Title: 277 North El Molino Avenue Predevelopment Plan Review


1
277 North El Molino Avenue Predevelopment Plan
Review
  • City Council MeetingMay 5, 2014

2
Vicinity Map
210 Freeway
Subject Site
Corson Street
EL Molino Avenue
Madison Avenue
Locust Street
Locust Street
Walnut Street
3
Subject Site
Corson Street
Subject Site
EL Molino Avenue
Locust Street
4
Project Description
  • Site is zoned CD-3
  • Central District Specific Plan, Walnut Housing
    Subdistrict.
  • Site is within Central District Transit Oriented
    Development Area
  • Subject to Transit-Oriented Development Section
    of the Zoning Code (17.50.340).
  • Multi-Family Housing within the Central District
    Specific Plan
  • Subject to Urban Housing Development Standards.

5
Project Description
  • Demolish two commercial buildings of 8,790 square
    feet and surface parking lot.
  • Construct six-story (75 ft.) residential building
    containing 105 units.
  • Two levels of parking, one on street level and
    one subterranean.
  • Maximum permitted height 60 ft. Request for
    height averaging to be reviewed by the Citys
    Design Commission.

6
Project Description
  • Maximum permitted density 87 units per acre or
    85 units.
  • Proposed 105 units, a 23 percent bonus permitted
    with the provision of affordable units.
  • Maximum permitted floor area ratio 2.25 or
    96,097 square feet.
  • Proposed building size 118,350 square or 2.77
    floor area ratio. Request for an Affordable
    Housing Concession Permit to increase the
    allowable floor area ratio.

7
Project Description
North end of the property
  • South end of the property

View from north of subject property
8
Project Description
El Molino Ave. Perspective
9
Project Description
Corner of El Molino Ave. and Corson St.
Perspective
10
Project Description
Southeast Corner Aerial
11
Project Description
South Elevation
North Elevation
12
Project Description
East Elevation
West Elevation
13
Discretionary Entitlements
  • Entitlements
  • Affordable Housing Concession Permit to increase
    the maximum permitted floor area ratio
    requirement of 2.25
  • Design Review for a project that exceeds 5,000
    square feet in size or contain 10 or more
    dwelling units and
  • Height Averaging for a project that exceeds
    60-feet in height.

14
Discretionary Entitlements
  • Review Authorities
  • Hearing Officer is decision maker on Affordable
    Housing Concession Permit
  • Design Commission will conduct design review and
    review and possibly approve Height Averaging and
  • Urban Forestry Advisory Committee will review
    requests to remove any street trees, and provide
    a recommendation to the City Manager.

15
Major Issues for Analysis
  • Maximum height and height averaging
  • Placement and design of a required street level
    landscaped courtyard and
  • Construction adjacent or near properties that are
    designated historic resources or resources that
    are eligible for historic designation.

16
Major Issues for Analysis
  • Historic Resources are
  • The residence at 267 North El Molino Avenue
    (Lukens House) is located immediately to the
    south of the project site, was built in 1896 and
    is listed in the National Register of Historic
    Places,
  • The residence located at 246 North El Molino
    Avenue (Frances K. Mason House) is located to the
    east of the site, was built in 1904 and is
    eligible for historic designation, and
  • The property at 684 Locust Street (to the east)
    is not eligible for historic designation but
    should be considered in the planning process in
    the future.

17
Historic Resources
210 Freeway
Subject Site
Corson Street
684 Locust Street
EL Molino Avenue
Madison Avenue
Locust Street
Locust Street
Lukens House
Frances K. Mason House
Walnut Street
18
Planning Division Comments
  • Topics related to Zoning Code
  • Height Maximum 60 feet or 75 feet when
    utilizing height averaging
  • The building is proposed to be five to six
    stories in height and have a overall height of 75
    feet. Height Averaging is required for the
    proposed height.
  • Size (Floor Area) Maximum 2.25 or 96,097 square
    feet
  • The building is proposed to be 118,350 square
    feet or have an FAR of 2.77. An Affordable
    Housing Concession Permit is required to increase
    the FAR from 2.25 to 2.77.
  • Density 87 units/acre or 85 units for the site
  • 105 units are proposed, which is a 23 density
    bonus.

19
Planning Division Comments
  • Topics related to Zoning Code
  • Setbacks Min 5 foot and max 10 foot along El
    Molino Avenue, 10 foot setback along Corson
    Street, rear and side property line.
  • As proposed, the building appears to be
    encroaching into the required 10 foot south side
    setback.
  • Parking When utilizing density bonus, the
    parking requirement is the following
  • 1 on-site space for 0-1 bedroom units
  • 2 on-site spaces for 2-3 bedroom units
  • Based on the project a total of 158 spaces are
    required, 159 spaces are proposed.

20
Planning Division Comments
  • Topics related to Zoning Code
  • Open Space Min area required 30 of the net
    floor area.
  • Proposed building area is 95,375 square feet
    therefore a min of 28,612 square foot open space
    is required. Total 30,434 square foot open space
    proposed.
  • Courtyard One 20 by 20 ground floor landscaped
    courtyard open to the street is required.
  • A 43 by 30 courtyard is proposed in the
    southeast corner of the property. Staff
    recommends that the courtyard connects/opens to
    the swimming pool podium or be relocated to break
    the building mass along El Molino Avenue.

21
Planning Division Comments
  • Topics related to Design Historic Preservation
  • Demolition
  • Existing buildings are not designated historic
    resources and do not appear to be eligible for
    designation.
  • Design Review Design Commission will review
    because
  • Project exceeds 5,000 square feet and the
    entails10 or more dwelling units, and is within
    the Central District Specific Plan.

22
Planning Division Comments
  • Topics related to Design Historic Preservation
  • Massing Siting care should be taken in
    creating a building form that appropriately
    responds to the existing context, especially the
    historic resource immediately to the south
  • Sitting A multi-family project is generally
    well suited for this location, but greater
    consideration should be given in the massing of
    the structure to appropriately respond to the
    nationally register listed historic resource
    adjacent to the site and other eligible historic
    resources on the periphery

23
Planning Division Comments
  • Topics related to Design Historic Preservation
  • Compatibility No specific building designs have
    been presented for review at this time and staff
    cannot comment on the new buildings
    architectural compatibility with its surroundings
    or its consistency with the applicable design
    guidelines however, the City of Pasadenas
    objective is to achieve architectural and design
    excellence. Buildings should improve the
    environment for the public, respond to their
    context and be compatible to the surroundings

24
Planning Division Comments
  • Topics related to General Plan
  • Policies and Objectives that apply include
  • OBJECTIVE 1 - TARGETED DEVELOPMENT Direct higher
    density development away from Pasadenas
    residential neighborhoods and into targeted
    areas, creating an exciting urban core with
    diverse economic, housing, cultural and
    entertainment opportunities.
  • OBJECTIVE 3 AFFORDABLE HOUSING Encourage the
    retention and creation of affordable housing
    throughout Pasadena by providing sufficient land
    and densities to develop new affordable housing.

25
Planning Division Comments
  • Topics related to General Plan
  • Policies and Objectives that apply include
  • Policy 27.4 Consultation Encourage project
    applicants to contact the surrounding
    neighborhood prior to submitting a formal
    application for the project.
  • Central District Specific Plan
  • The purpose of the Specific Plan is to include a
    diverse mix of land uses designed to create the
    primary business, financial, retailing and
    government center of the City.
  • Walnut Housing Subdistrict
  • This subdistrict is intended to promote the
    development of a high-density residential area
    north of Colorado Blvd and in close proximity to
    the Lake Avenue Light Rail Station.

26
Public Works Comments
  • Topics related to Public Works
  • Corner Rounding Land Dedication
  • In order to accommodate an Americans with
    Disabilities Act (ADA) compliant curb ramps, the
    applicant shall dedicate to the City the land
    necessary to provide a 30-foot radius property
    line corner rounding at the southwest corner of
    Corson Street and El Molino Avenue.
  • Street Trees
  • In order to protect the canopy of the existing
    street trees, the building setback shall be 8 to
    10 feet along Corson Street frontage and 10 to 12
    feet along El Molino Avenue frontage.

27
Transportation Comments
  • Topics related to Transportation
  • Traffic Impact Study Required per City
    guidelines.
  • New Driveways The driveway and apron shall have
    a minimum width of 18-feet to accommodate 2-way
    traffic.
  • Access It is recommended that a second access
    location off Corson Street be constructed to
    provide more vehicular circulation alternatives
    into and out of the parking garage.

28
Environmental Review
  • Per California Environmental Quality Act (CEQA),
    an environmental review of the project will
    occur.
  • Analyze projects potential to result in
    significant impacts, as identified by State and
    local environmental guidelines.
  • Per the Citys Zoning Code, a project proposed on
    this property must contain an housing component.
  • The site is located adjacent to the south of the
    210 Freeway, approximately 80-feet to the
    off-ramp, at its closest point, and 130-feet to
    the freeway.
  • In cases where sensitive receptors (generally
    defined as 24-hr occupied habitable buildings,
    such as residences) are proposed within 500 feet
    of the freeway, the City undertakes a Health Risk
    Assessment as part of the CEQA process.

29
Next Steps
  • Preliminary Consultation Design Commission.
  • To provide preliminary design comments on the
    project.
  • Affordable Housing Concession Permit Hearing
    Officer.
  • Environmental Review.
  • Includes Traffic Study.
  • Design Review and Height Averaging Design
    Commission.
  • Concept and Final.

30
277 North El Molino Avenue Predevelopment Plan
Review
  • City Council MeetingMay 5, 2014
