Learning PCFGs: Estimating Parameters, Learning Grammar Rules

1
Learning PCFGs Estimating Parameters,Learning
Grammar Rules

• Many slides are taken or adapted from slides by
• Dan Klein

2
Treebanks
An example tree from the Penn Treebank
3
The Penn Treebank

• 1 million tokens
• In 50,000 sentences, each labeled with
• A POS tag for each token
• Labeled constituents
• Extra information
• Phrase annotations like TMP
• empty constituents for wh-movement traces,
  empty subjects for raising constructions

4
Supervised PCFG Learning

• Preprocess the treebank
• Remove all extra information (empties, extra
  annotations)
• Convert to Chomsky Normal Form
• Possibly prune some punctuation, lower-case all
  words, compute word shapes, and other
  processing to combat sparsity.
• Count the occurrence of each nonterminal c(N) and
  each observed production rule c(N-gtNL NR) and
  c(N-gtw)
• Set the probability for each rule to the MLE
• P(N-gtNL NR) c(N-gtNL NR) / c(N)
• P(N-gtw) c(N-gtw) / c(N)
• Easy, peasy, lemon-squeezy.

5
Complications

• Smoothing
• Especially for lexicalized grammars, many test
  productions will never be observed during
  training
• We dont necessarily want to assign these
  productions zero probability
• Instead, define backoff distributions, e.g.
• Pfinal(VPtransmogrified -gt Vtransmogrified
  PPinto)
• a P(VPtransmogrified -gt Vtransmogrified
  PPinto)
• (1-a) P(VP -gt V PPinto)

6
Problems with Supervised PCFG Learning

• Coming up with labeled data is hard!
• Time-consuming
• Expensive
• Hard to adapt to new domains, tasks, languages
• Corpus availability drives research (instead of
  tasks driving the research)
• Penn Treebank took many person-years to manually
  annotate it.

7
Unsupervised Learning of PCFGS Feasible?
8
Unsupervised Learning

• Systems take raw data and automatically detect
  data
• Why?
• More data is available
• Kids learn (some aspects of) language with no
  supervision
• Insights into machine learning and clustering

9
Grammar Induction and Learnability

• Some have argued that learning syntax from
  positive data alone is impossible
• Gold, 1967 non-identifiability in the limit
• Chomsky, 1980 poverty of the stimulus
• Surprising result its possible to get entirely
  unsupervised parsing to work (reasonably) well.

10
Learnability

• Learnability formal conditions under which a
  class of languages can be learned
• Setup
• Class of languages ?
• Algorithm H (the learner)
• H sees a sequence X of strings x1 xn
• H maps sequences X to languages L in ?
• Question is for what classes ? do learners H
  exist?

11
Learnability Gold, 1967

• Criterion Identification in the limit
• A presentation of L is an infinite sequence of
  xs from L in which each x occurs at least once
• A learner H identifies L in the limit if, for any
  presentation of L, from some point n onwards, H
  always outputs L
• A class ? is identifiable in the limit if there
  is some single H which correctly identifies in
  the limit every L in ?.
• Example L a,a,b is identifiable in the
  limit.
• Theorem (Gold, 67) Any ? which contains all
  finite languages and at least one infinite
  language (ie is superfinite) is unlearnable in
  this sense.

12
Learnability Gold, 1967

• Proof sketch
• Assume ? is superfinite, H identifies ? in the
  limit
• There exists a chain L1 ? L2 ? L8
• Construct the following misleading sequence
• Present strings from L1 until H outputs L1
• Present strings from L2 until H outputs L2
• This is a presentation of L8
• but H never outputs L8

13
Learnability Horning, 1969

• Problem, IIL requires that H succeeds on all
  examples, even the weird ones
• Another criterion measure one identification
• Assume a distribution PL(x) for each L
• Assume PL(x) puts non-zero probability on all and
  only the x in L
• Assume an infinite presentation of x drawn i.i.d.
  from PL(x)
• H measure-one identifies L if the probability of
  drawing a sequence X from which H can identify
  L is 1.
• Theorem (Horning, 69) PCFGs can be identified
  in this sense.
• Note there can be misleading sequences, but
  they have to be (infinitely) unlikely

14
Learnability Horning, 1969

• Proof sketch
• Assume ? is a recursively enumerable set of
  recursive languages (e.g., the set of all PCFGs)
• Assume an ordering on all strings x1 lt x2 lt
• Define two sequences A and B agree through n
  iff for all xltxn, x is in A ? x is in B.
• Define the error set E(L,n,m)
• All sequences such that the first m elements do
  not agree with L through n
• These are the sequences which contain early
  strings outside of L (cant happen), or which
  fail to contain all of the early strings in L
  (happens less as m increases)
• Claim P(E(L,n,m)) goes to 0 as m goes to 8
• Let dL(n) be the smallest m such that P(E) lt 2n
• Let d(n) be the largest dL(n) in first n
  languages
• Learner after d(n), pick first L that agrees
  with evidence through n
• This can only fail for sequences X if X keeps
  showing up in E(L, n, d(n)), which happens
  infinitely often with probability zero.

15
Learnability

• Golds results say little about real learners
  (the requirements are too strong)
• Hornings algorithm is completely impractical
• It needs astronomical amounts of data
• Even measure-one identification doesnt say
  anything about tree structures
• It only talks about learning grammatical sets
• Strong generative vs. weak generative capacity

16
Unsupervised POS Tagging

• Some (discouraging) experiments
• Merialdo 94
• Setup
• You know the set of allowable tags for each word
  (but not frequency of each tag)
• Learn a supervised model on k training sentences
• Learn P(wt), P(titi-1,ti-2) on these sentences
• On ngtk, reestimate with EM

17
Merialdo Results
18
Grammar Induction

• Unsupervised Learning
• of Grammars and Parameters

19
Right-branching Baseline

• In English (but not necessarily in other
  languages), trees tend to be right-branching
• A simple, English-specific baseline is to choose
  the right chain structure for each sentence.

20
Distributional Clustering
21
Nearest Neighbors
22
Learn PCFGs with EM Lari and Young, 1990

• Setup
• Full binary grammar with n nonterminals X1, ,
  Xn
• (that is, at the beginning, the grammar has all
  possible rules)
• Parse uniformly/randomly at first
• Re-estimate rule expecations off of parses
• Repeat
• Their conclusion it doesnt really work

23
EM for PCFGs Details

• Start with a full grammar, with all possible
  binary rules for our nonterminals N1 Nk.
  Designate one of them as the start symbol, say N1
• Assign some starting distribution to the rules,
  such as
• Random
• Uniform
• Some smart initialization techniques (see
  assigned reading)
• E-step Take an unannotated sentence S, and
  compute, for all nonterminals N, NL, NR, and all
  terminals w
• E(N S), E(N-gtNL NR, N is used S), E(N-gtw, N is
  used S)
• M-step Reset rule probabilities to the MLE
• P(N-gtNL NR) E(N-gtNL NRS) / E(N S)
• P(N-gtw) E(N-gtw S) / E(N S)
• Repeat 3 and 4 until rule probabilities
  stabilize, or converge

24
Definitions
This is the sum of P(T, S G) over all possible
trees T for w1m where the root is N1.
25
E-Step

• We can define the expectations we want in terms
  of p, a, ß quantities

26
Inside Probabilities

• Base case
• Induction

Nj
Nl
Nr
wp
wd
wd1
wq
27
Outside Probabilities

• Base case
• Induction

28
Problem Model Symmetries
29
Distributional Syntax?
30
Problem Identifying Constituents
31
A nested distributional model

• Wed like a model that
• Ties spans to linear contexts (like
  distributional clustering)
• Considers only proper tree structures (like
  PCFGs)
• Has no symmetries to break (like a dependency
  model)

32
Constituent Context Model (CCM)
33
Results Constituency
34
Results Dependencies
35
Results Combined Models
36
Multilingual Results
