Exception Handling

1
Exception Handling

• Chapter 8

2
Objectives

• become familiar with the notion of exception
  handling
• learn Java syntax for exception handling
• learn to use exception handling effectively in
  classes and programs

3
Outline

• Basic Exception Handling
• Defining Exception Classes
• Using Exception Classes
• (optional) Graphics Supplement

4
Introduction

• A program can be written assuming that nothing
  unusual or incorrect will happen.
• The user will always enter an integer when
  prompted to do so.
• There will always be a nonempty list for a
  program that takes an entry from the list.
• The file containing the needed information will
  always exist.
• Unfortunately, it isnt always so.

5
Introduction, cont.

• Once the core program is written for the usual,
  expected case(s), Javas exception-handling
  facilities should be added to accommodate the
  unusual, unexpected case(s).

6
Introduction, cont.

• Exception handling divides a class or method
  definition into separate sections
• one section for the normal case(s)
• another section for the exceptional case(s).
• Depending on how a method is used, special cases
  may need to be handled in different ways.
• Sometimes an exception needs to be thrown to
  handle a problem outside the method.

7
Basic Exception Handling Outline

• Exceptions in Java
• Predefined Exception Classes

8
Exception Handling

• Either your code or Java signals when something
  unusual happens.
• The signaling process is called throwing an
  exception.
• Somewhere in your program, you can place code to
  handle the exception.

9
Exceptions in Java Example

• simple example
• Suppose the students are hosting an event to
  express appreciation to their professor, at which
  donuts and milk will be served.
• If the number of donuts is known, and the number
  of glasses of milk is known, it should be
  possible to calculate the number of donuts per
  glass of milk.

10
Exceptions in Java Example, cont.

• simple example, cont.
• But what if there is no milk?
• An attempt to divide the number of donuts by the
  number of glasses of milk will result in an
  attempt to divide by zero.
• This would be an utter (udder?) disaster, known
  in Java as an exception.

11
Exceptions in Java Example, cont.

• In Java, it is possible to test for this unusual
  situation using an if-else statement, for example.

12
Exceptions in Java Example, cont.

• class GotMilk

13
Exceptions in Java Example, cont.
14
Exceptions in Java Example, cont.

• In Java, it is also possible to throw an
  exception.

15
Exceptions in Java Example, cont.

• class ExceptionDemo

16
Exceptions in Java Example, cont.
17
Exceptions in Java Example, cont.
18
Exceptions in Java

• Exceptions are handled using a try-throw-catch
  threesome.
• try block syntax
• try
• Code_to_Try
• Throw_An_Exception_Or_Invoke_A_Method
  _That_Might_Throw_An_Exception
• Possibly_More_Code

19
Exceptions in Java, cont.

• Exception is a predefined class.
• The throw statement creates a new object of the
  class Exception and throws it.
• throw new Exception
• (Exception No Milk!)
• When an exception is thrown, control transfers
  from the try block to a catch block, and is
  called catching the exception.

20
throw Statement and catch Block

• throw statement syntax
• throw new Exception_Class_Name
• (Quoted_String_Argument)
• Quoted_String_Argument is passed to the
  constructor for class Exception which stores it
  in the instance variable of the Exception object.

21
throw Statement and catch Block, cont.

• catch block syntax
• catch(Exception e)
• Code_To_Be_Performed
• e is called the catch-block parameter.

22
The catch Block

• The class name preceding the catch-block
  parameter specifies what kind of exception the
  catch block can catch.
• Class name Exception permits any exception to be
  caught.
• The catch-block parameter provides a name for the
  exception that is caught, to permit the exception
  object to be used subsequently.

23
The catch Block, cont.

• If the program cannot recover from the exception,
  the catch block can include
• System.exit(0)

24
method getMessage

• Every exception has a method called getMessage.
• By default, this method retrieves the string
  given to the constructor of the Exception object.

25
method getMessage, cont.

• class ExceptionDemo Flow of Control - no
  exception is thrown

26
method getMessage, cont.

• class ExceptionDemo Flow of Control - an
  exception is thrown

27
try-throw-catch

• The try-throw-catch threesome is similar to an
  if-else statement.
• However, an object of the class Exception is
  created and its message can be carried by the
  thrown exception, providing more versatility than
  an if-else statement

28
Predefined Exception Classes

• Some methods in predefined classes can throw
  predefined exceptions.
• An invocation of such a predefined method can be
  included in a try block and followed by a catch
  block.
• some predefined exceptions
• IOException
• ClassNotFoundException
• FileNotFoundException

29
Predefined Exception Classes, cont.

• Class Exception is the root class of all
  exceptions.
• However, an exception typically is handled more
  appropriately by one of its descendants.
• The string returned by a predefined exception
  typically provides enough information to
  identify the reason for the exception.

30
ArrayOutOfBoundsException

• When a program attempts to use an array index
  that is out of bounds, an ArrayOutOfBoundsExceptio
  n is thrown.
• The program ends unless the exception is caught
  in a catch block.
• An ArrayOutOfBoundsException usually indicates a
  code error rather than an exception that should
  be caught.

31
Defining Exception Classes

• You can define your own exception classes, but
  they must be derived from an existing exception
  class.
• Constructors are the most important, and often
  the only methods (except for methods inherited
  from the base class).

32
Defining Exception Classes, cont.

• class DivideByZeroException

33
Defining Exception Classes, cont.

• class DivideByZeroExceptionDemo

34
Defining Exception Classes, cont.
35
Defining Exception Classes, cont.
36
Defining Exception Classes, cont.
37
Java Tip Preserve getMessage

• For all predefined exception classes, method
  getMessage returns either
• the string that is passed as an argument to the
  constructor or
• a default string if no argument is passed to the
  constructor.
• The behavior of method getMessage should be
  preserved in any exception class you define.

38
Java Tip Preserve getMessage, cont.

• This is done by including a string parameter that
  begins with a call to super.
• public MyException(String message)
• super(message)
• More_Code_If_Appropriate

39
Java Tip Preserve getMessage, cont.

• Also include a default constructor.
• public MyException()
• super(MyException thrown)
• More_Code_If_Appropriate

40
Programming Tip When to Define an Exception Class

• In general, define an exception class if you are
  going to insert a throw statement in your code.
• This permits catch blocks to distinguish between
  your exceptions and exceptions thrown by
  predefined methods.

41
Guidelines

• Use class Exception as the base class unless
  there is a compelling reason to do otherwise.
• Define at least two constructors. Typically, no
  other methods are needed.
• Begin each constructor definition with a call to
  the constructor of the base class.

42
Guidelines, cont.

• Include a default constructor in which the call
  to super has a string argument indicating the
  kind of exception.
• The string can be recovered using the getMessage
  method.
• Include a constructor that takes a single string
  argument used in the call to super.
• The string can be recovered with a call to
  getMessage.

43
Using Exception Classes Outline

• Declaring Exceptions (Passing the Buck)
• Exceptions That Need Not Be Caught
• (optional) The AssertionError Class
• Multiple Throws and Catches
• (optional) The finally Block
• (optional) Rethrowing an Exception

44
Declaring Exceptions (Passing the Buck)

• Sometimes is it appropriate to handle an
  exception other than in the method where the
  exception occurred.
• For example, it might be better to handle the
  exception in the method that called the method
  that called the method that threw the exception

45
Declaring Exceptions, cont.

• If a method can throw an exception but does not
  catch it, it must alert the programmer to the
  possibility of an exception by including a throws
  clause.
• Example
• public void someMethod()
• throws DivideByZeroException

46
Accounting for Exceptions

• An exception can be caught in a catch block
  within a method definition.
• Alternatively, the possibility of an exception
  can be declared at the start of the method
  definition by placing the exception-class name in
  a throws clause.
• These two approaches can be mixed in a method,
  catching some exceptions and declaring others in
  a throws clause.

47
Accounting for Exceptions, cont.

• If method_A uses a throws clause instead of
  handling an exception and method_B calls
  method_A, then method_B either must handle the
  exception or must also include a throws clause.

48
Accounting for Exceptions, cont.

• class DoDivision

49
Accounting for Exceptions, cont.

• A throws clause can include more than one
  exception type.
• example
• public int someMethod()throws
• IOException, DivideByZeroException

50
Accounting for Exceptions, cont.

• Some method in the calling hierarchy should
  handle the exception.
• If an exception is thrown, but never caught,
  either the program terminates or its behavior
  becomes unreliable.

51
Exceptions That Need Not Be Caught

• Some exceptions do not need to be accounted for
  in any way.
• (Perhaps these are the exceptions that prove the
  rule about needing to account for exceptions.)
• Exceptions that do not need to be accounted for
  result from errors and usually are thrown by
  methods in predefined classes.

52
Exceptions That Need Not Be Caught, cont.

• Exceptions that derive from the class Error or
  the class RunTimeException do not need to be
  accounted for.
• examples
• NoSuchMethodError
• OutOfMemoryError
• Adding a catch clause or passing the buck will
  not solve the problem.

53
Exceptions That Need Not Be Caught, cont.

• In the event you fail to account for some
  exception that Java requires you to account for,
  the compiler will alert you.

54
throws Clauses in Derived Classes

• When a method is redefined in a derived class,
  the redefined method cannot contain any exception
  classes that are not in the throws clause of the
  same method in the base class (though the derived
  class can list fewer exceptions in its throws
  clause).
• Any exceptions thrown in the derived class must
  be caught or thrown by the base class.

55
(optional) The AssertionError Class

• If your program contains an assertion check and
  the assertion check fails, the program may
  terminate with an error message.
• An exception of the class AssertionError is
  thrown.
• If it is not caught in a catch block (which is
  typical), the program will terminate.

56
Multiple Throws and Catches

• A try block can throw any number of different
  types of exceptions.
• Each catch block can catch only one type of
  exception.
• Multiple catch blocks after a try block can catch
  multiple types of exceptions.

57
Multiple Throws and Catches, cont.

• class TwoCatchesDemo

58
Multiple Throws and Catches, cont.
59
Multiple Throws and Catches, cont.
60
Multiple Throws and Catches, cont.
61
Multiple Throws and Catches, cont.

• class NegativeNumbersException

62
Java Tip Catch the More Specific Exceptions First

• catch blocks are examined in order.
• The first matching catch block is executed.
• More specific exceptions should precede less
  specific exceptions, i.e. exceptions lower in the
  exception hierarchy should come before exceptions
  higher in the exception hierarchy.

63
Programming Tip Exception Handling and
Information Hiding

• A method invocation can throw an exception that
  is declared in its throws clause.
• But, it does not matter where in the method
  definition the throw statement is located.
• The fact that it might throw an exception is all
  that matters.

64
Keep It Simple

• Attempt to modify a program or class definition
  so that it does not need a throw statement.
• In general, use exceptions sparingly.
• If the way the exception is handled depends on
  the calling method, let the calling method handle
  the exception.
• Consider throwing the exception and catching the
  exception in separate methods.

65
Keep It Simple, cont.

• public void methodB()
• ...
• try
• ...
• methodA()
• ...
• catch (MyException e)
• ...

66
Nested try-catch Blocks

• Inner try-catch blocks should be placed inside a
  method definition, with the method invocation in
  an outer try-catch block.
• If an inner try-catch block is placed inside an
  outer try-catch block, the catch-block parameters
  in the inner and outer blocks must have different
  names.

67
Nested try-catch Blocks, cont.

• If an inner try block and its catch block are
  placed inside an outer try block and an exception
  is thrown in the inner try block, but not caught
  by the inner catch block, the exception is
  propagated to the outer try block and might be
  caught by an outer catch block.

68
(optional) The finally Block

• A finally block can be added after a try block
  and its catch blocks.
• The finally block is executed
• if the try block throws no exceptions
• if the try block throws an exception which is
  caught by a catch block
• if an exception is thrown but not caught
• i.e. it is always executed.

69
The finally Block, cont.

• syntax
• try
• catch Block(s)
• finally

70
(optional) Rethrowing an Exception

• An exception can be thrown within a catch block
  for handling further up the method-call chain.

71
Case Study A Line-Oriented Calculator

• Write a program that behaves like a simple,
  hand-held calculator which does addition,
  subtraction, multiplication, and division.
• It does simple line-by-line text input and
  output.
• Each operation is on a line by itself.
• A session ends when the user enters E or e.

72
Case Study A Line-Oriented Calculator, cont.

• sample dialog
• result 0
• 80
• result 80 80
• updated result 80
• -2
• result - 2 78
• updated result 78

73
Case Study A Line-Oriented Calculator, cont.

• The current result is stored in a private
  instance variable called result.
• Method reset will reset result to zero.
• Method evaluate will calculate the result of one
  operation.
• Method getResult will access the value of result.

74
Case Study A Line-Oriented Calculator, cont.

• Method setResult will set the value of result to
  any specified value.
• Method doCalculation will include a loop to do a
  series of operations, with a call to evaluate
  during each loop iteration.
• An exception will be thrown if the user attempts
  to divide by zero.

75
Case Study A Line-Oriented Calculator, cont.

• If doubles are used, the operator cannot be
  used to test for exact equality.
• A DivideByZeroException should be thrown for is
  an attempt is made to divide by a number very
  close to zero.
• An UnknownOpException will be thrown if the user
  specifies an unknown operation.

76
Case Study A Line-Oriented Calculator, cont.

• class UnknownOpException

77
Case Study A Line-Oriented Calculator, cont.

• A preliminary version of the program is produced
  to test and debug the unexceptional behavior of
  the program.

78
Case Study A Line-Oriented Calculator, cont.
class PrelimCalculator
79
Case Study A Line-Oriented Calculator, cont.
class PrelimCalculator, contd.
80
Case Study A Line-Oriented Calculator, cont.
81
Case Study A Line-Oriented Calculator, cont.

• There are three places to catch an exception
  thrown by method evaluate
• in method evaluate or in method doCalculation if
  you want the user to reenter the operator
• in method main if you want to restart the
  calculation.
• The choice is to restart the calculation.

82
Case Study A Line-Oriented Calculator, cont.

• class Calculator

83
Case Study A Line-Oriented Calculator, cont.

• class Calculator, contd.

84
Case Study A Line-Oriented Calculator, cont.

• class Calculator, contd.

85
Case Study A Line-Oriented Calculator, cont.
86
Graphics Supplement Exceptions in GUIs

• An uncaught exception in a (non-GUI) application
  will end the program.
• An uncaught exception in a GUI program (either a
  JFrame GUI or an applet) will not end the
  program.
• However, unless the exception is caught, the GUI
  may not cope correctly with the exception or the
  user may receive insufficient instructions.

87
Programming Example A JFrame Using Exceptions

• The example JFrame GUI allows the user to write
  the name of a color in a text field and to click
  the Show Color button.
• If the GUI recognizes the color, the background
  color changes to the named color.
• Otherwise, the text field displays Unknown
  Color and the background changes to gray.

88
Programming Example A JFrame Using Exceptions,
cont.

• class ColorDemo

89
Programming Example A JFrame Using Exceptions,
cont.

• class UnknownColorException

90
Programming Example A JFrame Using Exceptions,
cont.

• class ShowColorDemo

91
Programming Example A JFrame Using Exceptions,
cont.
92
throws Clause Not Allowed in actionPerformed

• A throws clause cannot be added to method
  actionPerformed in any action listener class.
• Any exception thrown in method actionPerformed
  must be caught in method actionPerformed.
• Similarly, if method windowClosing is redefined
  in a window listener class, you may not add a
  throws clause to method windowClosing.

93
Summary

• You have become familiar with the notion of
  exception handling.
• You have learned Java syntax for exception
  handling.
• You have learned to use exception handling
  effectively in classes and programs.
