Interference and beats

1
Interference and beats
2
Echoes and reverberation
An echo is a reflected sound wave. If you clap
your hands 170 meters away from a large wall . .
. the sound will echo back to you one second
later.
3
Echoes and reverberation
Reverberation is the addition of multiple
reflections of a sound to the original sound.
This adds liveliness, depth, and richness to
sound. In an auditorium you hear music directly
from the stage AND a multiple echo called
reverberation.
4
Phase
A full wave has a phase of 360 degrees.
Interference between two or more sound waves
depends on their phase difference.
5
Constructive interference
Two waves are in phase when both begin at the
same point in their cycle. Waves that are in
phase interfere constructively.
6
Destructive interference
Two waves are out of phase if one wave begins
half a cycle ahead or behind the other. Waves
that are out of phase interfere destructively.
7
Beats

• When two frequencies are close but not the same,
  the sound waves drift in and out of phase, making
  beats.
• When the waves are in phase, they add to create a
  louder wave.
• When the waves are out of phase they cancel,
  reducing the sound.
• The result is a beat envelope with its own beat
  frequency.

8
What do beats sound like?
Click on this simulation on page 456 to explore
beats
9
Engaging with the concepts

• Create a set of two sound waves at 440 Hz and
  441 Hz.
• Set time to 5 s.
• Can you hear the beats?
• Can you see the beats?
• What is the beat frequency?

10
Engaging with the concepts

• Change the frequencies to 440 Hz and 442 Hz.
• How does the beat frequency change?
• Does it increase or decrease?

11
Engaging with the concepts
What do you think the formula is for the beat
frequency? Test your hypothesis with a new set
of frequencies. You may need to adjust the time
scale to see the beats. What wave behavior
causes beats?
12
Test your knowledge
What is the beat frequency between a 120 Hz wave
and a 140 Hz wave?
13
Test your knowledge
What is the beat frequency between a 120 Hz wave
and a 140 Hz wave?
20 Hz (20 beats per second).
14
Assessment

• What happens when two sound waves of the same
  frequency interfere with each other if they are
  180 out of phase?

15
Assessment

• What happens when two sound waves of the same
  frequency interfere with each other if they are
  180 out of phase?
• Two waves that are 180 apart in their cycles
  will be out of phase, because they will be one
  half wavelength apart.
• These waves will interfere destructively. If
  the waves have the same amplitude, they will
  cancel each other out completely. This is the
  idea behind noise-cancelling headphones.

16
Assessment

• Noise-canceling headphones use destructive
  interference. Which of the following explains
  destructive interference?

• harmonic motion
• refraction
• Fourier's theorem
• superposition principle

17
Assessment

• Noise-canceling headphones use destructive
  interference. Which of the following explains
  destructive interference?

• harmonic motion
• refraction
• Fourier's theorem
• superposition principle
