Title: Quantum Mechanical Model


1
Quantum Mechanical Model
2
Limitations of the Bohr Model
Only works for atoms with 1 e-
e- behave like waves instead of particles.
e- DO NOT travel in fixed paths around the
nucleus!!!
e- found in certain regions around the nucleus!
These regions (orbitals) are based on probability
where e- can be found.
3
It is not possible to determine the location
momentum of an e- at the same time (Heisenburg
Uncertainty Principle).
4
Quantum Numbers
  • Four Quantum Numbers
  • Specify the address of each electron in an atom

5
Quantum Numbers
  • 1. Principal Quantum Number ( n )
  • Energy level
  • Size of the orbital
  • n2 of orbitals in the energy level

6
Quantum Numbers
  • 2. Angular Momentum Quantum ( l )
  • Energy sublevel
  • Shape of the orbital

7
Quantum Numbers
  • n of sublevels per level
  • n2 of orbitals per level
  • Sublevel sets 1 s, 3 p, 5 d, 7 f

8
Quantum Numbers
  • 3. Magnetic Quantum Number ( ml )
  • Orientation of orbital
  • Specifies the exact orbitalwithin each sublevel

9
Quantum Numbers
px
py
pz
10
Quantum Numbers
  • Orbitals combine to form a spherical shape.

11
Quantum Numbers
  • 4. Spin Quantum Number ( ms )
  • Electron spin ? ½ or -½
  • An orbital can hold 2 electrons that spin in
    opposite directions.

12
Quantum Numbers
  • Pauli Exclusion Principle
  • No two electrons in an atom can have the same 4
    quantum numbers.
  • Each e- has a unique address

1. Principal ? 2. Ang. Mom. ? 3. Magnetic
? 4. Spin ?
energy level sublevel (s,p,d,f) orbital electron
13
If you recall
Each energy level consists of one or more
sublevels.
s lt p lt d lt f
14
Quantum Mechanical Model
There is a maximum of e- that can occupy each
sublevel.
As previously stated, e- are located in regions
(orbitals) where they have the highest
probability of being found!
