High energy Astrophysics

1
High energy Astrophysics
Mat Page
Mullard Space Science Lab, UCL
11. Gamma-ray bursts
2
11. Gamma-ray bursts
Slide 2

• This lecture
• Discovery of g-ray bursts
• Burst properties
• Models for g-ray bursts
• Detection and follow up in other wavebands

3
So what is a g-ray burst?
Slide 3

• Brief, intense burst of extraterrestrial g-rays
• Duration between 0.001 and 1000 seconds
• For this period they might be the brightest
  g-ray source in the sky
• Appears to be a once-only phenomena

4
Discovery of gamma-ray bursts
Slide 4

• Discovered in the 1960s by military satellites.
• First announced in public in 1973.

5
The big mystery
Slide 5

• Since their discovery, g-ray bursts were about
  the most mysterious objects ever discovered.
• Why?
• Only appear in g-rays
• Only last a tiny length of time
• Very difficult to investigate
• For the first 25 years, we didnt even know if
  they were from within or from outside our Galaxy!

6
Speculation
Slide 6

• There have been more different models for g-ray
  bursts than there are people in this room.
• Giant supernovae
• Jets or cannon-balls from supernovae
• Exhaust from alien spaceships
• Massive outbursts from AGN
• Jets from pulsars
• Neutron stars collapsing
• Merging of neutron stars
• Evaporating black holes

7
Big advances in the 1990s
Slide 7

• We learned a lot in the 1990s, primarily because
  of novel space observatories
• Compton Gamma-ray observatory
• All-sky burst survey with BATSE
• BeppoSAX
• Good positions and X-ray follow-up
• Here are some of the things that have been
  learned

8
Isotropically distributed
Slide 8
9
Very likely to be extragalactic
Slide 9
How would Galactic and extragalactic sources be
distributed?
10
Luminosities
Slide 10

• g-ray bursts must be very luminous if they are
  extragalactic.
• Instantaneously the most luminous sources of
  radiation in the sky.
• The total energy radiated in g-rays during the
  burst is between 1044-1047 J assuming the bursts
  are isotropic.
• The energy is emitted within a very short time
• energy densities not seen since the big bang
• If the radiation is beamed, energy emitted per
  burst is reduced to 1044 J
• but the number of bursts increases accordingly!

11
Burst light curves
Slide 11
Short GRBs
Long GRBs
12
Burst lightcurves
Slide 12

• The lightcurves or profiles of bursts show a
  variety of shapes, ranging from a smooth pulse to
  complicated flickering.
• With such a range of duration and pulse profiles,
  there must be a variety of things happening in
  g-ray bursts.
• Likely that long and short bursts are
  fundamentally different.
• Dividing line between long and short bursts at
  about 2s.

13
X-ray afterglows
Slide 14
14
Slide 15
Big data gap!!
Gamma-ray burst
X-ray Afterglow
15
Slide 16

• X-ray afterglows decline over a much longer
  timescale than the g-ray bursts themselves
  still visible a week after the burst.

16
Slide 17
Optical afterglows
17
Slide 18
18
Optical transients
Slide 19

• Bright optical transient seen in GRB990123
• 9th magnitude optical flash was observed while
  the g-ray burst was going off.
• Current record holder GRB080319b
• V magnitude 5.5 during the burst
• You could have seen it with the naked eye!
• Both the record breakers were at z1
• Of course optical emission means that we can
  harness our biggest optical telescopes to get
  spectra and redshifts for the bursts.

19
Slide 20
20
Models for g-ray bursts
Slide 21

• Whatever the progenitor, the leading model to
  describe what actually happens during the burst
  is called the relativistic fireball
• A shell of material is expanding at highly
  relativistic speeds.
• Almost inevitable the photon pressure alone
  would force a rapid expansion
• Obvious similarities with the relativistic jets
  observed in radio galaxies and quasars
• Material moving towards us dominates the observed
  emission so time dilation effects important.
• Likely to be beamed.

21
Pair dominated plasma
Slide 22

• Inverse Compton emission probably initial
  fundamental. However, balance of e e- pairs an
  important consideration because the g-ray energy
  density is extremely high
• e e- lt-gt g g
• Would expect the burst to be optically thick
  above 0.5 MeV
• The initial g-ray burst must be caused by
  internal shocks collisions between successive
  waves of ejecta reduces their relative velocities
  to smaller fractions of c and reduces the pair
  opacity.
• Complex lightcurves fit with repeated waves of
  ejecta

22
The X-ray and optical afterglow
Slide 23

• The X-ray afterglow comes from external shocks,
  as the ejecta ploughs into the surrounding
  interstellar medium.
• As the ejecta sweeps up material, it has to slow
  down, just like in a supernova remnant.
• Appreciable slowing happens much faster in a
  g-ray burst because the velocity is so close to
  c.
• Remember its 1/(1-v2/c2)1/2 thats important

23
Slide 24
24
The progenitor
Slide 25

• Why does a g-ray burst take place?
• The bursts weve identified so far do NOT take
  place in the centres of their host galaxies, so
  they arent AGN.
• Long bursts appear to be associated with star
  forming regions in star-forming galaxies, which
  are typically irregular dwarf galaxies similar to
  the Magellanic Clouds.
• This suggests that their progenitors are massive
  stars the hypernova scenario. Could be core
  collapse in an extremely massive, low-metallicity
  star, or a massive star that is merging with a
  companion.
• Theoretically, this is a good mechanism to
  produce long bursts

25
First direct Long GRB SN connection GRB980425 /
SN1998bw
SRON
VLT
Galama et al. 1998
26
What about the short bursts?
Slide 26

• Afterglows from Short bursts had not been
  detected until launch of Swift.
• For the short bursts, neutron star -neutron star
  mergers are the current leading model.
• When the neutron stars get close, their orbits
  decay rapidly due to gravitational radiation.
  Simulations suggest that as they collide about
  half a solar mass ends up as a toroidal structure
  which then collapses onto the merged star.

27
Slide 27

• Whatever the progenitor, the result is almost
  certainly a black hole.

28
Bursts as cosmological probes
Slide 28

• We know how that some g-ray bursts originate in
  distant galaxies, and have phenomenal
  luminosities.
• With current technology we could detect these
  bursts at redshifts of 10-15
• If g-ray bursts happened at these early epochs,
  we could use them to probe parts of the universe
  we have never seen before.

29
Slide 29

• They might tell us about star formation before
  the first galaxies had even formed!
• Their radiation has to pass through the early
  intergalactic medium the passage will leave its
  mark on the radiation.
• For example by absorption line spectroscopy we
  could work out the composition, ionization state
  of the primordial gas, presence of dust etc.

30
The NASA Swift Satelite has made GRBs the fastest
moving area in astrophysics!
Slide 30
31
Spacecraft and instrumentation
UV and Optical Telescope
X-ray Telescope
Slide 31
32
Slide 32
The Burst Alert Telescope (BAT)

• Coded mask telescope detector measures shadow
  of
• random mask, which allows direction of
  incidence to be
• reconstructed.
• 1.4 Steradian
• field of view
• Measures GRB
• positions correct to
• 4 arcminutes
• Built by GSFC

NASA
33
Slide 33
XRT hardware
Cooled X-ray CCD Detector 360,000 individual
pixel sensors (Leicester/E2V)
X-ray Mirror 12 Gold-coated Nickel Shells
(Brera)
Focal Plane Camera Assembly (Leicester)
34
Slide 34
The UV/Optical Telescope (UVOT)
30 cm Ritchie-Chretien UV/Optical telescope.
0.3 arcsecond positional accuracy optical and
UV filter photometry and grism spectroscopy.
Built at MSSL
35
Slide 35
UVOT hardware
Filter Wheel and Detector Assembly
UVOT Telescope Optics Primary and Secondary
Mirrors.
36
Slide 36
UVOT finds the afterglow GRB 050525a
z 0.606
37
Slide 37
XRT light curves
Nousek et al. 2006
38
Slide 38
Long GRBs the canonical X-ray lightcurve
revealed by the Swift XRT
flares
slow decline
final steeper decline
flux
initial steep decline
time
39
Little galaxies and GRBs
Slide 39
First UV spectrum of a gamma ray burst,
GRB081203a, taken with the Swift UVOT grism built
at MSSL.
40
Slide 40
High-redshift GRBs
XRT lightcurve
Latest record breakers GRB 090423 at z8.2, and
090429b at z9.4 were the most distant objects
ever detected at the time.
GRB 050904 at z 6.29
41
Slide 41
Short bursts GRB 050509b

• 0.05 s burst of gamma-rays
• 5 min detection of X-rays
• No UVOT counterpart but potential host galaxy
  observed

42
Slide 42
Short bursts GRB 050509b

• Probable host galaxy is populated by old red
  stars

An unlikely site for a hypernova explosion, as
these happen to young, massive stars. No
Supernova detected down to deep limits In this
case, the short burst is more likely to have been
caused by a collision between two neutron stars.
NASA
43
Some key points
Slide 43

• g-ray bursts are brief, intense bursts of g-rays
• They are the most luminous explosions we know
  about apart from the big bang.
• The g-rays are thought to be produced as waves of
  ejecta collide with each other
• X-ray and optical afterglows come as the ejecta
  collide with the surrounding medium
• Short bursts thought to be merging neutron stars
• Long bursts thought to be hypernovae
• Could be valuable probes of early universe

44
GRB Picture
Gehrels et al. 2002, Scientific American
