Sorting

1
Sorting
2
Introduction

• The objective is to take an unordered set of
  comparable data items and arrange them in order.
• We will usually sort the data into ascending
  order sorting into descending order is very
  similar.
• Data can be sorted in various ADTs, such as
  arrays and trees in fact, we have already seen
  how a binary search tree can be used to sort
  data.
• There are two main sorting themes address-based
  sorting and comparison-based sorting. We will
  focus on the latter.

3
The family of sorting methods
Main sorting themes
Address- -based sorting
Comparison-based sorting
Proxmap Sort
RadixSort
Transposition sorting
BubbleSort
Divide and conquer
Diminishing increment sorting
Insert and keep sorted
MergeSort
QuickSort
Insertion sort
Tree sort
ShellSort
4
Lecture schedule

• An overview of sorting algorithms
• We will not study address-based sorting in detail
  because they are quite restricted in their
  application
• One slide on Proxmap/Radix sort
• Examples from each type of comparison-based
  sorting algorithm
• Bubble sort transposition sorting
• Insertion sort (already seen, see Tree notes)
  insert and keep sorted
• Selection sort priority queue sorting
• Shell sort diminishing increment sorting
• Merge sort and Quick sort divide and conquer
  sorting

5
Bubble sort

• A pretty dreadful type of sort!
• However, the code is small

for (int iarr.length igt0 i--) for (int
j1 jlti j) if (arrj-1 gt arrj)
temp arrj-1
arrj-1 arrj arrj temp

6
Insertion sort

• Tree Insertion Sort
• This is inserting into a normal tree structure
  i.e. data are put into the correct position when
  they are inserted.
• Weve already seen this happening with a tree,
  requiring a find and an insert.
• We know the time complexity for one insert is
  O(logN) O(1) O(logN) therefore to insert N
  items will have a complexity of O(NlogN).
• Array Insertion Sort
• The array must be sorted insertion requires a
  find insert.
• The insertion time complexity is O(logN) O(N)
  O(N) for one item, therefore to insert N items
  will have a complexity of O(N2).

7
SelectionSort

• SelectionSort uses an array implementation of the
  Priority Queue ADT (not the heap implementation
  we will study)
• The elements are inserted into the array as they
  arrive and then extracted in descending order
  into another array
• The major disadvantage is the performance
  overhead of finding the largest element at each
  step we have to traverse over the entire array
  to find it

13
2
15
4
8
SelectionSort (2)

• In practice, we use the same array for the
  Priority Queue and the output results
• General algorithm
• 1. Initialise PQLast to the last index of the
  Priority Queue
• 2. Search from the start of the array to PQLast
  for the largest element call its position front
• 3. Swap element indexed by front with element
  indexed by PQLast
• 4. Decrement PQLast by one
• 5. Repeat steps 2 4

9
SelectionSort (3)
12
9
13
2
15
4
PQLast
etc.
10
Time complexity of SelectionSort

• The main operations being performed in the
  algorithm are
• 1. Comparisons to find the largest element in the
  Priority Queue subarray (to find front index)
  there are n (n-1) 2 1 comparisons,
  i.e., n/2 (n1) (n2 n) / 2 so this is an
  O(n2) operation
• 2. Swapping elements between front and PQLast
  n-1 exchanges are performed so this is an O(n)
  operation
• The dominant operation (time-wise) gives the
  overall time complexity, i.e., O(n2)
• Although this is an O(n2) algorithm, its
  advantage overO(n log n) sorts is its simplicity

11
Time complexity of SelectionSort (2)

• For very small sets of data, SelectionSort may
  actually be more efficient than O(n log n)
  algorithms
• This is because many of the more complex sorts
  have a relatively high level of overhead
  associated with them, e.g., recursion is
  expensive compared with simple loop iteration
• This overhead might outweigh the gains provided
  by a more complex algorithm where a small number
  of data elements is being sorted
• SelectionSort does better than BubbleSort as
  fewer swaps are required, although the same
  number of comparison operations are performed
  (each swap puts an element in its correct place)

12
Shell sort diminishing increment sorting

• Named after D.L. Shell! But it is also rather
  like shrinking shells of sorting, for Insertion
  Sort.
• Shell sort aims to reduce the work done by
  insertion sort (i.e. scanning a list and
  inserting into the right position).
• Do the following
• Begin by looking at the lists of elements x1
  elements apart and sort those elements by
  insertion sort
• Reduce the number x1 to x2 so that x1 is not a
  multiple of x2 and repeat these two steps until
  x2 1.
• It can be shown that this approach will sort a
  list with a time complexity of O(N1.25).

13
Shell Sort Illustration

• Consider sorting the following list by Shell sort

GAP3
GAP2
GAP1
6 7 23 24 91
45 23 4 9 6 7 91 8 12 24
9 24 45 91
6 8 23
4 7 12
9 6 4 24 8 7 45 23 12 91
4 8 9 12 45
4 6 8 7 9 23 12 24 45 91
4 6 7 8 9 12 23 24 45 91
14
Comparing O(N2), O(N1.25) and O(N)
15
How do you choose the gap size?

• The idea of the decreasing gap size is that the
  list becomes more and more sorted each time the
  gap size is reduced, therefore you dont (for
  example) want to have a gap size of 4 followed by
  a gap size of 2 because youll be sorting half
  the numbers a second time.
• There is no formal proof of a good initial gap
  size, but about a 10th the size of N is a
  reasonable start.
• Try to use prime numbers as your gap size, or odd
  numbers if you can not readily get a list of
  primes (though note gaps of 9, 7, 5, 3, 1 will
  be doing less work when gap3).

16
Divide and conquer sorting
MergeSort
QuickSort
17
Divide ...
5
1
4
2
10
3
9
15
18
and conquer
5
1
4
2
10
3
9
15
19
MergeSort divide and conquer sorting

• For MergeSort an initial array is repeatedly
  divided into halves (usually each is a separate
  array), until arrays of just one or zero elements
  remain
• At each level of recombination, two sorted arrays
  are merged into one
• This is done by copying the smaller of the two
  elements from the sorted arrays into the new
  array, and then moving along the arrays

1
13
24
26
2
15
27
38
20
Merging
1
13
24
26
2
15
27
38
1
etc.
21
Merge Sort In Pseudocode

• Basic idea in pseudocode

method mergeSort(array) is if len(array)
0 or len(array) 1 then // terminating
case return array else end
len(array) center end / 2 left mergeSort(
array0center ) // recursive
call right mergeSort( arraycenterend )
// recursive call return merge(left,right)
// method that merges lists end if
end method
22
Analysis of MergeSort

• Let the time to carry out a MergeSort on n
  elements be T(n)
• Assume that n is a power of 2, so that we always
  split into equal halves (the analysis can be
  refined for the general case)
• For n1, the time is constant, so we can take
  T(1) 1
• Otherwise, the time T(n) is the time to do two
  MergeSorts on n/2 elements, plus the time to
  merge, which is linear
• So, T(n) 2 T(n/2) n
• Divide through by n to get T(n)/n T(n/2)/(n/2)
  1
• Replacing n by n/2 gives, T(n/2)/(n/2)
  T(n/4)/(n/4) 1
• And again gives, T(n/4)/(n/4) T(n/8)/(n/8) 1

23
Analysis of MergeSort (2)

• We continue until we end up with T(2)/2 T(1)/1
  1
• Since n is divided by 2 at each step, we have
  log2n steps
• Now, substituting the last equation in the
  previous one, and working back up to the top
  gives T(n)/n T(1)/1 log2n
• That is, T(n)/n log2n 1
• So T(n) n log2n n O(n log n)
• Although this is an O(n log n) algorithm, it is
  hardly ever used for main memory sorts because it
  requires linear extra memory

24
QuickSort divide and conquer sorting

• As its name implies, QuickSort is the fastest
  known sorting algorithm in practice
  (address-based sorts can be faster)
• It was devised by C.A.R. Hoare in 1962
• Its average running time is O(n log n) and it is
  very fast
• It has worst-case performance of O(n2) but this
  can be made very unlikely with little effort
• The idea is as follows
• 1. If the number of elements to be sorted is 0 or
  1, then return
• 2. Pick any element, v (this is called the pivot)
• 3. Partition the other elements into two disjoint
  sets, S1 of elements ? v, and S2 of elements gt v
• 4. Return QuickSort (S1) followed by v followed
  by QuickSort (S2)

25
QuickSort example
5
1
4
2
10
3
9
15
12
Pick the middle element as the pivot, i.e., 10
26
QuickSort Example (full)
5
1
4
2
10
3
9
15
12
Unsorted List
5
1
4
2
3
9
15
12
10
Partition1
1
2
3
4
5
9
12
15
Partition2
1
3
2
5
9
Partition3
1
2
3
4
5
9
10
12
15
Sorted List
27
QuickSort Pseudocode

• Basic idea in pseudocode (compare with mergeSort)

method quickSort(array) is if len(array)
0 or len(array) 1 then // terminating
case return array else pivotIndx int(
random() len(array) ) pivot
array(pivotIndx) // just choose a random
pivot (left, right) partition(array, pivot)
// get left and right return quickSort(left)
pivot quickSort(right) end if end method
28
Partitioning example
5
11
4
25
10
3
9
15
12
Pick the middle element as the pivot, i.e., 10
29
Partitioning example (2)
10
4
5
25
11
3
9
15
12
30
Pseudo code for partitioning
pivotPos middle of array aswap apivotPos
with afirst // Move the pivot out of the
way swapPos first 1 for each element in the
array from swapPos to last do // If the
current element is smaller than pivot we //
move it towards start of array if
(acurrentElement lt afirst) swap
aswapPos with acurrentElement
increment swapPos by 1 // Now move the pivot
back to its rightful place swap afirst with
aswapPos-1 return swapPos-1 // Pivot
position
31
Analysis of QuickSort

• We assume a random choice of pivot
• Let the time to carry out a QuickSort on n
  elements be T(n)
• We have T(0) T(1) 1
• The running time of QuickSort is the running time
  of the partitioning (linear in n) plus the
  running time of the two recursive calls of
  QuickSort
• Let i be the number of elements in the left
  partition, then T(n) T(i) T(ni1) cn (for
  some constant c)

32
Worst-case analysis

• If the pivot is always the smallest element, then
  i 0 always
• We ignore the term T(0) 1, so the recurrence
  relation isT(n) T(n1) cn
• So, T(n1) T(n2) c(n1) and so on until we
  getT(2) T(1) c(2)
• Substituting back up gives T(n) T(1) c(n
  2) O(n2)
• Notice that this case happens if we always take
  the pivot to be the first element in the array
  and the array is already sorted
• So, in this extreme case, QuickSort takes O(n2)
  time to do absolutely nothing!

33
Best-case analysis

• In the best case, the pivot is in the middle
• To simplify the equations, we assume that the two
  subarrays are each exactly half the length of the
  original (a slight overestimate which is
  acceptable for big-Oh calculations)
• So, we get T(n) 2T(n/2) cn
• This is very similar to the formula for
  MergeSort, and a similar analysis leads to T(n)
  cn log2n n O(n log n)

34
Average-case analysis

• We assume that each of the sizes of the left
  partition are equally likely, and hence have
  probability 1/n
• With this assumption, the average value of T(i),
  and hence also of T(ni1), is (T(0) T(1)
  T(n1))/n
• Hence, our recurrence relation becomesT(n)
  2(T(0) T(1) T(n1))/n cn
• Multiplying by n givesnT(n) 2(T(0) T(1)
  T(n1)) cn2
• Replacing n by n1 gives(n1)T(n1) 2(T(0)
  T(1) T(n2)) c(n1)2
• Subtracting the last equation from the previous
  one givesnT(n) (n1)T(n1) 2T(n1) 2cn c

35
Average-case analysis (2)

• Rearranging, and dropping the insignificant c on
  the end, gives nT(n) (n1)T(n1) 2cn
• Divide through by n(n1) to getT(n)/(n1)
  T(n1)/n 2c/(n1)
• Hence, T(n1)/n T(n2)/(n1) 2c/n and so on
  down toT(2)/3 T(1)/2 2c/3
• Substituting back up givesT(n)/(n1) T(1)/2
  2c(1/3 1/4 1/(n1))
• The sum in brackets is about loge(n1) ? 3/2,
  where ? is Eulers constant, which is
  approximately 0.577
• So, T(n)/(n1) O(log n) and T(n) O(n log n)

36
Some observations about QuickSort

• We have seen that a consistently poor choice of
  pivot can lead to O(n2) time performance
• A good strategy is to pick the middle value of
  the left, centre, and right elements
• For small arrays, with n less than (say) 20,
  QuickSort does not perform as well as simpler
  sorts such as SelectionSort
• Because QuickSort is recursive, these small cases
  will occur frequently
• A common solution is to stop the recursion at n
  10, say, and use a different, non-recursive sort
• This also avoids nasty special cases, e.g.,
  trying to take the middle of three elements when
  n is one or two

37
Address-Based Sorting

• Proxmap uses techniques similar to hashing to
  assign an element to its correctly sorted
  position in a container such as an array using a
  hash function
• The algorithms are generally complex, and very
  often only suitable for certain kinds of data
• You need to find a suitable hashing function that
  will distribute data fairly evenly
• Clashes are dealt with using a comparison based
  sort, so the more clashes there are the further
  the time complexity moves away from O(n) (see
  notes view for more details)

38
Radix / Bucket / Bin sort

• Radix Sort
• In its favour, it is an O(n) sort. That makes it
  the fastest sort we have investigated.
• However it requires at least 2n space in which to
  operate, and is in principle exponential in its
  space complexity..
• A radix sort makes one pass through the data for
  each atom in the key. If the key is three
  character uppercase alphabetic strings, such as
  ABC, then A is an atom. In this case, there would
  be three passes through the data.
• The first pass sorts on the low order element of
  the key (the C in our example). The second pass
  sorts on the next atom, in order of importance
  (the B in our example). Each pass progresses
  toward the high order atom of the key.
• In each such pass, the elements of the array are
  distributed into k buckets. For our alphabetic
  key example, A's go into the 'A' bucket, B's into
  the 'B' bucket, and so on. These distribution
  buckets are then gathered, in order, and placed
  back in the original array. The next pass is then
  executed. When a pass has been made on the high
  order atom in the key, the array will be sorted.

39
Radix Sort Example
col1
col2
col3
121
123 121
123 134 156 121
123
123 234 345 134 245 356 156 267 378 121 232 343
134
Bins 0,2,4-9 Are empty
156
234 245 267 232
134
Bins 0-1,4,6-9 Are empty
156
234 232
232
345 356 378 343
245
234
267
Bins 0-1,3,5-9 Are empty
Bins 0-2,5,7-9 Are empty
. . .
Bins 0, 4-9 are empty
