MMX technology for Pentium

1
MMX technology for Pentium
2
Introduction

• Multi Media Extension (MMX) for Pentium Processor
  Which has built in 80X87
• Can be switched for multimedia computations
  working in Co processor mode with MMX instruction
  set
• The coprocessor works in SIMD instruction set
  processor for multi media applications
• Some MMX Applications are
• motion video
• combined graphics with video
• Image processing
• Audio and speech synthesis and compression
• Video conferencing
• Telephony
• 2D and 3D graphics

3
MMX Data types

• New packed data types
• Eight packed 8 bit bytes
• Four packed consecutive 16 bit words
• Two packed consecutive 32 bit double words
• Two access modes
• 64 bit access mode between CPU registers
• 32 bit access mode between FPU registers
• MMX technology uses the same 8 register set of
  FPU of 80 bit wide right justified
• MMX aliases the FPU resources for specific
  applications
• MMX registers are designated as MM0 MM7

4
MMX instruction set

• SIMD instructions of type Arithmetic,
  comparison, conversion, logical, shift and data
  transfer
• Instructions will start with letter P as first
  character
• Instructions are appended with B, W or D
• MMX instructions use dual operands and register
  set MM0 MM7
• The result of operation is moved on to First
  operand

5
MMX arithmetic Instruction set

• ADD
• PADDB, PADDW, PADDD
• PADDB MM1, MM2 adds the entire 64 bit contents
  of MM2 to MM1 byte by Byte and stores in MM1
• Any carries are dropped
• Adding a byte A0H to 70H gives 110H , but the
  carry is dropped and byte will be 10H
• Second operand can be a memory location
  containing 64 bit packed data

6
MMX arithmetic Instruction set (1)

• SUB
• PSUBB, PSUBW, PSUBD
• PSUBB MM1, MM2 subtracts the entire 64 bit
  contents of MM2 to MM1 byte by Byte and stores in
  MM1
• Like PADD , PSUB also does not carry or borrow
• Second operand can be a memory location
  containing 64 bit packed data
• If the result of subtraction due to underflow and
  overflow errors result in 7FH (128) for a
  overflow and 80H (-128) for underflow, Intel
  calls it as saturation

7
MMX arithmetic Instruction set (2)

• MUL
• PMULL, PMULH,
• PMULLW MM1, MM2 multiplies the entire 16 bit LW
  contents of MM2 with LW of MM1 and stores the 32
  bit result in MM1
• Like PADD , PSUB also does not carry or borrow
• Second operand can be a memory location
  containing 64 bit packed data
• PMADDWD instruction multiplies and adds. After
  multiplying four 32 bit results are added to get
  two 32 bit double word result.

8
MMX comparison Instructions

• Two comparison instruction
• PCMPEQ ( equal )
• PCMPGT ( greater than )
• Append it with B,W or D depending on the word
  length
• Operands can be MMX register or memory location
• These instruction does not change the flags
  instead it changes the result operand filled with
  000 or 111

9
MMX conversion Instructions

• Two basic conversion instructions
• PACK gtgt convert data in Dword/ Qword in MMX
  packed format Available as
• PACKSS ( signed saturation )
• PACKUS ( unsigned saturation )
• Can be appended with B, W, D
• PUNPCK gtgt convert packed data to normal data word
  / byte available as
• PUNPCKH ( unpack High data )
• PUNPCKL ( unpack Low data )
• To be used in combinations of WB ( word to byte )
  or DW ( double word to word )

10
MMX Logic Instructions

• PAND ( AND )
• PANDN ( NAND )
• POR ( OR )
• PXOR ( XOR )
• NO size extensions , BIT wise operation on all 64
  bit data
• Very powerful for bit manupulations

11
MMX shift Instructions

• Logical shift and Arithmetic shift
• Logic shifts are
• PSLL ( Left Logic )
• PSRL (Right Logic )
• Variations are W, D and Q
• Arithmetic shifts preserves the sign bit
• PSLA ( left Arithmetic )
• PSRA ( right arithmetic )
• Example PSLLD MM3,2 shifts the two 32 bit
  double word in MM3 left two places

12
MMX data transfer Instructions

• Two data transfer instructions MOVED and MOVEQ
• Transfers data between registers and memory
• Example MOVED ECX, MM2 moves the right most 32
  bits of MM2 to ECX register
• Example MOVEQ MM2, MM3 moves the 64 bit of MM3
  to MM2

13
MMX EMMS Instruction

• EMMS ( empty MMX state )
• Sets 11 for tags gtgtgt indicate that FPU barrel
  registers are empty
• Must be executed before the return instruction so
  that FPU smoothly takes over
• If not done FPU interrupt occurs and system
  crashes
