A Wavelet-based Anomaly Detector for Disease Outbreaks

1
A Wavelet-based Anomaly Detector for Disease
Outbreaks

• Thomas Lotze
• Galit Shmueli
• University of Maryland College Park
• Sean Murphy
• Howard Burkom
• Johns Hopkins University Applied Physics Lab

2
Outline

• Motivation
• Wavelet method
• Difficulties
• Preconditioning
• Results

3
Related Work

• Bakshi
• Wavelets in Chemical SPC
• Zhang
• Baseline wavelets
• Normalize syndromic baseline
• Goldenberg, et. al.
• Wavelets in syndromic surveillance

4
Motivation

• Detecting disease outbreaks
• Bioterrorist attacks
• Virulent diseases
• Early detection saves lives!
• Syndromic Data will show outbreaks
• Anomaly detection to find outbreaks faster

5
Wavelets

• Models a series as a sum of wavelets
• Wavelets are at different scales
• Wavelets are local (change over time)

6
(No Transcript)
7
Difficulties

• Holidays
• Non-stationary
• Day of week
• Seasonal
• Noisy
• Outbreaks are not labeled
• Outbreak pattern not known in advance

8
Preconditioning

• Differs from Goldenberg, et. al
• Replace holidays
• One week previous
• Day-of-week
• Ratio to moving average

9
Evaluation Simulated Outbreaks

• Real data from 5 cities, Resp and Gi
• Simulated outbreak patterns inserted
• Specific pattern of additional syndromes over
  several days
• Size is normalized by standard deviation of
  recent days
• Inserted at different starting points within the
  sample data
• Average detection rates vs. false alarm rates can
  be determined to create ROC curves

10
Results

• Comparable to Holt-Winters
• Not amazing

11
Results

• Preconditioning is important
• Detection is much better when preconditioned

12
Results

• Easier to detect on some days than others
• Days with low counts
• Daily preconditioning not sufficient

13
Summary

• Wavelets are a fairly good detection method
• Preconditioning is very important
• Day-of-week not fully accounted for

14
Questions?

• More details on wavelets method?
• Difficulties?
• Other outbreak signals?
• Future work?
• Will Microsoft survive Bill Gates' stepping down?

15
Bonus More on Wavelets

• Level 1
• Run the data through a low-pass filter. This
  gives the approximation coefficients
• Run the data through a high-pass filter. This
  gives the detail coefficients
• Down-sample
• Reconstruct approximation and detail by
  up-sampling and running reconstruction filters.
• Level 2 and on
• Repeat the steps by applying them to the previous
  level approximation coefficients.

16
Bonus Wavelets on Cough Medication Sales
Haar Wavelet h 1/sqrt(2), 1/sqrt(2) g
1/sqrt(2), -1/sqrt(2) Downsample Upsample h
1/sqrt(2), 1/sqrt(2) g -1/sqrt(2),
1/sqrt(2) In general s a5 d1 d2 d5
17
Bonus Wavelet Prediction

• Additional details
• 5 level decomposition
• Can be performed with more or fewer
• SWT Fill in holes
• Perform a decomposition for every possible
  position
• Series are no longer independent
• Edge issue
• Prediction is not possible at all time steps
• Solution construct wavelets backwards from
  most recent observations

18
Bonus Ratio-to-Moving-Average

• Way of normalizing day-of-week effects
• 1 Determine moving averages
• a(i)(x(i-3) x(i-2) ... x(i3)) /7
• 2 Determine ratio (raw seasonal) for each day
• r(i)x(i)/a(i)
• 3 Determine avg. ratio for each day
• r(Mon)sum(r(i) i is Mon) / count(i is Mon)
• 4 Normalize ratios to sum to 1
• r'(Mon)r(Mon) / (r(Mon) ... r(Sun))
• 5 Divide each day by its ratio
• x'(i)x(i)/r(Mon)

19
Bonus Possible Extensions

• Multivariate wavelets
• Each day-of-week as a separate series
• Different wavelet shapes
• Different wavelet scale basis
• Different preconditioning
• Different sizes, lengths of outbreaks
• Don't normalize outbreak by standard deviation of
  recent days
• Show when outbreaks are harder to detect
• Estimate confidence based on experience
• Boosting

20
Bonus Wavelet Prediction

• Decompose into timescales
• Use AR or EWMA to predict for each timescale
• Reconstruct prediction from predicted timescales
• Monitor deviations from prediction

21
Bonus Alternative Preconditioning

• Regression using day-of-week predictors
• 7-day differencing
• Holt-Winters as preconditioner
• Seasonal preconditioning

22
Bonus Other Outbreak Signals

• Normalized by total size
• Lognormal, exponential, step
• Spike is much easier than the others
