IB Physics 12

1
IB Physics 12

• Mr. Jean
• February 11th, 2014

2
The plan

• Video clip of the day.
• IA - Time
• Quantum Theory
• Energy Levels
• Photo Electric Effect

3
IA - Time

• Lets take the first 30 minutes to work on the
  IAs

4
Review of last day

• States of energy
• Excited particles Quantum Jumps

5
(No Transcript)
6
(No Transcript)
7
(No Transcript)
8

• What Planck was essentially saying was that
  energy emitted or absorbed by atoms is QUANTIZED
  or exists in packages (bundles) of energy in
  specific sizes.

9
Photoelectric Effect

• The photoelectric effect confirms the theory of
  the quantization of energy. Hertz was attempting
  to verify Maxwell's theories. ( 1887) He
  assembled a circuit that generated an oscillating
  current that caused sparks to jump back and forth
  across a gap.
• He showed that the sparks were generating
  electromagnetic waves by seeing sparks forming in
  the gap of the receiver.

10
Photoelectric Effect
11

• With this, he verified Maxwell's theories that
  when the metal electrodes were exposed to
  ultraviolet light, the sparks were enhanced.
• 10 years later, the electron was discovered.
  Physicists suggested that the UV light had
  ejected electrons from the electrodes.

12

• The ejection of electrons by UV light is the
  photoelectric effect.
• Lenard was the first to perform detailed
  experiments on the photoelectric effect. (1902)
• He designed an apparatus where electrodes were
  sealed in a vacuum tube with a quartz window. (UV
  light does not penetrate glass.)

13
(No Transcript)
14

• Lenard wanted to determine the kinetic energy of
  the photoelectrons. When the emitter was - and
  the collector was , he found that when the
  intensity increased, the current increased.
• When he switched the polarity of the emitter and
  the collector, he found that when he increased
  the potential difference (voltage), the current
  would eventually stop.

15
(No Transcript)
16
Results from Testing

• i) As the intensity of the light increases,
  energy absorbed by the surface increases and the
  number of photoelectrons increases. (classical
  physics)
• more intense light more energy absorbed by metal
  more electrons ejected from metal.

17
More Results

• ii) Classical physics also indicates that as the
  kinetic energy increases, the intensity
  increases.
• However Lenard found that the kinetic energy is
  not affected by the intensity.
• Kinetic energy is determined ONLY by the
  frequency of the light.

18
Important realization

• KE dependent on frequency not intensity.
• Einstein proposed that 'photoelectrons' are only
  ejected from the surface of the metal terminal if
  the frequency of the EMR was above a certain
  minimum level called the threshold frequency, fo.

19
(No Transcript)
20
(No Transcript)
21
Einsteins results

• Brightness or intensity of EMR had nothing to do
  with it, as EMR wave theory had predicted.
• In 1905, Einstein explained the photoelectric
  effect by saying EMR consisted of discrete
  bundles of energy which he called photons and
  that atoms would only absorb energy in these
  bundles.

22
Photo Electric Effect
23
Photo Electric Effect

• http//www.youtube.com/watch?vlTxs1usXSmk

24
(No Transcript)
25
(No Transcript)
26
Check out this websitePhotoelectric Effect

• http//phet.colorado.edu/en/simulation/photoelectr
  ic
• High resolution screen needed.

27

• Photons have an energy, KE. They either give up
  all their energy or none of it.
• The energy possessed by these photons depended on
  the frequency of the EMR.
• E hf
• Einstein was the first one to indicate that light
  and other EMR acted like particles.

28

• Kinetic energy (Ek) of electron freed by
  photoelectric effect is given by

29
(No Transcript)
30
(No Transcript)
31
Electron Volts

• Expressing extremely small amounts of energy at
  the atomic level is usually done in units called
  electron volts (eV).
• 1 eV 1.6x10-19 J

32
(No Transcript)
33
Example
34
(No Transcript)
35
Plancks Constant

• http//www.youtube.com/watch?vlTnpb9YPrQs

36
To do

• Work on questions from Chapter 18 19
• Study for Quiz Chapter 16 17
