converted to
  conjunctive normal form (CNF) (timelt8/9/04 OR
  rating5 OR sid3 ) AND (uid123 OR rating5 OR
  sid3).
• We only discuss the case with no disjunctions
  (most common in practice!)
• disjunctions may or may not be easy
• e.g., (timelt8/9/04 OR uid123)
• index on uid only may still warrant a scan
• e.g., (timelt8/9/04 OR uid123) AND sid 3
• index on sid helps tremendously
• - (time 8/9/04 OR uid123). Can you think of
  a clever strategy if given index on time and on
  uid?

6
Two Approaches to General Selections

• First approach Find the most selective access
  path, retrieve tuples using it, and apply any
  remaining conditions that dont match the index
• Most selective access path An index probe or
  index scan or table scan that we estimate will
  require the fewest page I/Os.
• e.g., timelt8/9/04 AND rating5 AND sid3.
  Suppose we have indexes (Btree) on time and
  (hash) on ltrating, sidgt. ? 2 options
• option 1 use the B tree index on time (check
  rating5 and sid3 for each retrieved tuple)
• option 2 use the hash index on ltrating, sidgt
  (check timelt8/9/94)
• Conditions that match this index reduce the
  number of tuples retrieved other conditions are
  used to discard some retrieved tuples, but do not
  affect number of tuples/pages fetched.

7
Intersection of Rids

• Second approach (if we have 2 or more matching
  indexes)
• Get sets of rids of data records using each
  matching index.
• Then intersect these sets of rids
• Retrieve the records and apply any remaining
  conditions.
• e.g., timelt8/9/04 AND rating5 AND sid3
• suppose we have a B tree index on time and an
  index on sid
• retrieve rids of records satisfying timelt8/9/04
  using the first
• retrieve rids of records satisfying sid3 using
  the second
• intersect the rids
• finally, retrieve records and check rating5
• Howd you implement intersection efficiently?

8
The Projection Operation
SELECT DISTINCT R.sid, R.uid FROM
Ratings R

• An approach based on sorting
• Modify Phase 1 of external sort to eliminate
  unwanted fields. Thus, sorted sublists (runs)
  are produced, but tuples in SSLs are smaller than
  input tuples. (Size ratio depends on and size
  of fields dropped.)
• Modify merging passes to eliminate duplicates.
  Thus, number of result tuples smaller than input.
  (Difference depends on of duplicates.)
• What should we sort on?

9
Projection Based on Hashing

• Partitioning phase Read R using one input
  buffer. For each tuple, discard unwanted fields,
  apply hash function h1 to choose one of B-1
  output buckets/buffers.
• Result is B-1 partitions (of tuples with no
  unwanted fields). Any two tuples from different
  partitions guaranteed to be distinct.
• Duplicate elimination phase For each partition,
  read it and build an in-memory hash table, using
  hash fn h2 (ltgt h1) on all fields, while
  discarding duplicates.
• If partition does not fit in memory, can apply
  hash-based projection algorithm recursively to
  this partition. (but what do you project on in
  recursive invocation(s)?)
• Note the similarity to hash join.

10
Set Operations

• Intersection and cross-product special cases of
  join.
• Union sorting based and hash based
• Sorting based approach
• Sort both relations (on combination of all
  attributes).
• Scan sorted relations and merge them.
• Alternative Merge SSLs from Phase 1 for both
  relations.
• An advantage result is sorted.
• Hash based approach to union
• Partition R and S using hash function h.
• For each S-partition, build in-memory hash table
  (using h2), scan corr. R-partition and add tuples
  to table while discarding duplicates.
• What is the buffer requirement for this?

11
Aggregate Operations (AVG, MIN, etc.)

• Without group-by
• In general, requires scanning the relation.
• Given index whose search key includes all
  attributes in the SELECT WHERE clauses, may
  suffice to do index scan. (remember what index
  scan is?)
• With group-by
• Sort on group-by attributes, then scan relation
  and compute aggregate for each group. (Can
  improve upon this by combining sorting and
  aggregate computation. In this case, the I/O cost
  is just that of sorting.)
• Similar approach based on hashing on group-by
  attributes.
• Maintain running info. for each group.

12
Summary

• A virtue of relational DBMSs queries are
  composed of a few basic operators the
  implementation of these operators can be
  carefully tuned (and it is important to do
  this!).
• Indeed relational algebra ? gold standard for
  algebra design simple ops sophisticated ones
  derivable by composition e.g., join, division.
• Many alternative implementation techniques for
  each operator no universally superior technique
  for most operators.
• Must consider available alternatives for each
  operation in a query and choose best one based on
  system statistics, etc. This is part of the
  broader task of optimizing a query composed of
  several ops.
