Never miss capturing a disturbance

1
Never miss capturinga disturbance

• Testing power quality inbackup power systems

2
Our automated world

• Data centers, banks, hospitals, industrial sites
  and other facilities all rely on electrical power
• Many have mission-critical systems/processes
• Inter-related systems add more complexity
• The 24/7 economy demands always-on so
• Growing dependence on UPS systems
  diesel-powered emergency generators

3
The hidden challenge

• Even with regular testing of your backup systems
• Undetected power quality problems elsewhere in
  the facility can still cause backup systems to
  malfunction
• Leading to higher energy costs
• or catastrophic failure and downtime!

4
The power quality challenges

• Spikes, transients, harmonics and frequency
  deviations often invisible and unpredictable
• How do you know what youre up against?
• Then capture it and measure it?
• Accurately, and in sufficient resolution?
• And be sure youve not missed an event?
• Answer Use long-term recording and analysis

5
Introducing the Fluke 1750

• The three-phase power recorder that reveals the
  true state of your electrical distribution system

6
Power quality testing is easy

• Worry-free setupautomatic threshold-free
  measurement system
• Never miss a disturbancecapture every event, on
  every cycle, all the time (30 day standard
  memory)
• Understand test outcomes easilyintuitive
  software for analysis and reporting
• Simplify compliance checksall the latest power
  quality standards are built-in

7
Now with enhanced features

• Auto Reportgenerate template-based reports in
  seconds or customized reports in minutes
• User definable summary limitsuser definition for
  summary reporting according to IEEE or IEC limits
• Enhanced graphicsauto/manual scaling relative
  and absolute cursor measurements improved data
  zoom
• Instrument control setupbutton for immediate
  power-down/quick stowage one-button PC time sync.
