Sudoku Project: SDS

1
Sudoku Project SDS

• Taryn, Jin, Jehsang, Phil and Matt

2
Overview

• Talk about the system
• System UML diagram
• Sequence diagram for playing a new puzzle
• Sequence diagram for registering
• Planned features for prototype/final product

3
The System
4
Playing a New Game
User enters desired difficulty level, pushes
start User enters numbers on the Sudoku grid User
pushes the Finished button. If the puzzle was
correct, the time it took to solve is shown to
the user
5
Registering for the Site

• User decides to register and navigates to the
  registration page
• They enter a desired ID and we check the database
  to see if the ID is available
• User submits all registration information and
  they are taken to the confirmation page if
  registration was successful.

6
Features of the Prototype

• Users should be able to register to the site
  not bug free (no mechanism for checking existing
  ID)
• Users should be able to login/logout not bug
  free (may or may not be maintained across
  multiple page loads, no mechanism for securing
  password)
• Users should be able to play at least one unique
  game of Sudoku (regardless of registration
  status) via our UI some bugs will be allowed at
  this stage
• Will not record best times for users
• Will keep time during game play
• No mechanism for verifying the integrity of
  submitted games

7
Features of the Final Product

• Users should be able to interactively register to
  the site (complete w/ check if ID is available)
• Users should be able to login/logout but free
  (user should be able to navigate site without
  having to login/logout a second time unless
  desired)
• Random games will be generated on the fly
  according to varying levels of difficulty
• UI will have a professional appearance
• Users will be able to play any number of games of
  Sudoku (regardless of registration status) via
  our UI no bugs, very robust
• Will record best times for users across various
  difficulty classes
• Will record global best times across users for
  each difficulty level
• Users will be able to request hints as to whether
  their puzzle has any mistakes
• Mechanism for verifying integrity of submitted
  games implemented
