Consistent Cuts

1
Consistent Cuts

• Ken Birman

2
Idea

• We would like to take a snapshot of the state of
  a distributed computation
• Well do this by asking participants to jot down
  their states
• Under what conditions can the resulting puzzle
  pieces be assembled into a consistent whole?

3
An instant in real-time

• Imagine that we could photograph the system in
  real-time at some instant
• Process state
• A set of variables and values
• Channel state
• Messages in transit through the network
• In principle, the system is fully defined by the
  set of such states

4
Problems?

• Real systems dont have real-time snapshot
  facilities
• In fact, real systems may not have channels in
  this sense, either
• How can we approximate the real-time concept of a
  cut using purely logical time?

5
Deadlock detection

• Need to detect cycles

A
B
C
D
6
Deadlock is a stable property

• Once a deadlock occurs, it holds in all future
  states of the system
• Easy to prove that if a snapshot is computed
  correctly, a stable condition detected in the
  snapshot will continue to hold
• Insight is that adding events cant undo the
  condition

7
Leads us to define consistent cut and snapshot

• Think of the execution of a process as a history
  of events, Lamport-style
• Events can be local, msg-send, msg-rcv
• A consistent snapshot is a set of history
  prefixes and messages closed under causality
• A consistent cut is the frontier of a consistent
  snapshot the process states

8
Deadlock detection

• Need to detect cycles

A
B
C
D
9
Deadlock detection

• Need to detect cycles

A
B
C
D
10
Deadlock detection

• Need to detect cycles

A
B
C
D
11
Deadlock detection

• A ghost or false cycle!

A
B
C
D
12
A ghost deadlock

• Occurs when we accidently snapshot process states
  so as to include some events while omitting prior
  events
• Cant occur if the cut is computed consistently
  since this violates causal closure requirement

13
A ghost deadlock
A B C D
14
A ghost deadlock
A B C D
15
A ghost deadlock
A B C D
16
Algorithms for computing consistent cuts

• Paper focuses on a flooding algorithm
• Well consider several other methods too
• Logical timestamps
• Flooding algorithm without blocking
• Two-phase commit with blocking
• Each pattern arises commonly in distributed
  systems well look at in coming weeks

17
Cuts using logical clocks

• Suppose that we have Lamports basic logical
  clocks
• But we add a new operation called snap
• Write down your process state
• Create empty channel state structure
• Set your logical clock to some big value
• Think of clock as (epoch-number, counter)?
• Record channel state until rcv message with big
  incoming clock value

18
How does this work?

• Recall that with Lamports clocks, if e is
  causally prior to e then LT(e) lt LT(e)
• Our scheme creates a snapshot for each process at
  instant it reaches logical time t
• Easy to see that these events are concurrent a
  possible instant in real-time
• Depends upon FIFO channels, cant easily tell
  when cut is complete a sort of lazy version of
  the flooding algorithm

19
Flooding algorithm

• To make a cut, observer sends out messages snap
• On receiving snap the first time, A
• Writes down its state, creates empty channel
  state record for all incoming channels
• Sends snap to all neighbor processes Waits for
  snap on all incoming channels
• As piece of the snapshot is its state and the
  channel contents once it receives snap from all
  neighbors
• Note also assumes FIFO channels

20
With 2-phase commit

• In this, the initiator sends to all neighbors
• Please halt
• A halts computation, sends please halt to all
  downstream neighbors
• Waits for halted from all of them
• Replies halted to upstream caller
• Now initiator sends snap
• A forwards snap downstream
• Waits for replies
• Collects them into its own state
• Sends own state to upstream caller and resumes

21
Why does this work?

• Forces the system into an idle state
• In this situation, nothing is changing
• Usually, sender in this scheme records
  unacknowledged outgoing channel state
• Alternative upstream process tells receiver how
  many incoming messages to await, receiver does so
  and includes them in its state.
• So a snapshot can be safely computed and there is
  nothing unaccounted for in the channels

22
Observation

• Suppose we use a two-phase property detection
  algorithm
• In first phase, asks (for example), what is your
  current state
• You reply waiting for a reply from B and give a
  wait counter
• If a second round of the same algorithm detects
  the same condition with the same wait-counter
  values, the condition is stable

23
A ghost deadlock
A B C D
24
Look twice and it goes away

• But we could see new wait edges mimicking the
  old ones
• This is why we need some form of counter to
  distinguish same-old condition from new edges on
  the same channels
• Easily extended to other conditions

25
Consistent cuts

• Offer the illusion that you took a picture of the
  system at an instant in real-time
• A powerful notion widely used in real systems
• Especially valuable after a failure
• Allows us to reconstruct the state so that we can
  repair it, e.g. recreate missing tokens
• But has awkward hidden assumptions

26
Hidden assumptions

• Use of FIFO channels is a problem
• Many systems use some form of datagram
• Many systems have multiple concurrent senders on
  same paths
• These algorithms assume knowledge of system
  membership
• Hard to make them fault-tolerant
• Recall that a slow process can seem faulty

27
High costs

• With flooding algorithm, n2 messages
• With 2-phase commit algorithm, system pauses for
  a long time
• Well see some tricky ways to hide these costs
  either by continuing to run but somehow delaying
  delivery of messages to the application, or by
  treating the cut algorithm as a background task
• Could have concurrent activities that view same
  messages in different ways

28
Fault-tolerance

• Many issues here
• Who should run the algorithm?
• If we decide that a process is faulty, what
  happens if a message from it then turns up?
• What if failures leave a hole in the system
  state missing messages or missing process state
• Problems are overcome in virtual synchrony
  implementations of group communication tools

29
Systems issues

• Suppose that I want to add notions such as
  real-time, logical time, consistent cuts, etc to
  a complex real-world operating system (list goes
  on)
• How should these abstractions be integrated with
  the usual O/S interfaces, like the file system,
  the process subsystem, etc?
• Only virtual synchrony has really tackled these
  kinds of questions, but one could imagine much
  better solutions. A possible research topic, for
  a PhD in software engineering

30
Theory issues

• Lamports ideas are fundamentally rooted in
  static notions of system membership
• Later with his work on Paxos he adds the idea of
  dynamically changing subsets of a static maximum
  set
• Does true dynamicism, of sort used when we look
  at virtual synchrony, have fundamental
  implications?

31
Example of a theory question

• Suppose that I want to add a location type to a
  language like Java
• Object o is at process p at computer x
• Objects a,b,c are replicas of ?
• Now notions of system membership and location are
  very fundamental to the type system
• Need a logic of locations. How should it look?
• Extend to a logic of replication and self-defined
  membership? But FLP lurks in the shadows

32
FLP
33
Other questions

• Checkpoint/rollback
• Processes make checkpoints, probably when
  convenient
• Some systems try to tell a process when to make
  them, using some form of signal or interrupt
• But this tends to result in awkward, large
  checkpoints
• Later if a fault occurs we can restart from the
  most recent checkpoint

34
So, wheres the question?

• The issue arises when systems use message passing
  and want to checkpoint/restart
• Few applications are deterministic
• Clocks, signals, threads scheduling,
  interrupts, multiple I/O channels, order in which
  messages arrived, user input
• When rolling forward from a checkpoint actions
  might not be identical
• Hence anyone who saw my actions may be in a
  state that wont be recreated!

35
Technical question

• Suppose we make checkpoints in an uncoordinated
  manner
• Now process p fails
• Which other processes should roll back?
• And how far might this rollback cascade?

36
Rollback scenario
37
Avoiding cascaded rollback?

• Both making checkpoints, and rolling back, should
  happen along consistent cuts
• In mid 1980s several papers developed this into
  simple 2-phase protocols
• Today would recognize them as algorithms that
  simply run on consistent cuts
• For those who are interested sender-based
  logging is the best algorithm in this area.
  (Alvisis work)
