Lay-Out Proofing
F.I.R.S.T.
Color Proofing
NCP
Textiles
Hexachrome proofing
Solvent
Raster proofing
Doming
Packaging proofing
Sublimation
Photographers
scanning
CMM
Air photography
Silk-screening films
Stickers
3
Lay-out Proofing
HP 1005 PRO CON Cheaper Expensive ink
consumption Quicker No NCP Small size No
Color Proofing
ROLAND FJ PRO CON Quick Expensive if only
bought for Cheap on ink lay-out proofing Lfp up
to 160 cm color proofing NCP
Return
4
Color Proofing
The Purpose of Proofing

• Predict final outcome
• Quality control

5
Color Proofing
Simulation from offset output
How to do what you need
-CMYK image in the correct working color space
-ICC profile from the offset press -Proof paper
with correct ICC profile -Ink CMYK Or/Gr for
wide gamut
-While using CMYK there will be problems in
the blue and violet area -The same problem will
appear while using Lc/Lm Offset profiles can be
found on the Fogra and Best websites.
Return
6
NCP
Nice, colorful pictures
Why Hi-Fi Jet ?
-Easy to use Level 3 RIP included -ICC Profiles
included -Large media pallet -Pantone
certified -Choice between Lc/Lm and Or/Gr -Almost
service free -Reliable
7
NCP
Nice, colorful pictures
Comparing price / sqm
HP 5000 FJ-500 130,-ATS 70,-ATS 8,3
USD 4,45 USD 7,28 EUR 3,9 EUR Proof A0 with
40 printing surface
The price of 130,- ATS was provided by an HP
dealer in competition with one of our Roland
dealers. This offer was made for 6 FJ-500 to
replace the customers IRIS proof system.
8
NCP
Nice, colorful pictures
Fj-52 RASTER
BUBBLE JET RASTER
OFFSET RASTER
9
EPSON GAMUT versus ROLAND GAMUT
10
Raster Proofing

• With the black magic software its possible to
• use the already separated data from Brisque,
• Taipan, etc
• -No ripping
• CMYK raster proof
• -Hexachrome raster proof
• -Lay-out control

For raster proofing we need the help of third
party software. On July 28th, beta testing was
finished Sales will start at Viscom Europe See
samples.
Return
11
F.I.R.S.T PRINTING SYSTEM by Compudif
Return
12
Silkscreening Raster Versus Digital Raster
13
This is a sample of our first silkscreening test

-Printed on FJ-50 -Backlight film -Pigmented
ink -Exposed on screen type 90 -Exposure
time 20 -Handprinted
14
Films for Silkscreening

• ColorChoice 1.xx
• ColorChoice 2.xx
• ColorChoice 3.0b
• ColorChoice 4.xx

15
ColorChoice 1.xx
Mac PC Remarks Photoshop ok ok Line art
raster Illustrator nty ok Line art
raster Quark ok ok Line art raster Coreldraw n
ty ok Line art Indisign nty ok Line art
raster Freehand nty ok Line art
Mac only with PC server and PC-Maclan Or ethernet
FJ-500/600 Raster fm simulation (only
photoshop) Need extra hdd for screen
poster Only Roland Backlight film and
Clearfilm Max. size depending on
software(version)
16
ColorChoice 1.xx
Results on BPLF Density2.91 pig
Density3.7 dye Density0.15 film
Film is not water resistant Film is not scratch
resistant Film has a very good register
Results on CPF Density3.1 pig
Densitypoor dye Density0.06 film
Film is water resistant Film is scratch
resistant Film has a good register
If used on FJ-500 the only mode is Normal
720dpi
From April 2001 until today our sales have raised
from 20 to 25
17
ColorChoice 1.xx
Print configuration for
Image should be set to CMYK first
18
ColorChoice 1.xx
Print configuration for
19
ColorChoice 1.xx
Print configuration for
20
ColorChoice 1.xx
Print configuration for
For DOT size changing use printer DPI settings
Use screen settings in Auto screens
Klik OK to return to page setup for parameter
settings
21
ColorChoice 1.xx
Print configuration for
Parameter setting
22
ColorChoice 1.xx setup
Printer Menu
23
ColorChoice 1.xx setup
Dither type always lx diffusion
720 dpi
Deselect the input colour profiles
Select the correct output profile
Rendering intent Spot color
Should be set to CMYK
24
ColorChoice 1.xx setup
ILLUSTRATOR will not give correct rasterpoints
RCC 1.xx should only be used for line art or
with Quark Xpress
Good results wil be achieved on Roland Backprint
media
BPLF WBPF
Excellent results will be achieved on Roland
clear film. CPF
25
ColorChoice 2.xx
SCREENING Not Possible
26
Scanning
For a good scan to use on FJ you should Make
sure that for a 720 Dpi print you have 120 PPI
(for A0 size) Scan A4 should be 600 PPI
A4 600 PPI A3 480 PPI A2 360 PPI A1 240 PPI
A0 120 PPI
A 120 PPI print on the FJ will give the best
result if printed with 720 Dpi Try to avoid
the use of interpolation
