magicolor 2480 MF

1
January 2006
2
magicolor 2480 MF
All-in-One Color Laser Productivity Center

• One machine, five essential business functions
• Desktop convenience combined with high-speed
  laser quality
• Based on the award-winningmagicolor 2400 Series
  engine
• Easy to set up and use
• Versatile and cost effective

3
magicolor 2480 MF
Print, Copy, Scan, Camera Direct Photo Printing,
PC Fax
20 ppm bw, 5 ppm color 2400 x 600 dpi 24-bit
color, up to 8.5" x 14" FaxTalk
CommunicatorNuance PaperPort USB 2.0, optional
10/100BaseTX Ethernet Device Server Camera Direct
Photo Printing Windows XP/2000/Me/98SE
Print / Copy Print Scan PC FaxDocument
Mgt. Interfaces PictBridge Compatibility
699
4
magicolor 2400 Series
New

• magicolor 2430 DL
• Network color laser
• Print
• Camera Direct Photo Print
• Small offices
• Home offices
• Workgroups
• 499

• magicolor 2450
• Network color laser
• Print
• PostScript, PCL
• Small offices
• Workgroups
• Small- to medium-sized businesses
• 499

• magicolor 2480 MF
• Color laser AIO
• Print, copy, scan
• Camera Direct Photo Print
• PC Fax
• Small offices
• Home offices
• Workgroups
• Small- to medium-sized businesses
• 699

• magicolor 2400W
• Personal color laser
• Print
• Small offices
• Home offices
• 399

5
magicolor 2480 MF
One Machine, Five Essential Business Functions

• Print
• Copy
• Scan
• Camera Direct Photo Print
• PC Fax

6
magicolor 2480 MF
A Reliable Printer . . .
BW Speed Color Speed BW First Page Out Color
First Page Out Warm-up Time Resolution Paper
Input Media Sizes Interfaces Memory Duty Cycle
20 ppm 5 ppm 12 seconds 21 seconds 45
seconds 2400 x 600 dpi 200 sheets std. / 700
max. Up to 8.5" x 14"Hi-Speed USB 2.0 Optional
10/100BaseTX Ethernet NIC 96 MB 35,000
prints/month
From an idle, ready state
7
magicolor 2480 MF
A Versatile Copier . . .
BW Copies Color Copies BW First Page Out Color
First Page Out Resolution Settings Document
Handling 50-page ADF
20 cpm 5 ppm 25 seconds52 seconds 2400 x 600
dpi 1200 x 600 dpi Light/Dark, Reduce/Enlarge,
Copy Count, Quality Collate, Duplex 2-in-1 For
unattended copying
From an idle, ready state
8
magicolor 2480 MF
Customizable Copy Settings

• Light/Dark
• Adjust the brightness of the copy
• Quality
• Specify the content of the document to be copied
  (text, photo, mixed)
• Reduce/Enlarge
• Set the size of the copy (50200 in 1
  increments)

• Duplex
• Make 2-sided copies
• 2in1
• Copy 2 originals onto 1 page
• Collate
• Copy multiple originals into sorted sets

9
magicolor 2480 MF
A Quality Scanner . . .
6 seconds/page 12 seconds/page Color or
bw Flatbed or ADF 24 bits 600 x 600 dpi Up to
8.5" x 14" Local or network PC For multi-page
documents TWAIN WIA Nuance PaperPort
BW Speed Color Speed Type Location Color
Depth Resolution Size Destination 50-page
ADF Compatibility Document Mgt.
From an idle, ready state
10
magicolor 2480 MF
Nuance PaperPort SE Document Management Imaging
Software

• Scan documents and photographs to PDF, JPEG,
  TIFF, and other formats
• Touch up and annotate scanned documents and
  images
• Organize scanned documents, digital photographs,
  and other image files visually
• Convert scanned documents to editable text via
  Optical Character Recognition (OCR)

11
magicolor 2480 MF
A Camera Direct Photo Printer . . .

• PictBridge 1.0 compatibility
• Up to 8.5" x 11"
• No PC or special software required
• Supported functions
• 1-up, 2-up, 3-up, 4-up, 6-up, or 8-up photos
• 4" x 6" borderless prints with special media
  (obtained through your KONICA MINOLTA dealer)
• Batch print
• Fit-to-page
• Index prints
• Multiple copies
• Plain paper or photo media
• Varied or duplicate images on the same page
• Other options may be supported, depending on
  the camera model

12
magicolor 2480 MF
Camera Direct Photo PrintingThree Simple Steps
3. Click Print in the cameras user
interface.
1. Connect the digital camera to the
printers USB 1.1 Host Port.
2. Select the photo(s) you want to print.
13
magicolor 2480 MF
PC FaxFaxTalk Communicator . . .

• Send and receive digital faxes
• Drag and drop fax documents from PaperPort
• Automatically print received faxes
• View and annotate faxes
• View fax logs
• Use the PC as aspeakerphone and answering
  machine

14
magicolor 2480 MF
A Perfect Fit for SOHO SMB

• Organizations seeking a one-productsolution for
  their essential business functions
• Satellite and home offices with limited space
  that need the functionality of several office
  machines
• Small departments within corporate environments
  that require private document management
• Businesses moving up from other technologies
  single-function devices, monochrome laser AIOs,
  and color inkjet AIOs

Recipes Crafts
What theyre producing . . .
Daily correspondence CD-ROM mailing
labels Envelopes Email web pages Business
papers Maps Newsletters Spreadsheets /
charts Photographs Posters Reports Invoice
s
15
magicolor 2480 MF
Product Overview
Optional Duplexer (for Two-Sided Printing
Copying)
50-Sheet Auto Document Feeder (for Copying
Scanning)
Flatbed Copier/Scanner
Easy-to-Use Control Panel
200-Sheet Output Tray
USB 2.0 Optional 10/100BaseTX Ethernet
Connectivity
Laser Printer
Easy-Access Consumables
PC Fax Software
Adjustable 200-Sheet Multipurpose Tray
USB 1.1 Host Port for Camera Direct Photo Printing
16
magicolor 2480 MF
ADF Input Tray50 sheets unattended copying
scanning
Scan copyUp to 8.5" x 14" via flatbed or Auto
Document Feeder (ADF)
Output tray100 sheets
ADF Output Tray
Small footprintFull front access
Thin-Layer Roller Fusing System Short Warmup
Toner Carousel
Wide-angle laser unit Small size
OPC Drum
DuplexerOptional
Input tray200 sheets
Waste Toner Storage Integrated part of the OPC
belt
Lower feeder500 sheets optional
17
magicolor 2480 MF
Fits in Any Office Environment

• Weight (without consumables) 63.1 lbs
• Weight (with consumables) 70.4 lbs
• Dimensions (W x D x H) 20.9" x 18.7" x 20.9"

18.7"
20.9"
20.9"
20.9"
18
magicolor 2480 MF
Fast and Easy to Set Up

• Installs in minutes
• From box to desktop
• Pre-installed supplies
• Ensure quick setup
• Auto-install software
• Guides users through driver installation

19
magicolor 2480 MF
Fast and Easy to Set Up
magicolor 2480 MF vs. HP 2840Time required to
set up the machine and print a configuration page
magicolor 2480 MF
4 min 43 sec
HP 2840
31 min1 sec
20
magicolor 2480 MF vs. HP 2840 Speed Benchmark
QualityLogic test suite 16 files, 257 pages
Excel, PowerPoint, Word, Acrobat, Illustrator,
CorelDRAW, Photoshop, QuarkXPress
magicolor 2480 MF
1 hr. 8 min. 53 sec.
HP 2840
29 min. 43 sec.
magicolor2480 MF
2500
3000
3500
4000
4500
5000
5500
6000
6500
2000
7000
Testing was performed using QualityLogic
PageSense, the industry-standard printer
performance testing tool for measuring and
reporting throughput performance of printers and
MFPs.
21
magicolor 2480 MF
Easy to UseIntuitive Control Panel

• Easy-to-view LCD message window
• One-touch control for common functions
• Easy-to-navigate menu system
• Gas gauges to report toner levels

22
magicolor 2480 MF
Easy to UseIntuitive Control Panel
Error Information
Toner Levels
Toner Replacement
Copy Settings
Device Configuration
StopReset
Alphanumeric Keypad
Cancel
Start
One-touch control panel provides easy access to
copy and configuration functions
23
magicolor 2480 MF
Easy to UseSupplies

• Only 5
• Same as other magicolor 2400 Series printers

• OPC Drum (with integrated waste toner) Up to
  45,000 pages

• Toner Cartridges (Y, M, C, K) Standard
  capacity (C, M, Y) 1,500 prints _at_ 5
  coverage High capacity (C, M, Y, K) 4,5000
  prints _at_ 5 coverage

24
magicolor 2480 MF
Easy to UseSupplies
Front access for easy replacement
Color-coded toner cartridges for fool-proof
replacement
Accurate gas gauge reporting through control
panel status list
Step-by-step replacement instructions inside
25
magicolor 2480 MF
Easy to UseSuperb Tech Support

• FastAverage response time less than 1 minute
• Toll-free, US-based, free for 5 years
• Online Answer Base available 24/7

26
magicolor 2480 MF
Amazing Color

• 2400 dpi printing copying
• Brilliant, true-to-life color documents
  photos
• All resolutions print at full engine speed
• Up to 20 ppm bw, 5 ppm color

27
magicolor 2480 MF
Amazing ColorSimitri Polymerized Toner

• Laser-sharp, true-to-life color for documents and
  photos
• Smaller particles, uniform in size shape
• Fine, detailed lines accurate halftones
  regardless of the type of media used
• High transfer efficiency
• Low power consumption, less waste toner, and less
  media dependence
• High-quality output on all supported media
• No smudging, smearing, or drying time

28
magicolor 2480 MF
Amazing ColorColor Controls and Tools

• Enhanced Automatic Image Density Control (eAIDC)
  built-in calibration
• Consistent quality without hands-on adjustments
• Automatic ICC-based color matching
• Generates the best possible color based on page
  contents
• ICC device profiles
• Support for Windows ICM and other ICC color
  management systems

29
magicolor 2480 MF
VersatileFlexible Media Handling

• Variety of media types
• Plain paper, thick stock, glossy stock, photo
  media, transparencies, labels, envelopeseven
  copier paper!
• Wide range of paper weights
• 1624 lb. Bond (60 - 90 g/m2)
• Up to 90 lb. Index (163 g/m2)
• 230 g/m2 photo media
• Custom sizes
• 3.62" x 5.83" to 8.5" x 14 " via the
  multipurpose tray
• Printable area
• 0.16" (4 mm) from all edges

30
magicolor 2480 MF
VersatileOptional Features to Increase
Productivity

• Duplex Option
• For automatic two-sided printing and copying

• 10/100BaseTX Ethernet NIC
• silex technology SX-1000U Device Server
  supporting printing/scanning via TCP/IP for
  Windows XP/2000

• 500-Sheet Lower Feeder
• Increases input to 700 sheets

31
magicolor 2480 MF
Cost EffectiveJust Pennies per Print

• Color and bw
• No special media required

11.3

• Imagine!
• Full-color pages for only 11.32 each
• Black white pages for only 2.3 each

2.3
Cost-per-page based on 5 page bw coverage and
20 color coverage.
32
magicolor 2480 MF
Cost EffectiveCompetitive Comparison
magicolor 2480 MF Epson AcuLaser CX11N Epson AcuLaser CX11NF
SpeedColor 5 ppm 5 ppm 5 ppm
SpeedBW 20 ppm 25 ppm 25 ppm
Resolution 2400 dpi 2400 dpi 2400 dpi
Interface USB 2.0, Ethernet USB 2.0, Ethernet USB 2.0, Ethernet
Auto Document Feeder Standard No Standard
Duty Cycle 35,000 pages / month 45,000 pages/month 45,000 pages/month
Toner Yield Up to 4,500 prints Up to 4,000 prints Up to 4,000 prints
Paper Input 200 std., 700 max 180 std., 680 max. 180 std., 680 max.
Automatic Duplex Optional No No
Camera Direct Photo Print Standard No No
Cost 699 699 799
Winner!
Winner!
Winner!
Winner!
33
magicolor 2480 MF
Cost EffectiveCompetitive Comparison
magicolor 2480 MF Canon ImageClass MF 8170c HP CLJ 2820 HP CLJ 2840
SpeedColor 5 ppm 4 ppm 4 ppm 4 ppm
SpeedBW 20 ppm 16 ppm 20 ppm 20 ppm
Resolution 2400 dpi 2400 dpi REt 2400 dpi REt 2400 dpi
Interface USB 2.0, optional Ethernet USB 2.0, Ethernet USB 2.0, Ethernet USB 2.0, Ethernet
Auto Document Feeder Standard Standard Standard Standard
Toner Yield Up to 4,500 prints Up to 5,000 prints K, 4,000 prints CMY Up to 5,000 prints K, 4,000 prints CMY Up to 5,000 prints K, 4,000 prints CMY
Duty Cycle 35,000 pgs / month N/A 30,000 pgs/month 30,000 pgs/month
Paper Input 200 std., 700 max 375 std., 375 max. 175 std., 425 max. 425 std., 425 max.
Auto Duplex Prints Copies Optional No No No
Photo Print PictBridge Camera Direct No No Media card slots
Cost 699 899 799 899
Winner!
Winner!
Winner!
Winner!
Winner!
34
magicolor 2480 MF
The Color Laser All-in-One with the Competitive
Advantage

• Five essential business functions in one
  unitPrint, copy, scan, camera direct photo
  print, and PC Fax
• Snappy print/copy speed to keep up with your busy
  office demands20 bw or 5 color pages per minute
• Affordable price for all five featuresOnly 699
• Laser-sharp 2400 dpi print quality for striking
  color documents
• Compact size and stylish designAppropriate for
  any office environment
• Quick and easy setupUp and running in minutes
• PictBridge support for camera direct photo
  printing
• Superb 24/7 technical supportNo waiting to have
  your questions answered
• Flexible media handling and optional automatic
  duplexing to address all of your document needs

35
Thank You!
