Sinamics EZ EPOS Agenda

• Starter Basic Sinamics Drive Setup
• Insert Drive (CU310 or CU320)
• Auto Configure CU and Drive-CLIQ Devices
• Starter Offline Configuration
• Drive Configuration Wizard
• Telegram Setup for EZ _EPOS Block
• Check S7 Hardware Configuration
• Execute EZ_EPOS Script File
• Copy from Example Project
• Execute and Save Project
• Download to Sinamics
• Step7 Simatic Manager Programming
• Copy Needed blocks to new Program
• Setup FB120 in new Program
• Edit Symbol Table
• Save and Download S7 Project
