Superscalar Pipelines Part 2

1
Superscalar PipelinesPart 2

• 12/1/08

2
An example six stage superscalar pipeline

• The six stages fetch, decode, dispatch, execute,
  complete, and retiring.
• The execute stage can include multiple
  (pipelined) functional units of different types
  with different execution latencies.
• The dispatch stage distributes instructions of
  different types to their corresponding functional
  units.
• the complete stage reorders instructions to
  ensure in-order updating of the machine state.

3
k 6 pipeline stages s 7 width
4
Fetch

• Multiple instructions are fetched from I-cache on
  each machine cycle.
• I-cache line needs to be a multiple of pipeline
  width s.

5
Fetch continued

• S instructions must be fetched on each clock
  cycle to sustain pipeline bandwidth.
• Problems
• Instruction misalignment
• Instructions that change program flow. i.e.
  branches.

6
Decode

• Identify individual instructions.
• Determine instruction types.
• Detect inter-instruction dependences among
  instructions that have been fetched but not yet
  dispatched.
• Determines which instructions can be dispatched
  in parallel.
• Complicated for s gt 1.
• Much simpler for RISC than CISC.
• CISCs typical require multiple pipeline stages
  for decoding.
• CISC instructions are translated into internal
  RISC instructions. Intel refers to these as ?ops
  (pronounced you-ops).
• Must quickly identify control-flow changing
  instructions and provide feedback to the fetch
  stage.

7
Pentium Pro example
8
Dispatch

• Different types of instructions are executed by
  different functional units.
• The decode stage identifies the instruction type.
• The dispatch stage routs the instruction to the
  appropriate functional unit in the execution
  stage.

9
(No Transcript)
10
Execution

• Execution unit is the heart of a superscalar
  computer.
• The trend is towards more parallel and more
  diversified pipelines.
• More functional units and more specialized
  functional units.
• Early scalar pipeline machines had only one
  functional unit. i.e. our Mips. With possibly a
  separate functional unit for floating point.
• Current superscalar processors may have multiple
  integer units and multiple floating point units.

11
(No Transcript)
12
Completion and retiring

• An instruction is complete when it finishes
  execution and updates the machine state.
• An instruction finishes execution when it exits
  the functional unit and enters the completion
  buffer.
• When the instruction exits the completion unit
  all registers have been updated. The instruction
  is architecturally complete.
• However, memory may still need to be written. The
  instruction exits the retire unit when memory has
  been written.
• Instructions that do not update memory are
  retired as soon as they exit the completion unit.

13
Interrupts and exceptions

• Interrupts asynchronous external events.
• Stop fetching new instructions.
• Allow instructions in pipeline to finish.
• Save machine state.
• Transfer control to interrupt service routine.
• Exceptions induced by the execution of an
  instruction.
• Precise interrupts require that machine state be
  save just prior to the exception.
• Complicated.

14
