Roofing Agricultural Structures

1
Lesson 10

• Roofing Agricultural Structures

2
Next Generation Science/Common Core Standards
Addressed!

• CCSS.ELA Literacy Cite specific textual evidence
  to support analysis of science and technical
  texts, attending to the precise details of
  explanations or descriptions..RST.9-10.1
• CCSS.ELA Literacy.RST.11-12.3 Follow precisely a
  complex multistep procedure when carrying out
  experiments, taking measurments,or performing
  technical tasks analyze the specific results
  based on ex HSNQ.
• HSNQ.A.1 Use units as a way to understand
  problems and to guide the solution of multi-step
  problems choose and interpret units consistently
  in formulas choose and interpret the scale and
  the origin in graphs and

3
Student Learning Objectives/Bell Work

• Explain the application of asphalt and fiberglass
  roofing materials.
• Explain the application of metal roofing
  materials.

4
Terms

• Drill screws
• Flashing
• H-clips
• Metal drip edge
• Pipe flashing collar
• Plastic cap nails
• Purlins

• Ridge
• Ridge cap
• Ridge vent
• Ring or screw-shank roofing mails
• Rolled roofing
• Roof vents

5
Terms

• Roofing felt
• Selvage-edge roll roofing
• Shingle
• Smooth-surfaced roll roofing
• Straight blade utility knife
• Wood shingles

6
Interest Approach

• What kind of roof do you have on your house?
• How was it secured down (nailed, screwed,
  fastened)?

7
What is a shingle?

• A shingle is the individual roofing unit made of
  slate, wood, asphalt, or fiberglass.
• The shingles used today are almost all three tab
  seal-down asphalt or asphalt-fiberglass
  combination shingles.

8
(No Transcript)
9
What is a shingle?

• In the early years of this country, most roofs
  were covered with wood or slate shingles.

10
The Roofing Process

• Regardless of the type of shingle used, roofing
  starts with the covering of the rafters or
  trusses with roof sheeting.

11
The Roofing Process

• 1st - H-clips are metal brackets shaped like an H
  installed between each set of rafters where two
  pieces of sheeting meet.
• The clip helps strengthen the joint.

12
Roofing Process

• 2nd - Metal drip edge, commonly called T-tin
  because of its shape, is nailed in place at the
  outer edges of the roof.

13
Roofing Process

• 3rd - Cover the sheeting with roofing felt.
• Roofing felt is an asphalt saturated felt that
  comes in a roll.
• Most common thickness used are 15 30 lbs.
• Straight blade utility knife is a retractable
  triangular pointed knife that works well to cut
  the felt.

14
Roofing Process

• 4th - Plastic cap nails are used to nail on the
  felt.
• Plastic cap nails have a one inch diameter cap on
  a ring shank nail.
• When the wind blows, the felt is less likely to
  blow off than if regular roofing nails are used.

15
Wood Shingles

• Wood shingles give a natural rustic look to a
  building but are very expensive and rarely used
  on agricultural buildings.

16
Wood Shingles

• Usually Cedar or other rot resistant wood is cut
  in a beveled 16 inch long piece with an
  approximate ½ inch base thickness.
• They are sold by the thousand or in bundles of
  250 each.

17
Asphalt Roofing Materials

• Rolled roofing is a three foot wide and 36 foot
  long roll.
• Rolled roofing is not as attractive as shingles
  and has a shorter life expectancy, but is
  cheaper.

18
Asphalt Roofing Materials

• Smooth-surfaced roll roofing is used in a single
  coverage type installation where it is overlapped
  only a few inches.

19
(No Transcript)
20
(No Transcript)
21
Todays Shingles

• Most shingles used today are three tab seal-down
  asphalt or asphalt-fiberglass combination
  shingles.

22
Metal Roofing

• Metal has gradually replaced asphalt and
  asphalt-fiberglass shingles in many agricultural
  buildings especially when the pole-type or
  rigid-arch type buildings are built.

23
Metal Roofing

• While metal roofing is noisy in a rain storm and
  not as attractive as shingles, it is fire
  resistant, cheaper, and much easier and faster to
  install.
• Metal roofing will be either steel or aluminum
  sheets.

24
(No Transcript)
25
Installing Metal Roofing

• With metal roofing after the rafters or trusses
  are in place, horizontal nailing boards called
  purlins. Metal perlins are actually more common
  in NM.

26
Installing Metal Roofing

• Purlins are installed to attach the roofing
  sheets.
• The purlin spacing depends on the type and
  thickness of the roofing sheets.
• Metal roofing is installed in a particular order.

27
Installing Metal Roofing

• Ridge Cap or Ridge Vent is installed to allow
  warm moisture to escape.
• Metal roofing may be fastened with ring or
  screw-shank nails.
• Ring or screw-shank roofing nails have a lead,
  neoprene, or rubber washer to prevent leakage and
  rings or screws to prevent the nail from popping
  out over time.
• Metal screws with a rubber washer may be used on
  wood or metal perlin.

28
(No Transcript)
29
(No Transcript)
30
All metal agricultural structures are more common
and economical in the southwest US as the metal
may be more inexpensive than wood. Metal is often
faster to assemble.
31
Metal roofing is attached to metal perlin using
TEK screws.

• Lap Screws Perlin Screws

32
Common Metal Perlin
33
Comparison of Types of Metal Roofing

• While steel sheets are stronger than aluminum
  they are subject to rust.
• To prevent rust,steel can be purchased with a
  baked on enamel paint or a galvanized coating.

34
Comparison of Types of Metal Roofing

• Galvanized steel roofing comes as corrugated
  sheets with a zinc coating.

35
Aluminum Roofing

• Aluminum roof sheeting will not rust but is
  expensive, thin, and easily damaged.
• Buildings covered with aluminum must have nailing
  boards with closer spacing than for galvanized
  steel.

36
Corrugated Roofing

• Corrugated roofing is made from flat sheets that
  have been formed into a series of alternate
  ridges and grooves, or hills and valleys, that
  run in the same direction.

37
Corrugated Roofing

• The corrugations give the sheets a greater
  stiffness, increased load-carrying ability, and
  prevent water siphoning between the sheets into
  the building.

38
Review/Summary

• What are the kinds of materials used to roof
  agricultural buildings?
• What different practices are used when installing
  a metal or aluminum roof?

39
