Chapter 22
Gasoline Injection Fundamentals
3
Contents
(18 Topics)

• Gasoline injection fundamentals
• Gasoline injection classifications
• Throttle body and multiport injection
• Gasoline injection controls
• Electronic fuel injection
• Engine sensors

4
Contents

• Injector pulse width

• Throttle body injection
• Engine idle speed control
• Continuous throttle body injection
• Electronic multiport injection
• Air-fuel emulsion injector

5
Contents

• Unitized multiport injection

• Injector resistor pack
• Airflow sensing multiport EFI
• Pressure sensing multiport EFI
• Hydraulic-mechanical continuous injection system
• Fuel accumulator

6
Gasoline Injection Fundamentals

• Uses pressure from an electric fuel pump to spray
  fuel into the engines intake manifold

• Provides the engine with the correct air-fuel
  mixture for specific operating conditions

7
Advantages

• Improved atomization
• Better fuel distribution
• Smoother idle
• Improved fuel economy
• Lower emissions
• Better cold-weather driveability
• Increased engine power
• Simpler

8
Atmospheric Pressure

• Formed by the air surrounding the earth
• At sea level, the atmosphere exerts 14.7 psi (103
  kPa)

9
Vacuum

• Lower than atmospheric pressure
• Less than 14.7 psi (103 kPa) at sea level
• Sometimes called suction

10
Differences in Pressure Cause Flow

• Engines use differences in pressure to force fuel
  and air into its cylinders
• Engine acts as a vacuum pump, producing low
  pressure, or vacuum in the intake manifold

11
Intake Manifold Vacuum
12
Engine Throttle Valve

• Controls airflow and gasoline engine power output
• When opened, airflow, fuel flow, and power
  increase

13
Drive-by-Wire System

• Uses a pedal sensor, control module and an
  actuator to operate the throttle valve on a
  gasoline engine
• When the pedal is pressed, it moves a variable
  resistor
• Control module senses pedal position by measuring
  current flow through the resistor, and sends a
  signal to the actuator, controlling engine speed

14
Gasoline Injection Classifications

• There are many types of gasoline injection
  systems
• A gasoline injection system is commonly called a
  fuel injection system
• A diesel injection system is also a fuel
  injection system

15
Throttle Body and Multiport Injection
16
(No Transcript)
17
(No Transcript)
18
Gasoline Injection Controls

• Electronic fuel injection
• Hydraulic fuel injection
• Mechanical fuel injection
• Injection timing
• Injector opening relationship

19
Electronic Fuel Injection

• Uses various engine sensors and a control module
  to regulate injection
• Most common type of gasoline injection system

Hydraulic Fuel Injection

• Uses hydraulic control devices moved by air of
  fuel pressure
• Airflow sensor and fuel distributor meter
  gasoline (continuous injection)

20
Mechanical Injection

• Uses throttle linkage, mechanical pump, and
  governor to control injection
• Used on older, high-performance, and diesel
  applications

Intermittent Injection

• Opens and closes injectors independently of
  engine intake valves
• Also known as modulated injection

21
Timed Injection

• Sprays fuel just before, or as the intake valves
  open
• A good example is diesel Injection

Continuous Injection

• Sprays fuel into intake manifold at all times
• Air-fuel ratio is controlled by increasing or
  decreasing fuel pressure at the injectors

22
Injector Opening Relationship

• Simultaneous Injection
• All the injectors open at the same time
• Pulsed on and off together
• Sequential Injection
• Injectors open one after the other
• Injection matches the firing order of the engine

23
Injector Opening Relationship

• Group Injection
• Several, but not all injectors open at the same
  time
• V-8 engineone group of injectors open at one
  time, another group of four open at a different
  time

24
Electronic FuelInjection (EFI)

• EFI system can be divided into four subsystems
• fuel delivery system
• air induction system
• sensor system
• computer control system

25
Systems Overview
26
Fuel Delivery System

• Components
• Electric fuel pump
• Fuel filter
• Fuel pressure regulator
• Injectors

27
Fuel Delivery System
28
Electric Fuel Pump

• Draws gasoline out of the tank
• Forces it to the fuel rail
• Unused fuel returns to the tank

29
Fuel Pressure Regulator

• Controls pressure entering injector(s)
• Returns excess fuel to the tank
• Vacuum may be ported into the regulator
• lower pressure at idle
• increasing pressure at higher load

30
Fuel Pressure Regulator
31
Injectors

• Solenoid-operated fuel valve
• When current flows, magnetism attracts armature
  to open injector

32
Air Induction System

• Air filter
• traps dust and debris
• Throttle valve(s)
• controls airflow through throttle body
• Sensors
• sense airflow and throttle position
• Ducts
• route clean air to throttle body

33
Air Induction System

• Throttle plates control airflow

34
Sensor System

• Inputs to the control module
• Signal the following operating conditions
• temperature
• position
• pressure or vacuum
• speed

35
Computer Control System

• Uses data from the sensors to control fuel
  injectors
• Wiring harness connects computer to sensors and
  injectors

36
Electronic Control Module

• Commonly mounted behind the instrument panel

37
Engine Sensors

• Exhaust gas oxygen
• Manifold absolute pressure (MAP)
• Throttle position (TP)
• Engine coolant temperature(ECT)
• Airflow
• Inlet air temperature (IAT)
• Crankshaft position (CKP)

38
Oxygen Sensor

• Measures oxygen content in the exhaust
• Threaded into exhaust manifold before the
  catalytic converter
• OBDII equipped vehicles also use a second sensor
  after the catalytic converter to monitor
  converter efficiency

39
Oxygen Sensor

• Signals air-fuel mixture

40
Oxygen Sensor Operation

• Increase in exhaust oxygen from lean mixture
  causes oxygen sensor voltage to increase
• Decrease in exhaust oxygen from rich mixture
  causes oxygen sensor voltage to decrease

41
Oxygen Sensor Construction
42
Open Loop

• Injection system does not use exhaust gas oxygen
  as an indicator of air-fuel mixture
• Operation is from information stored in the
  computer
• Cold engines operate in open loop

Closed Loop

• Computer uses exhaust oxygen as a main input for
  air-fuel mixture control
• Normally, hot engines operate in closed loop

43
Information Flow
44
Map Sensor

• Senses engine load by measuring pressure or
  vacuum inside the intake manifold
• High pressure (low vacuum) indicates high load
• Low pressure (high vacuum) indicates low load

45
Map Sensor

• Often mounted on the engine or in the engine
  compartment

46
MAP Sensor Theory

• Piezo-resistor chip converts pressure change into
  resistance change

47
MAP Sensor Side View

• Manifold vacuum flexes the chip, altering its
  resistance

48
Throttle Position Sensor

• Senses throttle position
• Variable resistor connected to the throttle plate
• As the throttle opens, sensor resistance changes,
  signaling throttle position

49
Throttle Position Sensor

• Variable resistor signals throttle position

50
Engine Coolant Temperature Sensor

• Senses engine coolant temperature
• At low temperature, sensor resistance may be
  high, signal voltage high, computer will richen
  mixture
• At high temperature, sensor resistance may be
  low, signal voltage low, computer will deliver
  leaner mixture

51
Airflow Sensor

• Measures amount of air entering engine
• Air flap or door operates a variable resistor
• Airflow opens the flap, changing position of the
  variable resistor, changing the signal voltage to
  the computer

52
Airflow Sensor Operation

• Airflow sensor operates a variable resistor

53
Inlet Air Temperature Sensor

• Measures temperature of air entering the engine
• Air temperature affects air density
• Cooler air is more dense, requiring more fuel
• Operation is similar to engine coolant
  temperature sensor

54
Crankshaft Position Sensor

• Detects engine speed and position
• Information is used by computer for ignition
  timing and fuel injection operation

55
Other Sensors

• Several other sensors may be used
• A/C compressor sensor
• transmission sensor
• EGR sensor
• vehicle speed sensor
• knock sensor

56
Digital Signals

• Signal is on or off
• Voltage goes from maximum to minimum instantly,
  like a switch
• Crankshaft position sensor output may be a
  digital signal

57
Analog Signals

• Signal varies in voltage or strength
• May be produced by change in resistance of a
  sensor, sensing changes in temperature, pressure,
  or position

58
Injector Pulse Width

• Pulse width is the time injector is energized
• At wide open throttle, computer lengthens
  injector pulse to richen mixture
• At low load, computer shortens pulse width

59
Injector Pulse Width

• Pulse width controls the amount offuel injected

60
Throttle Body Injection

• Components
• throttle body housing
• TBI injector
• TBI pressure regulator
• idle speed control
• throttle position sensor
• throttle plates

61
TBI Overview
62
TBI Assembly

• Fuel enters the regulator before passing into the
  injector

63
Throttle Body Housing

• Bolted to the intake manifold
• Injector(s) are in the upper housing
• Throttle plates are in the lower housing
• Holds the throttle position sensor, fuel pressure
  regulator and idle speed control device

64
TBI Injector

• Components
• solenoid coil
• armature or plunger
• ball or needle valve
• seat

65
TBI Injector

• This injector uses a ball-type valve instead of a
  pointed needle valve

66
Injector Operation

• When the computer energizes the injector, a
  magnetic field is produced in the coil
• Magnetism pulls the plunger and valve up to open
  the injector
• Fuel is sprayed above the throttle valve

67
TBI Pressure Regulator

• Contains a fuel valve, diaphragm and spring
• Spring holds the fuel valve closed, causing
  pressure increase as fuel flows in from the
  electric fuel pump
• When preset pressure is reached, fuel pressure
  acting on the diaphragm forces the fuel valve
  open, allowing fuel to flow back to the tank

68
TBI System Cutaway
69
Engine Idle Speed Control

• There are several different types of idle speed
  control devices
• fast idle thermo valve
• idle air control motor
• throttle positioner

70
Fast Idle Thermo Valve

• Thermowax plunger contracts when cold to allow
  more airflow at idle
• Plunger expands when the engine warms, closing
  valve, reducing airflow

71
Fast Idle Thermo Valve

• Idle air control valve and the thermo valve
  affect air that bypasses the throttle valve to
  alter idle speed

72
Idle Air Control Motor

• Computer controlled solenoid or
  servomotor-operated air bypass valve

73
Throttle Positioner

• Computer controlled motor opens or closes the
  throttle plates to control idle speed
• In this way, the computer can maintain a precise
  idle speed with changes in temperature, load and
  other conditions

74
Continuous ThrottleBody Injection (CTBI)

• Sprays a solid stream of fuel into the air horn
• Does not pulse the injectors on and off to
  control the air-fuel mixture
• System alters pressure applied to the throttle
  body nozzles to control mixture

75
Electronic Multiport Injection

• Uses a computer, sensors and one solenoid
  injector for each cylinder
• Components
• multiport throttle body
• multiport pressure regulator
• fuel rail

76
Multiport Fuel Injection
Controls
77
Multiport Fuel Injection
Air Delivery
78
Multiport Fuel Injection
Fuel Delivery
79
Injection Components

• Throttle body
• contains throttle plates and a throttle position
  sensor
• Multiport pressure regulator
• mounted on the fuel rail, maintains pressure at
  the inlet to the injectors by acting as a bypass

80
Injection Components

• Fuel rail
• connects the main fuel line to the inlet of each
  injector
• Multiport fuel Injector
• sprays fuel into the intake port, below the
  throttle valve

81
Injection Components
82
Injection Components
83
Multiport Fuel Injector

• Solenoid opens the injector when current flows
  through the coil

84
Air-Fuel Emulsion Injector

• Mixes air with the fuel creating a slurry
• Slurry is injected into the intake manifold
• Atomizes the fuel and improves combustion
• Low pressure air from the air injection pump may
  be used

85
Air-Fuel Emulsion Injector
86
Unitized Multiport Injection

• Mounts all of the injectors into a single
  assembly
• Plastic transfer lines carry fuel from each
  injector to a poppet valve located in the intake
  port

87
Components

• Fuel injection transfer lines
• connect each injector to its poppet valve
• Fuel injection poppet valve
• spring loaded valve prevents fuel leakage between
  injector pulses
• when the fuel injector opens, fuel pressure
  forces the poppet valve open, spraying fuel into
  the intake port

88
Components

• Fuel injection transfer lines
• connect each injector to its poppet valve
• Fuel injection poppet valve
• spring loaded valve prevents fuel leakage between
  injector pulses
• when the fuel injector opens, fuel pressure
  forces the poppet valve open, spraying fuel into
  the intake port

89
Unitized Injector

• Note the fitting for the plastic transfer line

90
Injector Resistor Pack

• Set of low-ohm resistors
• Control current flow to each injector coil
• Protect windings from excess current
• Usually 5-7 ohms
• Often mounted in the engine compartment

91
Injector Circuit
92
Airflow Sensing Multiport EFI

• Uses an airflow sensor as a main control
• Airflow sensor is placed at the inlet to the
  intake manifold
• Sensor converts airflow into a signal for the
  computer

93
System Overview
94
Airflow Sensor Operation
Throttle moved open for more power, increased
flow pushes sensor flap open
Throttle almost closed, sensor detects little
airflow
95
Pressure-Sensing Multiport EFI

• Uses intake manifold pressure (vacuum) as a
  primary control
• Pressure sensor is connected to the intake
  manifold
• Sensor converts changes in manifold pressure into
  changes in resistance
• Computer uses this data

96
System Overview
97
Hydraulic-Mechanical Continuous Injection System
98
Continuous Injection System (CSI)

• Hydraulic-mechanical system
• Mixture control unit senses airflow with an
  airflow sensor plate and distributes fuel
• Operates the injectors with a fuel distributor

99
Continuous Injection System (CSI)
100
Airflow Sensor

• Disc-shaped plate, hinged in the air horn
• Plate operates a lever arm
• Lever arm pushes up a fuel control plunger in the
  fuel distributor when air flows
• Plunger opens fuel passages to the injectors

101
CIS Fuel Distributor

• Hydraulically-operated valve mechanism
• Controls fuel flow or pressure to each injector
• Whenever air flows to the engine, the fuel
  distributor sends fuel to the injectors, causing
  them to spray continuously

102
CIS Operation
103
Continuous Fuel Injector

• Spring-loaded valve
• One injector for each cylinder
• Injects fuel continuously when the engine is
  running
• Spring holds the valve closed
• Fuel pressure forces it open, spraying fuel into
  the intake port
• Spring-loaded valve
• Fuel pressure forces the valve open

104
Continuous Fuel Injector
105
Cold Start Injector

• Extra fuel injector
• Sprays fuel into the intake plenum for cold
  engine starting and running
• Improves cold operation by enriching the air-fuel
  mixture
• Controlled by a thermo-time switch or control
  module

106
Cold Start Injector
107
Fuel Accumulator

• Damps pressure pulses
• May maintain pressure when shut down to aid
  restarting

108
Fuel Accumulator Components and Operation
Engine running, fuel pressure compresses
diaphragm spring
Engine off, spring pressure on diaphragm
maintains system pressure
