Java on Wireless Devices

1
Java on Wireless Devices

• J2ME

2
Contents

• Introduction to J2ME
• Constituents of J2ME Configurations and
  Profiles
• More into MIDP Applications - MIDlets
• Designing User Interfaces using MIDP
• Networking using MIDP
• J2ME Database

3
J2ME

• An Introduction

4
What is J2ME ?

• J2ME stands for Java 2, Micro Edition
• It just means Java for small devices which have
  many usability constraints such as
• Memory
• Display area
• Battery Life
• Network Connectivity
• J2ME is not
• A fixed, specific set of software
• A fixed, specific set of API
• J2ME is divided into Configurations and Profiles,
  which provide specific information and features
  for a group of related devices

5
Why J2ME ? Javas perspective

• Java API for low bandwidth devices
• Advanced Java API for Rapid Application
  Development on low end clients
• Inherits Javas USP Platform Independence,
  Object-oriented approach, In-built security, Easy
  to Use
• Large Developer community

6
Why J2ME ? Applications perspective

• Dynamically downloadable/upgradeable/removable
  Applications
• Dynamic content Applications
• Off-line execution on Device J2MEs edge over
  WAP
• APIs for Data Security applicable to banking and
  m-commerce applications
• Richer GUI related to the devices constraints
• APIs for Network Connectivity
• Stand alone applications (Usually) Do not need
  any browser to run

7
Position of J2ME in Java arena
8
Relative Features of various VMs
JVM Java Spec Target Devices Processor Memory
HotSpot VM J2EE Enterprise Servers Up to 64 bit Upwards of 2 MB
HotSpot VM J2SE Workstations, Desktop Clients, Laptops 32-64 bit Upwards of 2MB
CVM J2ME High end, consumer electronic and embedded devices like wireless communicators eg. devices running Symbian's EPOC OS), high-end PDAs (e.g. devices running embedded Linux or Windows CE), residential gateways, automotive telematic systems, set-top boxes and screen phones 32 bit 2MB 10 MB Min 512Kb ROM Min 256 kB RAM Relatively constrained GUI
KVM J2ME Cell Phones, Pagers, PDAs 16 bit 160-512 kB Highly constrained GUI
Card VM Java Card API Smart Cards 8 bit lt32 kB
9
Constituents of J2ME

• Configurations and Profiles

10
Configurations

• Suns definition A configuration is defined as
  the combination of a Virtual Machine (VM) and
  "core" APIs that represent an underlying
  development platform for a broad class of devices
• Thus,
• A configuration is a specification for a certain
  class of devices having similar capabilities
• Usually based on available memory, display and
  processing power of the target set of devices
• Specifies a JVM, which can be ported to the
  target set of devices
• Specifies a subset of J2SE APIs that will be
  available to the target set of devices

11
Profiles

• Suns definition A profile is defined as a set
  of APIs for a specific vertical market and relies
  upon the underlying configuration's capabilities
  to create new, market-specific APIs.
• Thus, a Profile
• Is Built on Configurations
• Targets more specific set of devices than
  configurations
• Adds APIs for User Interface, Persistent storage,
  available input and output facilities and other
  features that may be needed to run applications
  on that particular segment of devices.

12
J2ME Delivers

• Two Configurations
• CDC Connected Device Configuration
• CLDC Connected, Limited Device Configuration
• Two major Profiles
• MIDP Mobile Information Device Profile
• Foundation Profile
• Others Upcoming PDA Profile, Personal Profile,
  RMI Profile, Java Game Profile, MIDP_NextGen
  Profile

13
Configurations-1 CDC

• CDC is based on CVM
• The CVM is a full-featured, Java 2 Virtual
  Machine designed for devices needing the
  functionality of the Java 2 VM feature set.
• The CDC is a configuration that could become
  interesting for mobile terminals as their
  capabilities increase
• CDC targets networked devices with relatively
  constrained Graphical user Interfaces.
• Basic packages java.lang, java.util, java.net,
  java.io, java.text, java.security

14
Configurations-2 CLDC

• CLDC is based on KVM
• Limitations w.r.t. J2SE
• No support for JNI (Java Native Interface)
• Limited bytecode verifier
• Limited support for internationalization
• No support for object finalization
• No thread groups and daemon threads
• Limited error handling
• Simplified sandbox security model
• No certificates supported
• No refection No Serialization, RMI or JINI
• Features like Floating point support and J2ME Web
  Services support added in latest CLDC v1.1

15
CLDC Packages

• java.io - Provides for system input and output
  through byte and data streams.
• java.lang - Language Classes included from J2SE
• java.util - Utility Classes included from J2SE.

16
Profiles 1 - MIDP

• Target devices have a small display area (min.
  96x54 pixels) and a touch pad
• Adds the following features to CLDC
• Defining and controlling applications
• Displaying text, graphics and responding to user
  events
• Storing data in simple databases
• Network connectivity via a subset of HTTP
• Timer notifications
• kxml and Nanoxml are two XML parsers on the
  device side
• Latest MIDP v2.0 adds support of HTTPS for
  ensuring end-to-end security.
• Other features enhanced in GUI, network
  connectivity (using different types of sockets),
  Audio support, Game Support, OTA Provisioning
  etc.
• More details to be taken later

17
Profiles 1 MIDP (Contd.)

• New features added in MIDP 2.0
• Enhanced UI Richer and more flexible screen
  widgets
• Media Support You can add audio to your
  applications
• Game Support Game API for enhanced graphics,
  performance and ease of development
• Expanded Connectivity Added support for
  different types of sockets
• Push Architecture Servers can now invoke
  MIDlets for alerts and broadcast
• OTA Provisioning Mandates a single, standard
  approach for OTA MIDlet deployment on the
  devices.
• End to End Security Support of HTTPS and X.509
  PKI certificates.

18
Profiles 2 Foundation Profile

• It provides a profile of the Java 2 Platform,
  suitable for devices that need support for a
  rich, network enabled Java environment, but do
  not require a graphical user interface.
• It is used by other profiles, targeted for
  devices of similar profile, but having their own
  GUI packages.

19
Other Upcoming Profiles

• PDA Profile Is based on CLDC, meant for PDAs
• adds a display toolkit, which is a subset of AWT

• Simple persistent data storage for applications,
  data, and configuration information.
• Personal Profile Is based on CDC, meant for
  devices providing high Internet connectivity and
  web fidelity
• RMI Profile Provides RMI features for invoking
  remote services e.g. Printer, distributed objects
  from the device
• Java Games Profile Provides core audio-video
  features for development of Games, animations,
  videos etc.

20
MIDP Applications

• An Insight

21
MIDP Applications in a Device

• Layout of applications on a typical device is as
  shown below

22
MIDP Applications - MIDlets

• Applications in MIDP are called MIDlets
• These applications/MIDlets can be downloaded,
  updated for newer versions or removed from the
  device
• These MIDlet applications can be used in offline
  mode as well, e.g. Games, Text Editors etc. The
  user need to connect to the server only if he/she
  wants to upload some data.
• Properties of MIDlets are described in a
  application descriptor file a regular text file
  with an extension of .jad
• MIDlet suites are packaged as jar files, which
  contain the class files for that application as
  well as other resource files required at runtime
• A jar Manifest file contains other information
  like name, version, vendor, icon, MIDlet class
  name etc.

23
OTA Downloading of a MIDlet
24
Steps of OTA downloading

1. Applications are found on the network by either
   the user browsing the web or by a discovery
   application checking dedicated servers.
2. The descriptor URL is passed to the Application
   Management Software (AMS), usually developed by
   device manufacturer.
3. The AMS retrieves the application descriptor from
   the server.
4. In the application descriptor file, the AMS finds
   the URL to the MIDlets Jar file. The AMS
   downloads the Jar file.
5. The AMS stores the Jar file on the device.
6. The user selects the application to run and
   launches thus the KVM
7. and finally the application starts running.

25
MIDlets Life Cycle

• The application must extend the class
  javax.microedition.midlet to allow the
  application management software to control the
  MIDlet and to be able to retrieve properties from
  the application descriptor, notify and request
  state changes.

26
MIDP Packages

• Packages available for development of MIDP
  applications

27
MIDP Packages

• javax.microedition.lcdui - The UI API provides a
  set of features for implementation of user
  interfaces for MIDP applications
• javax.microedition.rms - The MIDP provides a
  mechanism for MIDlets to persistently store data
  and later retrieve it. E.g. RecordStore
• javax.microedition.midlet - The MIDlet package
  defines MIDP applications and the interactions
  between the application and the environment in
  which the application runs
• javax.microedition.io - This includes networking
  support classes based on the GenericConnection
  framework from the CLDC e.g. HTTPConnection,
  DatagramConnection etc.

28
MIDP Applications

• Designing User Interfaces

29
MIDP User Interface
30
MIDP User Interface (Contd.)

• Display is the primary class for any GUI There
  is only one instance of Display per MIDlet.
• Display instantiated as Display.getDisplay(MIDle
  t m)
• A Display displays the various Displayable
  objects, and also controls the sequence of the
  various Displayable objects. (setCurrent() API)
• Other classes Command, Image, Font, Graphics,
  Ticker etc.
• The Item class is the abstract parent of many
  items.

31
A Sample MIDlet

• import javax.microedition.midlet.
• import javax.microedition.lcdui.
• import javax.microedition.io.
• import java.io.
• import org.kxml.
• import org.kxml.parser.
• / Main MIDlet class /
• public class MyMIDlet extends MIDlet implements
  CommandListener
• private Command exitCommand // The exit command
• private Command goCommand
• private Display display // The display for this
  MIDlet
• private final static String SERVLET_URL 18.
  "http//127.0.0.18080/ServletXML/ServletXML"
• private List list
• private static String textBoxString ""
• public MyMIDlet()
• display Display.getDisplay( this )
• exitCommand new Command( "Exit",
  Command.EXIT, 2 )

• / Start up the MIDlet by associating list.with
  options, adding the commands and listener. /
• public void startApp()
• list.append(First command, null)
• list.append(Second command, null)
• list.addCommand( exitCommand )
• list.addCommand( goCommand )
• list.setCommandListener( this )
• display.setCurrent( list )
• / Pause is a no-op since there are no
  background activities or 43. record stores that
  need to be closed. /
• public void pauseApp()
• / Destroy must cleanup everything not handled
  by the garbage collector. /
• public void destroyApp(boolean unconditional)

• / Respond to commands/
• public void commandAction(Command c, Displayable
  d)
• if ( c exitCommand )
• destroyApp( false )
• notifyDestroyed()

32
Other GUI Components

• TextBox, TextField For Text Inputs
• Ticker To display a Scrolling message
• Alert A dialog message for Alarms, info,
  confirmation, error and warnings. Can be user or
  timer driven.
• List Displays a list of options to choose from
• Gauge Progress bar
• Image Any image to be associated with widgets.
  It is a .png file
• DateField For representing date fields
• Form A customizable screen which may contain
  many different components (like an HTML page).

33
Command Class

• A Command is equivalent to a Button
• It can be classified into OK, Back, Cancel,
  Exit, Screen etc.
• To show commands, add them to a Displayable
• Register with a Displayable to receive
  notifications, and pass a listener
• To listen for command events, implement the
  CommandListener interface
• This has only one method, commandAction()

34
Form

• A customizable screen which may contain many
  different components/items
• Use append() and insert() for adding items
• Use set() for modifying an item
• Use delete() to remove an item
• You can register an ItemStateListener with a Form
• Use the setItemStateListener() method
• The listener has a single callback
• public void itemStateChanged(Item item)

35
MIDP Applications

• Networking with External Entities

36
Network Connections in MIDP

• CLDC specifies a generic connection mechanism,
  which can be customized by implementations.
• MIDP defines Connection and its subinterfaces for
  more specific types of connections
• Connector is a factory class which takes in a URL
  string and opens a Connection, which can be
  typecast to any of the sub-defined connection
  interfaces.

37
HTTP Connections in MIDP

• POST
• Connection con (HttpConnection)Connector.open(ur
  l)
• // Set the request method and headers
• con.setRequestMethod(HttpConnection.POST)
• con.setRequestProperty("If-Modified-Since", "29
  Oct 1999 194331 GMT")
• con.setRequestProperty("User-Agent",
  "Profile/MIDP-1.0 Configuration/CLDC-1.0")
• con.setRequestProperty("Content-Language",
  "en-US")
• // Getting the output stream may flush the
  headers
• OutputStream os con.openOutputStream()
• os.write("LIST games\n".getBytes())
• os.flush()
• // Opening the InputStream will open the
  connection
• InputStream is con.openInputStream()
• // Get the length and process the data
• int len (int)con.getLength()
• if (len gt 0)
• byte data new bytelen
• int actual is.read(data)
• process(data)

• GET
• Connection con (HttpConnection)Connector.open(ur
  l)
• InputStream is con.openInputStream()
• // Get the length and process the data
• int len (int)con.getLength()
• if (len gt 0)
• byte data new bytelen
• int actual is.read(data)
• else
• int ch
• while ((ch is.read()) ! -1)
• doSomething(ch)
• is.close()
• con.close()

38
MIDP Applications

• Storing Persistent Data

39
J2ME Databases

• Persistent storage in MIDP is based on record
  stores
• A record store is a collection of records.
• Each record is an array of bytes with a unique
  identification number
• Actual storage of records depends on MIDP
  implementation. It could be hard disk on the
  device, a battery-backed RAM etc.
• The package javax.microedition.rms provides API
  for handling device datastores.
• The class RecordStore consists of APIs such as
  openRecordStore(), closeRecordStore(),
  deleteRecordStore(), listRecordStore() for
  RecordStore manipulation.
• It also consists of APIs such as addRecord(),
  deleteRecord(), get and setRecord() for record
  manipulation.

40
J2ME Databases (Contd.)

• A RecordStore allows eventlistener to be
  registered with itself.
• This eventlistener is a class which implements a
  RecordListener interface to get notifications for
  addition, deletion and updating of records in
  that RecordStore.
• J2ME also provides interfaces such as
  RecordComparator, RecordEnumerator and
  RecordFilter for comparing, enumerating and
  filtering of records from a RecordStore,
  respectively.

41
Mobile Databases

• File based storage
• PDB(Palm Database)
• Databases
• Sybase SQL Anywhere Studio 8.0
• Oracle 9i Lite Relational database
• UltraLite from AppForge and iAnyWhere
• Pocket Access 2002
• SQL Server CE

42
J2ME Toolkit

• J2ME provides a toolkit for compiling and
  verifying the source files. It then creates the
  jar file for the compiled classes and also makes
  the .jad file.
• This toolkit provides 4 different device
  emulators to test the application.
• It provides a Panel where the debug statements of
  the application get printed.
• It provides a UI to specify the Application
  Properties, such as Servlet path etc. which are
  used by the application at runtime.

43
Vistos J2ME Sync Client

• A client meant for synchronizing Calendar,
  Contacts and Email. (Currently, having default
  implementation for Calendar/Contacts)
• Consists of its own GUI for Email (Calendar and
  Contacts in future)
• Creates and Opens up its own RecordStore for
  storing of Emails, Calendar, and Contacts.
• Provisions the device for Email synchronization.
• Synchronizes the data present in its record
  stores with the ones at the Corporate Server
  through the Sync Server, after comparisions.
• Maintains the state machine of the sync at the
  client.
• Sends the Sync data in WBXML format.
• Also contains code for performing encoding and
  Blowfish encryption algorithms on the data.

44
Optional Profile Packages
45
Other competing technologies

• BREW (Binary Runtime Environment for Wireless)
  designed by QualComm, based on C, C - It
  provides the devices functionalities available
  to the application such as Memory Mgmt,
  Notifications, Networking, Display, UI etc.
• MExE (Mobile Execution Environment) created
  by ETSI, maintained by 3GPP) - provides a
  standardized environment for appln execution on
  Mobile Devices.It provides interoperability
  between devices by defining Classmarks which
  cater to different groups of devices, e.g. WAP
  Environment, PersonalJava Environment, J2ME CLDC
  Environment and an upcoming Microsoft .NET
  Environment.
• Personal Java and Embedded Java These are
  subsets of J2ME, and target the devices which
  have smaller footprint than the J2ME devices

46
Lets Think Small !!

• Thanks for Your Patience
